Fulgor Milano FBCD 362 NF ED Manuel utilisateur

ENGLISH Instructions for use Page 4

ITALIANO Istruzioni per l’uso Pagina 10

FRANÇAIS Mode d’emploi Page 16

ČESKY Návod k použití Strana 22

ESPAÑOL Instrucciones de uso Página 28

PORTUGUÊS Instruções de utilização Página 34

POLSKI Instrukcja obsługi Strona 40

РУССКИЙ Инструкции по пользованию прибором Страница 46

УКРАЇНСЬКАМОВА Інструкції з використання стор. 53

Always disconnect the appliance from the power supply before replacing the light bulb. Then

follow the instructions based on the type of light bulb for your product.

Replace the light bulb with one with the same features, available from the Technical Assistance

Service and authorised sellers.

Light type 1)

To remove the light bulb, unscrew it in an anti-clockwise direction, as

shown in the figure. Wait 5 minutes before reconnecting the appliance.

- traditional light bulb (max 25W)

- LED light bulb (with the same features)

only available from the Technical Assistance Service

Light type 2)

If the product has LED lights, as demonstrated in the figures below, contact the Technical

Assistance Service if you need a replacement.

LEDs last longer than traditional light bulbs, improve internal visibility and are environmentally-

friendly.

Clean the appliance occasionally with a cloth and a solution of warm

water and neutral cleaning agents specifically for cleaning the inside

of the refrigerator. Do not use abrasive cleaning agents. To ensure

the constant and correct flow of the defrosting water, regularly clean

the inside of the drain situated in the back wall of the refrigerator

compartment near the fruit and vegetable drawer using the utensil

provided (see figure).

Before carrying out any maintenance or cleaning, take the plug out of the socket or disconnect the

appliance from the power supply.

Connect the appliance to the power supply.

In models with electronics, a sound signal may be emitted, which means that the temperature

alarm has been activated: press the sound alarm off button. Where provided, position the

antibacterial anti-odour filter in the fan as demonstrated in the filter packaging.

Note: After turning the appliance on, you must wait for 4-5 hours for the correct storage

temperature to be reached for a normally filled appliance.

USING FOR THE FIRST TIME

MAINTENANCE AND CLEANING

OF THE APPLICANCE

REPLACING THE LIGHT BULB OR LED

(depending on the model)

Light bulb

LED light bulb

LED- strip

Dragon

et2

Disconnect the appliance from the power supply, empty it, defrost it (if necessary) and clean it.

Keep the doors slightly ajar to let air circulate inside the compartments. By doing this, you avoid

the development of mould and bad odours.

IN THE EVENT OF NON-USE

OF THE APPLICANCE

Keep the doors closed so the food stays cold for as long as possible. Do not re-freeze food that

has partially defrosted. If there is a prolonged power cut, the black out alarm may also activate

(in products with electronics).

IN THE EVENT OF AN INTERRUPTION TO

THE POWER SUPPLY

The refrigerator compartment allows for the storage of fresh food and drink.

The refrigerator compartment defrosts completely automatically.

The occasional presence of drops of water on the internal back wall of the compartment is a

sign of the automatic defrosting phase. The defrosting water is channelled into a drain and then

collected in a container, where it evaporates.

Depending on the model, the product may be equipped with a special "Zero Degrees"

compartment, which is ideal for storing fresh meat and fish.

Warning: do not clean refrigerator accessories in a dishwasher.

Note: the ambient temperature, how often the doors are opened and the position of the appliance

may affect the internal temperatures in the two compartments. Set the temperatures depending on

these factors.

Note: in very humid conditions, condensation may form in the refrigerator compartment, especially

on the glass shelves. In this case, it is recommended that you close containers with liquids in

(e.g. a pot of stock), wrap up food with a high water content (e.g. vegetables) and turn on the fan,

if there is one.

Removing the fruit and vegetable drawer (depending on the model)

Pull the drawer outwards as far as it will go, lift it up and take it out.

To make it easier to remove the fruit and vegetable drawer, it may be necessary to empty (and

possibly remove) the two lower door shelves and then continue to remove the drawer.

