Future Aqua Manuel utilisateur
590 REV02 REV DATE: SEPTEMBER 13, 2013
NT
USER MANUAL
CONTENTS
590 REV02 REV DATE: SEPTEMBER 13, 2013 2 AQUA NT
1 General...............................................................................................................................................................4
Labels .....................................................................................................................................................................5
Operating Safety Warnings ....................................................................................................................................6
Features..................................................................................................................................................................8
Safety Inspection Checklist ....................................................................................................................................9
Troubleshooting................................................................................................................................................... 11
2 Front Riggings ................................................................................................................................................. 12
Installing And Adjusting The Front Rigging Figure 1, Figure 2............................................................................ 12
3 Arms................................................................................................................................................................. 14
Adjusting And Installing Arms Figure 3Figure 4 .................................................................................................. 14
4 Back................................................................................................................................................................. 16
Replacing Upholstery And Adjusting Back Height Figure 5Figure 6................................................................... 16
5 Seat.................................................................................................................................................................. 18
Replacing Seat Assembly Figure 7 ..................................................................................................................... 18
6 Potty................................................................................................................................................................. 19
Removing and Installing Potty Figure 8 Figure 9 ................................................................................................ 19
7 Casters............................................................................................................................................................. 22
Adjusting commode seat height Figure 10.......................................................................................................... 22
8 Rear wheels (self-propelled only).................................................................................................................... 24
CONTENTS
590 REV02 REV DATE: SEPTEMBER 13, 2013 3 AQUA NT
Removing/Installing the rear wheels Figure 11 ................................................................................................... 24
9 Wheel locks –(self-propelled only).................................................................................................................. 25
Using the Wheel Locks Figure 12........................................................................................................................ 25
10 Anti-tippers (self-propelled only)...................................................................................................................... 27
Installing/adjusting anti-tippers Figure 13 Figure 15............................................................................................ 27
11 Seat to Floor .................................................................................................................................................... 30
Adjusting the seat to floor ratio Figure 15 Table 1............................................................................................... 30
12 Cleaning and maintenance.............................................................................................................................. 32
13 Warranty.......................................................................................................................................................... 34
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 4 AQUA NT
1 General
NOTE: Check all parts for shipping damages before using.
In case of damage, do NOT use the equipment.
Contact the Equipment Supplier for further instructions.
NOTICE
Information contained within this document is subject to change
without notice.
WARNING
DO NOT install this equipment without first reading and
understanding this instruction booklet. If you are unable to
understand these instructions, contact a healthcare professional,
dealer or technical personnel before attempting to install this
equipment - otherwise, injury or damage may occur.
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 5 AQUA NT
Labels
AQUA NT COMMODE
WEIGHT CAPACITY
300LBS. (136KGS)
REFER TO OWNER’S
MANUAL
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 6 AQUA NT
Operating Safety Warnings
Unless otherwise noted, all service and adjustment should be performed while the tilt commode is unoccupied.
To determine and establish your particular safety limits, practice bending, reaching and transferring activities in
several combinations in the presence of a qualified healthcare professional BEFORE attempting active use of the
tilt commode.
Always verify that the back assembly is secure PRIOR to use when an attendant is used to propel or lift the tilt
commode. Check for any signs of looseness or deterioration and if found, contact a qualified technician. DO
NOT attempt to move the tilt commode by using the back assembly is it is found to be unsecure or have
deteriorated.
DO NOT sit or transfer into the commode unless it is fully open and the commode seat assembly is properly
fastened to the commode frame though the use of clips.
DO NOT TRAVERSE, CLIMB or GO DOWN ramps or slopes greater than 9 degrees
DO NOT attempt to move up or down an incline with a water, ice or oil film
DO NOT operate on roads, streets or highways
DO NOT attempt to ride over curbs or obstacles. Doing so may cause your commode to tip over and cause
bodily harm to you or damage to the commode.
DO NOT attempt to reach objects if you have to move forward in the seat.
