Owner’s Manual

For The Fuller Brush

BARE FLOOR Maid Vacuum

Thank you for purchasing this

Fuller Brush Broom Vacuum.

To ensure the best results, please read this

manual and keep it for reference.

Model

FB-BFM

Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2

Two-Wire Polarized Cord � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Parts Identification � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4

Replacement Filter & Microfiber Polishing Pads � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4

How to Assemble the Vacuum � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5-6

How to Operate the Vacuum � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7

How to Empty the Dust Cup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8

How to Replace the Filter� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9

Maintenance and Care� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10

Troubleshooting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11

For Best Performance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11

Warranty � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12

The model and serial numbers of this product may be found on the back side of the unit� You should register your

vacuum online at www�FullerBrushVacuums�com as soon as possible for your protection� Also, note the model and serial

numbers of your unit in the spaces provided below, and retain this book as a permanent record of your purchase�

Model Number _____________________________________________________________________________________

Serial Number ______________________________________________________________________________________

Date Purchased _____________________________________________________________________________________

Your Fuller Brush vacuum cleaner is a product of high-quality materials and superior workmanship� We urge you to

read these operating instructions carefully before you use this vacuum cleaner in order to obtain the full performance and

satisfaction it can offer you�

Before you plug in your Fuller Brush vacuum cleaner, make sure the voltage indicated on the rating plate located on the

back of the vacuum is the same as your local supply�

Index

Customer’s Record

Save These Instructions

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the

following:

READ ALL INSTRUCTIONS BEFORE

USING THIS APPLIANCE

The manufacturer cannot accept responsibility for damage caused

when the appliance is not used according to the

instructions, or for uses other than those for which it

was intended.

To reduce the risk of fire, electric shock or injury:

• Do not leave appliance when plugged in.

Unplug from outlet when not in use and

before servicing.

• WARNING: ELECTRIC SHOCK COULD OCCUR IF

USED OUTDOORS OR ON WET SURFACES.

• Do not allow to be used as a toy. Close

attention is necessary when used by or near

children.

• Use only as described in this manual. Use only

manufacturer’s recommended attachments.

• Do not use with damaged cord or plug. Or if

appliance is not working as it should, has been

dropped, damaged, left outdoors, or dropped

into water.

• Do not pull or carry by cord, use cord as a

handle, close a door on the cord, or pull cord

around sharp edges or corners. Do not run

appliance over cord. Keep cord away from

heated surfaces.

• Do not unplug by pulling on cord. To unplug,

grasp the plug, not the cord.

• Do not handle plug or appliance with

wet hands.

• Do not put any object into openings. Do not

use with any opening blocked; keep free of

dust, lint, hair and anything that may reduce

air ﬂow.

• Keep hair, loose clothing, ﬁngers and all parts

of body away from openings and moving

parts.

• Do not pick up anything that is burning or

smoking, such as cigarettes, matches or hot

ashes.

• Do not use without ﬁlters in place.

• Turn oﬀ all controls before unplugging.

• Do not use to pick up ﬂammable or

combustible liquids such as gasoline or use in

areas where they may be present.

• Do not attempt to service the unit while

appliance is plugged in.

• Do not use vacuum to pick up water or any

wet materials.

• Use extra care when cleaning on stairs.

SAVE THESE INSTRUCTIONS.

WARNING:

Two-Wire Polarized Cord

To reduce the risk of electric shock, this product is equipped with a polarized alternating

current line plug (a plug having one blade wider than the other). This plug will fit into

the power outlet only one way. This is a safety feature. If you are unable to insert the

plug fully into the outlet, try reversing the plug. If the plug still does not fit, contact a

qualified electrician to replace the obsolete outlet. Do not defeat the safety purpose of

the polarized plug.

State of California Proposition 65 Warnings:

WARNING: This product contains one or more chemicals known to the State of California to

cause cancer.

WARNING: This product contains one or more chemicals known to the State of California to

cause birth defects or other reproductive harm.

Two-Wire Polarization Instructions

• Genuine Fuller Brush High Flow Filter

Part # FBQM-HFF

• Genuine Fuller Brush Microfiber Polishing Pads

Part # BFM-P

Parts Identification

Replacement Filters & Polishing Pads

On/Off

Button

Floor

Nozzle

Dust Cup Release Button

(to remove dust cup from

the vacuum)

Dust Cup

Handle

Power Cord

Cord Hooks

Main Body

Microfiber

Polishing Pad

Attaching the Handle

With the On/Off button facing the front of

the vacuum, insert the handle into the top

of the vacuum until it clicks into place (Fig. 1).

Attaching the Dust Cup Assembly

Line up the bottom of the dust cup with the base

of the vacuum. Then push the top of

the dust cup into the vacuum until it clicks

into place (Fig. 2).

Removing the Dust Cup Assembly

Push the dust cup release button and

remove the dust cup assembly from the

vacuum (Fig. 3).

How to Assemble the Vacuum

Fig. 1

Installation and removal of dust cup component

When dust cup is installed, please firstly check whether internal parts

of dust cup component are installed completely or not. Missed

installation should be avoided. Please firstly align to clamp at the

bottom of dust cup during installation. After the bottom of dust cup is

correctly aligned, dust cup component can be directly pulled into main

body, and reliable assembly can be ensured after locking sound is

heard.

If dust cup is should be removed, dust cup release button should be

pressed, and the dust cup should be removed according to direction in

the drawing.

Fig. 2

Installation and removal of dust cup component

When dust cup is installed, please firstly check whether internal parts

of dust cup component are installed completely or not. Missed

installation should be avoided. Please firstly align to clamp at the

bottom of dust cup during installation. After the bottom of dust cup is

correctly aligned, dust cup component can be directly pulled into main

body, and reliable assembly can be ensured after locking sound is

heard.

