TABLE OF CONTENTS

FEATURES

Mini-Splits Defined.......................................... 4

Individual Zoning ............................................ 6

Comfort Solution ............................................ 8

Energy Efficient ............................................. 9

Comfort & Convenience ............................... 10

Applications .................................................. 11

Feature Descriptions .................................... 12

MODEL LINEUP

Indoor and Outdoor Model Table .................. 14

SINGLE ZONE MINI-SPLITS

Wall Mount ................................................... 17

Floor/Ceiling ................................................. 23

Ceiling Suspended ....................................... 23

Duct .............................................................. 24

Compact Cassette ........................................ 26

Large Cassette ............................................. 28

MULTI-ZONE MINI-SPLITS

Overview ...................................................... 31

Indoor Units

Wall Mount ............................................... 33

Duct .......................................................... 34

Compact Cassette ................................... 35

Multi-Zone (2-4 Zones) Outdoor .................. 36

Flex-Zone (2-8 Zones) Outdoor ................... 37

Branch Boxes ........................................... 38

Wiring ........................................................ 40

Piping ........................................................ 41

Allowable Combinations ............................... 42

ACCESSORIES

Descriptions .................................................. 44

Compatibility Chart ....................................... 45

MISCELLANEOUS

Line Set Length Chart ................................... 46

Model Nomenclature .................................... 46

Fujitsu Mini-Splits:

Year-Round, Whole-Home or Business

Energy Efficient Heating and Cooling

compressor/

condenser

(outdoor)

FEATURES

What is a Mini-Split?

Halcyon systems eliminate the need for a

basement or attic-located evaporator unit and

bulky ductwork by using thin copper tubing

that pumps refrigerant directly to discreet wall

mounted or concealed units inside. Even more

remarkable, this same unit works in reverse in

winter, absorbing heat from the outside air and

moving it indoors to heat your home. The

result? Efficient cooling and heating for year-

round, whole-house comfort in most climates.

Available in numerous mix-and-match

capacities and configurations, there's a

Halcyon mini-split system for even the

most difficult to heat and cool areas.

How Does a Mini-Split Work?

Like your refrigerator, heat pumps use electricity to pump refrigerant and transfer heat from one space

to another. When we transfer heat from within our home to the outdoors, we call it "air conditioning".

Conversely, when we transfer heat from the outdoors to within the home, we call it a "heat-pump".

evaporator/

fancoil (indoor)

refrigerant lines,

electric, drain

Unit Can Be

Showcased...

Wall mounted units

eliminate the need

for ductwork, mount

high on a wall and

deliver all of the

cooling you pay for.

...or Hidden

Compact Duct units are

mounted above a

ceiling or in a framed

enclosure below a

ceiling, so only the

grilles show for a clean

look. They require

minimal ductwork.

air

return

grille

air

supply

grille

Compact Duct Unit

Wall Mount Unit

An electric heater converts electricity directly to

heat, and if we assume that the heat loss is zero,

the output from one kilowatt input is one kilowatt

or 3,400 BTU and the EER is 3.4.

Heat pumps are more efficient than some other forms

of heating because heat pumps do not actually create

heat - they just move it from one place to another.

For example, the output of an efficient 10 EER heat

pump is triple that of an electric heater.

Electric Heaters versus Heat Pumps

*EER (Energy Efficiency Rating) = Rated BTU capacity divided by total kW input.

Heat Pumps Provide Heat When it is Chilly

Because refrigerant is naturally much colder than outdoor

temperatures even on a very cold day, it actually absorbs heat

from outdoors, and transfers the heat it absorbs outside to

within your home. The refrigerant's physical properties do this

naturally. What you pay for is the electricity to pump refrigerant

via copper tubing from outdoors to indoors. Because we move

the heat rather than create it (as electric baseboard or resistant

heat does), we can deliver up to 4 times the heat for the energy

we consume!

Basic Heat Pump Configuration

compressor

evaporator

compressor

expansion

valve

Heat In

Heat

Out

Basic Air Conditioner Configuration

compressor

evaporator

compressor

expansion

valve

Heat Out

Heat

Air Conditioners Provide Cooling When It’s Warm

Come spring and summer, simply reverse the process and

put the same system into "cooling mode" and transfer heat

from indoors to the outside. For many climates, the advanced

technology that goes into these units creates a far more cost

effective alternative to either gas or oil-fired units for heat, or

a central ducted system for air conditioning. Fujitsu’s mini-splits

come in both cooling-only models or heat pumps, which

provide both heating and cooling.

