DATASHEET FUJITSU LIFEBOOK T1010 TABLET PC

Page 1 / 5 http://ts.fujitsu.com/tabletpc

DATASHEET

FUJITSU LIFEBOOK T1010 TABLET PC

STYLE IN ROTATION

LIFEBOOK T1010

The LIFEBOOK T1010 combines style and functionality. The brilliant 33.8 cm (13.3-inch) TFT display with

passive digitizer guarantees comfortable working whatever the application. Enjoy the advantages of exible

pen-based entries, such as automatic handwriting recognition and many other special features that only

a Convertible Notebook can offer. Special covers ensure that not only your presentations look unique but

also your LIFEBOOK T1010. Integrated WLAN and Bluetooth give you the freedom you need for effective

and efcient working.

PEN-BASED WORK WITH STYLE

Show that you have taste without having to do without comfortable, pen-based working.

Excellent design, individual covers possible, bidirectional swivel 33.8 cm (13.3-inch) display, passive 

digitizer

ULTIMATE CONNECTIVITY

Improved and structured information exchange: anytime, anywhere

Optional integrated 3G/UMTS, ConfCam, WLAN, Bluetooth, Port Replicator (optional)

CLEAR BENEFITS

No more duplicating notes. For effective and productive work.

Tablet functions, pen-based software

PERFORMANCE

Save time thanks to fast processing with the Intel turbo memory module.

More processes per second. Spends less time calculating your main tasks - higher productivity.

SAFETY

Protect your company data against unauthorized third-party access.

Computrace®enabled BIOS

BI- DIR ECTIO NAL ROT A TI ON

CONFCAM

DATASHEET FUJITSU LIFEBOOK T1010 TABLET PC

Page 2 / 5 http://ts.fujitsu.com/tabletpc

COMPONENTS

PROCESSOR Intel®Core™2 Duo processor P8700 (2.53 GHz, 3 MB, 1066 MHz)

Intel®Core™2 Duo processor P8600 (2.4 GHz, 3 MB, 1066 MHz)

Intel®Celeron®M processor M585 (2.16 GHz, 1 MB, 667 MHz)

MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM

2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM

Supported capacity RAM (max.) 4 GB

Memory slots total 2

Memory slot type DIMM

Memory notes 8 GB - with future memory modules.

HARD DISK DRIVES (INTERNAL) 320 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.

160 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.

128 GB SSD SATA, 2.5-inch S.M.A.R.T.

80 GB SSD SATA, 2.5-inch S.M.A.R.T.

Hard disk notes ShockSensor for HDD shock protection

One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.

Accessible capacity may vary, also depending on used software

WLAN (OPTIONAL) Atheros Minicard b/g 802.11 b/g

Intel®Wireless WiFi Link 5300 AGN 11/13ch

WIRELESS TECHNOLOGIES

Antennas 3 Dual band WLAN antennas, 1 Bluetooth 2.0

WLAN notes Import and usage according to country-specic regulations.

UMTS/HSUPA (OPTIONAL) Sierra Wireless MC8790 (downlink 7.2 Mbit/s, uplink 2.0 Mbit/s)

BLUETOOTH (OPTIONAL) Bluetooth 2.1

Base unit LIFEBOOK T1010, 13.3 WXGA

GENERAL SYSTEM INFORMATION

Chipset Intel®GM45, ICH 9-M

Intel platform Intel®Centrino®2 technology

BIOS features BIOS Flash EPROM

BIOS based on Phoenix TrustedCore Notebook

GRAPHICS

Max. resolution external display 1920 x 1200 pixel

Graphics brand name Mobile Intel®GMA 4500M HD

Graphics features DualView (Windows®XP & Windows®Vista)

INTERFACES

Memory card slots 1 (SD/MMC/MS/MSPro/XD)

ExpressCard slots 1

USB 2.0 total 3

VGA 1

Ethernet (RJ-45) 1

DC-in 1

Audio: line-in / microphone 1

Audio: line-out / headphone 1

Internal microphones 2

Docking connector for Port Replicator 1

Kensington Lock support 2

WIRED COMMUNICATION

LAN Built-in 10/100/1000 MBit/s Marvell 88E8055

DATASHEET FUJITSU LIFEBOOK T1010 TABLET PC

Page 3 / 5 http://ts.fujitsu.com/tabletpc

KEYBOARD AND POINTING DEVICES

Spill-resistant keyboard

Number of keyboard keys: 85, Keyboard pitch: 19 mm, Keyboard stroke: 2.7 mm

Touchpad with two mouse buttons and one scroll button

Application buttons

Status LED

Touch-screen

Tablet Pen

Digitizer

MULTIMEDIA

Audio type On board

Audio codec Realtek ALC269

Audio features Stereo speakers, 2 internal microphones

Camera Built-in webcam, 1.3 megapixel, VGA camera

POWER SUPPLY

AC adapter 19 V / 80 W (4.22 A)

Rated voltage range 100 - 240 V (AC Input)

Rated frequency range 50 - 60 Hz

1st battery 1st Li-Ion battery 6-cell, 5200 mAh, 56.16 Wh

2nd battery (optional) none

Battery features Dynamic charge supported (rapid charge)

Benchmark Mobile Mark 2005

Runtime 1st battery 3.5 h

Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features

utilized. Battery recharge time depends on usage.

