DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 1 / 6 http://ts.fujitsu.com/mobile
DATASHEET
FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
SMALL SIZE, BIG BUSINESS
ESPRIMO MOBILE U9210
You are frequently “on the road”? Travelling from city to city, from one meeting to the next? Then the
ESPRIMO Mobile U series is exactly the right travel companion for you. This small solid notebook ESPRIMO
Mobile U9210 with WXGA display in 30.7 cm (12.1-inch) format and the latest Intel®Centrino®dual
processor technology enables you to access all your relevant business data wherever you are. It is the
perfect combination: small in size, long battery life and unlimited connectivity. With its new clear-line
design the ESPRIMO Mobile U ts perfectly into your ofce environment.
A SMALL NOTEBOOK TO MEET BIG CHALLENGES
Compact notebook containing all the latest state-of-the-art components
30.7 cm (12.1-inch) WXGA display Intel®Centrino®dual processor technology
UNLIMITED MOBILITY
High performance and unrestricted connectivity enables constant data access and maximum productivity.
Intel®Centrino®dual processor technology, 3G/UMTS, WLAN, Bluetooth, optional integrated ConfCam
EXTREME RELIABILITY
Stable housing and innovative functions, built to meet the highest requirements.
ShockSensor, spill-proof keyboard, robust magnesium cover and housing
GREAT FLEXIBILITY
The family concept offers standardized accessory components for the ESPRIMO Mobile U, M, D, X series.
Standardized port replicator, power supply unit and modular bay for optical drive, second battery,
second hard disk or ExpressCard
MAXIMUM SECURITY
Protect your company data against unauthorized third-party access.
Computrace®enabled BIOS, integrated SmartCard reader, optional TPM module and SmartCase
Logon+
N
O
R
D
I
C
E
C
O
L
A
B
E
L
BEST CONNECTIVITY
FAMILY CONCEPT
CONFCAM
DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 2 / 6 http://ts.fujitsu.com/mobile
COMPONENTS
PROCESSOR Intel®Core™2 Duo processor T9600 (2.8 GHz, 6 MB, 1066 MHz)
Intel®Core™2 Duo processor P8800 (2.66 GHz, 3 MB, 1066 MHz)
Intel®Core™2 Duo processor P8700 (2.53 GHz, 3 MB, 1066 MHz)
Intel®Celeron®processor 585 (2.16 GHz, 1 MB, 667 MHz)
MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
Supported capacity RAM (max.) 4 GB
Memory slots total 2
Memory slot type DIMM (DDR3)
Memory notes 8 GB - with future memory modules.
HARD DISK DRIVES (INTERNAL) 320 GB, 7200 rpm, SATA, 2.5-inch S.M.A.R.T.
320 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.
320 GB, 5400 rpm, FDE-4, 2.5-inch S.M.A.R.T.
160 GB, 7200 rpm, SATA, 2.5-inch S.M.A.R.T.
160 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
WLAN (OPTIONAL) Atheros Minicard b/g 802.11 b/g
Intel®Wireless WiFi Link 5300 AGN 11/13ch
WIRELESS TECHNOLOGIES
Antennas 3 Dual band WLAN antennas, 2 UMTS antennas
WLAN notes Import and usage according to country-specic regulations.
