FTE MAX COMBO NET Manuel utilisateur
MAX COMBO NET
ENGLISH
USER'S MANUAL
(2012 11 05) manual.indd 3 2012-11-05 �� 8:48:07
1
GENERAL SAFETY 2
GENERAL INFORMATION 3
I. UNPACKING 3
II. FEATURES 3
III. REMOTE CONTROL UNIT (RCU) 4
IV. HOW TO SETTING RCU FOR TV 6
V. FRONT PANEL 8
VI. REAR PANEL 9
INSTALLING EQUIPMENT 10
CHANNEL LIST GUIDE 11
MENU GUIDE 13
MAIN PAGE 13
I. CHANNEL MANAGER 13
II. INSTALLATION 15
III. OPTIONS 20
IV. UTILITY 22
V. ACCESSORY 23
PVR Guide 24
TROUBLESHOOTING 31
SPECIFICATIONS 32
BRAND LIST 178
TABLE OF CONTENTS
To disconnect the apparatus from the mains, the plug must be pulled out
from the mains socket, therefore the mains plug shall be readily operable.
(2012 11 05) manual.indd 5 2012-11-05 �� 8:48:08
2
GENERAL SAFETY
Please read the following recommended instructions carefully to avoid the risk of
your physical Injury before the product is operated.
Do not cover the receiver and keep clear space around the receiver for sufficient.
Check the receiver’s operation voltage 90~250V, 50Hz~60Hz, 12V 2.5A Adaptor
Keep liquid away from the receiver.
The receiver shall not be exposed to dripping or splashing and no objects that filled
with liquid shall not be placed on the receiver.
Unplug the receiver from the wall outlet before cleaning.
Use a soft cloth and a mild solution of washing-up liquid to clean the casing.
Do not block the receiver’s ventilation slots which are provided for ventilation and
protection from overheating.
Please maintain the receiver in a free airflow.
Do not allow the receiver to be exposed to hot, cold or humid condition.
Do not use any cable and attachment that are not recommended as these may
damage your equipment.
Please unplug the receiver from the wall outlet and disconnect the cable between
the receiver and the antenna when you will not use it for long time.
Do not remove the cover to reduce the risk of electric shock.
Do not attempt to service the receiver yourself.
Refer all serving to qualified service personnel.
Manual may be updated as new features.
WARNING
(2012 11 05) manual.indd 6 2012-11-05 �� 8:48:08
3
GENERAL INFORMATION
Please ensure that the following items are included with the receiver in your pack-
ing.
1) Remote Control Unit (RCU)
2) Batteries (2EA)
3) CD with user manual
4) 12V 2.5A Adaptor
·Supports MPEG-2, MPEG-4, H.264 and fully DVB compliant
·Satellite & Terrestrial receiver
·2 Slot smart card
·DiSEqC 1.0, 1.1 1.2and
·Aspect ratio adjustment 4:3 (16/9 crop), 4:3 (16/9 letterbox), 16:9 (4/3 pillar box)
·User friendly OSD and operation
·Total 10,000 Channels Programmable
·Multi-language audio support / Multi-language menu text support
·Favorite channel selections
·Parental Guide and rating control
·EPG(Provider Electronic Program Guide) for On Screen Channel Information
·On-Screen Display with 65,536 Color
·Blind scan(Power Scan) & Powerful EPG
·Zoom Function in Pause
·Dolby Digital Bitstream Out through S/PDIF(Optical)
·Seletable output for 1080p, 1080i, 720p,576p and 576i format
·USB 2.0 Host (Access to HDD, USB memory, Others etc)
·Upgrade Software & Update Channel Database through USB 2.0 Port and RS232
·MP3 File Play by USB 2.0
·PVR Ready via USB
·Recorded file play on PC
·Reservation Recoding by EPG function
·Multimedia file play by USB 2.0
·Home streaming
I. UNPACKING
II. FEATURES
(2012 11 05) manual.indd 7 2012-11-05 8:48:08
4
GENERAL INFORMATION
III. REMOTE CONTROL UNIT (RCU)
(2012 11 05) manual.indd 8 2012-11-05 �� 8:48:08
5
GENERAL INFORMATION
III. REMOTE CONTROL UNIT (RCU)
1. POWER Switch the receiver between operation and standby mode.
2. MUTE Enable or disable the audio.
3. TV Switch to TV mode.
4. DVD Switch to DVD mode.
5. VCR Switch to VCR mode.
6. STB Switch to STB mode.
7. TV / RADIO Switch between TV and Radio.
8. RECALL Select the previously viewed channel.
9. AV / TV Select the TV or AV mode.
10. ←PR Select the previously viewed channel.
