FUST Novamatic TW727.2 E Manuel utilisateur
TW727.2 E
User Manual
Benutzerinformation
Tumble Dryer
Wäschetrockner
CONTENTS
Safety information 2
Safety instructions 4
Product Description 6
Control Panel 6
Programme table 7
Options 8
Settings 9
Before first use 9
Daily use 10
Hints and tips 11
Care and cleaning 12
Troubleshooting 14
Technical data 15
Product Information sheet in
reference to E.U. regulation
1369/2017
17
Subject to change without notice.
SAFETY INFORMATION
Before beginning the installation and use of this appliance,
carefully read the supplied instructions. The manufacturer is
not responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
- Read the supplied instructions.
Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
2
•Keep detergents away from children.
•Keep children and pets away from the appliance when the
door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
General Safety
•Do not change the specification of this appliance.
•If the tumble dryer is put on top of a washing machine, use
the stacking kit. The stacking kit, available from your
authorized vendor, can be used only with the appliance
specified in the instructions supplied with the accessory.
Read it carefully before installation (refer to the Installation
leaflet).
•The appliance can be installed as freestanding or below a
kitchen counter with correct space (refer to the Installation
leaflet).
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite side,
that would prevent the appliance door from being fully
open.
•The ventilation opening in the base must not be covered
by a carpet, mat, or any floor covering.
•CAUTION: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
•Connect the mains plug to the mains socket only at the
end of the installation process. Make sure that the mains
plug is accessible after installation.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an electrical
hazard.
•Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
3
•Do not use the appliance if items have been soiled with
industrial chemicals.
•Wipe away lint or packaging debris that has accumulated
around the appliance.
•Do not run the appliance without a filter. Clean the lint filter
before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
•Fabric softeners, or similar products, should only be used
as specified by the product manufacturer’s instructions.
•Remove all objects from items that could be a source of
fire ignition such as lighters or matches.
•WARNING: Never stop a tumble dryer before the end of
the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
SAFETY INSTRUCTIONS
Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be lower
than 5°C or higher than 35°C.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when it is being moved.
• The rear surface of the appliance must
be put against a wall.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
4
Electrical connection
WARNING! Risk of fire and
electric shock.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the E.E.C.
Directives.
Use
WARNING! Risk of injury,
electric shock, fire, burns or
damage to the appliance.
• This appliance is for household use
only.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a stain
remover, carry out an additional rinse
cycle before starting a drying cycle.
• Dry only fabrics that are suitable to dry
in the appliance. Follow the cleaning
instruction on the item label.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door of
the appliance.
• Do not dry dripping wet clothes in the
appliance.
Care and cleaning
WARNING! Risk of injury or
damage to the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• To prevent damage to the cooling
system be careful when you clean the
appliance.
Compressor
WARNING! Risk of damage to
the appliance.
• The compressor and its system in the
tumble dryer is filled with a special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
Disposal
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming trapped
in the drum.
• Dispose of the appliance in accordance
with local requirements for the disposal
of Waste Electrical and Electronic
Equipment (WEEE).
5
PRODUCT DESCRIPTION
1 2
3
4
5
8
9
6
10
7
1Water container
2Control panel
3Appliance door
4Primary Filter
5Bottom cover with the airflow slots
WARNING! Do not put any
object on the bottom cover
6Buttons to open the bottom cover
7Adjustable feet
8Heat exchanger door
9Knob to lock the heat exchanger door
10 Rating plate
For ease of loading laundry or
ease of installation the door is
reversible. (see separate
leaflet).
CONTROL PANEL
1 2 3 4 5 6
8
7
1On / Off button
2Programme selection touchpad
3Dryness selection touchpad
4Options selection touchpad
5Départ/Pause (Start/Pause) touchpad
6Child lock indicator
7Départ Différé (Delay) touchpad
8Indicators: Filtre (Filter) ,
Condenseur (Condenser) , Bac
plein (Tank)
6
Press the touch buttons with
your finger in the area with the
symbol or name of the option.
Do not wear gloves when you
operate the control panel.
Make sure that the control
panel is always clean and dry.
PROGRAMME TABLE
Programmes Type of load Load (max.)
1)
/
Fabric mark
2)
Coton (Cotton)
Eco
Cycle to be used to dry cotton with "cotton
cupboard" dryness level, with maximum en‐
ergy saving. 7kg/
Coton (Cotton) Cycle defined to dry all types of cotton ready
to store (cupboard dry). 7kg/
Synthétiques (Synthet‐
ic) Synthetic and mixed fabrics. 3,5kg/
Mixtes (Mix)
Cotton and synthetic fabrics. Low tempera‐
ture programme. Delicate programme with
warm air. 3kg/
Facile à Repasser+
(Easy Iron+)
Easy care fabrics for which a minimum of
ironing is necessary. The drying results can
be different from one type of fabric to anoth‐
er. Shake the items before putting them in
the appliance. When the programme has
ended, immediately remove the items and
put them on a hanger.
1kg (or 5
shirts)/
Couette (Duvets) Single or double duvets and pillows (with
feather, down or synthetic fillings). 3kg/
Rafraîchir (Refresh) Refreshing textiles that were in storage. 1kg
Minuterie 30' (Time 30
min)
Time programme to dry individual items of
laundry. 1kg/
1) The maximum weight refers to dry items.
2) The Coton (Cotton) Prêt à Ranger (Cupboard Dry) ECO programme is the “Standard cotton programme”
according to Commission Regulation EU No. 392/2012. It is suitable for drying normal wet cotton laundry and it is
the most efficient programme in terms of energy consumption for drying wet cotton laundry.
