PRIMERGY Server

October 2003

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Instructions

This document contains basic product and configuration information that will enable you to configure your system via

PC-/ SystemArchitect.

Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete

PRIMERGY Rack system.

You can configure your individual PRIMERGY server in order to adjust your specific requirements.

The System configurator is divided into several chapters that are identical to the current price list and PC-/ SystemArchitect.

Please follow the lines. If there is a junction, you can choose which way or component you would like to take. Go through

the configurator by following the lines from the top to the bottom.

Section III Memory, example

There are X memory slots which can be equipped with XXX MB.

It is permissible to make up to X passes through the memory upgrade options.

S26361-XXX-XXX S26361-XXX-XXX

Memory XXX MB Memory XXX MB

X times

max. X times per system max. X times per system

In one chapter you can only select as many components (here 4x) as the arrow indicates.

Please note that there are information symbols which indicate necessary information.

Further information in the internet see:

http://www.primergy.com

(internet)

http://extranet.fujitsu-siemens.com/primergy

(extranet)

Prices and availability see price list and PC-/ SystemArchitect.

Subject to change and errors excepted.

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 2 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Configuration diagram PRIMERGY T850

TOP VIEW FRONT/REAR VIEW

System unit ( I )

1st System Board

2nd System Board

Xeon MP

Processor ( II ) Memory ( III ) Processor ( II ) Memory ( III )

Extension slots

Two Power Supplies included

Graphics ( IV )

SCSI controller ( VII )

1st PS

2nd PS

Disk array ( VIII )

Communikation/Network ( IX )

6 PCI-X -slots, 1 slot occupied by RSB

Hot-plug 1+1 (redundant) Power Supply

PCI-X long 64 Bit / 133 MHz hot-plug 1050W at 220V or 525W at 110V each

PCI-X long 64 Bit / 133 MHz hot-plug

3.5"x0.5"

5.25"x0.5"

PCI-X long 64 Bit / 100 MHz hot-plug Floppy disk DVD

PCI-X long 64 Bit / 100 MHz hot-plug

PCI-X long 64 Bit / 66 MHz hot-plug Accessible drives ( V )

RemoteServiceBoard

(PCI-X long 64 Bit/66 MHz hot-plug) Hard disk drives ( VI )

hot plug

3.5"x1" 3.5"x1"

SCSI-drive

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 3 of 18

System configurator and order-information guide

Start "PRIMERGY T850"

PRIMERGY T850 Status 2003-09-23

SW Configurator

with OEM-Software without OEM-Software

for PRIMERGY Server for PRIMERGY Server

Later use of OEM operating system

Microsoft does not allowe software is not allowed,

Vmware-Software the use of OEM-software apart from OEM software by

- ESX Server 1.5 (OEM) under ESX. VMware and F5

- ESX Server 2.0 (OEM)(planned) Distributions-/ retailware is

- Virtual SMP for ESX 2.0 (OEM) allowed.

For all SW products listed below please refer to the corresponding software configurator accessible via the

Extranet under "PC Configurations, Configurator for PRIMERGY SW", URL see below.

MS - Software: W **) PRIMECLUSTER *)

- Windows 2000 Server - Clustering

- Windows 2000 Advanced Server - Load Balancing

- Windows 2000 Data Center Server

(only for certified systems)

- Windows Server 2003, Linux - Software: **)

Standard Edition - SuSE Linux Enterprise Server: S

Enterprise Edition - SuSE Professional Linux

- Red Hat Enterprise Linux

- Red Hat Professional Linux

CITRIX-Software für NT: W1

- Multiuser SW MetaFrame

LoadBalancing

Additional User Licences

MultiPath, Duplex Data easy Mirror for Linux

Manager for NT; W2K; Linux NT 4, WIN 2000

FSC System Management

Software: V *) Pay attention to release information on datasheet under

- RemoteView Software

http://www.primecluster.com

- RemoteView Service Board

- RemoteView Diagnosis **) Pay attention to release and order information in PRINCE -> Operating System

http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm

Backup-Software: U

- ARCserve for NT

You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses:

for internal users:

http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm

for partners:

http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm

Continue with PRIMERGY

HW configurator

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 4 of 18

System configurator and order-information guide

Start PRIMERGY T850

PRIMERGY T850 Status 2003-09-23

Section IBasic unit

System unit consisting of:

