Fuji Electric FRENIC-EcoPAK Manuel utilisateur

Fuji Electric Corp. of America FECA-IN-106 / 122010

Information subject to change without notice.

Instruction Manual

Non-Bypass Panels

FRENIC-EcoPAK

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 2 of 22

Safety Precautions

Read this manual thoroughly before proceeding with installation, connections (wiring), or

maintenance and inspection. Ensure you have sound knowledge of the device and

familiarize yourself with all safety information and precautions before proceeding to

operate the drive. Refer to the FRENIC-Eco drive instruction manual (INR-SI47-1225-E)

for further safety information.

Safety precautions are classified into the following two categories in this manual.

WARNING

Failure to heed the information indicated by this symbol may lead to dangerous

conditions, possibly resulting in death or serious bodily injuries.

CAUTION

Failure to heed the information indicated by this symbol may lead to dangerous

conditions, possibly resulting in minor or light bodily injuries and/or substantial property

damage.

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 3 of 22

FRENIC-EcoPAK Non-Bypass Panel Overview

The FRENIC-EcoPAK non-bypass panel is a packaged drive solution in a Type 1

enclosure. NEMA 12 ventilated enclosure is available as an option.

Features

Type 1 enclosure with “space-saving” footprint

Metallic enclosures to reduce radio frequency

interference (RFI)

Integral main disconnect with branch circuit

protection, including a padlockable through-the-door

operator handle mechanically interlocked with the

enclosure door

DC link reactor provided as standard to minimize

harmonics, with the option of a 3% or 5% AC line

reactor to minimize harmonics and provide transient

voltage protection for the drive

Control power transformer with primary & secondary

fusing

Door mounted drive keypad with backlit LCD and LED

displays for drive set-up, troubleshooting, local operation

control, maintenance indication, and operational indication

Damper Control Output Contacts

Built-in communications, user selectable between

Modbus RTU, Metasys®N2, or APOGEE®FLN (P1),

with additional communication options including:

LONWORKS®, BACnet, DeviceNet, and Profibus DP

UL/cUL Listed

APOGEE is a registered trademark of Siemens Building Technologies, Inc.

LONWORKS is a registered trademark of Echelon Corporation.

Metasys is a registered trademark of Johnson Controls, Inc

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 4 of 22

Panel Identification

Each FRENIC-EcoPAK panel has a nameplate label, like the example pictured above,

which contains important information about the panel. This label is located on the inside

of the hinged door on the enclosure.

CAUTION

Refer to the nameplate label to determine the panel input voltage and current

requirements prior to installation and wiring.

Refer to the nameplate label for the correct wiring diagram (Elementary Drawing).

Sizing of field wiring conductors should be based upon the current ratings listed on

the nameplate label.

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 5 of 22

Installation

CAUTION

The FRENIC-EcoPAK panel should be located indoors:

Away from flammable or combustible liquids, gases, and other materials

Away from sources of dust, metal shavings, or other particulate material

Away from liquids, spray, or mist

Away from sources of heat

Away from direct sunlight

Where the ambient temperature will remain between -10°C (14°F) and 40°C

(104°F)

Wall-mount panels must be mounted on a non-flammable heat-resistant surface that is

capable of supporting the weight of the panel.

Refer to the dimensional drawing that shipped with the panel for required clearances.

Routing of field wiring should be planned in coordination with choosing a mounting

location.

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 6 of 22

Wiring Overview

The FRENIC-EcoPAK panel must be connected to an input power source, a motor

(output power), and control signals.

WARNING

Wiring should be performed by a qualified electrician using standard practices as

specified by local and national codes.

Always make sure the input power source is OFF before connecting or disconnecting

any power input, output, or control wiring.

Ground the panel, as specified by local and national codes, using the provided

grounding lugs or bus bar.

Make sure that the input power source (phases, voltage, and current capacity)

matches the requirements of the panel as stated on the nameplate.

Never connect line voltage to the drive output terminals (U, V, and W).

When making holes for conduit fittings, be sure to cover the drive and other

components to protect them from metal shavings.

CAUTION

All field wiring should be copper with a minimum insulation rating of 75°C.

Sizing of field wiring conductors should be based upon the current ratings listed on

the nameplate label, in accordance with local and national codes.

Refer to the wiring diagram that shipped with this panel and the torque table in this

instruction manual.

Refer to the diagrams on the following pages for general component layout and for

general routing of power input, power output (motor connections), and control wiring for

your panel. Power input wiring should be routed away from power output wiring, and

both should enter the panel from separate conduit. Control wiring should be routed away

from power wiring, and should enter the panel from separate conduit. Knockouts are

provided on the Type 1 wall-mount panels. Floor-mount and NEMA 12 ventilated wall-

mount panels require holes to be drilled in the field. Refer to the panel outline drawing

provided for recommended conduit locations.

Refer to the following section Control Wiring for descriptions of the control connections.

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 7 of 22

Wiring Overview(cont’d)

UL/NEMA Type 1 UL/NEMA Type 1

2-10Hp @ 208/230V 15-20Hp @ 208/230V

2-20Hp @ 460V 25-40Hp@460V

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 8 of 22

Wiring Overview(cont’d)

NEMA 12 Ventilated NEMA 12 Ventilated

2-30Hp @ 208/230V 40Hp @ 208/230V

2-40Hp @ 460V 50-75Hp@460V

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 9 of 22

Wiring Overview(cont’d)

UL/NEMA Type 1 UL/NEMA Type 1

25-30Hp @ 208/230V 40-60Hp @ 208/230V

50-75Hp @ 460V 100-200Hp @ 460V

NEMA 12 Ventilated

50-60Hp @ 208/230V

100-200Hp @ 460V

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]

Page 10 of 22

Control Wiring

All control wiring, except the damper control output and the programmable relay outputs,

connects to the terminals on the drive. The following diagram shows control connections

that are available on FRENIC-EcoPAK panels:

Description of Control Connections

Damper Control output (DMPRLY):

oCTB 1-2

oUsed to control the position of a damper valve in coordination with drive

operation

Programmable Relay 1 output (PRLY1):

oCTB 3-4 for NO contacts rated for 1A @ 230VAC

oProvides drive output signal Y2, which is user-selectable

Programmable Relay 2 output (PRLY2):

oCTB 5-6 for NO contacts rated for 1A @ 230VAC

oProvides drive output signal Y3, which is user-selectable

Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: [email protected]
