Gamma+ Oculus 40 Manuel utilisateur

Oculus 40

12x40w RGBW LED Wash with Pixel Mapping

User Manual

Oculus 40 – GAMMA LED Vision

Page 1 of 12

Table of Contents

1. Introduction and Setup....................................................................................................................................3

Unpacking and In the Box..............................................................................................................................3

Mounting and Operation................................................................................................................................3

Features...................................................................................................................................................................3

Safety Precautions..............................................................................................................................................3

Customer Support..............................................................................................................................................5

2. Setup and Operation.........................................................................................................................................6

Using the LCD Menu and Buttons..............................................................................................................6

DMX Setup............................................................................................................................................................6

DMX Basics.......................................................................................................................................................6

DMX Wiring.....................................................................................................................................................6

DMX Modes and Configuration...................................................................................................................8

Pixel Layout – 68 Channel Mode:........................................................................................................10

3. Maintenance.......................................................................................................................................................11

Routine Maintenance......................................................................................................................................11

Troubleshooting Problems...........................................................................................................................11

4. Technical Specifications.................................................................................................................................12

Oculus 40 – GAMMA LED Vision

Page 2 of 12

1. Introduction and Setup

Unpacking and In the Box

Thank you for choosing our Oculus 40. For your own safety, please read this manual before

installing or using the device. This manual covers the important information on installation and

applications. Please install and operate the fixture with following instructions. Meanwhile,

please keep this manual for future needs.

In the box you will find:

Oculus 40 Fixture - 1

Omega Clamps - 2

Power Cable - 1

DMX Signal Cable 1

Mounting and Operation

Clamp Mounting: The Oculus 40 moving head provides a unique mounting bracket

assembly that integrates the bottom of the base, and the safety cable rigging point in one

unit.

When mounting this fixture to truss be sure to secure an appropriately rated clamp to the

included omega bracket using a M10 screw fitted through the center hole of the “omega

bracket”.

As an added safety measure be sure to attached at least one properly rated safety cable

to the fixture using on of the safety cable rigging point integrated in the base assembly.

Features

12*40w LED Wash light

12 Pixel-Mappable Zones

7°-70° Zoomable Beam Angle

Adjustable Strobe and Dimmer Effect

Safety Precautions

Do not expose this fixture to rain or moisture.

Do not spill water or other liquids into or on your unit.

Oculus 40 – GAMMA LED Vision

Page 3 of 12

Caution: For added protection mount the fixtures in areas outside walking paths, seating

areas, or in areas were the fixture might be reached by unauthorized personnel.

Before mounting the fixture to any surface, make sure that the installation area can hold a

minimum point load of 10 items the device’s weight.

Fixture installation must always be secured with a secondary safety attachment, such as an

appropriate safety cable.

Never stand directly below the device when mounting, removing, or servicing the fixture.

From a ceiling, or set on a flat level surface (see illustration below). Be sure this fixture is kept

at least 0.5m (1.5ft) away from any flammable materials (decoration etc.), and that .5m is kept

around the fixture for ventilation.

Always use and install the supplied safety cable as a safety measure to prevent accidental

damage and/or injury in the event the clamp fails.

∙Don’t try to modify the fixture without any instruction by the manufacturer or the appointed

repairing agencies.

∙Warranty is voided if there are any malfunctions from not following the user manual while

operating or any hazardous operation, like shock short circuit, electronic shock, lamp broken,

etc.

Oculus 40 – GAMMA LED Vision

Page 4 of 12

Customer Support

WARRANTY POLICY

GAMMA LED Vision warrants its products for the periods set below from the date of

purchase to be free of manufacturer and workmanship defects. Warranty does not cover

normal wear and tear caused by force, negligence or misuse of products. GAMMA LED

Vision is not responsible for any damages or injury caused by misuse or improper

handling of the products and in accordance with instructions and specifications of manual.

Warranty terms are as follows:

LED Fixtures:

Indoor: 2 Years

Outdoor (IP 54 or higher): 1 Year

Lamp Fixtures: 1 year / excludes the lamp

LED Video Products:

Indoor: 2 Years

Outdoor (IP 54 or higher): 1 Year

Controllers: 2 years

Batteries: 6 months

All Trussing Related Products and Accessories: 1 Year

Please visit WWW.GAMMALEDVISON.COM for complete Limited Warranty terms and

contact information.

Oculus 40 – GAMMA LED Vision

Page 5 of 12

2. Setup and Operation

Using the LCD Menu and Buttons

The Oculus features Up/Down/Menu/Enter Buttons to navigate the menu. Use “ENTER” to

go into the menu, UP/DOWN to make selections, and MENU to go back to a previous

menu.