* 4U rack mountable housing incl. 2 hot plug power supply modules redundant

- temperature sensor for CPU module and FSC PDA function

* 4 hot replace fans

* Drives / Bays

- 1 drive bay 3.5“/0.5“ high (occupied by 1 floppy disk

- 1 drive bay 5.25"/0.5" high (occupied by 1 DVD-ROM)

- 2 bays for 1“ hard disks

- 6 slots PCI-X 64 Bit (2x 133 MHz, 2x 100 MHz, 2x 64 MHz, (1x occupied by 1 RemoteView serviceboard)

Systemboard, to upgrade to 4 or up to 8 processors with:

- 2x Xeon processors, 100 MHz quad-pumped FSB

- 2-channel U160 SCSI controller on-board

- graphics processor on board 8 MB (PCI)

- LAN Controller 10/100/1000 on-board

- Fast-IDE controller (for DVD-ROM)

- RemoteView Serviceboard in a PCI slot

External Interfaces:

- 1x RS-232-C (serial, 9 pin)

- 1x keyboard (PS/2)

- 1x mouse (PS/2)

- 1x VGA (15 pin)

- 3x USB UHCI (1x front side)

- 1x LAN RJ45

- 3x SMP Interconnect

- 1x PCI extension

- 1x SCSI U160 (UHD68)

Cables:

1. IDE cable for CD/DVD

2. U160 SCSI cable for connection of the HD backplane

3. Power cord

Software:

- ServerStart packet incl. ServerBooks CD, ServerSupport CD and ServerView

Mounting kit for PRIMERGY T850 is part of the basic unit

- 1 pair of telescopic rails (710-815mm)

- 1 pair of carrier rails

- 1 bracket PC-Rack

- 1 cable management PC-racks

Mounting kit for mounting of servers in in FSC 19" PRIMECENTER- racks

and all server racks conforming to EIA standard EIA-310-D for 19" racks.

Therefore the mounting kit is variable in deepth from 710-815mm

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 5 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Rack Basic Unit (4U), 8-way Rack Basic Unit (4U), 4-way

including 2x Xeon MP processor including 2x Xeon MP processor

2 system boards 1 system board

upgradable to 8 CPUs upgradable to 4 CPUs

S26361-K846-V815 1,5 GHz / 1MB S26361-K846-V415 1,5 GHz / 1MB

S26361-K846-V819 1,9 GHz / 1MB S26361-K846-V419 1,9 GHz / 1MB

S26361-K846-V820 2,0 GHz / 2MB S26361-K846-V420 2,0 GHz / 2MB

16-way Upgrade S26361-F2738-L308

Requires two Rack Basic Units Ugrade System Board

fully equipped with 8 prcessors each. without processor

Only available after Special Release enables upgrade to 8 CPUs

is granted. max. 1x per system

For Windows 2000 Datacenter or

VMware 1.5 only. If two system boards are installed, both have

S26361-F2738-E316 to be equipped with processors and memory

The 16-way configuration is only

available on request of an

Special Release.

PRIMECENTER Rack

SNP:SY-F1647E301-P "Rack-mounting ex factory"

Installation ex works for one This service is to be ordered once

server or subsystem. per installable server/storage

Hereby the rack will be delivered subsystem, in order to get the

completely pre-mounted and server/storage subsystem

all wired connections are tested. mounted into the PRIMERGY racks.

With racks 12U, 24U, 38U: In case of the 46 U PRIMERGY Rack,

Systems and components this service has to be ordered,

will be delivered installed in the rack to get the mounting kits and the

With racks 46U: cables installed.