If dust cup is should be removed, dust cup release button should be

pressed, and the dust cup should be removed according to direction in

the drawing.

Fig. 3

Fig. 1

Fig. 2

How to Assemble the Vacuum

Attaching the Floor Nozzle

Place the floor nozzle on the floor with the neck

locked in the upright position. Line up the neck of

the floor nozzle with the inlet at the base of the

vacuum. Push until it clicks into place (Fig. 1).

Removing the Floor Nozzle

Press the metal button at the base of the vacuum

with a screw driver or other pointed tool. Then

remove the floor nozzle from the inlet (Fig. 2).

Attaching the Power Cord

Attach the cord to the clip on the back of the

handle, then wrap the cord around the upper

and lower cord hooks (Fig. 3).

Unwinding the Power Cord

The upper cord hook rotates to allow for quick

access to the power cord. Turn the upper cord

hook downward and you can quickly drop the

power cord to the floor without unwinding it from

the cord hooks.

When storing the vacuum cleaner, turn the upper

cord hook to the upright position and wrap the

power cord around the cord storage hooks (Fig. 4).

Fig. 4

Fig. 3

On/Off Button

Push the power button on the handle

(Fig. 1) to turn on the vacuum. Press the

power button again to turn off the vacuum.

Reclining the Vacuum

Place your foot on the top of the floor

nozzle and pull the handle toward you

(Fig. 2).

Vacuuming Rugs

The Bare Floor Maid is designed to sweep

and polish your bare floors in one easy step

thanks to the strong vacuum suction and

microfiber polishing pad. This microfiber

polishing pad prevents the vacuum from

gliding over rugs or carpet. Remove the

microfiber polishing pad from the bottom of

the floor nozzle to vacuum rugs or low pile

carpet (Fig. 3).

Fig. 1

Fig. 2

Fig. 3

How to Operate the Vacuum

WARNING: Empty the dust cup after each use

or before the contents reach the “MAX FILL”

line on the dust cup. Over-filling the dust cup

may cause dirt and debris to clog the filter and

cause loss of suction.

• Remove the dust cup from the vacuum by

pressing the dust cup release button on top of

the dust cup (Fig. 1).

• Remove the filter assembly by pulling it up

and out of the dust cup (Fig. 2).

• Tip the dust cup upside down over a trash

can to empty contents.

• Replace the filter assembly by lining up the

notches on the filter and the dust cup and

pushing straight down (Fig. 3).

• Replace the dust cup onto the vacuum body

and resume vacuuming (Fig. 4).

Installation and removal of dust cup component

When dust cup is installed, please firstly check whether internal parts

of dust cup component are installed completely or not. Missed

installation should be avoided. Please firstly align to clamp at the

bottom of dust cup during installation. After the bottom of dust cup is

correctly aligned, dust cup component can be directly pulled into main

body, and reliable assembly can be ensured after locking sound is

heard.

If dust cup is should be removed, dust cup release button should be

pressed, and the dust cup should be removed according to direction in

the drawing.

Installation and removal of dust cup component

When dust cup is installed, please firstly check whether internal parts

of dust cup component are installed completely or not. Missed

installation should be avoided. Please firstly align to clamp at the

bottom of dust cup during installation. After the bottom of dust cup is

correctly aligned, dust cup component can be directly pulled into main

body, and reliable assembly can be ensured after locking sound is

heard.

If dust cup is should be removed, dust cup release button should be

pressed, and the dust cup should be removed according to direction in

the drawing.

Fig. 1

Fig. 4

Fig. 2

Fig. 3

How to Empty the Dust Cup

Table des matières

Autres manuels Fuller Brush Aspirateur

Fuller Brush

Fuller Brush Mighty Maid FBMM-1T Manuel utilisateur

Fuller Brush

Fuller Brush FBP-14PW Manuel utilisateur

Fuller Brush

Fuller Brush Mighty Maid FBMM-1T Manuel utilisateur

Fuller Brush

Fuller Brush FB-SPDM Manuel utilisateur

Fuller Brush

Fuller Brush Nifty Maid FB-NFM Manuel utilisateur

Fuller Brush

Fuller Brush FB-SPFM Manuel utilisateur

Fuller Brush

Fuller Brush FB-SM Manuel utilisateur

Fuller Brush

Fuller Brush FB500 Manuel utilisateur

Fuller Brush

Fuller Brush Tidy Maid FBTM-PW Manuel utilisateur

Fuller Brush

Fuller Brush FBP-12PW Manuel utilisateur

Fuller Brush

Fuller Brush FB-JFM Manuel utilisateur

Fuller Brush

Fuller Brush FB-DCC Manuel utilisateur

Fuller Brush

Fuller Brush FB-GIM Manuel utilisateur

Fuller Brush

Fuller Brush Mini Maid FBMV Manuel utilisateur

Fuller Brush

Fuller Brush SPIFFY Maid FB-SPFM.2 Manuel utilisateur

Fuller Brush

Fuller Brush FB-PM Manuel utilisateur

Fuller Brush

Fuller Brush FB-QM Manuel utilisateur

Fuller Brush

Fuller Brush FB-EZM Manuel utilisateur

Fuller Brush

Fuller Brush FB-HM Manuel utilisateur

Fuller Brush

Fuller Brush FB-JFM Jiffy Maid Manuel utilisateur

Fuller Brush

Fuller Brush FB-NFM Manuel utilisateur

Fuller Brush

Fuller Brush FB-JFM Jiffy Manuel utilisateur

Fuller Brush

Fuller Brush Tidy Maid FBTM-PW Manuel utilisateur

Fuller Brush

Fuller Brush FBPT-2 Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
