ZC-D5000 XA SERIES DOMES
High Performance Domes
with Integrated Varifocal Lens
Cameras
2
Indoor Models ZC-D5025 XA ZC-D5212 XA ZC-DW5212 XA ZC-D 5212 XA ZC-DW 5212 XA ZC-D5550 XA ZC-DW5550 XA ZC-D 5840 XA
Focal Length 2.3-5mm 2.8-12mm 5-50mm 8.5-40mm
WDR Performance Digital WDR Digital WDR True WDR Digital WDR True WDR Digital WDR True WDR Digital WDR
Day/ ight Performance Digital D/N Digital D/N Digital D/N True D/N True D/N Digital D/N Digital D/N True D/N
DC Auto Iris F1.2- F360C F1.3 - F360C
Image Sensor 1/3”- type Interline transfer color CCD
Camera Resolution 700 TVL (for both Color & BW)
Horiz. Angle of View 114.8°-56.1° 98.2° - 23.8° 51.8° - 5.6° 33.5°-7.1°
Min.
Illum
@ F1.3
Normal 0.27 lux Color
0.027 lux B/W 0.3 lux Color / 0.03 lux B/W 0.08 lux Color / 0.008 lux B/W 0.3 lux Color / 0.03 lux B/W 0.08 lux Color /
0.008 lux B/W
50 IRE, SENS UP 0.000053 lux B/W 0.00006 lux B/W 0.000016 lux B/W 0.00006 lux B/W 0.000016 lux B/W
Wide Dynamic Range --
Max 82dB, 12,600x -Max 82dB, 12,600x -Max 82dB, 12,600x -
Power Source 24V AC ±10% (50/60 z ±1 z) or 12VDC ± 10, UL listed
Power Consumption 12VDC 230mA / 24VAC 240mA, 3.0W
Dimensions (indoor) 5.7” ø x 4.3” / 144 mm ø x 110mm
Optional eater - ZC5X- TR (for operating temp to -40oF)
* Add su ix “T” or NVT module. **Pre-installed NVT transmitter provides video transmission over CAT 5/Twisted pair cable (a separate receiver is required)
Some models also available with manual iris or black. Contact customer service or details.
Outdoor Housing ZC-OH5 - Optional Outdoor Housing Specifications
Housing Material IP66 rated cast aluminum with off white powder coat finish, all stainless steel hardware
Dome Material Impact-resistant clear polycarbonate dome with black interior liner (tinted option available)
Temp. Range w/o Heater -20° F to 122° F w/o heater (using 5000 Series domes, based on proper installation & maintenance procedures)
Temp. Range with Heater -40° F to 122° F w/ heater (using 5000 Series domes, based on proper installation & maintenance procedures)
Dimensions (outdoor) 6.7" Ø x 5" / 170mm Ø x 127mm
Indoor Mounting Options Outdoor/Impact-Resistant Mounting Options & Accessories
ZC-OH5
Outdoor ousing
Pendant Mount
Model ZC5-PM2
(1” NPT Pipe)
Pendant
ZC7-PM1
(3/4” NPT Pipe)
Wall Mount
ZC7-WM1
Wall Mount
ZC5-WM2A
Flush Mount
ZC-FM3
4S Box
Adapter
ZCA-GAP
with
ZC-D5000 XA Series Domes
700 VL Day/Night High Performance Domes
Go to Page 5 for
CS mount ameras
featuring GX5
Te hnology.
These high performance domes feature Ganz GX5technology, combining 700TVL, WDR
performance, intelligent image enhancement and advanced OSD controls. With an
unprecedented level of resolution, sensitivity and control for optimal video surveillance in
all conditions. The OSD menu provides multiple programming options & installation tools.
• 700 TVL Ultra igh Resolution
• 12,600x WDR (Wide Dynamic Range) on True WDR models
• 2.3-5mm, 2.8-12mm, 5-50mm or 8.5-40mm computar®integrated varifocal lens
• Extremely igh Sensitivity Day/Night modes
• Automatically switches between preprogrammed profiles for best image results
• Smart Day/Night mode synchronizes with IR LED
• 2D/3D Digital Noise Reduction
• Test pattern output with color bar
• UL Listed
ZCD5-NVT Optional
NVT Transmitter
ZC5X- TR
Optional eater