Systems and components

will be delivered separately

To be ordered only together with

a PRIMERGY-

PRIMECENTER rack

e.g.:

S26361-K826-V10x

refer configurator PC-Rack

max. 1x per System

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 6 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Section II Processor

The PRIMERGY T850 can carry up to 2 system boards.

The basic units include either one or two system boards.

Please note that the basic units already includes two processors.

Each system board requires at least 1 processor can be upgraded to max. 4 processors.

Only processors with the same clock frequency and the same third level cache (TLC) can be used.

Terminators are automatically included if necessary.

For a multi-processor system a multi-processor operating system is required.

Important: The necessary operating system license depends possibly on the number of the processors,

e.g. with Windows 2000 Datacenter and the pertinent update subscription.

Also with additional processor armaments it can be that the licensed CPU number is exceeded.

Then an appropriate license must be ordered. See also for this W2k Datacenter Product Facts, chapter 5

S26361-F2740-E151 S26361-F2740-E191 S26361-F2740-E202

XEON MP 1,5GHz XEON MP 1,9GHz XEON MP 2GHz

with 1 MB TLC on Chip, with 1 MB TLC on Chip, with 2MB TLC on Chip,

heat sink heat sink heat sink

occupies slot for one CPU occupies slot for one CPU occupies slot for one CPU

max. 2x for 1 system board max. 2x for 1 system board max. 2x for 1 system board

max. 6x for 2 system boards max. 6x for 2 system boards max. 6x for 2 system boards

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 7 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Section III Memory

There are 16 memory slots available (4 banks with 4 modules each) on each system board.

Mixing different modules within a bank is not support,

therefore only complete banks with 4 modules are offered

Each system board must be pupolated with at least 1 bank

Memory mirroring functionality is possible as an option between banks

S26361-F2741-E142 S26361-F2741-E144

max. 4x Main memory 2.048 MB Main memory 4.096 MB

per 133 MHz Registered SDRAM 133 MHz Registered SDRAM

system

board consisting of 4 modules consisting of 4 modules

occupies one bank occupies one bank

max. 4x per system board max. 4x per system board

Section IV Graphics

Graphics controller other than the 8MB on-board controller (S3 Savage4) are not tested and released.

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 8 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Section VAccessible Drives

The Basic Unit includes one Floppy Disk and one DVD Drive.

Other integrated accessable drives are not supported.

Section VI Hard Disk Drives

while stocks last

SNP:SY-F2336E118-P SNP:SY-F2336E136-P

Hard disk 18GB Hard disk 36GB

10000rpm, <7ms, min. 4MB Cache 10000rpm, <7ms, min. 4MB Cache

U160 SCSI (160 MB/sec) U160 SCSI (160 MB/sec)

Interface: WIDE SCA (80 pins) Interface: WIDE SCA (80 pins)

hot pluggable drive hot pluggable drive

occupies 1" bay occupies 1" bay

max. 2x per system max. 2x per system

S26361-F2336-E173 S26361-F2336-E114

Hard disk 73GB Hard disk 146GB

10000rpm, <7ms, min 8MB Cache 10000rpm,<5,5ms,min. 8MB Cache

U160 SCSI (160 MB/sec) Ultra 160 SCSI (160MB/s)

Interface: WIDE SCA (80 pins) Interface: Wide SCA (80-pins)

max. 2x hot pluggable drive hot pluggable drive

occupies 1" bay occupies 1" bay

max. 2x per system max. 2x per system

S26361-F2336-E518 S26361-F2336-E536 S26361-F2336-E573

Hard disk 18GB Hard disk 36GB Hard disk 73GB

15000rpm, <4ms, min. 8MB Cache 15000rpm, <4ms, min. 8MB Cache 15000rpm, <4ms, min. 8MB Cache

Ultra 160 SCSI (160MB/s) Ultra 160 SCSI (160MB/s) Ultra 160 SCSI (160 MB/sec)

Interface: Wide SCA (80-pins) Interface: Wide SCA (80-pins) Interface: Wide SCA (80-pins)

hot pluggable drive hot pluggable drive hot pluggable drive

occupies 1" bay occupies 1" bay occupies 1" bay

max. 2x per system max. 2x per system max. 2x per system

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 9 of 18

System configurator and order-information guide

PRIMERGY T850 Status 2003-09-23

Section VII SCSI/Fibre Channel Controller

Inclusive The two HD SCSI drives are connected to one on-board SCSI channel.

