Fujitsu Primergy RX300 S2 Manuel utilisateur

PRIMERGY RX300 S2

Server

Options Guide

Edition March 2007

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

RX300 S2 Options Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Overview of the documentation . . . . . . . . . . . . . . . . . 7

1.2 Options and upgrade . . . . . . . . . . . . . . . . . . . . . . 9

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 12

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1 Removing the server form the rack . . . . . . . . . . . . . . 21

4.2 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 23

5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.1 Memory module population . . . . . . . . . . . . . . . . . . 26

5.2 Upgrading/replacing the main memory . . . . . . . . . . . . 28

6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6.1 Installing a second processor . . . . . . . . . . . . . . . . . 33

6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . 39

7 ROMB (RAID on Motherboard) . . . . . . . . . . . . . . . . 43

7.1 Installing the ROMB upgrade kit . . . . . . . . . . . . . . . 43

OptionsGuide RX300 S2

Contents

8 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . . 45

8.1 Installing a FD drive . . . . . . . . . . . . . . . . . . . . . . . 46

8.2 Installing a LocalView module . . . . . . . . . . . . . . . . . 51

8.3 Installing the CD/ DVD-ROM drive . . . . . . . . . . . . . . . 58

9 PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

9.1 Installing a PCI controller in a low-profile slot . . . . . . . . . 64

9.2 Installing the PCI controller in the riser card . . . . . . . . . 66

9.3 Population of the PCI slots . . . . . . . . . . . . . . . . . . . 70

10 RemoteView components . . . . . . . . . . . . . . . . . . . . 71

10.1 Installing the chipDISK . . . . . . . . . . . . . . . . . . . . . 71

10.2 RemoteView Service Board S2 LP . . . . . . . . . . . . . . . 72

11 External SCSI interface . . . . . . . . . . . . . . . . . . . . . 75

11.1 Installing the external SCSI interface . . . . . . . . . . . . . 75

12 Parallel interface . . . . . . . . . . . . . . . . . . . . . . . . . 87

12.1 Installing a parallel interface . . . . . . . . . . . . . . . . . . 87

13 Converting from 1- to 2-channel version . . . . . . . . . . . . 93

13.1 Removing 2nd SCSI backplane . . . . . . . . . . . . . . . . . 95

13.2 Installing 2nd SCSI backplane . . . . . . . . . . . . . . . . . 98

14 Converting from low-profile to standard PCI Slots . . . . . 101

14.1 Removing lp slot cage . . . . . . . . . . . . . . . . . . . . 101

14.2 Installing Riser card . . . . . . . . . . . . . . . . . . . . . . 104

RX300 S2 Options Guide

Contents

15 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

15.1 Closing the server . . . . . . . . . . . . . . . . . . . . . . . 107

16 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

16.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

16.2 Configuration diagram . . . . . . . . . . . . . . . . . . . . . 114

16.3 Hard disk mirroring . . . . . . . . . . . . . . . . . . . . . . . 115

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

RX300 S2 Options Guide 7

1 Introduction

The PRIMERGY RX300 S2 has been designed for multi-server configurations

(clusters), front-end solutions, e-commerce applications and ERP solutions.

The PRIMERGY RX300 S2 is outstanding for applications and fields of use that

demand maximum scalability, performance and availability in a space-saving

rack cabinet.

The PRIMERGY RX300 S2 offers very great expandability with up to 6 hard

disks for a rack server and takes up just 2 height units (U) in a 19-inch rack.

1.1 Overview of the documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD which is supplied in the ServerView Suite package for every server

system.

These PDF files can also be downloaded free of charge from the

Internet: at http://manuals.fujitsu-siemens.com you will find an overview

page with the online documentation available on the Internet. You can go

to the PRIMERGY Server documentation by clicking on “industry standard

servers”.

Concept and target groups

This Options Guide shows you how you can expand and upgrade the server.

IThe Operating Manual for the server describes how you install/remove

the hot-plug components.

The activities described in this manual may only be performed by specialist

personnel with technical training.

