DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 1 / 6 http://ts.fujitsu.com/tabletpc
DATASHEET
FUJITSU LIFEBOOK T5010 TABLET PC
YOUR ULTIMATE MOBILE MEETING TOOL
LIFEBOOK T5010
The LIFEBOOK T5010 is a slim lightweight Convertible Notebook with a modular bay. The brilliant 33.8 cm
(13.3-inch) TFT display with active digitizer or dual digitizer guarantees comfortable working whatever the
application. Enjoy the advantages of exible pen-based entries, such as automatic handwriting recognition
and many other special features that only a Convertible Notebook can offer. The integrated UMTS gives
you the freedom to work wherever you want.
PEN-BASED WORK WITHOUT ANY RESTRICTIONS
Give your work that personal handwritten touch and enjoy the benets of multiple touch with the dual
diigitizer option
Bidirectional swivel 33.8 cm (13.3-inch) display, active digitizer or dual digitizer
FLEXIBLE WORKING
Increase your productivity and adapt the notebook to your particular way of work.
Modular bay for an optional second hard disk or second battery, pen-based software
MAXIMUM CONNECTIVITY
Be available wherever you are; wireless connectivity anytime anywhere, even if there is no hotspot
nearby.
Optional embedded 3G/UMTS, WLAN and Bluetooth
MORE THAN ENOUGH PERFORMANCE
More processes per second. Save time thanks to faster data processing.
Intel® Turbo memory module, Intel®Centrino®2 with vPro™ technology
HIGHEST SECURITY
Maximum data security thanks to the optionally integrated TPM module
End-to-end anti-theft features with Advanced Theft Protection
DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 2 / 6 http://ts.fujitsu.com/tabletpc
COMPONENTS
PROCESSOR Intel® Core™2 Duo processor T9600 (2.8 GHz, 6 MB, 1066 MHz)
Intel® Core™2 Duo processor P8800 (2.66 GHz, 3 MB, 1066 MHz)
Intel® Core™2 Duo processor P8700 (2.53 GHz, 3 MB, 1066 MHz)
MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
Supported capacity RAM (max.) 8 GB
Memory slots total 2
Memory slot type DIMM (DDR3)
HARD DISK DRIVES (INTERNAL) SSD SATA, 128 GB, 2.5-inch
SSD SATA, 80 GB, 2.5-inch
SATA, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
FDE, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
WLAN (OPTIONAL) Atheros Minicard b/g 802.11 b/g
Intel® Wireless WiFi Link 5300 AGN 11/13ch
WIRELESS TECHNOLOGIES
Antennas 3 Dual band WLAN antennas, 2 UMTS antennas, 1 Bluetooth
WLAN notes Import and usage according to country-specic regulations.
3G/UMTS (OPTIONAL) Sierra Wireless MC8790 (downlink 7.2 Mbit/s, uplink 2.0 Mbit/s)
DISPLAY 33.8 cm (13.3-inch), TFT, (WXGA), anti-glare (“Berliner Glass”) display, 1280 x 800 pixel
BLUETOOTH (OPTIONAL) Bluetooth 2.1
MODULAR BAY OPTIONS 2nd battery
2nd hard disk drive
DVD Super Multi
Weight saver
Base unit LIFEBOOK T5010 LIFEBOOK T5010 dual digitizer
GENERAL SYSTEM INFORMATION
Chipset Intel® GM45, ICH 9-ME
BIOS features BIOS Flash EPROM
BIOS based on Phoenix TrustedCore Notebook
Display 33.8 cm (13.3-inch), TFT active digitizer, (WXGA), glossy or
anti-glare (“Berliner Glass”) display, 1280 x 800 pixel
33.8 cm (13.3-inch), TFT dual digitizer, (WXGA), anti-glare
display, 1280 x 800 pixel
Display notes Wide-View High-Bright LED WXGA Display (for enhanced outdoor viewing)
GRAPHICS
Max. resolution external display 1920 x 1200 / true color / 85 Hz
Graphics brand name Mobile Intel® Graphics Media Accelerator 4500MHD
Graphics features DualView (Windows® XP & Windows®Vista)
INTERFACES
Memory card slots 1 (for SD/SDHC/SDXC/MS/MSPro) 1 (for SD/SDHC/SDXC/MS/MSPro)
ExpressCard slots 1 (34mm and 54mm supported) 1 (34mm and 54mm supported)
SmartCard slot 1 1
SIM card slot 1 (optional) 1 (optional)
DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 3 / 6 http://ts.fujitsu.com/tabletpc
INTERFACES
Modem (RJ-11) 1 (optional) 1 (optional)
USB 2.0 total 3 3
FireWire (IEEE1394) 1 1
VGA 1 1
Ethernet (RJ-45) 1 1
DC-in 1 1
Audio: line-in / microphone 1 1
Audio: line-out / headphone 1 1
Internal microphones 2 2
Docking connector for Port Replicator 1 1
Kensington Lock support 2 2
WIRED COMMUNICATION
