Manual of Two-Way Radio System www.FrSky-rc.com P1of9

2.4GHz Two-Way Radio System

1. Introduction

The Two-way Radio System developed by FrSky provides an additional return link

that would be used for monitoring the Rx’s voltage, temperature, location, speed and so

on.

2. Overview

2.1 Transmitter modules:

a) Model: DFT

Compatible with the following transmitters:

Futaba: 3PM, 3PK, 7U, 8U, 8J, 9C, 9Z, 10C, FN series, T10C, FC-18, FC-28.

Hitec: Optic 6, Eclipse 7, Prism 7.

WFLY: WFT09, WFT08.

b) Model: DJT

Compatible with the following transmitters:

JR: 347/388/783/U8/PCM10/PCM10S/PCM10SX/PCM10IIS/8103/J9303/PX/9XII.

2.2 Receiver module:

a) Model: D8R, D8RHV

Compatible with FrSky Two Way module DFT/DJT.

b) Model: V8R, V8RHV, V8R7, V8R7HV, V8R4

V8 receivers work with DFT/DJT, just in receive-only mode.

3. Features

a) Advanced Continuous Channel Shifting Technology (ACCST SYSTEM)

achieves high reliable link in interference rich environments.

b) Easy to bind and instant link-up.

c) Excellent reboot times.

d) All channels failsafe.

Manual of Two-Way Radio System www.FrSky-rc.com P2of9

e) Quick response.

f) Very smooth servo movement.

g) Alarm on events of receiver (low battery voltages, poor reception, etc.)

h) Error-free link, by using 48bits CRC algorithm.

i) Low power consumption.

j) True two-antenna diversity.

k) Firmware upgradable.

4. Function of Two Way communication

a) Two way communication between receiver and transmitter

b) Receiver is able to accept 2 analog inputs, which can be used to monitor battery

voltage, temperature sensor, etc., and transfer them to transmitter. Users can set the

Alarm Level of these analog voltages, when exceed or below these levers, sound alarm

is issued.

c) Receiver is able to accept serial data streams from simple 3-wire RS232 port, such

information as GPS, altitude, and user developed data can be transferred to Tx without

error, and sentat the RS232 port on the Tx.

5. Specifications

5.1 Receiver specifications:

Model: D8R

Weight: 16.2g

Dimension: 54*27*17mm

Operating Voltage Range: 4.0V-7.2V

Operating Current: 100mA

Specified Range: 1.5km (Ground Range)

Resolution: 3072

Latency: 22ms

Number of Channels: 8CH

Analog voltage: 0~3.3V

Manual of Two-Way Radio System www.FrSky-rc.com P3of9

5.2 Transmitter module specifications:

Model: DFT, DJT

Operating Voltage Range: 6.0V-13.0V

Operating Current: 50mA

Output Power: 60mW

Resolution: 3072

Important!

The effective range of control refers to the distance between the transmitter and the

receiver clear of obstruction. All data was tested and verified by FrSky.

However this is not guaranteed due to many factors such as the flying environment

and the weather, which can greatly affect the effective range of control.

It is extremely important to range check your models prior to each flying

session!

6. How To Use

6.1 Setup

6.1.1 Installation of the transmitting module:

a) Remove the original transmitting module.

b) Put the FrSky 2.4GHz transmitter module into the module port of your RC

transmitter and screw on the transmitting antenna.

c) Check the MODE switch to its corresponding position.

Mode

Switch 1

Switch 2

Mode

OFF

Two-way Mode

OFF

V8 Mode

OFF

Not Defined

Firmware Upgrade

d) Turn the transmitter power on and check the LED status on the module.

Manual of Two-Way Radio System www.FrSky-rc.com P4of9

6.1.2 Installation of receivers:

The D8R receiver incorporates two separate antennas which enable them to

receive the radio signal at two different locations. Please make sure that the two

antennas are placed apart and oriented 90 degrees to each other.