7
OPTIONS
Séchage (Dryness)
This function helps to get the laundry
more dried. There are 4 possible
selections:
• Extra Sec (Extra Dry)
• Très Sec (Strong Dry) (for Cotton
only)
• Prêt à Ranger (Cupboard Dry)
• Prêt à repasser (Iron Dry)
Anti-froissage 90' (Anticrease
90')
Extends the anti-crease phase by 60
minutes at the end of the drying cycle.
This function reduces creases. The
laundry can be removed during the anti-
crease phase.
Anti-froissage 60' (Anticrease
60')
Extends of 30 minutes the standard
anticrease phase (30 minutes) at the end
of the drying cycle. This function prevents
the laundry from creases. The laundry can
be removed during the anticrease phase.
Minuterie 60' (Time 60 min)
Extends of 30 minutes the Minuterie 30'
(Time 30 min) programme.
Options table
Programmes
Anti-
frois‐
sage
90'
(Anti‐
creas
e 90')
Anti-
frois‐
sage
60'
(Anti‐
creas
e 60')
Mi‐
nute‐
rie 60'
(Time
60
min)
Coton
(Cotton) Eco ■ ■ ■
Coton (Cotton) ■ ■ ■ ■ ■ ■
Synthétiques
(Synthetic) ■ ■ ■ ■ ■
Mixtes (Mix) ■ ■ ■
Facile à Re‐
passer+ (Easy
Iron+)
■ ■ ■
Couette (Du‐
vets) ■
Rafraîchir (Re‐
fresh) ■ ■
Minuterie 30'
(Time 30 min) ■ ■ ■
8
SETTINGS
A B C D FE
A. On / Off button
B. Programme selection touchpad
C. Dryness selection touchpad
D. Options selection touchpad
E. Départ/Pause (Start/Pause) touchpad
F. Départ Différé (Delay) touchpad
Child lock function
This option prevents children to play with
the appliance while a programme
operates. The programme knob and the
touchpads are locked.
Only the on/off button is unlocked.
Activating the child lock option:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold touchpads (C) and (D)
at the same time. The child lock
indicator comes on.
The child lock indicator comes on.
It is possible to deactivate the
child lock option while a
programme operates. Press
and hold the same touchpads
until the child lock indicator
goes off.
Buzzer on/off
To deactivate or activate the acoustic
signals, press and hold for approximately
2 seconds touch buttons (B) and (C) at
the same time.
Adjustment of the remaining
laundry moisture degree
To change the default degree of the
remaining moisture of the laundry:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold buttons (B) and (D) at
the same time.
One of the these indicators comes on:
• Bac plein (Tank) - the maximum
dry laundry
• Filtre (Filter) - the more dry
laundry
• Condenseur (Condenser) - the
standard dry laundry
4. Press the button (E) again and again
until the indicator of the correct level
comes on.
5. To confirm the adjustment, press and
hold buttons (B) and (D) at the same
time for approximately 2 seconds.
BEFORE FIRST USE
Before you use the appliance for the first
time:
• Clean the tumble dryer drum with a
moist cloth.
• Start a 1 hour programme with moist
laundry.
9
At the beginning of the drying
cycle (first 3-5 min) there could
be a slightly higher sound level.
This is due to the compressor
starting up. This is normal for
compressor powered
appliances such as
refrigerators and freezers.
DAILY USE
Start a programme without
delay start
1. Prepare the laundry and load the
appliance.
CAUTION! Make sure that
when you close the door,
the laundry does not get
caught between the
appliance door and the
rubber seal.
2. Press the on/off button to activate the
appliance.
3. Set the correct programme and
options for the type of load.
4. Press the Départ/Pause (Start/Pause)
touch button.
The programme starts.
Starting the programme with
delay start
1. Set the correct programme and
options for the type of load.
2. Press the delay start button again and
again as necessary.
You can delay the start of a
programme by 3, 6 or 9
hours.
3. Press the Départ/Pause (Start/Pause)
button.
The LEDs (9H, 6H, 3H) change on each 3
hours.
Change a programme
1. Press the on/off button to deactivate
appliance
2. Press the on/off button to activate the
appliance.
3. Set the programme.
At the end of the programme
When the programme is completed:
• An intermittent acoustic signal
operates.
• The indicators Filtre (Filter) and Bac
plein (Tank) comes on.
• The Départ/Pause (Start/Pause)
indicator is on.
The appliance continues to operate with
the crease guard phase for approximately
other 30 minutes.
The crease guard phase prevents creases
from your laundry.
You can remove the laundry before the
crease guard phase is completed. We
recommend, for better results, that you
remove the laundry when the phase is
almost completed.
When the crease guard phase is
completed:
• The indicators Filtre (Filter) and Bac
plein (Tank) comes on.
• Départ/Pause (Start/Pause) indicator
goes off.
1. Press the on/off button to deactivate
the appliance.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
10
Table des matières
Langues :
Autres manuels FUST Séchoir
FUST
FUST PRIMOTECQ TA 506 E Manuel utilisateur
FUST
FUST PRIMOTECQ TW730E Manuel utilisateur
FUST
FUST NOVAMATIC TK 816 E Instructions d'utilisation
FUST
FUST PRIMOTECQ TA 507 E Manuel utilisateur
FUST
FUST NOVAMATIC TW740E Manuel utilisateur
FUST
FUST Novamatic TW 7757 Manuel utilisateur
FUST
FUST NOVAMATIC TW 748 E Manuel utilisateur
Manuels Séchoir populaires d'autres marques
Indesit
Indesit IDV 75 Manuel utilisateur
Infiniton
Infiniton SD-DG85C Manuel utilisateur
BOMANN
BOMANN WT 5019 Manuel utilisateur
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manuel utilisateur
Asko
Asko T793C Manuel utilisateur
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
