Gainward GTX 570 1280MB PHANTOM Manuel utilisateur

Gainward GTX 570 1280MB DVI DisplayPort

“PhantomTM”

GPUCoreMemoryCapacityTypeOutputs

GTX570750MHz1950MHz1280MBGDDR5/320bitsDualDVI‐I,DP,HDMI

PRODUCT SPECIFICATIONS

zSuperior Hardware Design

zGainward’s award winning High-Performance/

Wide-BandwidthTM hardware design powered

by NVIDIA’s GeForceTM GTX 570 GPU (40nm)

integrating 1280MB/320bits high-speed

GDDR5 memory which offers enhanced,

leading-edge performance for the 3D

enthusiasts.

z750MHz core clock, 1950MHz (DDR 3900)

memory clock

zHigh performance 2.5-slot/three- fan cooler

zDual DVI-I, DisplayPort (support up to

2560x1600) and HDMI support

zFull integrated support for HDMI 1.4a

including xvYCC, Deep color and 7.1 digital

surround sound.

zDual-link HDCP Capable: Designed to

meet the output protection management

(HDCP) and security specifications of the

Blu-ray Disc formats, allowing the playback

of encrypted movie content on PCs when

connected to HDCP-compliant displays.

zSupports two monitors simultaneously,

enabled by the NVIDIA nView™Multi-

Display Technology for office applications,

3D gaming and professional applications

such as CAD, DTP, animation or video

editing. NVIDIA nView™allows end-users

to select any combination of multiple

displays.

CHIPSET SPECIFICATIONS

zNVIDIA GeForceTM GTX 570

zMicrosoft DirectX 11 Support: DirectX

11 GPU with Shader Model 5.0 support

designed for ultra high performance in the

new API’s key graphics feature, GPU-

accelerated tessellation.

zNVIDIA PhysXTM:Full support for NVIDIA

PhysX technology, enabling a totally new

class of physical gaming interaction for a

more dynamic and realistic experience

with GeForce.

zNVIDIA 3D VisionTM Ready: GeForce

GPU support for NVIDIA 3D Vision,

bringing a fully immersive stereoscopic 3D

experience to the PC. A combination of

high-tech wireless glasses and advanced

software, 3D Vision transforms hundreds

of PC games into full stereoscopic 3D. In

addition, you can watch 3D movies and

3D digital photographs in eye popping,

crystal-clear quality.

zNVIDIA CUDATM Technology: CUDA

technology unlocks the power of the

GPU’s processor cores to accelerate the

most demanding system tasks such as

video transcoding, physics simulation, ray

tracing and more, delivering incredible

performance over traditional CPUs.

zMicrosoft Windows 7 Support: Windows

7 is the next generation operating system

that will mark a dramatic improvement in

the way the OS takes advantage of the

GPU to provide a more compelling user

BUNDLED ACCESSORIES

•Gainward QuickStart Manual

•Driver CD and Application S/W

Driver for Windows 7/Vista/XP

•Cables and Accessories

6-pin to 8-pin cable (optional)

Gainward GTX 570 1280MB DVI DisplayPort

“PhantomTM”

zEasy Plug-and-Play AUTORUN installation

from CD-ROM.

zIncludes Gainward’s award winning

EXPERTool™ tuning utility for

customized performance enhancements

and efficient desktop management.

z3-way NVIDIA SLITM Technology: Industry

leading 3-way NVIDIA SLI technology offers

amazing performance scaling by

implementing 3-way AFR (Alternate Frame

Rendering) for the world’s premier gaming

solution under Windows 7 with solid, state-of-

the-art drivers.

zNVIDIA GeForce Unified Driver

Architecture (UDA): Delivers a proven

record of compatibility, reliability, and

stability with the widest range of games

and applications. NVIDIA GeForce drivers

provide the best out-of-box experience for

every users and deliver continuous

performance and feature updates over the

life of NVIDIA GeForce GPUs.

zPCI Express 2.0 Support: Designed for

the new PCI Express 2.0 bus architecture,

offering the highest data transfer speeds

for the most bandwidth-hungry games and

3D applications, while maintaining

backwards compatibility with existing PCI

Express motherboards for the broadest

support.

experience. By taking advantage of the

GPU for both graphics and computing,

Windows 7 will not only make today’s PCs

more visual and more interactive but also

ensure that they have the speed and

responsiveness customers want.

zDirectCompute Support: Full support for

DirectCompute, Microsoft’s GPU

computing API.

zOpenCL Support: Full support for

OpenCL GPU computing API.

z32x Anti-aliasing Technology: Lightning

fast, high-quality anti-aliasing at up to 32x

sample rates obliterates jagged edges.

zOpenGL 4 Optimizations and Support:

Ensures top-notch compatibility and

performance for OpenGL applications.

zPureVideoTM HD technology: The

combination of high-definition video

decode acceleration and post-processing

that delivers unprecedented picture

clarity, smooth video, accurate color, and

precise image scaling for movies and

video.

zHardware Decode Acceleration:

Provides ultra-smooth playback of H.264,

VC-1, WMV, DivX, MPEG-2 and MPEG-4

HD and SD movies without the need for a

dual or quad-core CPU.

DVI to VGA converter

Note: Gainward's bundle items are subject to

change. Please refer to your local Gainward

dealer for more information, or the description

in the regional product package

SYSTEM REQUIREMENTS

•Intel Core2Duo series, AMD Athlon 64 X2

series or above CPU

•Minimum of 2GB system memory

•Minimum 550W system power supply with one

6-pin and one 8-pin PCI Express

supplementary power connectors

•DVD-ROM drive

•Requires a PCI Express 2.0 compliant

motherboard

•Requires a dual-width x16 graphics slot

•Windows 7/Vista/XP

API SUPPORT

•DirectX 11 in hardware

•OpenGL 4 support

OS SUPPORT

•Windows 7/Vista/XP

BAR CODE

•Large Box: 426018336-1732