Modem type Optional: 56 K V.92 modem MDC1.5
LAN Built-in 10/100/1000 MBit/s Intel®82567 LM
KEYBOARD AND POINTING DEVICES
Spill-resistant keyboard
Number of keyboard keys: 85, Keyboard pitch: 19 mm, Keyboard stroke: 2.7 mm
Touchpad with two mouse buttons and one scroll button
Fingerprint sensor
Launch keys
Status LED
Application buttons
Tablet Pen
Touchpad with two mouse buttons and one scroll button
Fingerprint sensor
Launch keys
Status LED
Application buttons
Tablet Pen
Touch-screen
MULTIMEDIA
Audio type On board
Audio codec Realtek ALC269
Audio features Stereo speakers, 2 internal microphones
Camera Optional: Built-in webcam, 1.3 megapixel
POWER SUPPLY
AC adapter 19 V / 80 W (4.22 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
1st battery Li-Ion battery 6-cell, 5800 mAh, 62.64 Wh
2nd battery (optional) Li-Ion battery 3-cell, 3800 mAh, 41 Wh
Battery features Dynamic charge supported (rapid charge)
Benchmark Mobile Mark 2005
Runtime 1st battery up to 6 h
Runtime 1st + 2nd battery up to 9 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time depends on usage.
POWER CONSUMPTION
Power consumption note See white paper Energy Consumption
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=2a742509-dd72-459d-a48b-4f801fbb3014
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 319 x 244 x 36.5 (without foot) mm
Weight 2.0 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 20 - 85 % (running)
DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 4 / 6 http://ts.fujitsu.com/tabletpc
OPERATING SYSTEM
Operating system optional preinstalled Microsoft® Windows Vista®Business 32-bit
Microsoft® Windows®7 Professional 32-bit
TwinLoad Microsoft® Windows® XP Tablet PC Edition 2005 (DVD)
Operating system compatible Microsoft® Windows® XP Tablet PC Edition 2005
Operating system notes Driver support for Microsoft® Windows® XP
ADDITIONAL SOFTWARE
Additional software (preinstalled) Adobe Acrobat Reader
Application Panel
Camera
Nero Essentials (burning software)
Norton Internet Security (incl. Firewall) on Drivers & Utilities
DVD for Microsoft Windows XP
Tablet Button Utility
Display Manager
Power Saving Utility
ShockSensor Utility
Wireless Selector Utility
Adobe Acrobat Reader
Application Panel
Camera
Nero Essentials (burning software)
Norton Internet Security (incl. Firewall) on Drivers & Utilities
DVD for Microsoft Windows XP
Tablet Button Utility
Microsoft® Touch Pack for Windows®7
Display Manager
Power Saving Utility
ShockSensor Utility
Wireless Selector Utility
Additional software (optional) Drivers & Utilities DVD (DUDVD)
UMTS connection manager (optional with UMTS)
DVD playback software
Recovery DVD (Windows®7)
Recovery DVD (Windows Vista®)
Additional software (included as a CD/
DVD)
SmartCase Logon+
MANAGEABILITY
Manageability features DeskUpdate Driver management
iAMT Intel Active Manageability Technology v4.0 (not activated, not provisioned, for Windows XP Professional and Windows
Vista Business only)
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Supported standards WMI
PXE
BootP (made4you)
Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html
SECURITY
Physical security Kensington Lock support
System security Advanced Theft Protection
Computrace®enabled BIOS
Norton Internet Security (incl. Firewall) 90 days version
Write protect option for the Flash EPROM
Control of all USB interfaces
Optional: Trusted platform module (TPM 1.2)
User security Integrated Fingerprint Sensor
Hard disk password
SystemLock BIOS SmartCard security
SmartCase Logon+ incl. ngerprint & security software
User and supervisor BIOS password
Integrated SmartCard slot
SystemLock BIOS SmartCard security
Hard disk password
SystemLock BIOS SmartCard security
SmartCase Logon+ incl. ngerprint & security software
User and supervisor BIOS password
Integrated SmartCard slot
SystemLock BIOS SmartCard security
Integrated Fingerprint Sensor
COMPLIANCE
Model LIFEBOOK T5010
DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 5 / 6 http://ts.fujitsu.com/tabletpc
COMPLIANCE
Germany GS optional
Europe CE
CE!
