Fujitsu AMILO Pro V2040 Manuel utilisateur

Amilo Pro V2040

Service Guide

PART NO.: 49.46I01.001 PRINTED IN TAIWAN

Revision History

Please refer to the table below for the updates made on Amilo Pro V2040 service guide.

Date Chapter Updates

III

reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer

language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of Wistron Incorporated.

Disclaimer

The information in this guide is subject to change without notice.

Wistron Incorporated makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular

purpose. Any Wistron Incorporated software described in this manual is sold or licensed "as is". Should the

programs prove defective following their purchase, the buyer (and not Wistron Incorporated, its distributor, or

its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential

damages resulting from any defect in the software.

Intel is a registered trademark of Intel Corporation.

Pentium is a registered trademark of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks of their respective holders.

Conventions

The following conventions are used in this manual:

Screen messages Denotes actual messages that appear

on screen.

NOTE Gives bits and pieces of additional

information related to the current

topic.

WARNING Alerts you to any damage that might

result from doing or not doing specific

actions.

CAUTION Gives precautionary measures to

avoid possible hardware or software

problems.

IMPORTANT Reminds you to do specific actions

relevant to the accomplishment of

procedures.

Preface

Before using this information and the product it supports, please read the following general information.

1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION

decided for Wistron "global" product offering. To better fit local market requirements and enhance product

competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.

add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered

in this generic service guide. In such cases, please contact your regional offices or the responsible

personnel/channel to provide you with further technical details.

2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information

available on your regional web or channel. If, for whatever reason, a part number change is made, it will

not be noted in the printed Service Guide. For Medion AUTHORIZED SERVICE PROVIDERS, your

Medion office may have a DIFFERENT part number code to those given in the FRU list of this printed

Service Guide. You MUST use the list provided by your regional Medion office to order FRU parts for

repair and service of customer machines.

Chapter 1 1

This document contains step-by-step procedures on how to disassemble the notebook computer for

maintenance and troubleshooting.

To disassemble the computer, you need the following tools:

TWrist grounding strap and conductive mat for preventing electrostatic discharge

TFlat screwdriver

TPhillips screwdriver

THex screwdriver

TPlastic flat screwdriver

NOTE: The screws for the different components vary in size. During the disassembly process, group the

screws with the corresponding components to avoid mismatch when putting back the components.

Chapter 1

Machine Disassembly and Replacement

2Amilo Pro V2040

General Information

Before You Begin

Before proceeding with the disassembly procedure, make sure that you do the following:

1. Turn off the power to the system and all peripherals.

2. Unplug the AC adapter and all power and signal cables from the system.

3. Remove the battery pack.

Disassembly Procedure Flowchart

The flowchart on the succeeding page gives you a graphic representation on the entire disassembly sequence

and instructs you on the components that need to be removed during servicing. For example, if you want to

remove the main board, you must first remove the keyboard, then disassemble the inside assembly frame in

that order.

I x 1

J x1

Start

E x 2

A x 1

Hard Disk

Drive Cover

Hard Disk

Drive

Bracket

Hard Disk

Drive

Hard Disk

Drive

Module

A x 2 F x 4

A x 8

Lower

Cover

Thermal

Module

CPU

Modem

Board

Optical

Disk

Drive

B x 1

D x 1

Optical Disk

Drive Module

Optical

Bracket

C x 4

G x 2

B x 2

Middle Cover

C x 1A x 1

DIMM

Plate

DIMM

Keyboard

B x 15

C x 1

A x 1

Upper Case

D x 4

Touch Pad

Bracket

Touch Pad

Board

D x 4

Touch Pad

Bracket

Touch Pad

Board

A x 2

H x 1 G x 1

FAN

G x 1

Lower

Case

G x 1

Right

Speaker

Main Board

Battery

RTC

Battery

Left

Speaker

LCD Module Wireless

LAN

Board

4Amilo Pro V2040

Screw List

Item Description

A SCREW M2XL4 (Black)

B SCREW M2.5XL6 (Black)

C SCREW M2.5XL8 (Silver)

D SCREW M2XL3 (Silver)

E SCREW M3XL4 (Silver)

F SCREW CPU SPRING (Silver)

G SCREW M2.5XL5 (Silver)

H SCREW M2XL2 (Silver)

I SCREW M2XL6 (Silver)

J SCREW NUT M2.5XL2.5 (Silver)

D x 4D x 4

G x 3

G x 1

Inverter Board

G x 1

Inverter Board

LCD Module

B x 2

Right Hinge

B x 2

Right Hinge

LCD FPC

Cable

LCD Assembly LCD Panel

D x 2

Main Antenna D x 2

Aux Antenna

D x 2

Aux Antenna

B x 2

LCD Bezel

B x 2

LCD Bezel

B x 2

Left Hinge

B x 2

Left Hinge

Left LCD

Bracket Right LCD

Bracket

LCD