The 2nd channel of the Dual- The second on-board SCSI channel can be used for external devices.

on-board U2W-SCSI controller

can be used for external drives

Included in the basic and system

units.

Controller for the connection of an external storage system:

S26361-F2399-E1 not released for

SCSI 160 controller VMware ESX Server

Adaptec SCSI card 29160

1 channel: LVD+Fast/Ultra (decoup.)

LVD con. for HD, withoud cable

Fast/Ultra con. access. drives

64/66 (32/33) PCI, min. 180mm

int: Fast 50-pin or Ultra HD68

+ LVD HD68; ext: HD68(LVD)

SW:

max. 2x per system

Fibre Channel controller for subsystems and SAN

while stocks last while stocks last

SNP:SY-F2244E1-A SNP:SY-F2244E2-A

1GBit/s FC Controller 1GBit/s FC Controller

Qlogic Qlogic

QLA 2200 QLA 2200F

1 Channel 1GBit/sec FC Controller 1 Channel 1GBit/sec FC Controller

CU (copper) Interface MMF(Multimode Fibre) Interface

incl. SW and description (Ger/US) incl. SW and description (Ger/US)

PCI 64Bit / 66MHz, 175mm PCI 64Bit / 66MHz, 175mm

3.3V and 5V tolerant signaling 3.3V and 5V tolerant signaling

4x max. 4x per system max. 4x per system while stocks last

S26361-F2843-E1 S26361-F2624-E1 Attention

2GBit/s FC Controller 2GBit/s FC Controller 2GBit/s FC Controller

Emulex Emulex require other interface

LP9802 LP9002L connectors for the

1 Cannel 2GBit/sec FC Controller 1 Channel 2GBit/sec FC Controller optical cables than

LC Interface for 50um Fiber LC Interface for 50um Fibre 1GBit/s fibre channel.

PCI 64Bit / 133MHz, 170mm PCI 64Bit / 66MHz, 170mm

3.3V and 5V tolerant signaling 3.3V and 5V tolerant signaling

max. 4x per system max. 4x per system

freigegeben

There are other components such as switches, GBICs or cables which can be ordered for fibre channel SAN attachments. (see price list)

All controllers for the connection of external storage systems are delivered without cables.

For the configuration of external cabling see the configurator for external storage systems.

All internal cables and adapters are included within the basic units and components respectively.

Fujitsu Siemens Computers

Enterprise Products - PRIMERGY Server 10 of 18

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu Primepower200 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel de service

Fujitsu

Fujitsu SPARC Enterprise T5140 Manuel utilisateur

Fujitsu

Fujitsu Server PRIMERGY TX1330 M1 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M4000 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M8000 Guide d'installation

Fujitsu

Fujitsu PRIMERGY SX940 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX4770 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX200 S3 Manuel du propriétaire

Fujitsu

Fujitsu PRIMERGY RX300 S7 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX150 S8 Guide de l'utilisateur

Fujitsu

Fujitsu PRIMERGY BX400 S1 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Manuel utilisateur

Fujitsu

Fujitsu primergy h250 Manuel utilisateur

Fujitsu

Fujitsu Primergy RX300 S4 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel de service

Fujitsu

Fujitsu PRIMERGY RX2540 M1 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Instructions d'utilisation et d'entretien

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel utilisateur

Fujitsu

Fujitsu l ETERNUS AF Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel de service

Fujitsu

Fujitsu SPARC ENTERPRISE T1000 Manuel technique

Fujitsu

Fujitsu PRIMERGY RX1330 M3 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
