SwitchPanel
EN
1. Presentation
The SwitchPanel is a backlit button panel that communicates with PowerFT
ECUs via FTCAN 2.0, available in 4 different versions with 4,5 and 8 buttons.
By using SwitchPanel, your project will appear more neat since installation wiring
will be minimized. Each button is identified through several predefined stickers
that are included with the product; blank stickers are also included so you can
make your own IDs. Thus, each button will be very well identified in particular by
the multicolor LED backlight that varies according to the programmed function.
Another benefit of using SwitchPanel is that you can reallocate up to 8 PowerFT
ECU inputs to extra sensors or functions, allowing you to expand your project
without having to purchase more devices with more inputs.
SwitchPanel is compatible with all the features in the PowerFT. All buttons from
the ECU can be selected such as 2-step, Air conditioning, Boost +, Engine
Startup, dashboard screen switch, etc. The switch functions are also compatible
such as Day / night mode switch, Burnout, Progressive Nitrous, datalogger, etc.
In addition to compatibility with the existing features, of the PowerFT ECUs
added map switching through buttons, single-button or a button for each map.
The SwitchPanel has well spaced buttons with clear touch perception and
is perfect for use with gloves. It has IP67 protection against water and dust
(complete protection against dust and immersion up to 1 meter for up to 30
minutes).
The case has two 10-32 screws on the back, allowing an easy and discrete
installation onto the dashboard, making your project even more professional.