Fan and antibacterial anti-odour filter (depending on the model)

The fan allows for the even distribution of the temperatures inside the compartments and,

consequently, better preservation of the food and reduction of excess humidity. Do not obstruct

the ventilation area. The fan can be turned on/off manually (see the Quick Guide); if it is turned on,

it operates automatically when necessary.

REFRIGERATOR COMPARTMENT

Model with separate freezer compartment

The freezer compartment allows for the storage of frozen food (for the period indicated on the

packaging) and the freezing of fresh food. The quantity of fresh food that can be frozen in 24 hours is

written on the rating plate. Arrange the fresh food in the freezing area inside the freezer compartment

(see Quick Guide), leaving enough space around the food packages to allow air to circulate freely. It

is advisable that you do not re-freeze food that has partially defrosted. It is important to wrap the food

in a way that prevents the ingress of water, humidity or condensation.

Making ice cubes

Fill 2/3 of the ice tray (if available) with water and put it back in the freezer compartment. Do not

use sharp or pointed objects to remove the ice under any circumstances.

Removing the drawers (depending on the model)

Pull the drawers outwards as far as they will go, lift them up and remove them. To get more

volume, the freezer compartment can be used without the drawers.

Make sure that the door is closed properly after putting the food back on the grilles/shelves.

For frost free models it is not necessary to carry out any defrosting procedures.

For other models, the build up of frost is a normal occurrence.

The quantity and speed of frost accumulation varies depending on the ambient conditions and

how often the door is opened. It is advisable to set the temperature colder or, if available, turn on

the quick freeze function (see Quick Guide) four hours before removing the food from the freezer

compartment, to prolong the preservation of the food during the defrosting phase. To defrost, turn

the appliance off and remove the drawers. Put the frozen food in a cool place. Leave the door

open to allow the frost to melt. To prevent the water from escaping during the defrost, it is advised

that you place an absorbent cloth on the bottom of the freezer compartment and wring it out

regularly.

Clean the inside of the freezer compartment and dry it carefully.

Turn the appliance back on and put the food back inside.

HOW TO DEFROST

THE FREEZER COMPARTMENT (depending on the model)

FREEZER COMPARTMENT

In the freezer compartment you can also freeze fresh

food. The quantity of fresh food that can be frozen in 24 hours

is written on the rating plate.

How to freeze fresh food:

• arrange the food on the grille, if present (figure 1), or directly on the

bottom of the compartment (figure 2)

• put the food in the middle of the compartment without it

coming into contact with food that is already frozen, keeping a

distance of about 20 mm (figure 1 and 2).

Models with an internal product compartment

14m_4s

12m_4s

Figure 1

Figure 2

STOP FROST SYSTEM (depending on the model)

The STOP FROST SYSTEM (available depending on the model) facilitates the defrost procedure

for the freezer compartment. The STOP FROST accessory (figure 1) is designed to collect some

of the frost that forms in the freezer compartment and it is easy to remove and clean, therefore

reducing the time needed to defrost the inside of the freezer compartment.

To remove the frost on the STOP FROST accessory follow the cleaning procedure demonstrated

below.

PROCEDURE TO CLEAN THE STOP FROST

ACCESSORY

- Open the freezer compartment door and

remove the upper drawer (figure 2).

- Unfasten the STOP FROST accessory

(figure 3) and remove it (figure 4), taking

care not to drop it on the glass shelf below.

Note: if the accessory is jammed or difficult

to remove, do not keep trying to remove it,

but proceed with the complete defrost of the

freezer compartment.

- Close the door to the freezer compartment.

- Remove the frost on the accessory by rinsing

it under running (not hot) water (figure 5).

- Let the accessory drip dry and dry the plastic

parts with a soft cloth.

- Reinsert the accessory by placing the back

part on the projections shown in figure 7-A,

then refasten the handle of the accessory to

the clasps above (figure 7-B).

- Reinsert the upper drawer and close the door

to the freezer compartment.

It is possible to clean the STOP FROST

accessory on its own without completely

defrosting the freezer compartment. Cleaning

the STOP FROST accessory regularly helps

to reduce the need to completely defrost the

freezer compartment.