UMTS/HSUPA (OPTIONAL) Option UMTS GTM 382 (downlink 7.2 Mbit/s, uplink 2.0 Mbit/s)
BLUETOOTH (OPTIONAL) Bluetooth 2.1
DISPLAY
Base unit name ESPRIMO Mobile U9210
Display 30.7 cm (12.1-inch); TFT; (WXGA); anti-glare display; 1280 x 800 pixel
MODULAR BAY OPTIONS 2nd battery
2nd hard disk drive
DVD Super Multi
Weight saver
Base unit ESPRIMO Mobile U9210
GENERAL SYSTEM INFORMATION
Chipset Intel®GM45, ICH 9-M
Intel platform Intel®Centrino®technology
BIOS features BIOS based on Phoenix TrustedCore Notebook
GRAPHICS
Max. resolution external display 1920 x 1200 / true color / 60 Hz
Graphics brand name Mobile Intel®GMA 4500M HD
Graphics features DualView (Windows®XP & Windows®Vista)
INTERFACES
Memory card slots 1 (SD/MMC/MS/MSPro/XD)
ExpressCard slots Optional in bay module
SIM card slot 1
Modem (RJ-11) Optional
DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 3 / 6 http://ts.fujitsu.com/mobile
INTERFACES
USB 2.0 total 3 (2x USB 2.0, 1x eSATA & USB port)
VGA 1
Ethernet (RJ-45) 1
DC-in 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
Internal microphones 2
Docking connector for Port Replicator 1
Kensington Lock support 1
WIRED COMMUNICATION
Modem type Optional: 56 K V.92 modem MDC1.5
LAN Built-in 10/100/1000 MBit/s Intel®82567 LF
KEYBOARD AND POINTING DEVICES
Spill-resistant keyboard
Number of keyboard keys: 86, Keyboard pitch: 19 mm, Keyboard stroke: 2.7 mm
Touchpad with two mouse buttons
Application buttons
INPUT DEVICES (OPTIONAL) Optional: TouchStick
MULTIMEDIA
Audio type On board
Audio codec Realtek ALC262
Audio features Stereo speakers, Internal microphone (array)
Camera Optional: Built-in webcam, 1.3 megapixel, VGA camera
POWER SUPPLY
AC adapter 20 V / 90 W (4.5 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
1st battery Li-Ion battery 6-cell, 5200 mAh, 57 Wh
2nd battery (optional) Optional: Li-Ion battery 6-cell, 3800 mAh, 40 Wh
Battery features Dynamic charge supported (rapid charge)
Runtime 1st battery up to 6 h
Runtime 1st + 2nd battery up to 10 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time depends on usage.
POWER CONSUMPTION
Power consumption note See white paper Energy Consumption
Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=fbb0bd8b-cef6-4312-9f34-57e0e79181aa
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 300 x 229 x 36.5 mm
Weight 1.95 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 20 - 85 % (running)
OPERATING SYSTEM
Operating system optional preinstalled Microsoft®Windows®7 Professional 32-bit
Microsoft®Windows Vista®Business 32-bit
Microsoft®Windows Vista®Home Basic 32-bit
TwinLoad Microsoft®Windows®XP Professional (DVD)
Operating system compatible Microsoft®Windows®XP Professional
Operating system notes Driver support for Microsoft®Windows®XP
DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 4 / 6 http://ts.fujitsu.com/mobile
ADDITIONAL SOFTWARE
Additional software (preinstalled) Adobe Acrobat Reader
Camera
EasyGuide online user documentation
Nero Essentials (burning software)
Norton Internet Security (incl. Firewall) on Drivers & Utilities DVD for Microsoft Windows XP
Drivers & Utilities DVD (DUDVD)
Toshiba Bluetooth Stack (only with Windows Vista®or Windows®XP operating systems)
Mobile Software Suite:
Application Button Utility
Wireless Selector Utility
ShockSensor Utility
Fan Control Utility
Power Saving Utility
Additional software (optional) Windows Vista®recovery media
Drivers & Utilities DVD (DUDVD)
UMTS connection manager (optional with UMTS)
DVD playback software
MANAGEABILITY
Manageability features DeskUpdate Driver management
DeskView Migrate (optional)
DeskView Control (optional)
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Security Remote Control
DeskView Helpdesk Integration
WoL (Wake on LAN)
Supported standards PXE
BootP (made4you)
WMI
Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html
SECURITY
Physical security Kensington Lock support
System security Optional: Trusted platform module (TPM 1.2)
Symantec Norton Internet Security (90 day test version)
User security Hard disk password
User and supervisor BIOS password
Separate SmartCard slot
SystemLock 2 BIOS SmartCard Security
COMPLIANCE
Germany GS
Europe CE
CE!