CB
USA/Canada cUL
FCC Class B
Global Microsoft Operating Systems (HCT / HCL entry / WHQL)
RoHS (Restriction of hazardous substances)
WiFi certied
ENERGY STAR®5.0
WEEE (Waste electrical and electronical equipment)
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
PORTREPLICATOR INTERFACES (OPTIONAL)
DC-in 1 1
Power on switch 1 1
Audio: line-out 1 1
USB 2.0 total 4 4
VGA 1 1
DVI 1 1
HDMI 1 1
Ethernet (RJ-45) 1 1
Kensington Lock support 1 1
WARRANTY
Standard Warranty 2 years
Service level Collect & Return Service (depending on country)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION
Recommended Service 3 years, Collect and Return Service, where available: Executive On-site Service
Spare Parts availability 5 years
Service Weblink htttp://ts.fujitsu.com/Supportservice
RECOMMENDED ACCESSORIES
DATASHEET FUJITSU LIFEBOOK T5010 TABLET PC
Page 6 / 6 http://ts.fujitsu.com/tabletpc
CONTACT
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-06-01 CE-EN
FUJITSU PLATFORM SOLUTIONS
In addition to Fujitsu LIFEBOOK T5010, Fujitsu
provides a range of platform solutions. They
combine reliable Fujitsu products with the best in
services, know-how and worldwide partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-Service.
How much you benet from Fujitsu technologies
and services depends on the level of cooperation
you choose. This takes IT exibility and efciency
to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
MORE INFORMATION
Learn more about Fujitsu LIFEBOOK T5010,
please contact your Fujitsu sales representative
or Fujitsu Business partner, or visit our website.
http://ts.fujitsu.com/tabletpc
FUJITSU GREEN POLICY INNOVATION
Fujitsu Green Policy Innovation is our worldwide
project for reducing burdens on the environment.
Using our global know-how, we aim to resolve
issues of environmental energy efciency
through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment/
COPYRIGHTS
All rights reserved, including intellectual property
rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that
the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their own
purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/
terms_of_use.html
Copyright © Fujitsu Technology Solutions
DISCLAIMER
Technical data are subject to modication and
delivery subject to availability. Any liability that
the data and illustrations are complete, actual
or correct is excluded. Designations may be
trademarks and/or copyrights of the respective
manufacturer, the use of which by third parties
for their own purposes may infringe the rights of
such owner
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Fujitsu Ordinateur portable
Fujitsu
Fujitsu Lifebook T730 Manuel utilisateur
Fujitsu
Fujitsu LifeBook V700 Manuel utilisateur
Fujitsu
Fujitsu Lifebook N6210 Manuel utilisateur
Fujitsu
Fujitsu S6520 - LifeBook - Core 2 Duo 2.4 GHz Manuel utilisateur
Fujitsu
Fujitsu Lifebook P1110 Manuel
Fujitsu
Fujitsu LifeBook B2610 Manuel utilisateur
Fujitsu
Fujitsu LIFEBOOK A556 Manuel utilisateur
Fujitsu
Fujitsu P1610 - LifeBook - Core Solo 1.2 GHz Guide de référence
Fujitsu
Fujitsu LifeBook P5020 Manuel
Fujitsu
Fujitsu CELSIUS H270 Manuel utilisateur
Fujitsu
Fujitsu S6520 - LifeBook - Core 2 Duo 2.4 GHz Manuel
Fujitsu
Fujitsu V1020 - LifeBook - Core 2 Duo GHz Manuel utilisateur
Fujitsu
Fujitsu E Series Manuel utilisateur
Fujitsu
Fujitsu A1220 - LifeBook - Core 2 Duo 2.2 GHz Manuel utilisateur
Fujitsu
Fujitsu S7220 - LifeBook - Core 2 Duo 2.4 GHz Manuel de la liste des pièces
Fujitsu
Fujitsu LifeBook S-4530 Manuel utilisateur
Fujitsu
Fujitsu Lifebook P771 Manuel utilisateur
Fujitsu
Fujitsu S7210 - LifeBook - Core 2 Duo 2.2 GHz Manuel utilisateur
Fujitsu
Fujitsu CELSIUS H7613 Manuel utilisateur
Fujitsu
Fujitsu P3010 - LifeBook - Athlon Neo 1.6 MHz Manuel utilisateur