8 OptionsGuide RX300 S2

Overview of the documentation Introduction

Additional documentation about the server

The PRIMERGY TX300 S2 documentation comprises the following additional

manuals:

– The “Safety notes and other important information” manual (printed copy

always supplied with the server, and available as a PDF file on the

ServerBooks DVD supplied)

– The “Warranty” manual (printed copy always supplied with the server, and

available as a PDF file on the ServerBooks DVD supplied)

– The Operating Manual for PRIMERGY RX300 S2 (PDF available on the

ServerBooks DVD supplied)

– The Technical Manual for the system board D1889/D2089 (PDF available on

the ServerBooks DVD supplied)

– The “BIOS Setup” manual (PDF available on the ServerBooks DVD supplied)

– The “PRIMERGY ServerView Suite - ServerStart” manual (printed copy

always supplied with the server, and available as PDF file on the ServerBooks

DVD supplied)

IYou can order a supplementary ServerBooks DVD by sending an e-mail to

the following address, quoting your server data:

Reklamat-PC-LOG@fujitsu-siemens.com

Further sources of information:

– Technical Manual on the relevant rack

– Manual on the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Manual on LocalView

– Documentation on boards and drives

– Documentation on your operating system

– Information files on your operating system

(see also chapter „Related publications“ on page 117)

RX300 S2 Options Guide 9

Introduction Options and upgrade

1.2 Options and upgrade

Second processor

The system board can be upgraded with a second processor. Only processors

of the same type may be used on the system board. The second processor must

have the same clock frequency and the same cache as the first processor.

Upgrading of the main memory

The eight slots for the main memory are suitable for PC2-3200 DDR DIMM

memory modules. The organization in four memory banks, 0 to 3, permits rapid

memory access with two-way interleaving.

Memory modules must always be incorporated in pairs. A memory bank must

always be equipped fully with the same type of memory modules.

ROMB (RAID on motherboard)

The System is extended with an on board Intel I/O processor. If the controller is

activated, the on-board 2 channel U320 SCSI-Controller supports RAID Level

0, 1, 10, 5 and 50 on both SCSI channels

"MegaRaid PCI Express™ ROMB" can be activated with two different

upgrading kits.

Additional accessible drives

One 3.25-inch bay and one 3,5-inch bay are available for accessible drives.

One 5.25-inch bay can be installed with a 3.5 inch x 0.5 inch floppy disk drive or

a LocalView module and the other bay can be installed with a 5.25-inch x 0,5

inch DVD-ROM drive.

10 OptionsGuide RX300 S2

Options and upgrade Introduction

LocalView module (alphanumeric system display)

The LocalView module provides you with the option of displaying system infor-

mation and hardware system faults alphanumerically. This is an intelligent

module with a micro-controller and its own memory, which functions indepen-

dently of the server system.

The LocalView module consists of an LCD display panel and a toggle switch,

both accommodated in a suitable mount. The mechanical mechanism used

allows the LCD display panel to be pulled out and flapped out. Further infor-

mation on operating the display modes are provided in the documentation on

the LocalView module.

Hard disk drives

the installation up to six HDD modules is possible. Each HDD module can

accommodate a SCSI hard disk drive with an SCA (Single Connector

Attachment) interface and a height of at most 1 inch. The connection to the

SCSI backplane is made without cables via the SCA interface. This makes it

simple to plug in or pull out the HDD modules. If the server has a RAID controller

and the corresponding RAID configuration, faulty HDD modules can also be

replaced while the system is operating.

Additional controllers in non-hot-plug PCI slots

The system board offers five PCI slots. Slots 1-3 are non-hot-plug PCI slots with

a PCI bus speed of 100 MHz. If slot 1 and slot 2 are not occupied, slot 3 can

work with the PCI bus speed of 133 MHz (IDoubleOP™).

PCI slots 4 and 5 are hot-plug PCI slots which can be equipped with controllers

that have hot-plug capability (the hot-plug PCI slots are described in the

Operating Manual).

Optional riser card

Optionally you can install a Riser card into slot 5, which can be equipped with 3

controllers. The bus speed is 100 MHz. Two slots (6 and 7) can be equipped with

short standard PCI controllers and slot 8 can be equipped with a full length full

height PCI controller.
