Furuno ETR-30N Manuel utilisateur

NETWORK SOUNDER

ETR-30N

SAFETY INSTRUCTIONS

WARNING

Turn off the power at the switchboard

before beginning the installation.

Fire or electrical shock can result if the

power is left on.

Do not install the equipment where it

may get wet from rain or water splash.

Water in the equipment can result in fire,

electrical shock or damage to the equipment.

Be sure no water leaks in at the trans-

ducer mounting location.

Water leakage can sink the vessel. Also,

confirm that the transducer will not loosen

by ship's vibration. The installer of the

equipment is solely responsible for the

proper installation of the equipment.

FURUNO will assume no responsibility for

any damage associated with improper

installation.

Be sure that the power supply is

compatible with the voltage rating of

the equipment.

Connection of an incorrect power supply

can cause fire or damage the equipment.

Do not diassemble or modify the

equipment.

Electrical shock, damage to the equipment

or injury may result.

ELECTRICAL SHOCK HAZARD

Do not open the equipment

unless totally familiar with

electrical circuits and

service manual.

Only qualified personnel

should work inside the

equipment.

WARNING

Install the transducer tank according

to the installation instructions.

Failure to install the tank correctly may

result in water leakage and damage to

the ship's hull.

The transducer cable must be handled

carefully, following the guidelines

below.

•Keep fuels and oils away from the

cable.

•Locate the cable where it will not be

damaged.

•The cable sheath is made of chloro-

phrene or polychloride vinyl, which

is easily damaged by plastic solvents

such as toulene. Locate the cable

well away from plastic solvents.

Use the correct fuse.

Use of a wrong fuse can cause serious

damage to the equipment.

Be sure to enter transducer model

correctly.

Incorrect setting may damage the

transducer.

Do not enter transducer type manually

if the transducer type is programmed

into the equipment.

Damage to the transducer may result.

WARNING LABEL

A warning label is attached to the equip-

ment. Do not remove the label. If the

label is missing or illegible, contact

a FURUNO agent or dealer about

replacement.

WARNING

To avoid electrical shock, do not

remove cover. No user-serviceable

parts inside.

Name: Warning Label (1)

Type: 86-003-1011-1

Code No.: 100-236-231

Observe the following compass safe

distances to prevent interference to a

magnetic compass:

Ground the equipment to

prevent mutual interference.

Do not allow warm water or any liquid

other than seawater or freshwater to

contact the transducer.

Damage to the transducer may result.

Do not install the transducer where

noise or air bubbles is present.

Performance will be affected.

Standard

compass

Steering

compass

ETR-30N

1.7 m 1.1 m

CAUTION CAUTION

iii

TABLE OF CONTENTS

SYSTEM CONFIGURATION................................................................................ iv

EQUIPMENT LISTS............................................................................................. vi

1. MOUNTING ...................................................................................................... 1

1.1 Network Sounder.............................................................................................................1

1.2 Transducer......................................................................................................................2

2. WIRING, SETUP...............................................................................................3

2.1 Wiring..............................................................................................................................3

2.2 Settings for Single Network Sounder...............................................................................6

2.3 Settings for Two Network Sounders...............................................................................12

2.4 Erasing Transducer Setting...........................................................................................15

3. OPERATION, MAINTENANCE...................................................................... 16

3.1 Controls.........................................................................................................................16

3.2 Additions to NavNet Series Operator’s Manual..............................................................17

3.3 Replacing Fuses ...........................................................................................................18

3.4All Clear.........................................................................................................................19

APPENDIX NEW BLT TRANSDUCERS ........................................................AP-1

SPECIFICATIONS........................................................................................... SP-1

PACKING LIST ................................................................................................. A-1

OUTLINE DRAWINGS...................................................................................... D-1

INTERCONNECTION DIAGRAM ......................................................................S-1

SYSTEM CONFIGURATION

Single network sounder

: Standard

: Option

: Local Supply

Transducer Transducer

High

Freq.

* = By using a hub, one NavNet series radar and three NavNet display units may be connected.

Low

Freq.

Network Sounder

ETR-30N

NavNet

Radar

Display Unit

NavNet

Radar

Display Unit

NavNet

Display Unit

Ship’s Mains

12-24 VDC

Rectifier

PR-62

100/110/115/220/230 VAC,

φ,

50/60 Hz

HUB*

NavNet Series

NavNet

Display Unit

NavNet

Display Unit

System configuration, single network sounder

Multiple network sounders

Network Sounder

ETR-30N

NavNet

Radar

Display Unit

NavNet

Display Unit

: Standard

: Optional Supply

: Local Supply

HUB*1

NavNet Series

*1 = By using a hub, one NavNet series radar and two NavNet display units may be connected.

*2 = Maximum two network sounders may be installed.

*3 = Connect to NET KP.