POWER CONSUMPTION

Power consumption note See white paper Energy Consumption

Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=90e0917e-cc67-44ac-ad61-22c32e5d386c

DIMENSIONS / WEIGHT / ENVIRONMENTAL

Dimensions (W x D x H) 319 x 244 x 37 - 39 mm

Weight 2,3 kg

Weight notes Actual weight may vary depending on conguration

Operating ambient temperature 5 - 35°C

Operating relative humidity 20 - 85 % (running)

OPERATING SYSTEM

Operating system optional preinstalled TwinLoad Microsoft®Windows®XP Tablet PC Edition 2005 (DVD)

Microsoft®Windows Vista®Business 32-bit

Microsoft®Windows Vista®Home Premium

Operating system compatible Microsoft®Windows®XP Tablet PC Edition 2005

Microsoft®Windows®7 Home Premium 32-bit

Microsoft®Windows®7 Professional 32-bit

Operating system notes Driver support for Microsoft®Windows®XP

ADDITIONAL SOFTWARE

Additional software (preinstalled) Adobe Acrobat Reader

Application Panel

Camera

Drivers & Utilities DVD (DUDVD)

Microsoft® Ofce Ready (Trial)

Nero Essentials (burning software)

Norton Internet Security (incl. Firewall) on Drivers & Utilities DVD for Microsoft Windows XP

Toshiba Bluetooth Stack (only with Windows Vista®or Windows®XP operating systems)

EasyGuide online user documentation

Tablet Button Utility

Additional software (optional) Windows Vista®recovery media

Drivers & Utilities DVD (DUDVD)

DVD playback software

DATASHEET FUJITSU LIFEBOOK T1010 TABLET PC

Page 4 / 5 http://ts.fujitsu.com/tabletpc

MANAGEABILITY

Manageability features DeskUpdate Driver management

DeskView Migrate (optional)

DeskView Control (optional)

Manageability type DeskView 10.x client management including:

DeskView features Detailed system inventory management and reports

BIOS Management

System notications

DeskView Helpdesk Integration

WoL (Wake on LAN)

Supported standards WMI

PXE

BootP (made4you)

Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html

SECURITY

Physical security Kensington Lock support

System security Computrace®enabled BIOS

Symantec Norton Internet Security (90 day test version)

User security User and supervisor BIOS password

Hard disk password

COMPLIANCE

Model LIFEBOOK T1010

Europe CE

CE!

USA/Canada UL

cUL

FCC Class B (depending on wireless conguration)

Global Microsoft Operating Systems (HCT / HCL entry / WHQL)

RoHS (Restriction of hazardous substances)

WiFi certied

Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx

PORTREPLICATOR INTERFACES (OPTIONAL)

DC-in 1 1

Power on switch 1 1

Audio: line-out 1 1

USB 2.0 total 4 4

VGA 1 1

DVI 1 1

HDMI 1 1

Ethernet (RJ-45) 1 1

Kensington Lock support 1 1

WARRANTY

Standard Warranty 2 years

Service level Collect & Return Service (depending on country)

MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION

Recommended Service 3 years, Collect and Return Service, where available: Executive On-site Service

Spare Parts availability 5 years

Service Weblink htttp://ts.fujitsu.com/Supportservice

DATASHEET FUJITSU LIFEBOOK T1010 TABLET PC

Page 5 / 5 http://ts.fujitsu.com/tabletpc

CONTACT

FUJITSU Technology Solutions

Website: http://ts.fujitsu.com

2010-01-25 CE-EN

FUJITSU PLATFORM SOLUTIONS

In addition to Fujitsu LIFEBOOK T1010, Fujitsu

provides a range of platform solutions. They

combine reliable Fujitsu products with the best in

services, know-how and worldwide partnerships.

Dynamic Infrastructures

With the Fujitsu Dynamic Infrastructures

approach,Fujitsu offers a full portfolio of IT

products, solutions and services, ranging

from clients to datacenter solutions, Managed

Infrastructure and Infrastructureas-a-Service.

How much you benet from Fujitsu technologies

and services depends on the level of cooperation

you choose. This takes IT exibility and efciency

to the next level.