FEATURES

Individual Zoning: Personalized Whole Home Comfort

Halcyon HFI Systems are some of today’s most advanced forms of heating and air

conditioning. One outdoor unit can operate up to 8 indoor units simultaneously. Fujitsu’s

HFI Systems are super quiet as well as highly energy efficient.

Each indoor unit can be operated independently via remote control

Choose from a variety of indoor unit styles

Provide both heating and cooling (not simultaneously)

High energy efficiencies

Quiet operation

Wall Mounted

Stylish, slim and elegant, wall

mounted units are designed to

complement any interior décor.

Compact size

Wireless remote control

Automatic swinging louvers

Shown here is a 3-zone system using outdoor unit AOU36RLXFZ.

flex

48,000 BTUs

multi

18, 24, 36,000 BTUs

Compact Duct

Mounted in a ceiling or in a framed

enclosure below a ceiling. They use

minimal ductwork and remain very

energy efficient.

Concealed and out of sight

Look of central air with the

efficiency of a mini-split

Less ducts = higher efficiency

Compact Cassette

Cassettes are extremely discreet, with

only the grille showing in the ceiling.

They use the latest fan technology to

distribute the conditioned air evenly.

Wired remote controller

(wireless is optional)

Powerful turbo fan operation

Fits into a standard 2’ x 2’

ceiling grid

Wall Mounted

They mount high on a wall, out of sight

and do not require ductwork, increasing

energy efficiency.

Quiet operation

Easy maintenance

High delivered efficiency means

lower utility bills

FEATURES

Whole Home or Business Comfort

Fujitsu's Halcyon HFI systems provide home

and business owners just the right amount of

heating and cooling needed by installing 2 to 8

indoor units connected to one outdoor unit.

Indoor units vary by size and style and each

creates its own "zone" of comfort, allowing you

to heat or cool individual rooms, hallways and

open spaces.

Thick black lines

represent ducts

of a Central Air

System.

Red lines

represent mini-

ducts of a Fujitsu

Quad Zone

Compact Duct

System.

Ductless Technology

Don’t waste money cooling and heating the ducts

in your walls and attic. Fujitsu systems are duct-

less, meaning they install easily and won’t take

up valuable closet space. Since mini-splits have

little to no ducting, they forego those energy

losses typically associated with central forced-air

systems. Duct losses in a central air system can

easily account for more than 30% of energy

consumption, especially if the ducts are not

sealed tight or in an unconditioned space such

as an attic or crawlspace.

Central Air System versus Fujitsu HFI Quad Zone

A Solution for All of Your Comfort Needs

2°

°F

8°

°F

4°

°F

0°

°F

A Year Round Solution

Revolutionary Halcyon heat pumps provide

both heating and cooling for year round comfort

in most climates. A simple push of a button on

the remote control allows you to switch from

heating to cooling (or vice versa) automatically.

Energy Efficient: The Smart Choice in Comfort

*Savings may vary based on model selected, hours of operation

and geographical location. Example given based on 26-SEER

system versus 13-SEER system.

Where Does My Money Go? Other

Electronics

Lighting

10%

Clothes

Washer &

Dryer 6%

Dishwasher

Refrigerator

5% Water

Heater

13%

Heating

& Cooling

49%

Fujitsu

saves 25%

on your

utility bill

Rebates

To encourage customers to buy energy efficient products, many

local utility companies offer significant rebates for the purchase

of a ductless mini-split system. Go to Fujitsu’s web site to search

for local rebates, consumer loans and utility bill discounts. We

provide a listing of rebates and offerings on qualifying Fujitsu

mini-splits by state. www.fujitsugeneral.com/utility_rebates.htm

As much as half of the energy used in your home goes to heating and cooling.

So, making smart decisions about your home’s heating and air conditioning

system can have a big effect on your utility bills — and your comfort.

