FULGOR FM36CDFDS1 Manuel utilisateur
FM36CDFDS1
Thank you for choosing Fulgor Milano .This manual contains all the information
you will need to safely and correctly use your refrigerator. Please read all the
instructions prior to using the appliance and keep this manual in a secure place
for future reference. Do not remove the attached adhesive identification label
containing code, model number, manufacturer and other information from the
refrigerator. This label will be used by the authorized serviceFulgor Milano
representative in the event that your refrigerator needs servicing.
Welcome to the world of
simple handling and no worries
Environmental advice
The packaging material used is recyclable; we recommend that you separate
plastic, paper and cardboard and give them to recycling companies. To help
preserve the environment, the refrigerant used in this product is R134a
(Hydrofluorocarbon - HFC), which does not affect the ozone layer and has little
impact on the greenhouse effect.
. If you need to dispose of this appliance in the
future, do NOT throw it away with the rest of your domestic garbage. Remove
01
the doors and drawers and cut the power cord and recycle in accordance with
local ordinances.
Contents
Safety.........................................................................................................03
Product Description...................................................................................05
Installation........................... ...............................................................07........
Door Handles....................................... ................................................17.. ...
Making Minor Adjustments between doors................................................18
Installing the water line..............................................................................19
Operation...................................................................................................21
Cleaning and Maintenance.......................................................................25
Solutions to Problems.............................................................................. 26
The refrigerator you have just purchased may be slightly different from the one shown in
the drawings in this manual, but its overall design intent is the same.
Please read the information referring to its operation.This refrigerator is intended for
domestic use only.
The plug on the refrigerator you have purchased may be different from the one shown in
the manual, as the plug that accompanies the product meets your country's electrical
specifications.
02
Attention
Please keep children from entering or climbing the refrigerator to avoid locking the
children inside the refrigerator and hurting them should the refrigerator tip over due
to their weight.
Be mindful of children's whereabouts when closing and opening doors and drawers
to avoid injuries to probing hands and fingers.
Children should be supervised to ensure that they do not play with the appliance.
Never pull out the plug by pulling the power cable. Always hold the plug and pull it
out from the socket. Don't have the power cable pinched under the refrigerator or
feet. When the refrigerator is moved away from the wall, never pinch or damage
the power cable. If the power cable is damaged or the plug is worn, don't use
it anymore.You must have the damaged cable replaced by an authorized service
technician. Any repairs made by unauthorized persons will void the warranty.
When coal gas or other inflammable gases are leaked, close the valve for leaking
gases. Open the door and windows. Don't pull out or insert the plug of refrigerator
or other electric appliances.
Don't put inflammable, explosive, volatile or strongly corrosive substances into
the refrigerator to avoid damaging the refrigerator or starting fire or other
Don't use inflammable solvent near the refrigerator to avoid injury due to freezing.
It is advisable that you don't put the power socket, voltage stabilizer, microwave
oven and other electric appliances on top of refrigerator to ensure safety. Don't
appliances inside the refrigerator (except for the model
recommended) to avoid electromagnetic interference or other accidents.
When the refrigerator starts to work, don't touch the cold surface of the freezer
compartment, especially with wet hands, to avoid injury due to freezing.
The gap between doors and between the door and refrigerator body is small.
Don't put your hands into these areas to avoid pinching.
spray water onto or rinse the refrigerator with water. Don't put the
refrigerator in wet or places exposed to water spray so as not to compromise
the electric insulation property of the refrigerator.
Don't disassemble or modify the refrigerator by yourself. Never damage the
refrigeration tubing or components. Please get the refrigerator repaired by
professionals.
Safety
For children
For the user
accidents.
use any electric
Don't
03
Don't put fluid in bottles or sealed containers into the freezer,such as
bottled beer or drinks to avoid the containers cracking or exploding and
During a power outage or cleaning, pull out the plug.
Wait at least 5 minutes
after cutting the power before restarting to allow the refrigeration system to
equilize as immediate
startup might damage the compressor
When the refrigerator is out of service, please remove the refrigerator's doors
and drawers, remove the door seal and shelves and dispose of them appropriately
to avoid that children might play inside and become trapped or injured.
This product is a household refrigerator and is only suitable for storage of food
according to applicable standards. It can't be used for other purposes, like storage
of blood, drugs, biological products, etc.
04
potentially causing damage to other contents or the appliance.
Product description
Left door for refrigerator compartment
Upper drawer for freezer compartment
Lower drawer for freezer compartment
Right door for refrigerator compartment
Ice storage bin
Ice scoop
Partition plate for lower freezer drawer
Partition plate for upper freezer drawer
Upper freezer drawer
Lower freezer drawer
8
9
10
11
12
13
6
8
9
10
11
12
13
Refrigerator body
1Display
Door handle
Drawer handle
2
3
4
5
6
7
05
1
2
3
4
5
7
Rated Voltage/Frequency: 115V/60Hz
Rated Current: 2.7A
Total Storage Volume 20.8cu.ft/590L
Freezer Storage Volume: 6cu.ft/170L
Refrigerator Storage Volume: 14.8cu.ft/420L
Net Weight: 137kg
Gross Weight: 148kg
Product Dimensions: 911x728.5x1775mm
(without handle)
35.8x28.6x69.9in
1
Left door for refrigerator compartment
Cantilever shelf
French door sealing flap
Sliding cantilever shelf
Fruit and vegetable drawer
Water tank
Large drawer
Automatic ice maker
Drawer handle
Leveling leg
Switch for refrigerator compartment lamp
Top lamp for refrigerator compartment
Right door for refrigerator compartment
Butter box
Air duct cover plate
Folded cantilever shelf
Side lamp for refrigerator compartment
Gallon bottle shelf (with egg holder)
Light-wave freshness lamp
Specialty bottle shelf
Top lamp for freezer compartment
Upper door for freezer compartment
Lower door for freezer compartment
Decorative toe kick cover
2
3
8
9
10
4
5
6
7
11
12
13
14
15
20
21
22
16
17
18
19
23
24
1
2
3
4
5
6
7
8
9
10
11
12
15
17
13
14
16
18
19
20
21
22
23
24
0406
Remove all packaging material before
using the new refrigerator. This
includes the foam base and all
adhesive tape holding the refrigerator
accessories inside and outside.