NavNet

Display Unit

Network Sounder

ETR-6/10N*2

System configuration, two ETR-30N

Network Sounder

ETR-30N

NavNet

Radar

Display Unit

NavNet

Display Unit

: Standard

: Optional Supply

: Local Supply

HUB*

NavNet Series

* = By using a hub, one NavNet series radar and two NavNet display units may be connected.

NavNet

Display Unit

Network Sounder

ETR-6/10N

System configuration, ETR-30N + ETR-6/10N

EQUIPMENT LISTS

Standard supply

Name Type Code No. Qty Remarks

Network

Sounder ETR-30N —

Spare Parts* SP02-04601 002-180-150 1 set

CP02-07100

(

w/NavNet

connection

cable)

— • Power Cable

MJ-A3SPF0013-035

• NavNet connection cable

MJ-A6SPF0014-050 (5 m)

• CP02-07101

Installation

Materials*

CP02-07110

(No NavNet

connection

cable)

— 1 set • Power Cable

MJ-A3SPF0013-035

• CP02-07101

* = See packing list at end of manual.

Optional supply

Name Type Code No. Remarks

Piggyback

Mount Kit OP02-84 002-186-170 For mounting two network

sounders piggyback style

MJ-A6SPF0014-010 000-144-421 6P-6P, 1 m, For NavNet

MJ-A6SPF0014-050 000-144-422 6P-6P, 5 m, For NavNet

MJ-A6SPF0014-100 000-144-423 6P-6P, 10 m, For NavNet

MJ-A6SPF0014-200 000-144-424 6P-6P, 20 m, For NavNet

MJ-A6SPF0014-300 000-144-425 6P-6P, 30 m, For NavNet

MJ-A6SRMD/TM11AP8-005 000-144-463 For HUB

NCS255AD-254P-L500 000-142-518 For connection of

combination transducers

Cable Assy.

MJ-A7SPF0002-050 000-127-656 For connecting ETRs

000-013-484 100 VAC

000-013-485 110 VAC

000-013-486 220 VAC

Rectifier PR-62

000-013-487 230 VAC

Transducer See the next several pages for transducer and recommended thru-hull pipe

and tank.

vii

Available transducers

1kW transducer

Freq.

(kHz) Ship Transducer Thru-hull pipe Tank

Steel — —

FRP

28F-8 (000-015-003)

50B-6 (000-015-042)

50B-6B (000-015-043, 15M)

(000-015-018, 30M)

(000-015-255, 40M) — —

Steel TWB-6000 (2)

(000-015-207) T-656

(000-015-982)

FRP

28F-8 (000-015-003)

50B-9 (000-138-574)

50B-9B (000-015-065) — —

Steel — —

28/50

FRP 28F-8 (000-015-003)

50F-8G (000-015-066) — —

Steel — —

28/68 FRP 28F-8 (000-015-003)

68F-8H (000-015-067) — —

Steel TWB-6000 (2)

(000-015-207) T-657

(000-015-983)

28/88 FRP

28F-8 (000-015-003)

88B-8 (000-015-024) — —

Steel — —

28/200 FRP 28F-8 (000-015-003)

200B-5S (000-015-029) — —

Steel — —

FRP

50B-6 (000-015-042)

50B-6B (000-015-043, 15M)

(000-015-018, 30M)

(000-015-255, 40M)

88B-8 (000-015-024) — —

Steel TWB-6000 (2)

(000-015-207) T-658

(000-015-984)

FRP

50B-9 (000-138-574)

50B-9B (000-015-065)

88B-8 (000-015-024) — —

Steel — —

50/88

FRP 50F-8G (000-015-066)

88B-8 (000-015-024) — —

viii

1kW transducer (con’t)

Freq.

(kHz) Ship Transducer Thru-hull pipe Tank

Steel — —

FRP

50B-6 (000-015-042)

50B-6B (000-015-043, 15M)

(000-015-018, 30M)

(000-015-255, 40M)

200B-5S

(

000-015-029

)

— —

Steel — —

FRP

50B-9 (000-138-574)

50B-9B (000-015-065)

200B-5S (000-015-029) — —

Steel — —

FRP 50F-8G (000-015-066)

200B-5S (000-015-029) — —

Steel — —

FRP 50/200-1T (000-015-170) — —

Steel — —

50/200

FRP 50/200-1ST (000-015-110) — —

Steel — —

68/200 FRP 68F-8H (000-015-067)

200B-5S (000-015-029) — —

Steel — —

88/200 FRP 88B-8 (000-015-024)

200B-5S (000-015-029) — —

2kW transducer

Freq.

