nüvi 2565 Quick Start Manual 1
Getting Started
WARNING
Refer to the Important Safety and
Product Information guide available
on www.garmin.com for product
warnings and other important
information.
When using your device for the rst
time, complete the following tasks.
1. Connect the device to vehicle
power (page 1).
2. Mount the device (page 3).
3. Register the device (page 4).
4. Updating the Software and Maps
(page 4).
Connecting the Device to
Vehicle Power
WARNING
This product contains a lithium-ion
battery. To prevent the possibility of
personal injury or product damage
caused by battery exposure to extreme
heat, remove the device from the
vehicle when exiting or store it out of
direct sunlight.
Charge your device before using it on
battery power.
1. Fit the bottom of your device into
the mount.
2. Tilt your device back until it snaps
into place.
190-01195-26_0A.indd 1 2011/5/24 下午 01:59:56
2 nüvi 2565 Quick Start Manual
3. Plug the vehicle power cable
➊
into the mini-USB connector
➋
on the mount.
➊
➋
➍
➌
4. Plug the other end of the vehicle
power cable into a power outlet in
your vehicle.
5. If you are using a trafc receiver,
connect the external antenna to the
trafc receiver and secure it to the
windshield using the suction cups.
6. Video in connector
➌
, connecting
rear view camera. Driving
recorder connector
➍
to connect
driving recorder. Rear camera
and driving recorder are optional
subscriptions.
After the device has been connected
to vehicle power, the following
occurs.
• The device turns on.
• The device acquires satellite
signals. When at least one of the
bars is green, your device has
acquired satellite signals.
• NOTE: The device may need a
clear view of the sky to acquire
satellite signals.
• The device charges as you drive.
in the status bar indicates the
190-01195-26_0A.indd 2 2011/5/24 下午 01:59:57
nüvi 2565 Quick Start Manual 3
status of the internal battery.
Mounting Your Device
NOTICE
Before mounting the device, see
the Important Safety and Product
Information guide for information
about laws pertaining to windshield
mounting.
1. Remove the clear plastic from the
suction cup.
2. Clean and dry your windshield
and the suction cup with a lint-free
cloth.
3. Press the suction cup to the
windshield.
4. While pressing, ip the lever back
toward the windshield.
5. Snap the mount
➊
onto the
suction cup arm
➋
.
➊➋
Mounting Driving Recorder
(Optional)
➊
➋
1. Snap driving recorder- GDR 10 to
the other arm.
2. Connect GDR 10 transmitter to
microUSB port on mount located
aside.
190-01195-26_0A.indd 3 2011/5/24 下午 01:59:57
4 nüvi 2565 Quick Start Manual
Registering the Device
Go to www.my.garmin.com for
registration
Updating the Software and
Maps
Go to www.garmin.com.sg for
software and map updates
nüMaps Guarantee
Your device is eligible for one
free map update within 60 days of
acquiring satellites while driving with
your nüvi. You are not eligible for
the free map update if you register
by phone or wait longer than 60
days after the rst time you acquire
satellites while driving with your
nüvi. For more information, go to
www.garmin.com/numaps.
Device Overview
➊
➋➌
➊
Power key
➋
microSD
™
card slot
➌
External GPS antenna conenctor
Using the Power Key
1. Press and quickly release the
Power key to view additional
options.
2. Select an option:
• To adjust screen brightness,
touch and drag the scroll bar.
• To turn off your device, touch
Off.
• To reset the device, hold the
Power key for 10 seconds.
190-01195-26_0A.indd 4 2011/5/24 下午 01:59:58
nüvi 2565 Quick Start Manual 5
• To exit the menu, press and
release the Power key.
About Points of Interest
The detailed maps loaded in your
device contain points of interest,
such as restaurants, hotels, and auto
services.
Finding a Point of Interest by
Category
1. From the Main menu, touch
Where To? > Points of Interest.
2. Select a category.
3. If necessary, select a subcategory.
4. Select a destination.
5. Touch Go!.
Touch > Save on this page to
save the location to a Favorites
folder on the device. Use the
Favorites folder to save the
location of your workplace, home,
and other common destinations.