Nordic Swan
USA/Canada FCC Class B (depending on wireless conguration)
UL
cUL
Global RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronical equipment)
ENERGY STAR®5.0
Microsoft Operating Systems (HCT / HCL entry / WHQL)
WiFi certied
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
PORTREPLICATOR INTERFACES (OPTIONAL)
DC-in 1
Power on switch 1
DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 5 / 6 http://ts.fujitsu.com/mobile
PORTREPLICATOR INTERFACES (OPTIONAL)
Audio: headphone 1
Audio: microphone 1
USB 2.0 total 4
VGA 1
DVI 1, DVI-D single link, maximal resolution 1920 x 1200 pixel (WUXGA)
Serial (RS-232) 1
Mouse / Keyboard (PS/2) 1
Ethernet (RJ-45) 1
Parallel 1
Kensington Lock support 2
eSATA 1
RECOMMENDED ACCESSORIES
AC Adapter S26391-F740-L100
1st battery S26391-F746-L500
2nd battery S26391-F746-L100
Memory (2GB) S26391-F736-L200
2nd hard disk S26391-F727-L300
S26391-F728-L300
DVD super Multi S26391-F725-L200
Port replicator S26391-F740-L500
Port replicator / AC adapter / cable kit S26391-F740-L2001 (EU cable)
S26391-F740-L3002 (UK cable)
Recommended cases S26391-F119-L50
S26391-F119-L73
WARRANTY
Standard Warranty 1 year
Service level Collect & Return Service / Bring-In Service (depending on country)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION
Recommended Service 3 years, On-site Service
Spare Parts availability 5 years
Service Weblink htttp://ts.fujitsu.com/Supportservice
DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK
Page 6 / 6 http://ts.fujitsu.com/mobile
CONTACT
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-01-25 CE-EN
FUJITSU PLATFORM SOLUTIONS
In addition to Fujitsu ESPRIMO Mobile U9210,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach,Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructureas-a-Service.
How much you benet from Fujitsu technologies
and services depends on the level of cooperation
you choose. This takes IT exibility and efciency
to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
MORE INFORMATION
Learn more about Fujitsu ESPRIMO Mobile
U9210, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
http://ts.fujitsu.com/mobile
FUJITSU GREEN POLICY INNOVATION
Fujitsu Green Policy Innovation is our worldwide
project for reducing burdens on the environment.
Using our global know-how, we aim to resolve
issues of environmental energy efciency
through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment/
COPYRIGHTS
All rights reserved, including intellectual property
rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that
the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their own
purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/
terms_of_use.html
Copyright © Fujitsu Technology Solutions
DISCLAIMER
Technical data are subject to modication and
delivery subject to availability. Any liability that
the data and illustrations are complete, actual
or correct is excluded. Designations may be
trademarks and/or copyrights of the respective
manufacturer, the use of which by third parties
for their own purposes may infringe the rights of
such owner
Table des matières
Autres manuels Fujitsu Ordinateur portable
Fujitsu
Fujitsu N6010 - LifeBook - Mobile Pentium 4 3.2 GHz Manuel utilisateur
Fujitsu
Fujitsu A1130 - Lifebook T6500 4GB 500GB Manuel utilisateur
Fujitsu
Fujitsu Lifebook AH550 Manuel utilisateur
Fujitsu
Fujitsu CELSIUS H7510 Manuel utilisateur
Fujitsu
Fujitsu FPCR34121 Manuel utilisateur
Fujitsu
Fujitsu S7210 - LifeBook - Core 2 Duo 2.2 GHz Manuel utilisateur
Fujitsu
Fujitsu CELSIUS H7613 Manuel utilisateur
Fujitsu
Fujitsu Lifebook E-6624 Manuel
Fujitsu
Fujitsu E8420 - LifeBook - Core 2 Duo 2.26 GHz Manuel
Fujitsu
Fujitsu LifeBook UH572 Manuel utilisateur
Fujitsu
Fujitsu S7110 - LifeBook - Core 2 Duo 1.83 GHz Manuel
Fujitsu
Fujitsu LIFEBOOK Notebook Manuel utilisateur
Fujitsu
Fujitsu Lifebook A3130 Manuel
Fujitsu
Fujitsu LifeBook C series Manuel utilisateur
Fujitsu
Fujitsu LifeBook B6110D Manuel utilisateur
Fujitsu
Fujitsu LifeBook E752 Manuel utilisateur
Fujitsu
Fujitsu T5010 - LifeBook Tablet PC Manuel utilisateur
Fujitsu
Fujitsu LifeBook T4210 Manuel
Fujitsu
Fujitsu U820 - LifeBook Mini-Notebook - Atom 1.6 GHz Manuel de service
Fujitsu
Fujitsu LifeBook A6010 Manuel utilisateur