The high energy efficiencies of

Halcyon systems slash utility

bills by up to 25%. If your

average annual utilities are

$4,200, Fujitsu can save you up to

$1,050 annually or $10,500 in 10 yrs!*

Federal Tax Credit Up To $300 through 2013

A tax credit can provide significant savings. It reduces the

amount of income tax you have to pay. Unlike a deduction,

which reduces the amount of income subject to tax, a tax

credit directly reduces the tax itself.

Federal tax credits are effective for systems purchased

through December 31, 2013 for “Qualified Energy Property”

The federal tax credit for qualified equipment is 10% of the

amount paid but shall not exceed $300 for the qualified

energy property.

Fujitsu has 16 qualifying systems in 2013

Check with your tax professional for details and visit

www.energystar.gov and click on “Tax Credits” for additional

information.

FEATURES

Comfort and Convenience

Flexible and Quiet

Mini splits offer flexibility because they can

be suspended from a ceiling, mounted flush

behind a drop ceiling, hung on a wall or floor-

standing. Ductless heat pumps allow for a

peaceful inside environment by enabling the

contractor to install components like

compressors and motors outdoors.

Weakest

Sound

Heard

Jet Engine

at 100’

Whisper

Quiet

Library

Normal

Conversation

from 3 - 5’

Power

Tools

140

105

dB(A) Level

Fujitsu

Indoor

Units

22~49

dB(A)

User Friendly Control

Fujitsu is using ergonomics to expand the use of

user friendly designs such as easy-to-read large

LCD displays, easy-to-operate buttons, and

displays with easily recognizable colors and icons.

We are producing control systems that provide

greater convenience for both individual and

centralized control with operability suitable

for the application.

Standard

Wireless

Remote for

RLS2 and

RLS2H

Systems

Optional Wired

Remote UTY-RVNUM

Constant Comfort through

Inverter Technology

Inverter technology is like cruise control for your

heating or cooling system. Compressors only run as

fast as they need to handle the cooling or heating

demand. They can handle greater extremes in

temperature, are smoother and more stable in

operation, and reach the desired temperature more

quickly than conventional air conditioners. Set

Temp.

Set

Temp.

Inverter System

Conventional

System

Inverter Benefits

More heat at lower outdoor temperatures

Lower RPMs = quieter operation

Desired temperature in half the time

Up to 30% more efficient

Stable temperature

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fujitsu Climatiseur

Fujitsu

Fujitsu ARY90ELA3 Manuel utilisateur

Fujitsu

Fujitsu UTZ-KXGC Manuel utilisateur

Fujitsu

Fujitsu ASYG09KGTA Manuel de service

Fujitsu

Fujitsu Suelo AGY40-KV Manuel utilisateur

Fujitsu

Fujitsu Halcyon ASU9RLS2 Manuel utilisateur

Fujitsu

Fujitsu AUU9RLF Manuel de service

Fujitsu

Fujitsu AU*A30LBLU Manuel de service

Fujitsu

Fujitsu Airstage AUUA4TLAV1 Manuel utilisateur

Fujitsu

Fujitsu Airstage AUXM018GLEH Manuel utilisateur

Fujitsu

Fujitsu Halcyon 9362292047 Manuel utilisateur

Fujitsu

Fujitsu ASU9RLS3 Manuel de service

Fujitsu

Fujitsu ABYG-LRTA Series Manuel utilisateur

Fujitsu

Fujitsu ASYG30LFCA Manuel utilisateur

Fujitsu

Fujitsu Inverter Halcyon ASU24RL Manuel utilisateur

Fujitsu

Fujitsu AIRSTAGE AU 25UF Series Manuel utilisateur

Fujitsu

Fujitsu AirStage ARXA30GBLH Manuel utilisateur

Fujitsu

Fujitsu AUYF18LBL Manuel utilisateur

Fujitsu

Fujitsu FG Nordic ABYG36-54LRTA Manuel utilisateur

Fujitsu

Fujitsu ASYG18KMTE Manuel de service

Fujitsu

Fujitsu AOHG22KBTB Manuel de service

Fujitsu

Fujitsu AirStage AG A004GCEH Series Manuel utilisateur

Fujitsu

Fujitsu Airstage VR-II ABUA30TLAV Manuel utilisateur

Fujitsu

Fujitsu ast9umad Manuel utilisateur

Fujitsu

Fujitsu ARTG65LHTA Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur

Webasto

Webasto Frigo Top 25 DS Manuel utilisateur
