FUTABA T16IZ Manuel utilisateur

YourFutabaT16IZSUPERtransmitterprogrammingcanbeupdated

easilyonline.Whenfunctionsareaddedorimproved,theupdateﬁle

canbedownloadedfromourwebsite.Copytheupdatefilestothe

microSDcardandthenusethefollowingproceduretoupdatethe

program.CheckourwebsitefortheFAQregardingupdatingformore

information.

HowtoupdateT16IZSUPER

ŸƓƇƄƗƌƑƊŃƓƕƒƆƈƇƘƕƈ

Note: If the battery fully discharges during

program updating, updating will fail. When

the remaining battery capacity is 50% or

less, always recharge the battery before

updating.

Note: The model data in the transmitter can

be used unchanged after updating, but to

be safe, back up the model data before

updating.

1. Download the zip file of the update data

from our website.

([WUDFWWKH]LSÀOHRQ\RXUFRPSXWHU

3. The "FUTABA" folder will be created on your

computer.

4. Copy the "FUTABA" folder into your microSD

card.

Note: If the microSD card has already had

"another FUTABA" folder before you make a

copy, the "FUTABA" folder is OVERWRITTEN.

5. Insert the microSD card with "FUTABA" folder

that contained the update software into

the SD card slot on your T16IZ SUPER radio

transmitter.

6. Turn on the transmitter power while pressing

down the "HOME/EXIT" button. The update

screen appears on the LCD display of your

T16IZ SUPER and the software update is

started.

FutabaWEB

16IZSUPERUpdateZipﬁle

Download

Copythe"FUTABA"

folderintoyourSDcard.

InstalledmicroSDcard

oftheupdateﬁle

PresstheHOME/EXITswitchandturnon

Updating

7. When the software update is completed,

"Completed" message is shown on the LCD

display of your T16IZ SUPER. (Show below

picture.)

8. Turn off the power switch of your T16IZ SUPER

and remove the microSD card from the card

slot.

Possible Problems

When one of the error messages shown

below appears on the LCD screen your

T16IZ SUPER, the software update will not be

completed.

"Low battery."

Software update is postponed because

of low battery. Retry the software update

after the battery is recharged.

8SGDWHÀOHQRWIRXQG

7KH7,=683(5FDQQRWÀQGWKHXSGDWHÀOH

on the microSD card. Check to be sure all

the update files have been copied onto

the microSD card.

%URNHQÀOH

The T16IZ SUPER detects the update file

HUURU7KHXSGDWHÀOHPD\EHEURNHQRUIRU

another transmitter.

"Write error."

The software update procedure is stopped

for an unknown reason. Contact your local

service center when this error message

appears on the LCD screen of your T16IZ

SUPER.

Don't absolutely remove the battery

and the microSD card from the

transmitter during the update.

There is a possibility that the transmitter

will be damaged.

Recovering a failed update

If you failed to update for any reason, it

may transmitter will not start.

In that case, please update again

transmitter in the following procedure.

1. Detach the battery from the transmitter.

2. Insert the microSD card that contained

WKHXSGDWHÀOHVWRWKHWUDQVPLWWHU

3. Attach the battery to the transmitter

while pressing down the "HOME/EXIT"

button.

4. The update will start.

Even after the above steps, if the

transmitter fails to update or does not

start, please have it serviced.

Complete

1M23Z09106 T16IZSUPERSOFTWAREUPDATECHANGES

V2.1

Thissoftwareupdatesoraltersthefunctionsandfeaturesnotedbelow.Theinstructionsandinformationthatfollowaremeantasasupplementtotheoriginal

instructionmanualthataccompaniedtheT16IZSUPERtransmitter.Pleaserefertotheoriginalinstructionmanualwhereapplicable,butreplacethestepsindicated

belowwiththeseinstructions.Pleasechecktoensurethattheupdatehasbeeninstalled.

1)SelecttheSystemMenu.

2)Touchthe[Information]button.

3)Conﬁrmthattheinformationinthedisplayindicatestheversionnumbersasnotedabove.

1.BugﬁxforEuropeanT16IZSUPER[ForEuropeonly]

FixedanissuewherecommunicationbecameunstablewhenoperatinganothertransmitteratashortdistancewhenusingtheT16IZSUPER

soldintheEuropeanregion.ThisproblemisONLYwhenyouuseT16IZSUPERunderS-FHSSmode.

*T16IZSUPERsoldoutsideEuropedoesnothavetheaboveproblem.Also,T16IZdoesnothavetheaboveproblem.

1.Receiverorgyroupdates

ByconnectingareceiverorgyrothatsupportsupdatestotheS.I/Fconnectorofthetransmitter,itispossibletoupdatetheirsoftware.

① DownloadtheupdateﬁleoftheupdatedatafromFutabawebsite.

② Extracttheupdateﬁleonyourcomputer.The"FUTABA"folderwillbecreatedonyourcomputer.

③ Copythe"FUTABA"folderintoyourmicroSDcard.

④ InsertthemicroSDcardwith"FUTABA"folderthatcontainedtheupdatesoftwareintotheSDcardslotonyourtransmitter.

⑤ Turnonthetransmitterandcall"SystemMenu"⇒"Update".

⑥ Selecttheproducttoupdate.

*ConventionalServoUpdateandSensorUpdatescreensopenfromthisscreen.

⑦ Selecttheproductnametoupdate.

V2.0

V1.2

AirplaneGyroGYA553iscompatiblewith3rdaileronand4thaileron.

1.GYA553NewﬁrmwareVersion3.xsupport. → RefertoT16IZ/T16IZSUPERGYA553V3Setting

manual

©FUTABA CORPORATION

⑧ Theupdatescreenisdisplayed.ConnectthereceiverorgyrotobeupdatedtotheS.I/Fconnectorofthetransmitter,prepare

forupdate,andthentapthe[Update]button.

⑨ Updatestart.

⑩ Whenﬁnished,thefollowingwillappear.

⑪ Disconnectthereceiverorgyrofromthetransmitter'sS.I/Fconnector.
