GAI-Tronics 263 Manuel utilisateur

Pub. 42004-178D

GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA

610-777-1374 800-492-1212 Fax: 610-796-5954

VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS

GAI-TRONICS®

AHUB BE L LC OM P ANY

Model 263

Isolation Barrier Unit

Confidentiality Notice

This manual is provided solely as an operational, installation, and maintenance guide and contains

sensitive business and technical information that is confidential and proprietary to GAI-Tronics.

GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,

and such information may only be used in connection with the operation of your GAI-Tronics product or

system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any

third party.

General Information

GAI-Tronics Corporation offers intrinsically-safe (I.S.) telephones and isolation barrier units (IBU),

which conform to all pertinent requirements in the USA and Canada. For convenience, a telephone and

an IBU can be purchased together under a single model number: Model 261-001 for indoor use, and

Model 271-001 for outdoors.

However, for rack-mount configurations or special applications, the telephones and IBUs can be

purchased separately:

•Model 262-001 Indoor I.S. Phone

•Model 272-001 Outdoor I.S. Phone

•Model 263 Isolation Barrier Unit

The I.S. telephones are designed to be installed in all hazardous areas. The IBU or rack-mount card unit

is placed in a non-hazardous area up to one mile from the phone, limiting the energy levels going to the

hazardous area to conform to intrinsically-safe requirements.

The Model 263 Isolation Barrier Unit is constructed of durable glass-reinforced polyester, which is highly

resistant to chemicals and weather, and is rated Type 3R (rainproof).

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 2 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Installation

Installation Guidelines

When installing any GAI-Tronics telephone equipment, please adhere to the following guidelines to

ensure the safety of all personnel:

•NEVER install telephone wiring during a lightning storm.

•Install a UL Listed lightning arrestor on any phone installed where the phone or phone cable is at

risk of being exposed to lightning strikes. The lightning arrestor must be installed as close to the

phone as possible to maximize the protection. The lightning arrestor must not be installed within the

enclosure supplied with the phone.

•NEVER install telephone jacks in wet locations unless the jack is specifically designed for wet

locations.

•NEVER touch uninsulated telephone wires or terminals unless the telephone line has been

disconnected at the network interface.

•USE CAUTION when installing or modifying telephone lines.

•Install UL Listed telephone line suppressor (customer-supplied) on the telephone line.

•Use silicone sealant or equivalent around and inside all conduit entries

Installation of the IBU

The Model 263 Isolation Barrier Unit provides an intrinsically-safe circuit when connected in accordance

with GAI-Tronics Pub. 42004-380, Control Drawing 73242. It must be installed in a non-hazardous

location. See Figure 1 for a typical installation.

The Model 263 Isolation Barrier Unit interior includes a power switch selector, a ring pitch adjustment,

and four troubleshooting LEDs. The IBU housing is composed of two modular subassemblies, the front

panel and the rear enclosure assembly, for easy installation and wiring.

Figure 1. Typical intrinsically-safe installation

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 3 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Wiring Requirements

Design Limits

In order to be intrinsically safe, energy and energy storage must be constrained to “safe” levels in

hazardous area apparatus. Wiring inherently has capacitance formed by a dielectric material between two

conductors. A buildup of this capacitance can form a surge of electricity, a dangerous situation in a

hazardous area.

Intrinsically-safe telephones require cabling that will limit the amount of capacitance formed. The

limitation on cable length was set by Underwriter’s Laboratory (UL) based on test results. This “worst

case” cable available was found to have a capacitance of 60 picofarads/foot. Therefore, UL set the cable

limitation at one mile, the length at which this worst-case cable capacitance level was still within

acceptable bounds. Cable types with less capacitance have been specified to allow connection distances

over one mile.

For example: GAI-Tronics Model 60059-001 and 60021-301 cables allow connection distances of up to

1.5 miles.

Shielded Cable

Where multiple I.S. telephone wires are routed together, shielded cable should be used. The use of

shielded cable prevents cross-talk from occurring between multiple I.S. telephone circuits. The shield

must be grounded to an I.S. ground and connected only at the IBU.

