Base Block is a compact and multifunctional GPS/GLONASS vehicle tracking device that
is suitable for a wide range of tasks in the field of transport monitoring and fleet
management. The device not only allows to track the vehicle’s location in real time but
also to apply a wide range of features due to the option of connecting up to 16 additional
sensors and connecting to the CAN-bus of the vehicle.
Base Block modifications:
Galileosky Base Block
Galileosky Base Block Lite
Galileosky Base Block Optimum
Galileosky Base Block Wi-Fi
Galileosky Base Block Wi-Fi Hub
Galileosky Base Block Iridium
Package
The standard package includes Galileosky tracker,
SIM-holder
a connector with contacts
fuse with holder
passport
a certificate of equipping a vehicle with GLONASS/GPS devices.
You will also need USB-cable and Power supply unit 9-39V (15 W).
Tech specs
Parameter Base
Block Lite
Base
Block
Optimum
Base
Block Wi-
Fi
Base
Block Wi-
Fi Hub
Base Block
Iridium
Analog-discrete
4 pcs;
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
2/28
and pulse
frequency inputs
voltage range -0-33V;
maximum measured frequency-4 kHz
Transistor
outputs (output
0/1)
2 pcs.; maximum voltage 30V; maximum current 80mA.
Battery type Li-Ion
battery;
600mAh
Average power
consumption
0,48 W 0,54 W 0,6 W 0,6 W 0,6 W
ADC resolution in
bits
16
CANBUS J1939, FMS, J1979, OBD II, 29-bit and 11-bit identifiers
RS 485 1
USB 2.0 Micro-USB, device setting, troubleshooting, firmware updating
Accelerometer built-in
GLONASS/GPS
receiver
Sensitivity – 161 dBm
Cold start 25 s.;
Hot start 1 s
Coordinates
determination
accuracy, 95% of
time, not worse
5 m
SIM-card type,
pcs
Micro-SIM, 1
GSM modem GSM 850/900/1800/1900, GPRS class 12
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
3/28
Wi-Fi no no IEEE 802.11 b/g/n no
Iridium no yes
Archive capacity
up to
400 000
points
up to 2 500 000 points for each GB by using the micro
SD card
1-Wire yes
RS 232 no 2 2 2 2
microSD
no up to 64 GB.
It is recommended to use the following micro SD
cards:
Transcend slc mode 230i 8 (TS8GUSD230)
Kingston sdcit/8gb (SDCIT/8GB)
Speakerphone no a push-to-talk or a speaker and a microphone
Speaker
(Autoinformer)
no built-in
The number of
geofences for
voice prompts
no limited by microSD capacity
Frequency of
autoinformer
discretization
no
8kHz 8kHz 16kHz 8kHz
Speaker output
type
no
analog, 250mW
Enhancement By means of creating Easy Logic algorithms, stored in the tracker’s
memory and executed with no interference with the firmware
Protocol of data
1. Galileosky: variable length-tag.
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
4/28
transmission 2. EGTS (GOST R 54619-2011, Order № 285 of the RF Ministry
of Transportation)
Enclosure
protection
IP54
GLONASS/GPS
aerial
external, Fakra
GSM aerial external, Fakra
Wi-Fi aerial no no external external no
Iridium aerial no external
Operating
temperature
range
-40…+85 °C
Storage
temperature
-40…+85 °C
Relative humidity 0…90% (0…35 °C); 0…70% (35…55 °C)
Performance
(height above the
sea level)
0-2000 m
Storage 0-10000 m
Operating power
supply
9-39V; is protected against voltage jumps in the vehicle power
supply
Allowable voltage -900…+200 V – continuously applied to power input, that does not
let the device fail
Dimensions (mm) 80 x 71 x
28
80 х 71 х 40
Weight (not
more)
150 g 215 g
Body material metal
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
5/28
Contact Description
Average service
life
10 years
Warranty (from
date of purchase)
5 years 2 years
Internal Li-Ion
battery life
500 charge/discharge cycles, three years maximum
Safe Operating Rules
Before using the tracking device, study the instructions of GSM/3G/GPRS devices safe
operating.
Make sure the polarity is correct when connecting to the power supply.
The device should be connected straight to the vehicle battery, not to the vehicle power
supply.