Please note:

As the wave length of 2.4GHz is shorter than older RC systems, its ability to go

around solid obstacles is weaker than 72 or 36 MHz. So the antennas must avoid

objects with high conductivity, such as metal parts, servos, ESC’s, battery packs, wires,

and carbon fiber structures. If possible put the tip of the antennas outside of the fuselage

for maximum reception.

6.1.3 Receiver and Transmitter Setup Instructions:

Follow the steps below to properly set up your system.

a) Turn your FUTABA or JR transmitter on and switch it to PPM mode, power off the

TX.

b) Check the working mode of the Tx module.

c) Turn the transmitter on while holding the programming button. Release it a few

seconds later. The RED LED on the transmitter module will flash indicating the

transmitter is ready to bind the receivers.

d) Connect the battery to the receiver while holding the receiver’s button. The LED on

the receiver will flash indicating the binding process is complete. Turn off the receiver.

e) Turn off the transmitter and receiver to finish the binding procedure.

f) Turn on the transmitter.

g) Connect the battery to the receiver, the Green LED on the receiver will indicate the

receiver is receiving commands from the transmitter.

After the steps above are completed, both the transmitter and receiver are ready to

be used.

6.2 Range check

Manual of Two-Way Radio System www.FrSky-rc.com P5of9

For safe operation, it is necessary to perform pre-flight range check.

Caution must be paid when you perform check in an environment with metal fences,

concrete buildings, or rows of trees. Loss of signal may be experienced.

Perform a range check as follows (Note: this would be done with the receiver

installed in the model):

a) Place the model at least two feet (60cm) above non-metal contaminated ground;

for example a wooden bench.

b) Place the receiver’s antenna apart. Do NOT let the antenna touch the ground.

c) Place the antenna of the transmitter in a vertical position.

d) Turn on the transmitter and receiver.

e) To enter Range Check Mode, press and hold the “F/S Range” button of the

transmitter for 4 seconds, the RED LED of the transmitter module will be turned off, the

effective distance will be decreased to 1/30.

f) Walk away from the model while simultaneously operating the controls on the

transmitter, confirm that all controls are completely and correctly operational at least 30

meters away.

g) Press the “F/S Range” button for 1S-4S, the transmitter will exit Range Check

Mode.

7. Safety range indicator

The Two-Way Radio System has a feature to show the RSSI (Received Signal

Strength Indication) of the receiver. When the RSSI is low, the Tx module will issue

three types of alarms.

Red: The receiver is very far from the Tx.

Orange: The receiver is sound, but would be far from Tx.

Yellow: The receiver is sound,

Green: The receiver is OK.

Note: Due to many environment factors, there may be casual alarm.

8. Failsafe

Manual of Two-Way Radio System www.FrSky-rc.com P6of9

The receiver integrates the failsafe function for all channels.

ROM A version: This is FrSky acquiescent failsafe version.

To set failsafe positions, press briefly(less than 1 second) the “F/S Range” button of

the Receiver, the Tx module will make a long “beep” indicating the failsafe position is

remembered by the receiver.

ROM B version: Provided for users to upgrade FrSky two way transmitter modules’

failsafe version. In this case, you can set failsafe position on the Tx module at any time

during your flight.

Option1: To set failsafe positions, press briefly(less than 1 second) the “F/S Range”

button of the Receiver, the Tx module will make a long “beep” indicating the failsafe

position is remembered by the receiver.

Option2: To set failsafe position, press briefly (less than 1 second) the “F/S Range”

button of the Tx module, the Tx module will make a long “beep” indicating the failsafe

position is remembered by the receiver.

Note: Please kindly note that if you accidently press the “F/S Range” button of the

Tx module during your flight, you will change the failsafe state inadvertently.

9. Alarm operation

9.1 Alarm states

Tx module monitors the state of receiver and notify user by audible alarm.