Wiring Guidelines/ControlDrawing

The Model 263 provides an intrinsically-safe circuit when installed in accordance with GAI-Tronics Pub.

42004-380, Control Drawing 73242. In addition, the NEC and the CEC provide additional installation

details that are recommended for safe installation.

General Wire Types

24 AWG 22 AWG 20 AWG 19 AWG 18 AWG

Maximum capacitance,

C (picofarads/mile) 316,800 pF/mile

Maximum resistance,

R (ohms/mile) 271 171 107 85 67

*Ring signal loss,

decibels (dB/mile) -16 -12 -8 -6 -4

*Nominal ring signal is 98 dB @ 10 feet.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 4 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

System Setup

GAI-Tronics recommends taking the following steps to ensure a safe and trouble-free installation:

1. Install the Model 263 Isolation Barrier Unit (IBU) and wire it completely, except for the hazardous

area signal wires.

WARNING The unit must be wired in accordance with Pub. 42004-380, Control

Drawing 73242, to ensure intrinsic safety.

2. Next, temporarily connect the I.S. telephone to the IBU with a short pair of conductors, and operate

the unit by making a test phone call. If any problems are detected, see the Troubleshooting section.

3. Call the I.S. telephone from another telephone, and adjust the RING PITCH (located on the IBU) to

the desired pitch. See Figure 2 for location.

4. Disconnect the I.S. telephone and install it in the intended permanent location.

WARNING The unit must be wired in accordance with Pub. 42004-380, Control

Drawing 73242, to ensure intrinsic safety.

5. Make a call from the I.S. telephone. If any problems are detected, see the Troubleshooting section.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 5 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Figure 2. Rear of IBU enclosure with cover removed

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 6 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Mounting

1. Remove the front panel by loosening the four front captive screws.

2. Refer to Figure 3. Determine which of the conduit locations is to be used. Drill spots have been

provided for use with a chassis punch or hole saw. Using a hole saw is recommended.

3. One 0.280-inch diameter hole is located in each corner of the rear enclosure. Install the rear

enclosure to a wall of an appropriate surface through the supplied mounting holes.

4. Refer to Pub. 42004-380, Control Drawing 73242, for wiring details.

NOTE:Telephone system wire must be connected to the Isolation Barrier Unit only and not directly

to the I.S. telephone. Battery backup connection is not required for operation of the Model 262-001

and 272-001 I.S. Phones. If battery backup is desired, please consult the factory for specifications.

5. Apply power and test telephone operation.

6. Refer to the Troubleshooting section of problems are detected.

When proper operation has been verified, replace the cover and secure it by tightening the four captive

screws.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 7 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Figure 3. Model 263 Isolation Barrier Unit dimensions

Operation

The Model 263 Isolation Barrier Unit requires no operator intervention for routine functions.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 8 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Maintenance

This section includes two troubleshooting charts designed to quickly pinpoint the source of problems.

Troubleshooting

NOTE:It may be advantageous to temporarily connect an I.S. telephone panel directly to the output

terminals of the Model 263 IBU when troubleshooting. Then, using the charts below, the cause of the

problem should be more easily determined.

Non-EquipmentRelated Problems

Problem Solution

The I.S. phone is inactive with

no lights on the IBU when the

phone is off-hook.

1. Check the ac power to the Model 263 IBU.

2. Check the ac fuse F4 at the Model 263 IBU.

3. Ensure there is no wiring open at the I.S. phone.

1. If the I.S. phone has a wiring short, the IBU lights will be lit in

the following pattern: O= On, P= Off

ISLOOP

OLOCK

HOOK

PTELCO

2. If the TELCO line has an open, the IBU lights will be lit in the

following pattern: : O= On, P= Off

ISLOOP

OLOCK

The I.S. phone has no dial tone.

HOOK

OTELCO

The lights on the IBU flash

randomly. The I.S. phone has an intermittent wiring short. The short may be

between the conductors or either/both conductor(s) to ground/shield.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 9 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Equipment-Related Problems

Problem Solution

There is no incoming ring tone. 1. Check the I.S. telephone panel.