To avoid failure:
Make sure the contacts are connected correctly. Unused contacts must be we
Contacts Description
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
6/28
VCC Positive supply voltage
GND Negative supply voltage
IN0 Zero analog-discrete input
IN1 1st analog-discrete input
IN2 2nd analog-discrete input
IN3 3rd analog-discrete input
RS485A A signal of RS485 channel
RS485B B signal of RS485 channel
RXD0 RXD signal of zero RS232 port (only for Optimum/Iridium/Wi-Fi/Hub/3G m
TXD0 TXD signal of zero RS232 port (only for Optimum/Iridium/Wi-Fi/Hub/3G m
RXD1 RXD signal of the first RS232 port (only for Optimum/Iridium/Wi-Fi/Hub/3G
modifications)
TXD1 TXD signal of the first RS232 port (only for Optimum/Iridium/Wi-Fi/Hub/3G
modifications)
CAN_H CAN_H contact of CAN interface (only for Optimum/Iridium/Wi-Fi/Hub/3G
CAN_L CAN_L contact of CAN interface (only for Optimum/Iridium/Wi-Fi/Hub/3G
Vol0 Zero contact to connect an external speaker for Autoinformer (only for
Optimum/Iridium/Wi-Fi/Hub/3G modifications)
Vol1 First contact to connect an external speaker for Autoinformer (only for
Optimum/Iridium/Wi-Fi/Hub/3G modifications)
1-Wire 1-Wire interface
GND Ground to connect interfaces which need the ground contact
Out0 Zero transistor output (output 0/1)
Out1 First transistor output (output0/1)
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
7/28
Connecting GLONASS aerial
The top of the aerial must face the sky. To get the best view of the sky, we recommend
installing the aerial on the roof or on the windshield, or under the dashboard of the
vehicle.
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
8/28
Blinking of the green LED 1 time means successful reception of a signal from the
satellites.
Connecting GSM/3G-aerial
Position the GSM/3G antenna in such a way that the GSM/3G network signal is not
strongly weakened by the metal housing of the vehicle.
Blinking of the blue LED 1 time means successful connection to the monitoring server.
Connecting Iridium aerial
Carefully screw the aerial to the Terminal, the upper side is above. To have a better view
of the sky it is recommended that the aerial should be mounted on the vehicle roof,
windscreen or under the dashboard.
To provide the proper connection, we recommend that the Iridium antenna is
installed on the horizontal surface at a zero angle to the horizon and with
clear, 360 degrees view of the sky, for example, on the top of the vehicle.
Inserting SIM-card
Insert the SIM cards with the GPRS and SMS services connected. To remove the SIM
card, gently push it in until it clicks and the card automatically slides out of the mobile
computer.
Connecting power supply to the device
Positive supply voltage should be connected to VCC contact, negative supply voltage
should be connected to GND.
If the connection is correct, the red LED will be on.
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
9/28
LED indicators
Red LED is on when the power unit is connected to the tracking device.
Yellow LED is on when the microcontroller is running (blinks with the frequency of 1 Hz). It
is also used to indicate the bootloader mode.
Green LED shows the GLONASS/GPS unit status.
Blinking frequency,
times Description
3 GLONASS/GPS unit is not found or is at the
initialization stage
2 GLONASS/GPS unit is found but correct
coordinates are absent
1 GLONASS/GPS unit works properly, coordinates
are found and updated once a second
Blue LED shows the GSM/3G-unit status.
Blinking frequency,
times Description
3 GSM/3G-unit is not found or is at the
initialization stage
2 GSM/3G-unit is found, GPRS-session is
activated
1 GSM/3G-unit works properly, server is
connected
Connecting to PC
In order to connect the tracking device to PC, use USB A – Micro-USB B.
Using defective cables (with disconnected grounds contacts on connectors) may lead to
device’s failure.
19.11.2021, 11:52
Base Block
base.galileosky.com/articles/#!en-documentation/base-block-user-manual
10/28
Discrete-analog inputs (DAI)
Tracking device has 4 discrete-analog inputs.
Feature Value
Maximum measured voltage 33 V
Analog inputs resolution 1 mV
Maximum transmitted signal
frequency 4 kHz
DAI have the following settings:
Parameter Explanation
Filter type (input
function) 0 - arithmetical average (discrete input
state is also generated);
1 - pulse count;
2 - frequency input;
Filter length to
calculate the mean
value
The greater this parameter, the more
slowly the device responds to the input
signal change. With filter length equal to 1
- averaging does not happen.
Set this parameter to 1 for frequency
inputs.
It is necessary to set this parameter to 1
for pulse inputs. If the tracking device
counts extra pulses, the filter length
should be increased by one and accuracy
should be estimated.
