AIR CONDITIONER

2-unit multi-split type

SERVICE MANUAL

INDOOR

AUXG07–14KVLA ARXG07–14KSLAP ARXG07–14KLLAP ASHG07–14KGTB

ASHG07–14KGTE ASHG07–14KMTB

ASHG07–14KMCC

ASHG07–14KMCE

ASHG07–14KETA

ASHG07–14KETE

ASHG07–14KETA-B

ASHG07–14KETE-B

AGHG09–14KVCA

OUTDOOR

AOHG14KBTA2 AOHG18KBTA2

SR_MU001EG_11

2022.04.13

Notices:

• Product specifications and design are subject to change without notice for future improvement.

• For further details, please check with our authorized dealer.

Trademarks

FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.

Google Play™ is trademark of Google Inc.

App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.

CONTENTS

1. GENERAL INFORMATION

2. TECHNICAL DATA AND PARTS LIST

3. TROUBLESHOOTING

4. CONTROL AND FUNCTIONS

5. FILED WORKING

1. GENERAL INFORMATION

2022.03.15

SR_CH01_MU001EG_04

CONTENTS

1. GENERAL INFORMATION

1. Specifications..............................................................................................01-1

1-1. Indoor unit ......................................................................................................................01-1

1-2. Outdoor unit..................................................................................................................01-12

2. Dimensions................................................................................................01-14

2-1. Compact cassette type .................................................................................................01-14

2-2. Mini duct type ...............................................................................................................01-16

2-3. Slim duct type ...............................................................................................................01-18

2-4. Wall mounted type........................................................................................................01-20

2-5. Floor type .....................................................................................................................01-30

2-6. Outdoor unit..................................................................................................................01-32

1. Specifications

1-1. Indoor unit

¢Compact cassette type

Model name AUXG07KVLA AUXG09KVLA AUXG12KVLA AUXG14KVLA

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power W 18 23 28

Running current A 0.15 0.19 0.22

Fan

Airflow rate

Cooling

HIGH

m3/h

540 610 680

MED 490 530 580

LOW 440 470 490

QUIET 390 410 410

Heating

HIGH 540 610 790

MED 490 530 680

LOW 440 470 580

QUIET 390 410 450

Type × Q'ty Turbo fan × 1

Motor output W 54

Sound pressure level *

Cooling

HIGH

dB (A)

33 37 38

MED 31 34 35

LOW 29 31 32

QUIET 27 28 29

Heating

HIGH 34 37 43

MED 32 34 38

LOW 29 31 34

QUIET 27 29 30

Sound power level Cooling dB (A) 46 49 50

Heating 47 49 55

Heat exchanger type

Dimensions (H × W × D) mm 210 × 1,310 × 13.3

210 × 1,250 × 13.3

Fin pitch mm 1.2

Rows × Stages Main1: 1 × 10

Main2: 1 × 10

Pipe type Copper tube

Fin type Aluminum

Dimensions

(H × W × D)

Net mm 245 × 570 × 570

Gross 265 × 730 × 625

Weight Net kg 15

Gross 19

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Drain hose Material PVC

Size mm VP25 (Ø 25 [I.D.], Ø 32 [O.D.])

Cassette grille

(Grid type: Option)

Model name UTG-UFGF-W

Material Polystyrene

Color White

Approximate color of Munsell 9PB 9.1/0.2

Dimensions

(H × W × D)

Net mm 49 × 620 × 620

Gross 120 × 765 × 755

Weight Net kg 2.3

Gross 4.5

NOTES:

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-1) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

¢Mini duct type

Model name ARXG07KSLAP ARXG09KSLAP ARXG12KSLAP ARXG14KSLAP

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power Fan

HIGH

33 40 47 72

MED 23 23 26 44

LOW 20 20 22 30

QUIET 18 18 18 18

Running current A 0.29 0.33 0.38 0.58

Fan

Airflow rate

Cooling

HIGH

m3/h

550 600 650 800

MED 440 450 490 640

LOW 390 400 430 530

QUIET 360 360 360 360

Heating

HIGH 550 600 650 800

MED 440 450 490 640

LOW 390 400 430 530

QUIET 360 360 360 360

Type × Q'ty Sirocco fan × 2

Motor output W 75

Recommended static pressure Pa 0 to 30 0 to 50

Sound pressure level *

Cooling

HIGH

dB (A)

