PRIMERGY 400 SERVER UMR

STANLEITUNG CONVERSION GUIDE

PRIMERGY 400 SERVER

TOWER-SERVER ↔RACK-SERVER

UMRÜSTANLEITUNG

Einleitun

Umrüstun

Tower-Server

in Rack-Serve

Umrüstun

Rack-Server

in Tower-Serve

Ausgabe Mai 2000

Alle genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der

jeweiligen Inhaber und werden als geschützt anerkannt.

des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

A26361-K482-Z121-2-7419

Contents

Introduction .....................................................................................................................................1

Notational conventions ......................................................................................................................1

Important notes .................................................................................................................................2

Converting a tower server into a rack server ................................................................................3

Checking the contents of delivery......................................................................................................3

Modifying the tower server.................................................................................................................5

Converting rack server to tower server .......................................................................................19

Checking the contents of delivery....................................................................................................19

Converting the rack server...............................................................................................................20

A26361-K482-Z121-2-7419 English - 1

Introduction

The two casing variants for PRIMERGY 400 servers offer great flexibility. The option of a

subsequent conversion to the alternate casing offers still greater flexibility and security against

obsolescence.

These instructions describe the steps necessary to change from tower server to rack server and

vice versa. You should also consult the publications "PRIMERGY 400 / 200 Server Systems" and

the Technical Handbook of the rack.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to texts marked with this symbol. Failure to observe this warning

endangers your life, destroys the devices, or may lead to loss of data.

Supplementary information, remarks and tips follow this symbol.

Ê Texts which follow this symbol describe activities that must be performed in the order shown.

Introduction

2 - English A26361-K482-Z121-2-7419

Important notes

!You should also observe the safety notes in the operating manual for your server or your

memory expansion unit.

Boards with electrostatic sensitive devices (ESD) may be identified by labels.

When you handle boards fitted with ESDs, you must observe the following points under all

circumstances:

• You must always discharge yourself (e.g. by touching a grounded object) before working.

• The equipment and tools you use must be free of static charges.

• Pull out the power plug before inserting or pulling out boards containing ESDs.

• Always hold boards with ESDs by their edges.

• Never touch pins or conductors on boards fitted with ESDs.