DO NOT attempt to reach objects if you have to pick them up from the floor by reaching down between your
knees.
DO NOT lean over the top of the back upholstery. This will change your center of gravity and may cause you
to tip over.
DO NOT shift your weight or sitting position toward direction you are reaching as the commode may tip over.
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 7 AQUA NT
WHEEL LOCKS ARE NOT BRAKES. DO NOT attempt to stop a moving commode with wheel locks.
These locks are to be engaged by the occupant or attendant when the commode is stationary and prior to use
by the occupant.
CASTER LOCKS ARE NOT BRAKES. DO NOT attempt to stop a moving commode with caster locks.
These locks are to be engaged by the attendant when the commode is stationary and prior to use by the
occupant.
DO NOT tip the commode without assistance.
DO NOT use an escalator to move a commode between floors. Serious bodily injury may occur.
Before attempting to transfer in and out of the commode, every precaution should be taken to reduce the gap
distance. Turn both casters parallel to the object you are transferring onto. When transferring to and from the
commode, ALWAYS ENGAGE BOTH WHEEL and CASTER LOCKS.
DO NOT use parts, accessories or adapters other than those authorized by Future Mobility Healthcare Inc.
Otherwise, the warranty is void.
DO NOT attempt to lift the commode by any removable (detachable) part. Lifting by means of any removable
(detachable) parts of a commode may result in injury to the user and/or assistant or damage to the commode.
DO NOT stand on the frame of the commode.
DO NOT use the footplate as a platform. When getting in or out of the commode, make sure that the
footplates are in the upward position.
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 8 AQUA NT
Features
FEATURES
SPECIFICATIONS
Removable seat and potty
Removable cantilever fixed height arm rest
Incredibly low 16-1/4” seat to floor height
Quick release clip on casters for adjustment of
seat to floor heights
Height adjustable back frame
50 or 70 degree swing away front riggings
(optional)
Removable rear wheels with stainless steel or
plastic hand rims (self-propelled only)
Composite footplates
Heel loops
Seat Width: 17”, 20”, 22”
Seat Depth: 17”
Overall Width: Seat Width +7” (self-propelled),
seat width + 6” (attendant propelled)
Seat to Floor: 15-1/4” –19”1/2”
Caster Size: 5” urethane w/lock
Rear Wheels: 20”, 22”, 24” (self-propelled only)
Back Style: Mesh Back
Back Height: 20”
Front Riggings: Swing away
Weight Capacity: 300lbs (136kgs)
Product Weight: 38lbs
Frame Material: Stainless Steel
Frame Finish: Electro polished or white powder
coat
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 9 AQUA NT
Safety Inspection Checklist
Initial adjustments should be made to suit your personal body structure needs and preference. Thereafter follow
these maintenance procedures:
Item
Initially
Weekly
Monthly
Periodically
GENERAL
Commode rolls straight (no excessive
drag or pull to one side)
X
X
X
FRAME AND CROSSING TUBES
Inspect for loose or missing hardware
Inspect for bent frame or cross tubes
X
X
X
X
X
X
SEAT AND BACK
Inspect for rips or sagging
Inspect for loose or broken hardware
Inspect cane and back support for
wear/looseness
X
X
X
X
X
X
X
FRONT AND REAR CASTERS
Inspect caster assembly for proper
tension by spinning caster; caster should
come to a gradual stop
X
X
1GENERAL
590 REV02 REV DATE: SEPTEMBER 13, 2013 10 AQUA NT
Adjust bearing system if wheel wobbles
or binds to a stop. Ensure wheel
bearings are clean and free of moisture.
Check caster stem for tightness
Inspect casters for cracks and wear
Inspect for cracked, bent or broken
spokes
Inspect Tente Caster lock to ensure it
engages properly
X
X
X
X
X
X
X
X
X
X
X
CLEANING
Clean upholstery and armrests
Clean potty and commode seat
Check commode for sign of human waste
on all parts to maintain sanitary
conditions.
X
X
X
X
X
X
X
X
X