Computing Products

www.fujitsu.com/global/services/computing/

Software

www.fujitsu.com/software/

MORE INFORMATION

Learn more about Fujitsu LIFEBOOK T1010,

please contact your Fujitsu sales representative

or Fujitsu Business partner, or visit our website.

http://ts.fujitsu.com/tabletpc

FUJITSU GREEN POLICY INNOVATION

Fujitsu Green Policy Innovation is our worldwide

project for reducing burdens on the environment.

Using our global know-how, we aim to resolve

issues of environmental energy efciency

through IT.

Please nd further information at http://www.

fujitsu.com/global/about/environment/

COPYRIGHTS

rights. Changes to technical data reserved.

Delivery subject to availability. Any liability that

the data and illustrations are complete, actual or

correct is excluded.

Designations may be trademarks and/or

copyrights of the respective manufacturer,

the use of which by third parties for their own

purposes may infringe the rights of such owner.

For further information see http://ts.fujitsu.com/

terms_of_use.html

DISCLAIMER

Technical data are subject to modication and

delivery subject to availability. Any liability that

the data and illustrations are complete, actual

or correct is excluded. Designations may be

trademarks and/or copyrights of the respective

manufacturer, the use of which by third parties

for their own purposes may infringe the rights of

such owner

Autres manuels pour FPCM11383

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fujitsu Ordinateur portable

Fujitsu

Fujitsu V1040 - LifeBook - Core 2 Duo 2.4 GHz Manuel de service

Fujitsu

Fujitsu P3010 - LifeBook - Athlon Neo 1.6 MHz Manuel utilisateur

Fujitsu

Fujitsu Lifebook S4546 Manuel utilisateur

Fujitsu

Fujitsu LIFEBOOK E753 Manuel utilisateur

Fujitsu

Fujitsu Lifebook A6230 Manuel utilisateur

Fujitsu

Fujitsu N6110 - LifeBook - Pentium M 1.86 GHz Manuel utilisateur

Fujitsu

Fujitsu LifeBook U9312 Manuel utilisateur

Fujitsu

Fujitsu LIFEBOOK U5x4 Manuel utilisateur

Fujitsu

Fujitsu FPCR34711 Manuel utilisateur

Fujitsu

Fujitsu S2020 - LifeBook - Athlon XP-M 1.67 GHz Manuel utilisateur

Fujitsu

Fujitsu LIFEBOOK S782 Manuel utilisateur

Fujitsu

Fujitsu E8420 - LifeBook - Core 2 Duo 2.26 GHz Manuel de service

Fujitsu

Fujitsu LifeBook S762 Manuel utilisateur

Fujitsu

Fujitsu T2020 - LifeBook Tablet PC Manuel utilisateur

Fujitsu

Fujitsu LifeBook B2150 Manuel utilisateur

Fujitsu

Fujitsu Lifebook T580 Manuel utilisateur

Fujitsu

Fujitsu Lifebook A1110 Guide Manuel utilisateur

Fujitsu

Fujitsu LIFEBOOK T935 Manuel utilisateur

Fujitsu

Fujitsu Lifebook LH530 Manuel utilisateur

Fujitsu

Fujitsu LifeBook C6544 Manuel utilisateur

Fujitsu

Fujitsu FI-6750S Manuel utilisateur

Fujitsu

Fujitsu LifeBook S2210 Manuel

Fujitsu

Fujitsu LifeBook E Series E8110 Manuel

Fujitsu

Fujitsu LifeBook Q2010 Manuel

Manuels Ordinateur portable populaires d'autres marques

HP ze2401xt - Pavilion Notebook PC Manuel utilisateur

Velocity

Velocity NoteMagix M10 Manuel utilisateur

Dell

Dell Alienware 17 R2 Manuel utilisateur

Toshiba

Toshiba A105-S2236 Manuel utilisateur

HP ENVY 17 Manuel

Winbook

Winbook LM Manuel utilisateur

Dell

Dell Inspiron 1464 Manuel utilisateur

Dell

Dell Inspiron 15R 5537 Manuel utilisateur

HP PROBOOK 4520S Manuel

Dell

Dell Latitude ATG D620 Manuel utilisateur

Sony

Sony VAIO PCG-FX270 Manuel utilisateur

Dell

Dell Latitude 7310 Manuel utilisateur

Dell

Dell Precision GU806 Manuel utilisateur

Sony

Sony VAIO PCG-R505JLK Manuel utilisateur

Lenovo

Lenovo THINKPAD X32 Manuel utilisateur

HP Compaq tc4200 Guide de démarrage rapide

Toshiba

Toshiba mini NB300 Manuel utilisateur

Lenovo

Lenovo ThinkPad X201 Tablet Manuel