11. Fn Network File Manager / Reboot.
12. V. Format Switch to HD Type.
13. ZOOM Select Zoom IN/OUT.
14. Fn2 Reserved.
15. Move down a page in the channel list.
16. Move up a page in the channel list.
17. V+ / V- Turn volume up or down.
18. P+ / P- Change channels up or down on normal mode.
19. ▲▼ Change channel or move to the item in the menu.
20. ◀ ▶ Adjust the volume or move to left or move item in the menu.
21. MENU Display the main menu on screen.
22. EXIT Return to the previous menu or normal viewing mode from a menu.
23. INFO Display the program information box on the screen and edit the name of favorite
channel list.
24. STOP Stop recording or playing.
25. PLAY Display file lists and plays slow/normal.
26. PAUSE Pause the playing picture or go to normal mode.
27. RECORD Record the program.
28. REWIND Start reverse playback and change the speed of reverse playback.
29. F / F Start fast forward or fast motion playback and change the speed of forward playback.
30. AUDIO Change the audio languages.
31. E
Subtitles
Teletext
PG Display the TV or Radio program guide.
32. Enable subtitles mode.
33. Enable teletext mode.
34. Numeric buttons Select the TV or Radio service channels and individual menu.
35. FAV Toggle the selected favorite mode.
36. SAT Toggle the selected Satellite list.
(2012 11 05) manual.indd 9 2012-11-05 �� 8:48:09
6
GENERAL INFORMATION
IV. HOW TO SETTING RCU FOR TV
4
3
2
5
1
(2012 11 05) manual.indd 10 2012-11-05 �� 8:48:09
7
GENERAL INFORMATION
IV. HOW TO SETTING RCU FOR TV
I. Manual Search
At first, Turn on the TV
1) Press ➊Device LED Key ( STB or TV or VCR or DVD ) + ➋"OK" key at the same time during 2 or 3 seconds.
Then the Device LED Lamp will be on →Setting Mode.
2) Find the 3-Digit code of Device in brand list and input 3-Digit code accordingly one by one. - The Device LED
will be twinked ontime one by one also. When you finish inputting 3-Digit, the Device (TV or VCR or DVD) will be
turned off one time.
3) Then click OK to finish setting. (The Device LED will be turned off after twinkling 2 times.)
*NOTE : If you are not able to find the TV code which you are watching currently, please perform the below "Auto
Search". Then RCU will find the proper code automatically and it will work properly.
II. Auto Search (Using Up or Down key)
1) Press ➊Device LED Key ( STB or TV or VCR or DVD ) + ➋"OK" key at the same time during 2 or 3 seconds.
Then the Device LED Lamp will be on →Setting Mode.
2) Press ➌Up or Down Key of RCU to find out equivalent device. At the moment of RCU matching to the equiva-
lent device, the device will be turned off.
3) Then click OK to finish setting. (The Device LED will be turned off after twinkling 2 times.)
III. Factory Reset
1) Press ➍TV LED + ➎REC button at the same time during more than 5 seconds.
2) Device LED will be turn off/on "TV →DVD →VCR →STB" 3 times one by one and RCU will go to default mode.
(2012 11 05) manual.indd 11 2012-11-05 �� 8:48:09
8
GENERAL INFORMATION
V. FRONT PANEL
NOTE: All USB 2.0 flash drive may not be compatible with the product.
1. POWER Switch the receiver power On and Standby.
2. USB To upgrade firmware / Recording.
3. SMART SLOT Insert Smart Card.
1 2 3
3
4 8 9
11
56
7
10 12
1
2
(2012 11 05) manual.indd 12 2012-11-05 �� 8:48:10
9
GENERAL INFORMATION
VI. REAR PANEL
1. AERIAL Connect to Terrestrial antenna cable.
2. LOOP OUT Connect to another STB.
3. SAT IN Connect to Satellite antenna cable.
4. LOOP OUT Connect to another STB.
5. TV SCART Connect to TV SCART cable.
6. HDMI Connect to HDMI jack of TV.
7. RS 232 Connect to personal computer for software upgrade.
8. Ethernet Connect to Lan cable.
9. USB Connect to USB device.
10. OPTICAL Output for connecting to a amplifier.
11. ADAPTOR Connect to Adaptor.
12. POWER BUTTON Turn On/Off.
3
4 8 9
11
56
7
10 12
1
2
(2012 11 05) manual.indd 13 2012-11-05 �� 8:48:10