6. If necessary, select an option:
• Touch Drive to calculate a
route you will navigate by
driving.
• Touch Walk to calculate a
route you will navigate by
walking.
• Touch Public Transit to
calculate a route that combines
public transit and walking.
NOTE: You must have
cityXplorer™maps loaded to
navigate using public transit.
Go to www.garmin.com to
purchase cityXplorer maps.
190-01195-26_0A.indd 5 2011/5/24 下午 01:59:58
6 nüvi 2565 Quick Start Manual
Using the Main Menu
➊
➋ ➌
➍ ➐ ➑ ➒➎ ➏
• Touch
➊
to select a transportation
mode.
• Touch
➋
to nd a destination.
• Touch
➌
to view the map.
• Touch
➍
to stop a route.
• Touch
➎
to detour a route.
• Touch
➏
to make a call when
connected to a compatible mobile
phone. See www.garmin.com/
bluetooth for information.
• Touch
➐
to start Voice Command.
• Touch
➑
to adjust the volume.
• Touch
➒
to open the menu of
tools and settings.
Customise Main Menu
Make your own main menu
1. Find the main menu, touch Tools
> Settings > Main Menu
2. Select Customize and add any
features you like, maximum up to
15 icons.
190-01195-26_0A.indd 6 2011/5/24 下午 01:59:59
nüvi 2565 Quick Start Manual 7
3. Touch Save.
Your Route on the Map
NOTICE
The speed limit icon feature is for
information only and does not replace
the driver’s responsibility to abide
by all posted speed limit signs and to
use safe driving judgment at all times.
Garmin will not be responsible for
any trafc nes or citations that you
may receive for failing to follow all
applicable trafc laws and signs.
Your route is marked with a magenta
line on the map. If you depart from
the original route, your device
recalculates the route. A speed limit
icon could appear as you travel on
major roadways.
Using the Map Functions
➊ ➋
➌
➍➎
➏
➓
➐
➑➒
• Touch
➊
to view the next turn.
If a view of a junction exists,
the junction view appears.
• Touch
➋
to view the turn list.
• Touch
➌
to zoom in and out.
• Touch
➍
to return to the Main
menu.
• Touch and hold
➍
from any
screen to return to the Main
menu.
190-01195-26_0A.indd 7 2011/5/24 下午 01:59:59
8 nüvi 2565 Quick Start Manual
• Touch
➎
to change the data
eld.
• Touch
➏
to view the Where
Am I? page.
• Touch and drag
➐
to view a
different area of the map.
• Touch
➑
to view trip
information.
• Touch
➒
to change the speed
limit if the speed limit shown
on the map is incorrect.
•
➓
means current lane info.
You will not lose direction,
any turn or exist.
Using myTrends
As you drive with the device on,
myTrends™gathers information that
allows the device to predict when you
are traveling to a common destination,
like your workplace or home. When
myTrends is activated, the destination
and estimated time of travel will
appear in the navigation bar on the
map. If a trafc receiver is connected,
trafc information may also appear in
the navigation bar.
myTrends only works for locations
that are saved as Favorites (page 5).
When myTrends information
appears in the navigation bar,
touch the navigation bar to view
route information.
190-01195-26_0A.indd 8 2011/5/24 下午 02:00:00
nüvi 2565 Quick Start Manual 9
Avoiding Road Features
1. Find the main menu, touch
Tools > Settings > Navigation
> Automobile > nuRoute >
Avoidances.
2. Select the road features to avoid
on your route.
3. Touch Save.
Custom Avoidances
1. Find the main menu, touch Tools
> Car > nuRoute > Custom
Avoidances.
2. Select avoid area or avoid road
you wish.
3. Touch Save.
Routes Preview
Navigate to the destination before
travelling and preview 3 routes, select
the most suitable route for navigation.
1. Find the main menu, touch Tools
> Settings > Navigation > Car >
nuRoute > Calculation Mode.
2. If selecting Prompted, GPS will
show three different routes for
preview before navigation.
3. Touch Save.