29 29 31 35

MED 26 26 27 30

LOW 24 24 25 27

QUIET 23 23 23 23

Heating

HIGH 29 29 31 35

MED 26 26 27 30

LOW 24 24 25 27

QUIET 23 23 23 23

Sound power level Cooling dB (A) 52 54 55 60

Heating 53 56 57 62

Heat exchanger type

Dimensions (H × W × D) mm 336 × 490 × 26.6

Fin pitch mm 1.3

Rows × Stages 2 × 16

Pipe type Copper tube

Fin type Aluminum

Enclosure Material Steel sheet

Color —

Dimensions

(H × W × D)

Net mm 198 × 700 × 450

Gross 250 × 930 × 580

Weight Net kg 15.5

Gross 19.0

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Drain hose Material Hard PVC

Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)

NOTES:

• Values mentioned in the table are based on the following conditions:

– Static pressure: 07-12 models: 10 Pa, 14 model: 15 Pa

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-2) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

¢Slim duct type

Model name ARXG07KLLAP ARXG09KLLAP ARXG12KLLAP ARXG14KLLAP

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power W 33 49 58 76

Running current A 0.33 0.30 0.35 0.51

Fan

Airflow rate

Cooling

HIGH

m3/h

550 600 650 800

MED 490 550 600 700

LOW 470 500 550 600

QUIET 440 450 480 480

Heating

HIGH 550 600 650 800

MED 490 550 600 700

LOW 470 500 550 600

QUIET 440 450 480 480

Type × Q'ty Sirocco fan × 2

Motor output W 80 81

Recommended static pressure Pa 0 to 90

Sound pressure level *

Cooling

HIGH

dB (A)

28 28 29 32

MED 26 27 28 30

LOW 25 26 27 28

QUIET 24 25 26 26

Heating

HIGH 28 28 29 32

MED 26 26 28 30

LOW 25 25 27 28

QUIET 24 24 24 25

Sound power level Cooling dB (A) 57 58 60

Heating 57 58 60

Heat exchanger type

Dimensions (H × W × D) mm 294 × 500 × 26.6 294 × 500 × 39.9

Fin pitch mm 1.3

Rows × Stages 2 × 14 3 × 14

Pipe type Copper tube

Fin type Aluminum

Enclosure Material Steel sheet

Color —

Dimensions

(H × W × D)

Net mm 198 × 700 × 620

Gross 276 × 968 × 772

Weight Net kg 16 17

Gross 21 22

Connection

pipe

Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Drain hose Material PVC

Size mm Ø 25 (I.D.), Ø 32 (O.D.)

NOTES:

• Values mentioned in the table are based on the following conditions:

– Static pressure: 25 Pa

• The protective function might work when using it outside the operation range.

• *: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

1-1. Indoor unit - (01-3) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

¢Wall mounted type

Model name ASHG07KGTB ASHG09KGTB ASHG12KGTB ASHG14KGTB

Power supply 1Ø 230 V ~50 Hz

Available voltage range 198—264 V

Capacity kW class 2.0 2.5 3.5 4.0

Input power W 23 27 27 33

Running current A 0.20 0.24 0.24 0.29

Fan

Airflow rate

Cooling

HIGH

m3/h

650 700 700 770

MED 540 560 560 600

LOW 430 430 430 450

QUIET 270 270 270 280

Heating

HIGH 720 750 770 800

MED 580 610 640 660

LOW 460 470 520 520

QUIET 330 330 330 340

Type × Q'ty Crossflow fan × 1

Motor output W 30 49

Sound pressure level *1

Cooling

HIGH

dB (A)