Note: the product specifications, including

volume and energy, are calculated without the

STOP FROST accessory.

Click!!

3 4

"ZERO DEGREES" COMPARTMENT

(depending on the model)

The “Zero Degrees” compartment is specifically designed

to maintain a low temperature and the correct humidity to

preserve fresh food for longer (for example, meat, fish, fruits

and winter vegetables).

Humidity control technology coupled with Activ0° provides

the best food preservation when the food is not completely

packed.

Turning on and turning off the compartment

The internal temperature of the compartment is approximately 0° when the compartment is turned

on.

To turn on the compartment, press the

button shown in the figure for more than

one second until the symbol lights up.

The lit symbol means that the compartment

is working. Press the button again for more

than one second to turn off the compartment.

To turn off the compartment completely, you

must remove the drawer.

For the correct functioning of the “Zero Degrees” compartment, it is necessary that:

- the refrigerator compartment is turned on

- the temperature is between +2°C and +6°C

- the drawer in the "Zero Degrees" compartment must be inserted for it to be turned on

- one of the following special functions is not selected: Stand-by, Cooling-Off, Vacation (if present),

in this case, remove the food contained in it.

Note:

- if the symbol does not light up when you turn on the compartment, check that the drawer is

properly inserted; if the problem persists contact the authorised Technical Assistance Service.

- if the compartment is turned on and the drawer is open, the symbol in the control panel may

automatically turn off. The symbol will light up again when the drawer is inserted

- regardless of the state of the compartment, you may hear a faint noise, which you should

consider as normal

- when the compartment is not in operation, the temperature inside it depends on the general

temperature of the refrigerator compartment. In this case, it is advised that fruits and vegetables

that are not sensitive to cold (berries, apples, apricots, carrots, spinach, lettuce, etc.) are stored

in it.

Important: if the compartment is turned on and food with a high water content is present,

condensation may form on the shelves. In this case, turn the function off temporarily.

Be careful when positioning food and containers that are small in size on the upper shelf of the

"Zero Degrees" compartment in order to prevent them accidentally falling between the shelf and

the back wall of the refrigerator compartment.

Before contacting the Technical

Assistance Service:

Restart the appliance to check if the problem

has been solved. If not, disconnect the

appliance again and repeat the procedure after

one hour.

If, after having completed the checks listed in

the guide for malfunctions and after restarting

the appliance, your appliance continues to

function incorrectly, contact the Technical

Assistance Service, clearly describing the

problem and stating:

• the type of malfunction

• the model

• the type and serial number of the appliance

(written on the rating plate)

• the Service number (if available) (the number

that is after the word SERVICE on the rating

plate placed inside the appliance)

Note:

Reversing the doors of the appliance, if

carried out by the Technical Assistance

Service, is not considered as a warranty

claim.

TECHNICAL ASSISTANCE SERVICE

Removing the "Zero Degrees" compartment:

Carry out the following steps:

- to make it easier to remove the compartment, we recommend that you empty (and possibly

remove) the lower door shelves

- turn off the compartment

- remove the compartment by rotating it upwards

- remove the white plastic shelf under the compartment

Note: it is not possible to remove the upper shelf and side supports.

To use the “Zero Degrees” compartment again, carefully reposition the white plastic shelf under

the compartment before inserting the drawer and turning the function back on.

To have a larger refrigerator volume and to reduce energy consumption, it is recommended that

you turn off the “Zero Degrees” compartment and remove the compartment.

Clean the compartment and its components occasionally using a cloth and a solution of warm

water (taking care not to submerge the white plastic shelf under the drawer) and neutral cleaning

agents specifically for cleaning the inside of the refrigerator. Do not use abrasive cleaning agents.

Before cleaning the compartment (also externally) it is necessary to remove the drawer to

disconnect the electrical supply for the compartment.

Scollegare sempre l’apparecchio dall’alimentazione elettrica prima di sostituire la lampadina quindi

seguire le istruzioni in base alla tipologia di illuminazione del vostro prodotto.

