Fujitsu P2711 TE QHD Instructions d'installation

Page 1 of 14

Disassembly and Repair 2

Information on the installation and removal of components 3

Tools 4

Disassembly 5

P2711 TE/TS QHD Monitor Exploded Drawing 10

P2711 TS CAM Monitor Exploded Drawing 11

Replaceable Components and Services 12

Disposal information for recycling companies 13

Disassembly and repairs

Display P2711 TE QHD

Display P2711 TS QHD

Display P2711 TS

CAM

Version date 12.01.2023

Category Disassembly and repairs

Contents

Page 2 of 14

Disassembly and Repair

We recommend printing out the relevant sections of this chapter prior to installation

as the device for installing/removing hardware components needs to be switched off.

In order to repair the display, please follow the disassembly instructions to remove the defect part, replace it with spare part, then follow the

instructions in reverse order.

If you have received any further documents with your device, you should read these through carefully.

Please note the following instructions before installing/removing system components:

■ The device must be switched off when installing/removing components and it must

not be in power-saving mode.

■ Disconnect the mains plug before opening the device.

■ After unplugging the mains plug, discharge the remaining voltage by pressing the

activation button.

■ Remove all externally connected cables.

■ Take care not to flex foil cablech any cables when installing/removing components.

■ Please ensure that the installed components that might heat up intensely during

operation do not exceed the permitted operating temperature.

Page 3 of 14

Information on the installation and removal of components

Please pay attention to the locking mechanism (indentations and centring flex foil cables) when installing hardware components.

Note that some components on the mainboard may be very hot if the device was in use shortly before the case was removed.

Utmost care is required during installation and removal to avoid damaging components.

Never use items with sharp edges (screwdrivers) to lever them out.

Parts with Electrostatic Sensitive Devices (ESD) can be identified by a corresponding label.

When dealing with boards with ESDs, the following points must always be observed:

■ Always ensure there is a static discharge (e.g. by touching a grounded object) prior to commencing

with the work.

■ The devices and tools being used must not be statically charged.

■ Only touch the components along the edges or on the areas marked in green (contact points).

■ Contacts and electronic components must not touch when handling components equipped with ESD

protection.

Page 4 of 14

Tools

Screwdriver: Pozidriv PZ 2

Screwdriver: Phillips PH 1

Hexagon Screwdriver size 5

Flat Head Screwdriver

Page 5 of 14

Disassembly

Step Figure Description

Remove the

Stand Base

Ass'y.

Remove the

screws to

remove the

stand base

assy.

Remove the

rear cover

Remove the

rear cover

Disconnect

the flex foil

cable.

Disconnect the

flex foil cable

to remove the

rear cover.

Page 6 of 14

Remove the

tapes and the

flex foil cable

Remove the

tapes and the

flex foil cable

Remove the

screws to

remove the

middle frame

and the panel

Remove the

screws to

remove the

middle frame

and the panel

Take off the

tape and

disconnect

the flex foil

cable

Take off the

tape and

disconnect the

flex foil cable

Page 7 of 14

Remove the

main board

and power

board

Remove the

screws to

remove the

main board and

power board

Remove the

connectors

Remove the

connect flex foil

cables

Remove the

speakers

Remove the

speakers

Page 8 of 14

The panel

The WEBCAM

Remove the

screws to

remove the

WEBCAM

The key board

Remove the

screws to

remove the key

board

Page 9 of 14

The middle

frame

The middle

frame

The USB

board

Remove the

screw to

remove the

USB board.

The Rear

Cover

The Rear

Cover

Page 10 of 14

P2711 TE/TS QHD/CAM Monitor Exploded Drawing