38 40 40 43

MED 33 34 35 36

LOW 29 29 30 30

QUIET 21 21 21 21

Heating

HIGH 41 42 42 44

MED 35 36 38 39

LOW 31 31 33 33

QUIET 22 22 22 24

Sound power level Cooling dB (A) 54 55 56 57

Heating 56 57 58 59

Heat exchanger type

Dimensions (H × W × D) mm Main1: 210 × 670 × 26.6

Main2: 112 × 670 × 20.0

Main1: 210 × 670 × 26.6

Main2: 112 × 670 × 20.0

Sub: 84 × 670 × 13.3

Fin pitch mm Main1: 1.2

Main2: 1.1

Main1: 1.2

Main2: 1.1

Sub: 1.4

Rows × Stages Main1: 2 × 10

Main2: 2 × 7

Main1: 2 × 10

Main2: 2 × 7

Sub: 1 × 4

Pipe type Copper tube

Fin type Aluminum

Enclosure

Material Polystyrene

Color White + Pearl white (painted)

Approximate color of Munsell N 9.25/

Dimensions

(H × W × D)

Net mm 270 × 834 × 215

Gross 277 × 914 × 332

Weight Net kg 10.0

Gross 12.5 13.0

Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)

Gas Ø9.52 (Ø3/8)

Method Flare

Drain hose Material PP + HDPE

Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)

Operation range Cooling °C 18 to 32

%RH 80 or less

Heating °C 16 to 30

Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])

NOTES:

• The protective function might work when using it outside the operation range.

• *1: Sound pressure level:

– These are the measured values in the manufacturer’s anechoic chamber.

– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.

• *2: Available on Google Play™ store or on App Store®. Optional WLAN adapter is also required. For details, refer to the setting manual.

1-1. Indoor unit - (01-4) - 1. Specifications

GENERAL

INFORMATION

GENERAL

INFORMATION

Autres manuels pour AUXG07KVLA

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fujitsu Climatiseur

Fujitsu

Fujitsu ASY18LMA-W Manuel utilisateur

Fujitsu

Fujitsu ASYG09LLCA Manuel utilisateur

Fujitsu

Fujitsu ABU36RSLX Manuel utilisateur

Fujitsu

Fujitsu AST9RSG-W Manuel utilisateur

Fujitsu

Fujitsu AOYG12-14LBLA Manuel utilisateur

Fujitsu

Fujitsu Halcyon ASU9RLS2 Manuel de service

Fujitsu

Fujitsu AU*A45LCLU Manuel de service

Fujitsu

Fujitsu AOYR14LCL Manuel d'utilisation original

Fujitsu

Fujitsu ASYA07LGC Manuel utilisateur

Fujitsu

Fujitsu ARYG72LHTA Manuel d'utilisation original

Fujitsu

Fujitsu ASYG24LFCA Manuel utilisateur

Fujitsu

Fujitsu ASG07LLCC Manuel de service

Fujitsu

Fujitsu Halcyon HFI Systems Manuel utilisateur

Fujitsu

Fujitsu Inverter Halcyon ASU9RLS Manuel utilisateur

Fujitsu

Fujitsu ABYA12-24LBTH Manuel utilisateur

Fujitsu

Fujitsu AIRSTAGE J-III L AJ 072LELAH Series Manuel de service

Fujitsu

Fujitsu Halcyon Manuel utilisateur

Fujitsu

Fujitsu ASTB30LDC Manuel utilisateur

Fujitsu

Fujitsu ASU9R1 Manuel utilisateur

Fujitsu

Fujitsu AOYS09LDC Manuel utilisateur

Fujitsu

Fujitsu AU G18LVLB Series Manuel de service

Fujitsu

Fujitsu ARYA45LCTU Manuel utilisateur

Fujitsu

Fujitsu AO G12KATA Series Manuel d'utilisation original

Fujitsu

Fujitsu ASU18RLF Mode d'emploi

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur

Webasto

Webasto Frigo Top 25 DS Manuel utilisateur