(kHz) Ship Transducer Thru-hull pipe Tank

Steel TFB-7000 (2)

(000-015-209) T-634

(000-015-810)

28/50

FRP

28F-18 (000-015-004, 15M)

(000-138-573, 30M)

50B-12 (000-015-020) — —

Steel — —

28/68 FRP

28F-18 (000-015-004, 15M)

(000-138-573, 30M)

68F-30H (000-015-073) TRB-1100 (2)

(000-015-218) T-634-F

(000-015-811)

Steel TFB-7000 (2)

(000-015-209) T-636

(000-015-813)

28/88 FRP

28F-18 (000-015-004, 15M)

(000-138-573, 30M)

88B-10 (000-015-025) TRB-1100 (2)

(000-015-218) T-636-F

(000-015-814)

Steel TFB-7000 (2)

(000-015-209) T-638

(000-015-818)

28/200

FRP

28F-18 (000-015-004, 15M)

(000-138-573, 30M)

200B-8 (000-015-030)

200B-8B (000-015-032)

200B-8N (000-015-045) TRB-1100 (2)

(000-015-218) T-638-F

(000-015-819)

Steel TFB-7000 (2)

(000-015-209) T-643

(000-015-821)

50/88 FRP

50B-12 (000-015-020)

88B-10 (000-015-025) TRB-1100 (2)

(000-015-218) T-643-F

(000-015-822)

Steel TFB-7000 (2)

(000-015-209) T-645

(000-015-826)

FRP

50B-12 (000-015-020)

200B-8 (000-015-030)

200B-8B (000-015-032)

200B-8N (000-015-045) — —

Steel TWB-6000 (2)

(000-015-207) T-693

(000-015-044)

50/200

FRP

50BL-12 (000-015-246)

200B-8B (000-015-032) TRB-1100 (2)

(000-015-218) T-693-F

(000-015-241)

Steel TFB-7000 (2)

(000-015-209) T-647

(000-015-831)

68/200

FRP

68F-30H (000-015-073)

200B-8 (000-015-030)

200B-8B (000-015-032)

200B-8N (000-015-045) TRB-1100 (2)

(000-015-218) T-647-F

(000-015-832)

Steel TFB-7000 (2)

(000-015-209) T-649

(000-015-833)

88/200

FRP

88B-10 (000-015-025)

200B-8 (000-015-030)

200B-8B (000-015-032)

200B-8N (000-015-045) TRB-1100 (2)

(000-015-218) T-649-F

(000-015-834)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Furuno Équipement marin

Furuno

Furuno TZTL15F Manuel

Furuno

Furuno FRS-1000 Manuel

Furuno

Furuno FCV-295 Manuel utilisateur

Furuno

Furuno MD-550 Manuel utilisateur

Furuno

Furuno FELCOM 70 Manuel utilisateur

Furuno

Furuno GP-1810F Manuel utilisateur

Furuno

Furuno LS-6000 Manuel utilisateur

Furuno

Furuno NAVNET 3D MFDBB Instructions de montage

Furuno

Furuno FCV-780/782 Manuel utilisateur

Furuno

Furuno Sc 50 Manuel

Furuno

Furuno FA-170 Manuel

Furuno

Furuno FELCOM19 Inmarsat Mini-C MES Manuel utilisateur

Furuno

Furuno FMD-3200-BB Manuel utilisateur

Furuno

Furuno FE-700 Guide de démarrage rapide

Furuno

Furuno IF-7000 Manuel utilisateur

Furuno

Furuno FCV-665 Manuel utilisateur

Furuno

Furuno FE-800 Manuel utilisateur

Furuno

Furuno FEA-2807 Manuel utilisateur

Furuno

Furuno RD-33 Manuel utilisateur

Furuno

Furuno BBWX4 SiriusXM Guide d'installation

Furuno

Furuno felcom15 Manuel utilisateur

Furuno

Furuno TECDIS Manuel utilisateur

Furuno

Furuno CI-80 Manuel utilisateur

Furuno

Furuno ED-222 Manuel utilisateur

Manuels Équipement marin populaires d'autres marques

Clarion

Clarion CMS2 Manuel de réparation

EBS

EBS M7000 Manuel utilisateur

Kongsberg

Kongsberg M3 Bathy Manuel utilisateur

NPK

NPK SCS-1002 Manuel utilisateur

Harken

Harken 1561 Manuel utilisateur

Simrad

Simrad DD15 Manuel utilisateur

Notifier

Notifier FS-BSO Manuel utilisateur

Raymarine

Raymarine ST40 Manuel utilisateur

E2S

E2S E2XS112UL Manuel utilisateur

R2Sonic

R2Sonic 2026 Manuel utilisateur

COBHAM

COBHAM SAILOR 6000 Manuel utilisateur

Clarion

Clarion GR10BT Manuel de réparation

Raymarine

Raymarine Maxiview ST80 Guide de l'utilisateur

GUIDANCE MARINE

GUIDANCE MARINE 20- Series Instructions de montage

Raymarine

Raymarine ST60 Tridata Guide de l'utilisateur

olympia electronics

olympia electronics ΒS-531/1/MAR Manuel utilisateur

Sonic

Sonic 2024 Manuel utilisateur

Quicksilver

Quicksilver 88688A25 Manuel