2. Check the Model 263 IBU.

No receiver audio, no sidetone,

and cannot hear touch tones

when pressed.

1. Check the I.S. telephone panel.

2. Check the Model 263 IBU.

3. There may be a wiring open or a short in the connecting cable.

Cannot dial out, but can hear

touch tones when pressed. 1. Check the Model 263 IBU.

2. There is no TELCO connection or it is faulty.

I.S. phone appears inactive. 1. Check the I.S. telephone panel.

2. Check the ac fuse F4 at the Model 263 IBU.

3. Ensure there is no wiring open in the connecting cable or at the I.S.

telephone.

CAUTION

Any field repairs on the intrinsically-safe design of the phone are strictly prohibited. Any such

change will void ALL hazardous approvals. Please contact the GAI-Tronics Field Service Department at

800-492-1212 inside the USA or 610-777-1374 outside the USA for the Regional Service Center closest

to you.

Pub. 42004-178D

Model 263 Isolation Barrier Unit (IBU) Page: 10 of 13

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-178d.doc

03/06

Lightning Protection

Telephone lines are susceptible to lightning strikes and must be properly protected and maintained. On-

premise line protection is usually provided at the building entrance by the responsible telephone company

when it is installed. This protection is often neglected after installation.

Degradation of conventional protection, such as carbon blocks or gas discharge types, will occur with

each lightning strike. To ensure safe operation, protective elements should be replaced frequently and

checked for proper connection and grounding. Gas discharge types are by far the most robust, cost-

effective means of protection.

The registered I.S. equipment meets all isolation and safety requirements of FCC, Part 68, DOC CS-03,

UL 913, and CSA C22.2-No. 157. However, lightning strikes are not predictable or considered to be a

condition of fault likely to occur in practice as defined by the guidelines for intrinsic safety. Therefore, it

is imperative that the user employ and maintain a proper lightning protection scheme. This is true for all

hazardous area equipment and all telecommunications equipment subject to lightning.

Figure 4. Example of a lightning protection design

Table des matières

Autres manuels GAI-Tronics Téléphone

GAI-Tronics

GAI-Tronics Titan Illuminated Crossing Telephone Manuel utilisateur

GAI-Tronics

GAI-Tronics PHP400 Manuel utilisateur

GAI-Tronics

GAI-Tronics Titan CB Manuel utilisateur

GAI-Tronics

GAI-Tronics Titan Manuel utilisateur

GAI-Tronics

GAI-Tronics 226-002 Manuel utilisateur

GAI-Tronics

GAI-Tronics Auteldac 4 Manuel utilisateur

GAI-Tronics

GAI-Tronics Commander SMART Manuel utilisateur

GAI-Tronics

GAI-Tronics ITR1000-001 Manuel d'utilisation

GAI-Tronics

GAI-Tronics 12576-502 Manuel utilisateur

GAI-Tronics

GAI-Tronics 227-005 Manuel utilisateur

GAI-Tronics

GAI-Tronics 491-204 Manuel utilisateur

GAI-Tronics

GAI-Tronics ITR1000A Manuel d'utilisation

GAI-Tronics

GAI-Tronics KETS 1141 Manuel utilisateur

GAI-Tronics

GAI-Tronics Titan GSM Manuel utilisateur

GAI-Tronics

GAI-Tronics 352-101 Manuel utilisateur

GAI-Tronics

GAI-Tronics IPE2500A Manuel d'utilisation

GAI-Tronics

GAI-Tronics ILC-1117 Manuel utilisateur

GAI-Tronics

GAI-Tronics 256S Manuel utilisateur

GAI-Tronics

GAI-Tronics 700 Series Manuel utilisateur

GAI-Tronics

GAI-Tronics 354-001 series Manuel utilisateur

GAI-Tronics

GAI-Tronics Auteldac 4 VoIP Manuel utilisateur

GAI-Tronics

GAI-Tronics 716-102 Manuel utilisateur

GAI-Tronics

GAI-Tronics Clean Phone 295F Manuel utilisateur

GAI-Tronics

GAI-Tronics Commander GSM Mode d'emploi

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

AT&T

AT&T Trimline 205 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur
