FUTABA Mega Tech 3PK Manuel utilisateur

Digital Proportional R/C System

1M23N11002

Thank you for purchasing the Futaba 3PK.

Prior to operating your 3PK, please read this manual thoroughly and use your

system in a safe manner.

After reading this manual store it in a safe place.

Application, Export and Reconstruction

1. Use this product in surface models only.

The product described in this manual is subject to regulations of the Ministry of

Radio/Telecommunications and is restricted under Japanese law to such pur-

poses.

2. Exportation Precautions

(a) When this product is exported from Japan, its use is to be approved by the

Radio Law of the country of the destination.

(b) Use of this product with other than models may be restricted by Export and

Trade Control Regulations. An application for export approval must be submit-

ted.

3. Modification, adjustment and replacement of parts.

Futaba is not responsible for unauthorized modification, adjustment and re-

placement of parts of this product.

THE FOLLOWING STATEMENT APPLIES TO THE

RECEIVER (FOR U.S.A.)

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions.

(1) This devise may not cause harmful interference, and

(2) This devise must accept any interference received, including interference

that may cause undesired operation.

THE RBRCTM SEAL (FOR U.S.A.)

The RBRCTM SEAL on the (easily removable) nickel-cadmium battery con-

tained in Futaba products indicates that Futaba Corporation of America is vol-

untarily participating in an industry program to collect and recycle these batter-

ies at the end of their useful lives, when taken out of service within the United

States. The RBRCTM program provides a convenient alternative to placing used

nickel-cadmium batteries into the trash or municipal waste which is illegal in

some areas.

Futaba Corporation of America's payments to RBRCTM makes it easy for you to

return the spent battery to Futaba for recycling purposes. You may also contact

your local recycling center for information on where to return the spent battery.

Please call 1-800-8-BATTERY for information on Ni-Cd battery recycling in

your area. Futaba Corporation of America's involvement in this program is part

of its commitment to protecting our environment and conserving natural re-

sources.

RBRCTM is a trademark of the Rechargeable Battery Recycling

Corporation.

-No part of this manual may be reproduced in any form without prior permission.

-The contents of this manual are subject to change without prior notice.

-This manual has been carefully written, please write to Futaba if you feel that any corrections or clarifica-

tions should be made.

-Futaba is not responsible for the use of this product.

For Your Safety As Well As That Of Others .........

Explanation of Symbols ...................................................................................

High Response System (H.R.S) Precautions .................................................

Operation Precautions ....................................................................................

Nicad Battery Handling Precautions..............................................................

Storage and Disposal Precautions ................................................................

Other Precautions..........................................................................................

Table Of Contents

Before Using ............................................................

Features...........................................................................................................

Set Contents ...................................................................................................

Nomenclature.................................................................................................

Installation................................................................

Receiver and Servo Connections ..................................................................

Installation Safety Precautions .....................................................................

Initial Set-Up............................................................

Preparations (Transmitter) ..........................................................................

Functions ..................................................................

End Point Adjuster .........................................................................................

Steering EXP ..................................................................................................

Steering Speed................................................................................................

Throttle EXP ..................................................................................................

Throttle Speed ...............................................................................................

A.B.S. Function ...............................................................................................

Throttle Acceleration ....................................................................................

Start Function / Engine Cut ..........................................................................

Brake Mixing ...................................................................................................

Idle-Up .............................................................................................................

Timer ...............................................................................................................

Lap List ............................................................................................................

Programmable Mixing 1/2 .............................................................................

Boat Mode .......................................................................................................

Function Map ...........................................................

Menu Selection ...............................................................................................

Direct Selection..............................................................................................

Subtrim .................................................................................................

Channel Reverse ..................................................................................

Fail Safe/Battery Fail Safe (HRS/PCM Mode Only) ..........................

Model Select .........................................................................................

Model Reset ..........................................................................................

Model Copy...........................................................................................

Model Name .........................................................................................

Function Select Dial ............................................................................

Function Select Switch ........................................................................

Dual Rate/Second Dual Rate ..............................................................

ATL Function .......................................................................................

Channel 3 Position ...............................................................................

HRS/PCM/PPM Select .........................................................................

Level Select ..........................................................................................

System functions ..................................................................................

Direct Selection Button ......................................................................

Servo View............................................................................................

HRS ESC Set Up ..................................................................................

Adjuster ................................................................................................

For Your Safety

As Well As

That Of Others

Before

Using

Installation

Initial

Set-Up

Function

Map

Functions

Reference

Reference ........................................................

Ratings.................................................................................................

Optional Parts ....................................................................................

Troubleshooting.................................................................................

Error Displays.....................................................................................

When requesting repair ..............................................

Glossary ..............................................................................................

Glossary (LCD Display) .....................................................................

3PKData Sheet......................................................................

For Your Safety As Well As That Of Others

Use this product in a safe manner. Please observe the following safety precautions at

all times.

Explanation of Symbols

The parts of this manual indicated by the following symbols are extremely important

and must be observed.

Danger

Indicates a procedure which could lead to a dangerous situ-

ation and may cause death or serious injury if ignored and

not performed properly.

Warning Indicates procedures which may lead to dangerous situa-

tions and could cause death or serious injury as well as su-

perficial injury and physical damage.

Caution Indicates procedures that may not cause serious injury, but

could lead to physical damage.

Symbols: ; Prohibited ; Mandatory

Symbols Explanation

In case of the High Response System (H.R.S) receiver R203HF, always use only the

following conditions:

Servo; 6V type Digital Servo only

Power supply; 6V Nicd battery

Transmitter setting; "HRS" mode

If the conditions are different, control is impossible.

And Fail Safe Unit (FSU1) is not available.

Caution

High Response System (H.R.S) Precautions

Mandatory Procedures

FCC Compliance Statements:

Any adjustment or modification to the device not expressly authorized by the party responsible for

compliance could result in a violation of the FCC Rules and void the users authority to operate the

equipment.

For Your Safety As Well As That Of Others

Operation Precautions

Warning

Prohibited Procedures

Do not operate two or more models

on the same frequency at the same

time.

Operating two or more models at same time on the

same frequency will cause interference and loss of

control of both models.

AM, FM (PPM) and PCM are different methods

of modulation. Nonetheless the same frequency

can not be used at the same point in time, regard-

less of the signal format.

Do not operate outdoors on rainy

days , run through puddles of water or

when visibility is limited.

Should any type of moisture (water or snow) enter any

compoent of the system, erratic opreation and loss of

control may occur.

Do not operate in the following

places.

-Near other sites where other radio control

activity may occur.

-Near people or roads.

-On any pond when rowboats are present.

-Near high tension power lines or communi-

cation broadcasting antennas.

Interference could cause loss of control . Improper in-

stallation of your Radio Control System in your model

could result in serious injury.

Do not operate this R/C system when

you are tired, not feeling well or under

the influence of alcohol or drugs.

Your judgment is impaired and could result in a dan-

gerous situation that may cause serious injury to

yourself as well as others.

Mandatory Procedures

Extend the transmit-

ter antenna to its full

length.

If the transmitter antenna is not

fully extended the operating

range of the radio will be re-

duced.

Check the transmitter antenna to be

sure it is not loose.

If the transmitter antenna works loose, or is discon-

nected while the model is running signal transmission

will be lost. This will cause you to lose control of the

model..

Always perform a operating range

check prior to use.

Problems with the radio control system as well as im-

proper installation in a model could cause loss of con-

trol.

(Simple range test method)

Have a friend hold the model, or clamp it down or

place it where the wheels or prop can not come in

contact with any object. Walk away and check to

see if the servos follow the movement of the con-

trols on the transmitter. Should you notice any ab-

normal operation, Do not operate the model. Also

check to be sure the model memory matches the

model in use.

For Your Safety As Well As That Of Others

Caution

Prohibited Procedures

Mandatory Procedures

Do not touch the engine, motor, speed control or any part of

the model that will generate heat while the model is operating

or immediately after its use.

These parts may be very hot and can cause serious burns.

Turning on the power switches.

Always check the throttle trigger on the

transmitter to be sure it is at the neutral

position.

1. Turn on the transmitter power switch.

2. Turn on the receiver or speed control

power switch.

Turning off the power switches

Always be sure the engine is not

running or the motor is stopped.

1. Turn off the receiver or speed control power switch.

2. Then turn off the transmitter power switch.

If the power switches are turned off in the opposite

order the model may unexpectedly run out of control

and cause a very dangerous situation.

When making adjustments to

the model do so with the en-

gine not running or the motor

disconnected.

You may unexpectedly lose control and

create a dangerous situation.

When operating your model

always display a frequency

flag on your transmitter an-

tenna.

When adjusting the transmitter on land while preparing to run (cruise), take measures

so that the wind will not knock over the transmitter.

If the transmitter is knocked over, the throttle stick may be accidentally set to the operating position and you may

lose control.

(Fail safe function) ---H.R.S or PCM mode only

Before running (cruising), check the fail safe function.

Check Method;

Before starting the engine, check the fail safe function as follows:

1) Turn on the transmitter and receiver power switches.

2) Wait at least one minute, then turn off the transmitter power switch. (The transmitter automatically transfers the fail

safe data to the receiver every minute.)

3) Check if the fail safe function moves the servos to the preset position when reception fails.

The fail safe function is a safety feature that minimizes set damage by moving the servos to a preset position when

reception fails. However, if set to a dangerous position, it has the opposite effect. When the reverse function was used

to change the operating direction of a servo, the fail safe function must be reset.

Setting example: Throttle idle or brake position

For Your Safety As Well As That Of Others

Nicad Battery Handling Precautions

(Only when Nicad batteries are used)

Warning

Mandatory Procedures

Always check to be sure your batter-

ies have been charged prior to oper-

ating the model.

Should the battery go dead while the model is operat-

ing loss of control will occur and create a very danger-

ous situation.

To recharge the transmitter Nicad ,

use the special charger made for this

purpose.

Overcharging could cause the Nicad battery to over-

heat, leak or explode. This may lead to fire, burns,

loss of sight and many other type's of injuries.

Caution Prohibited Items

Do not use commercial AA

size Nicad batteries.

Quick charging may cause the

battery contacts to overheat and

damage the battery holder.

Do not short circuit the Nicad battery

terminals.

Causing a short circuit across the battery terminals

may cause abnormal heating, fire and burns.

Do not drop the Nicad battery or ex-

pose it to strong shocks or vibrations.

The battery may short circuit and overheat, electrolyte

may leak out and cause burns or chemical damage.

When the model is not being used,

always remove or disconnect the

Nicad battery .

Should the battery be left connected this could create

a dangerous situation if someone accidentally turns

on the receiver power switch. Loss of control would

occur.

Special

Charger

Nicad AA size

batteries.

Use

prohibited

Shock

Prohibited

For Your Safety As Well As That Of Others

Storage and Disposal Precautions

Warning

Prohibited Procedures

Do not leave the radio system or

models within the reach of small chil-

dren.

A small child may accidentally operate the system,

this could cause a dangerous situation and injuries.

Nicad batteries can be very dangerous when mis-

handled and cause chemical damage.

Do not throw Nicad batteries into a

fire. Do not expose Nicad batteries to

extreme heat. Also do not disas-

semble or modify a Nicad battery

pack.

Overheating and breakage will cause the electrolyte

to leak from the cells and cause skin burns, loss of

sight as well as other injuries.

Mandatory Procedures

When the system will not be used for

any length of time store the system

with batteries in a discharged state.

Be sure to recharge the batteries prior

to the next time the system is used.

If the batteries are repeatedly recharged in a slightly

discharged state the memory effect of the nicad bat-

tery may considerably reduce the capacity . A reduc-

tion in operating time will occur even when the batter-

ies are charged for the recommended time.

The electrolyte in Nicad batteries is a strong alkali. Should you get even the

smallest amount of the electrolyte in your eyes, DO NOT RUB, wash immedi-

ately with water, seek medical attention at once. The electrolyte can cause blind-

ness. If electrolyte comes in contact with your skin or clothes, wash with water

immediately.

Caution

Prohibited Procedures

Do not store your R/C system in the

following places.

- Where it is extremely hot or cold.

- Where the system will be exposed to direct

sunlight.

- Where the humidity is high.

-Where vibration is prevalent.

-Where dust is prevalent.

-Where the system would be exposed to

steam and condensation.

Storing your R/C system under adverse conditions

could cause deformation and numerous problems

with opreation.

Mandatory Procedure

If the system will not be used for a

long period of time remove the batter-

ies from the transmitter and model

and store in a cool dry place.

If the batteries are left in the transmitter electrolyte

may leak and damage the transmitter. This applies to

the model also, remove the batteries from it also to

prevent damage.

A used Nicad battery is valuable resource. Insulate the battery terminals and

dispose the battery by taking it to a battery recycling center.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels FUTABA Télécommande

FUTABA

FUTABA 2PL Manuel du propriétaire

FUTABA

FUTABA 6XA Manuel utilisateur

FUTABA

FUTABA T8FG Manuel utilisateur

FUTABA

FUTABA Magnum 3PK Super Manuel utilisateur

FUTABA

FUTABA T32MZ Manuel

FUTABA

FUTABA T32MZ Manuel

FUTABA

FUTABA 16IZS Instructions d'installation

FUTABA

FUTABA T16IZ Manuel technique

FUTABA

FUTABA SKYSPORT-6A Manuel utilisateur

FUTABA

FUTABA CONQUEST Manuel utilisateur

FUTABA

FUTABA FP-S130 Manuel utilisateur

FUTABA

FUTABA 12K Manuel utilisateur

FUTABA

FUTABA 3PL-2.4G Manuel utilisateur

FUTABA

FUTABA 6EX 2.4GHZ Manuel du propriétaire

FUTABA

FUTABA FASSTest-2.4GHz T16SZ Series Manuel utilisateur

FUTABA

FUTABA FP-5FG Manuel utilisateur

FUTABA

FUTABA Attack 2ER Manuel utilisateur

FUTABA

FUTABA SKYSPORT-6H Manuel utilisateur

FUTABA

FUTABA GYA450 Manuel utilisateur

FUTABA

FUTABA T4GRS-24G Manuel utilisateur

FUTABA

FUTABA FP-G134 Manuel utilisateur

FUTABA

FUTABA FASSTest-2.4GHz T16SZ Series Manuel utilisateur

FUTABA

FUTABA 3pv-2.4g Manuel utilisateur

FUTABA

FUTABA 8FG Mode d'emploi

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

Invacare

Invacare G91S Manuel utilisateur

JR Racing

JR Racing XR2 Manuel utilisateur