Clean both the inside and outside of
the refrigerator with wet cloth (a little
detergent could be added into the
warm water to wash the cloth and
then wipe it again with the clean
water);
Prepare an independent three-pole
socket with grounding contact 115V
/60Hz for the refrigerator and it shall
not share a multi-purpose socket with
other electrical appliances.
Open the refrigerator body and take
out the accessory (decorative toe kick
cover ) and the three screws from the
instruction packaging bag; then install
them into the bottom beam as shown
by the schematic diagram on the right.
The decorative cover is non-functional
beam is used as ornament, so you
can choose not to install it. It won't
affect the refrigerator's performance
or conditions whether you install it or
not.
Installation
Transport and Placing of Your
Refrigerator
Transport
Keep upright and avoid squeezing or
vibration during transport. Avoid a
slant angle over 45 degree during
handling.
Avoid the door or top cap from being
under excessive stress when moving;
otherwise, it may become deformed.
07
Screws
Decorative toe kick cover for bottom beam
Do not remove grounding prong
from appliance cord or in any other
way adapt the cord to an ungrounded
receptacle.The receptacle must have
a reliable ground back to the service
panel.
Placement
Place your refrigerator in a well-
ventilated place and avoid proximity to
heat sources and direct sunlight. Don't
place it in any humid or wet place so
as to avoid rust and reduction to the
effectiveness of the insulation.
There must be a space not less than
1 inch from the top of your refrigerator
and not less than 1 inch from both
sides or the back of the refrigerator to
the adjacent walls respectively. This
requirement is necessary for door
clearance and proper ventilation.
The refrigerator must be placed on
solid, level flooring (if not flat, you
can use the leveling legs for
adjustment).
Keep Your Refrigerator Standing
If it was necessary at any point to lay
the appliance horizontal or tip beyond
a 45° angle, be sure to allow the
appliance to stand vertically for 24
hours prior to connecting to a power
supply to ensure all lubrication is
allowed to return to the compressor.
Make sure the power cord is not
pinched or pressured by the
refrigerator or other objects so as
to avoid accidents arising from power
wire faults or overheating due to
increased resistance in the cord.
Please ensure the power supply
matches the power requirements of
the appliance prior to connecting it
and switching it on.
08
Attention
The refrigerator must be disconnected
from the source of electrical supply
before attempting the installation of
any electrical accessories..
Don't use mechanical or heating
equipment or other methods to
accelerate the defrosting process except
the means recommended by the
manufacturer
Don't use any electrical appliances in
the food storage compartments except
any models recommended by the
manufacturer.
The cyclopentane foam insulation
blowing agent used in the refrigerator
is inflammable. All waste and discarded
refrigerators must not be exposed to
open flame.
09
Start Up
You must observe all safety
precautions and make sure that
your refrigerator has been placed
properly in its final position before
using.
1. Unpacking
Please install the decorative cover for
bottom beam onto your refrigerator
after unpacking and adjust the front
leveling legs to level your refrigerator.
2. Connecting Your Refrigerator to
the Power Supply
Your refrigerator will start in the
factory default state after connecting
to the power supply and it will display
the set temperatures for the refrigerator
compartment and freezer
compartment.
3.Operating Modes of Your Refrigerator
You can configure your refrigerator in either
of the following two ways:
Auto mode: we suggest you
choose this mode if you have no
special requirements. Your
refrigerator will work automatically
at the factory default settings.
Manual mode: You can set the
temperature by pressing the
temperature adjustment key.Refer to the
Tips: The interior temperature may
require a certain period of time to
reach balance if the setting
temperature is changed or other food
is put into the refrigerator. Such a
period of time depends on the change
to the setting temperature, the
surrounding temperature, opening
frequency, the amount of the stored
food and etc.
(Installation of this piece is optional
and exists only for aesthetic purposes)
section "Appliance Functions" later in this
manual for more details.
4. Put Food into Your Refrigerator
Depending on ambient conditions it
may take several hours for the cooling
and freezing compartments to reach
their set temperatures. Avoid adding
food to these compartments prior to
set temperatures being reached.
Table des matières
Langues :
Autres manuels FULGOR Réfrigérateur
FULGOR
FULGOR SOFIA PRO F7IRC30O1 Manuel utilisateur
FULGOR
FULGOR SOFIA PRO F7IRC36O1 Manuel utilisateur
FULGOR
FULGOR F7PBM36S2 Manuel utilisateur
FULGOR
FULGOR FBFD 351 NF ED Manuel utilisateur
FULGOR
FULGOR F7PBM36S1-L Manuel utilisateur
FULGOR
FULGOR SOFIA PRO F7SRC36S1 Manuel utilisateur
FULGOR
FULGOR FBCD 761 TNF EDBL Manuel utilisateur