DMX Setup

DMX Basics

DMX512 stands for digital multiplex 512. This means that 512 channels are controlled

digitally through 1 data cable.

A channel is a set of 255 steps that are assigned to control attributes in each light. This

may be a color like red, green or blue, and intensity, strobe, pan/tilt or other attributes.

Multiple sets of 512 “universes” may be used. Only 1 universe will travel on a DMX cable,

but through networked DMX (Art-Net or sACN E1.31), many universes can travel over a

network.

DMX Wiring

DMX works by connecting 1 or multiple lights to the output of a DMX lighting console or

software with a DMX interface.

DMX lights connect in what is called a “daisy-chain”. Your first DMX cable will plug it’s

male DMX connector into the female DMX connector on your lighting console. The

remaining female connector will then connect to the DMX input on your first light.

You may then connect your next fixture to the output of your first light, and continue the

chain.

Oculus 40 – GAMMA LED Vision

Page 6 of 12

32 Fixture Rule – DMX only allows you to connect up to 32 fixtures in a single daisy

chain for signal strength. Sometimes, depending on the fixtures and cable length, this

number is less (or more).

DMX Cables can be 3-pin or 5-pin. These use the same type of data, and in the 5-pin

only pins 1, 2, and 3 are used. The cable should be a 2 conductor, shielded cable of at

least 110 ohms resistance. Microphone cable is not DMX cable.

Please refer to the diagram below:

For installations where the DMX cable has to run a long distance or is in an electrically

noisy environment, it is recommended to use a DMX terminator. This helps in preventing

corruption of the digital control signal by electrical noise and reflections. The DMX

terminator is simply an XLR plug with a 120 Ω resistor connected between pins 2 and 3,

which is then plugged into the output XLR socket of the last fixture in the chain. Please

see illustrations below:

Oculus 40 – GAMMA LED Vision

Page 7 of 12

DMX Modes and Configuration

The Oculus 40 has multiple DMX modes, sometimes called “personalities”, “profiles”, or as

we will use here “modes”.

In general, modes with more DMX channels offer a greater level of control or options but

take up more of your output channels on your lighting console or software.

Modes with less DMX channels often offer less control, but may be plenty for your needs.

Depending on your needs and control solution, you may not need channels for

automated programs, strobes, or macros – your console may have great effects! In this

case, you can use a lesser channel mode and fit more lights per DMX universe.

View the DMX mode charts below to find the mode that best suits your needs.

DMX Channel Mode Sheet:

See below for the DMX channel layouts of the Oculus 40:

18CH 24CH 68CH Function Channel Value Description

1 1 1 Pan 0-255

2 2 2 Pan Fine 0-255

3 3 3 Tilt 0-255

4 4 4 Tilt Fine 0-255

5 5 5 PTSpeed 0-255

6 6 Zoom 0-255

6 7 7 Dimmer 0-255

7Dimmer Fine 0-255

8 8 8 Strobe 0-255

9 9 9* Red 0-255 RGBW for each cell from

channels 9-56

10 10 10* Green 0-255 RGBW for each cell from

channels 9-56

11 11 11* Blue 0-255 RGBW for each cell from

channels 9-56

12 12 12* White 0-255 RGBW for each cell from

channels 9-56

13 13 57 CTO 0-255 Color Temperature Correction

Oculus 40 – GAMMA LED Vision

Page 8 of 12

14 14 58 Fixed Color

Macros

0-255 Color Macros on entire front

lens

15 15 59 Shapes Macros 0-255 Macros that use segments of

the front lens

16 60 Macro Set 1 0-255

17 61 Background Red 0-255 Background is the color for

parts of the lens not used in the

current Shapes Macro.

18 62 Background

Green

0-255 Background is the color for

parts of the lens not used in the

current Shapes Macro.

19 63 Background Blue 0-255 Background is the color for

parts of the lens not used in the

current Shapes Macro.

20 64 Background White 0-255 Background is the color for

parts of the lens not used in the

current Shapes Macro.

21 65 N/A

22 66 Macro Speed 0-255

16 BG Dimmer 0-255 Overall Intensity for the

background color.

17 Zoom 0-255 7°-70°

18 23 67 Reset 1-9 No Function

10-255 Reset

24 68 Reset with light off 1-239 No Function

240-255 Reset with Light Off

Oculus 40 – GAMMA LED Vision

Page 9 of 12

Pixel Layout – 68 Channel Mode:

Center is 1-3, Clockwise

Outer Ring is 4-12, Clockwise:

Oculus 40 – GAMMA LED Vision