There are three alarm states:

Red (Highest): constant three Beeps

Orange (Medium): constant two Beeps

Yellow (General): one Beep

Green: No Beep

Alarm sourced from:

-Rx interface 1: Analog Port 1 on Rx;

Manual of Two-Way Radio System www.FrSky-rc.com P7of9

-Rx interface 2: Analog Port 2 on Rx;

-Rx interface 3: RSSI of Rx;

Note: The alarm threshold of Rx interface 1 and 2 could be set by user. Two

alarm thresholds and three levels alarm state are available for both of Rx interface

1 and 2.

And the RSSI alarm setting is default by factory.

9.2 Pins Definition:

The Pin definition on receiver and Tx module:

It should be noted that the 3.3V voltage only have a limited driving current

(1~10mA), should not be used for driving a MPU.

RXD

+5V

GND

AD2

GND

AD1

GND

RXD

Input to Tx module

TXD

Output from Tx module

+5V

Not regulated voltage

GND

Ground

RXD: input to receiver, RS232 level

AD2: Voltage: max 3.3V

AD1: Voltage: max 3.3V

Pins Definition at Rx Pins Definition at Tx

10. LED Status:

10.1 LED status on Transmitter module:

Red LED on and Green LED flashing: Working Mode.

Red LED off and Green LED flashing: Range Check Mode.

Red LED flashing: Binding Mode.

Manual of Two-Way Radio System www.FrSky-rc.com P8of9

10.2 LED status on Receiver:

Red LED on and Green LED glooming: Working Mode.

Red LED flashing and Green LED off: No Signal.

Red LED flashing and Green LED on: Binding OK.

11. Firmware Upgrade

Frsky have developed a mechanism of firmware upgrade. With it, user would like to

upgrade to new version of software when available. And the Two-Way Radios System is

supported by this mechanism.

Steps are the following:

a) Set module to Upgrade Mode.

b) Connect the module to PC through a RS232 cable.

c) Start Upgrade software on PC.

d) Select file and corresponding port.

e) After the Serial No. is got, press Download.

f) After the progress bar reached 100%, the software of the module is

updated.

FCC Statement

Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

Manual of Two-Way Radio System www.FrSky-rc.com P9of9

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

Measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

CE in which countries where the product may be used freely: Germany, UK, Italy,

Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg, Austria,

Finland, Sweden, Norway and Iceland.

France: except the channel 10 through 13, law prohibits the use of other channels.

For more information, please kindly refer to the Two Way Protocol.

Should you have further queries, pls feel free to contact FrSky

technical support by e-mail: sales4tech@gmail.com.

Autres manuels pour DFT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels FrSky Récepteur

FrSky

FrSky ARCHER PLUS SR8 Manuel utilisateur

FrSky

FrSky ARCHER PLUS R10+ Manuel utilisateur

FrSky

FrSky SR18 Manuel utilisateur

FrSky

FrSky ACCESS XM Manuel utilisateur

FrSky

FrSky TARANIS X9D Manuel utilisateur

FrSky

FrSky ARCHER PLUS R6FB Manuel utilisateur

FrSky

FrSky ACCESS G-RX6 Manuel utilisateur

FrSky

FrSky TARANIS X9D Manuel utilisateur

FrSky

FrSky TD R12 Manuel utilisateur

FrSky

FrSky ARCHER R10 PRO Manuel utilisateur

FrSky

FrSky ACCESS RX4R Manuel utilisateur

FrSky

FrSky D6FR Manuel utilisateur

FrSky

FrSky L9R Manuel utilisateur

FrSky

FrSky Delta 8 Manuel utilisateur

FrSky

FrSky ARCHER PLUS R8 Manuel utilisateur

FrSky

FrSky ARCHER R8 PRO Manuel utilisateur

FrSky

FrSky ARCHER PLUS R6Mini Manuel utilisateur

FrSky

FrSky R9 STAB OTA Manuel utilisateur

FrSky

FrSky TARANIS X9D Manuel utilisateur

FrSky

FrSky R9 Manuel utilisateur

FrSky

FrSky TW R6 Manuel utilisateur

FrSky

FrSky ACCESS G-RX8 Manuel utilisateur

FrSky

FrSky X4R-SB Manuel utilisateur

FrSky

FrSky ARCHER R8 PRO Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
