User’s Manual
H.264 Series 2-Megapixel Network
Camera
N600E
Version: 1.5
Date: 12/26/2011
1
Contents
Notices .........................................................................................................................................................2
Introduction..................................................................................................................................................3
Installation....................................................................................................................................................4
Using the Web UI.......................................................................................................................................12
1. Live View.......................................................................................................................................13
2.Video...............................................................................................................................................16
3.Camera............................................................................................................................................19
General.......................................................................................................................................19
Advanced ...................................................................................................................................21
4 .Event ..............................................................................................................................................23
5. Schedule.........................................................................................................................................29
General.......................................................................................................................................29
Storage .......................................................................................................................................30
6. Network..........................................................................................................................................33
General.......................................................................................................................................33
Advanced ...................................................................................................................................34
SMTP (E-Mail)..........................................................................................................................35
DDNS.........................................................................................................................................36
7. System............................................................................................................................................37
User............................................................................................................................................38
Date & Time...............................................................................................................................39
Server Maintenance ...................................................................................................................40
Log Service................................................................................................................................41
8. Customize ......................................................................................................................................42
FAQ............................................................................................................................................................44
1. Connectors .....................................................................................................................................44
View of Back panel....................................................................................................................44
DC-Iris .......................................................................................................................................44
Composite Video Output............................................................................................................45
Audio Out...................................................................................................................................45
SD Card Slot..............................................................................................................................46
2. I/O Terminal Connector - Pin Assignment.....................................................................................47
Restore Factory Default Settings ...............................................................................................49
3. Technical Specifications ................................................................................................................50
Product Specifications ...............................................................................................................50
Video Streams Specification......................................................................................................53
2
Notices
This user manual is intended for administrators and users of the H.264 Series Network Camera, including
instructions for using and managing the camera on your network. The use of surveillance devices may be
prohibited by law in your country. It is the user’s responsibility to ensure that the operation of such devices is legal
before installing this unit for its intended use.
Before the Network Camera is installed, all the safety and operating instructions should be carefully read and
followed to avoid damage due to faulty assembly and installation. This also ensures the product is used properly as
intended.
Heed all warnings
Do not drop or strike this equipment
Sensitive electronics inside the camera are vulnerable to excessive strike.
Do not install the equipment near any flames or heat sources
Excessive heat could damage this equipment.
Do not cover cloth or to install this equipment in poorly ventilated places.
Overheating could damage this equipment.
Do not expose this equipment to rain or moisture. Do not touch the power connection with wet
hands
Risk of short circuit, electric shock or fire
Do not damage the power cord or leave it under pressure
Risk of fire or shock circuit
To reduce the risk of electric shock, do not remove the Cover (or Back).
No user-serviceable parts inside. Misusage, improper, and negligence could damage this equipment.
Need to refer servicing to qualified service personnel.
Do not continue to operate if there appears to be fault.
If the unit ceases to function, contact qualified service personnel for help.
All work related to the installation of this product should be made by qualified service personnel
or system installers.
3
Introduction
H.264 N600 Series Network Camera delivers superior H.264-AVC performance, state of the art design and
function. N600 Series is specifically adapted for maximum performance indoor applications, such as
commercial, banking, government buildings, schools, universities and airports.
H.264-AVC video compression can lower bandwidth and storage requirements without compromising image
quality; Motion JPEG is supported for increased flexibility, as well as multiple independent video streaming.
N600 Series value-added features include; on-board video motion detection, SD slot for storage recording, and
two-way audio. N600E, the PoE model, is available with full PoE (IEEE-802.3af) feature that supplies function of
power to the camera via the network, eliminating the need for power cables, reducing installation costs and
complexity. Consequently, N600 Series is “Best in Class” for maximum performance IP video surveillance
systems, demanding superior image quality, ease of installation, and intelligent video capabilities.
4
Installation
1. Hardware Connection
5
2. Software Installation
The following software is necessary for the proper display and use of the N600 from the Web site. The
software will be available from the Software Package CD.
IP Installer
The IP Installer is used to locate and configure network cameras and video servers on the LAN. This utility is
useful for conveniently configuring the network settings of the device, or for finding a device once the network
settings have been modified. To install the IP Installer, from the Software Package CD UI, select IP installer,
then follow the on screen instructions.
XVID Codec
An H.264 codec is applied for displaying the video stream and playing the recoded AVI files. If the video
stream can’t be displayed or the recorded AVI files can’t be play on PC, install this software from the Software
Package CD.
VLC
Though not necessary, this can be used for viewing the streaming without a Web browser.
6
3. Network Configuration
IP Installer is a utility that provides an easier, more efficient way to configure the IP address and network
settings of the devices. It even provides a convenient way to set the network settings for multiple devices
simultaneously using the batch setting function. Moreover, IP Installer can save the network settings for all
devices as a backup and restore them when necessary. NOTE: Default mode for N600 is DHCP.
Preparation before IP Assignment
1. Always consult your network administrator before assigning an IP address to your server in order to avoid
using a previously assigned IP address.
2. Ensure the N600 is powered on and correctly connected to the network.
3. MAC Address: Each device has a unique Ethernet address (MAC address) shown on the label of the device
as the serial number (S/N) with 12 digits (e.g. 000429-XXXXXX).
4. Although the IP Installer is able to find and configure any N600 on the LAN except those that are behind a
router, it is a good idea to set the host PC to the same subnet. In order to connect to the Web-based user
interface of the camera, the host PC must be in the same subnet. For more information about subnets, please
consult your network administrator.
Using IP Installer to Assign an IP Address to N600
1. Once IP Installer has been successfully installed on the PC, double click the IP Installer icon on the desktop
2. Click the [Device Search] to search the device in the LAN.
*0004290000
B1
7
3. From the list, select the device with the MAC Address that corresponds to the N600 that is to be configured.
The MAC Address is identical to the unit’s S/N (Serial Number).
4. Double click the select item to open the Property Page or right click the item to select the
[Single Device Setting]
5. Modify the network settings of the camera
8
6. After filling in the properties, click [Set] button to complete the configuration settings.
9
7. Click the [Batch Device Setting] to set several devices.
8. Language support for Chinese, English and Spanish.