Sostituire la lampadina con un tipo delle stesse caratteristiche disponibile presso il Servizio

Assistenza Tecnica ed i rivenditori autorizzati.

Illuminazione tipo 1)

Per rimuovere la lampadina svitare in senso antiorario come

indicato in figura. Aspettare 5 minuti prima di ricollegare

l’apparecchio.

- lampadina di tipo tradizionale (max 25W)

oppure

- lampadina LED (con le stesse caratteristiche)

disponibile solo presso il Servizio Assistenza Tecnica

Illuminazione tipo 2)

Se il prodotto è dotato di luci a LED, come rappresentato nelle figure seguenti, rivolgersi al

Servizio Assistenza tecnica in caso di sostituzione.

Rispetto alla lampadina tradizionale i LED durano più a lungo, migliorano la visibilità interna e

rispettano l’ambiente.

Pulire periodicamente l’apparecchio utilizzando un panno ed una

soluzione di acqua tiepida e detergenti neutri specifici per la pulizia

interna del frigorifero. Non usare mai detergenti abrasivi. Per

garantire il deflusso costante e corretto dell’acqua di sbrinamento,

pulire regolarmente l’interno del foro di scarico situato sulla parete

posteriore del comparto frigorifero in prossimità del cassetto frutta e

verdura, usando l’utensile in dotazione (vedi figura).

Prima di eseguire qualsiasi operazione di manutenzione o pulizia,

disinserire la spina dalla presa di corrente o scollegare l’apparecchio dall’alimentazione elettrica.

Collegare l’apparecchio alla rete elettrica.

Nei modelli con elettronica potrebbe attivarsi un segnale acustico, significa che è intervenuto

l’allarme di temperatura: premere il pulsante di spegnimento allarmi acustici. Ove previsto

posizionare il filtro antibatterico-antiodore nella ventola come indicato nella confezione del filtro.

Nota: Dopo la messa in funzione è necessario attendere 4/5 ore prima che venga raggiunta la

temperatura di conservazione adeguata ad un normale carico dell’apparecchio.

PRIMO UTILIZZO

MANUTENZIONE E PULIZIA

DELL’APPARECCHIO

SOSTITUZIONE LAMPADINA O LED

(a seconda del modello)

Lampadina

Lampadina LED

LED- strip

Dragon

et2

Table des matières

Langues :

Autres manuels Fulgor Milano Réfrigérateur

Fulgor Milano

Fulgor Milano F7IFC30O1 Manuel utilisateur

Fulgor Milano

Fulgor Milano FBCD 355 TNF EDBL Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4FBM28SS Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4BM28FBI Manuel utilisateur

Fulgor Milano

Fulgor Milano FBR 300 F ED Manuel utilisateur

Fulgor Milano

Fulgor Milano FBCD 701 TNF EDBL Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4BM22FBI Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4BM30FBI Manuel utilisateur

Fulgor Milano

Fulgor Milano F7IRC36O1 Manuel utilisateur

Fulgor Milano

Fulgor Milano FBF 290 NF ED Manuel utilisateur

Fulgor Milano

Fulgor Milano FM36CDFDS1 Manuel utilisateur

Fulgor Milano

Fulgor Milano FBC 343 T NF ED Manuel utilisateur

Fulgor Milano

Fulgor Milano F6FBM36S1 Manuel utilisateur

Fulgor Milano

Fulgor Milano FBC 342 TNF ED Manuel utilisateur

Fulgor Milano

Fulgor Milano ITALIAN Series Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4BM30FBI Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4FFD31SS Manuel utilisateur

Fulgor Milano

Fulgor Milano F7PBM36S2-L Manuel utilisateur

Fulgor Milano

Fulgor Milano F7PBM36S1-L Manuel utilisateur

Fulgor Milano

Fulgor Milano FM4BM22FBI Manuel utilisateur

Fulgor Milano

Fulgor Milano F7PBM36S2-R Manuel utilisateur

Fulgor Milano

Fulgor Milano FRSI 400 FEX Guide de démarrage rapide

Fulgor Milano

Fulgor Milano FBCD 761 TNF EDBL Manuel utilisateur

Fulgor Milano

Fulgor Milano F6FBM36S1 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
