FRP GPB03 Manuel utilisateur
Digital User Manual
GPB03
40cc Off Road
Pocket Bike
User Manual
www.frptoys.com
833-970-3777 (Toll Free) M-F
8am-5pm PST
ΔThis mark noties a very important item for safety. Be sure to
observe the notice.
Do not use 4 cycle engine oil.(otherwise,it cause the plug to be
degraded ,the piston ring to seize or the mufer to be clogged.)
PROHIBITED ITEMS
ΔDo not allow anyone who does not understand this instruction
manual to operate the bike.
ΔDo not use any degraded fuel (which smells sour) or fuel of wrong
mixture ratio. It will cause a poor start, insufcient output or damage
the engine.
ΔDo not use 4cycle engine oil.(otherwise, it cause the plug to be
degraded, the piston ring to seize or the mufer to be clogged.)
ΔDo not run the engine in a room or poody ventilated area.( the
exhaust gas includes odorless but hazardous carbon monoxide.)
ΔDo not put your hand or foot near any moving or rotating
part of engine.
SAFE FOR USE (CAUTION PLEASE!!!)
ΔDo not store, spill or use any gasoline near a re, stove, oven,
boiler or other instruments which uses a pilot light or spark.(Other-
wise,it may cause an explosion.)
ΔSmoking is strictly prohibited while relling the fuel.
ΔWhile the engine is running or while it remains hot soon after
stopping, do not remove the lid of the fuel tank or rell the fuel.(Be-
fore or relling the fuel, stop the engine and cool it down 2 minutes
or more.)
ΔIf any gasoline split or smelled or any danger of explosion is felt,
do not run the engine,)
ΔDo not stop theengine while choke lever is in the closed position.
ΔDo not aimlessly adjust the revolution speed setting of the engine.
ΔDo not check any spark while keeping the spark plug removed.
ΔDo not run the engine with the mufer or air cleaner cover
removed.
ΔDo not touch any hot, mufer or engine part(Otherwise, it may
cause a burn)
Δ When the engine runs, do not touch any spark plug cap or high
tension cord.(Otherwise, it may cause an electric shock and harm
your body.)
Δ Do not run any engine as a single unit.(Be sure to run with the
racing)
ΔALWAYS WEAR HELMET&SAFETY GEARS.
Δ ALWAYS CHECK THE BRAKE INSTRUMENTS BEFORE RIDING.
Δ DO NOT RIDE IN RAINNING, SNOWING DAY, SLIPPERY SUR-
FACE,OR UNSTABLE DUE GRAVEL,SAND etc
ΔPREGNANT PERSONS SHOULD NOT USE THIS PRODUCT.
ΔNEVER USE ALCOHOL OR DRUGS BEFORE OR WHILE OPERAT-
ING
Δ DO NOT STOP STOP THE SCOOTER SUDDENLY(Run slowly
3-5minutes after start-up or before stopping.)
This bike is not intended for operation on pedestrian, street, highway
and freeway.
Please check with your local department of motor vehicles for regula-
tion in your country.
This PRODUCT IS NOT INTENDED FOR EXTREME
Use! Please take care of your motorcycle.
DO NOT JUMP or ABUSE THIS PRODUCT!
DO NOT RIDE IN WET/ICY CONDITIONS!
Failure to follow these instructions properly or
abusing your motorcycle will
VOID YOUR WARRANTY!
Failure to follow these INSTRUCTIONS will
VOID YOUR WARRANTY!
WARNING
DO NOT operate this product in trafc, on wet, frozen, oily or unpaved
surfaces or under the inuence of drugs and/or alcohol. Avoid uneven
surfaces, potholes, surface cracks and obstacles.
DO NOT use a water hose to clean this product. See Product Handbook
for more information.
This product is recommended for riders 13 YEARS OF AGE and older.
SAFETY
Persons without excellent vision, balance, coordination, reex, muscle
and bone strength and good decision-making capabilities should not use
this product.
Minors without adult supervision should not use this product.
Persons unwilling or unable to take responsibility for their own actions
should not use this product.
The user of this product assumes ALL risks associated with its use. To
minimize these RISKS, the user must wear appropriate safety gear such as
helmet, goggles, gloves, elbow and kneepads and appropriate footwear.
Never start the engine inside a closed room or building. Breathing
exhaust fumes can be fatal.
IMPORTANT
PLEASE READ BEFORE USING THIS PRODUCT
READ THIS FIRST!
Fuel Safety
Mix and pour fuel outdoors away from sparks or ames.
Only use a container approved for fuel
Do not smoke or allow smoking near the motorcycle while working on the engine, or
while the engine is running.
Wipe up and clean all fuel spills before starting the engine.
Move at least 10 feet away from where you fueled before starting engine.
Stop engine before removing the fuel cap.
It is recommended that you empty the fuel tank prior to shipping or storage to prevent
fuel leaks.
Do not store your motorcycle near open ames, furnaces, electric motors or switches.
Maintenance
Maintain your motorcycle as recommended in this Product Handbook.
Disconnect the spark plug cap before performing any engine maintenance, except
for carburetor adjustments.
Keep others away while making carburetor adjustments.
Use only quality replacement parts as recommended by the manufacturer.
Transportation and Storage
Carry your motorcycle by the handle bar tube with the engine off and the mufer
away from your body.
Allow the engine to cool, empty the fuel tank and fold the motorcycle before carrying
or storage.
It is recommended that you empty the fuel tank prior to shipping or storage to prevent
fuel leaks.
Clean the motorcycle carefully and store in a cool, dry place.
Product Safety
Keep hands and feet away from moving parts.
Inspect the entire product prior to each use. Replace damaged parts. Check for
fuel leaks and make sure all fasteners are in place and securely fastened.
Replace all parts that are cracked, chipped or damaged before use.
Use only parts and accessories that are recommended by the manufacturer.
If a situation arises that is not covered in the manual,
proceed with caution and use good judgment.
Contact your dealer if you need further assistance
QUICK REFERENCE
SAFETY GUIDE
06 BEFORE RIDING
01 TECHNICAL SPECIFICATION 1
02 MINI PARTS DESCRIPTION 2
03 FAST INSTALLATION
3
04 PREPARATION BEFORE STAT-UP
4
05 OPERATING AND RUNNING
5
07 BRAKING
08 OPERATING PROCEDURES
4
09 CARBURETOR ADJUSTMENT
5
10 STOPPING
5-6
11 BRAKING SYSTEM 6
6
12 ADJUSTING THE BRAKES 7
13 ADJUSTING THE CHAINS 7-8
14 MAINTENANCE SCHEDULE 8
15 STORAGE 9
16 TROUBLE SHOOTING 9-10
3
1
Engine type: 40cc 4-stroke/EPA
Fuel: Gasoline >#90
NO OIL MIX!!!
Start Mode: Hand Pull Start
Brake: front & rear disk brake
Tire: 90/65-6.5 Pneumatic (F),110/50-6.5(R)
Max Traveling Noise: 45db
Max Load: 165lbs
Net Weight: 50lbs
Fuel Capacity: 0.26gal(1L)
Driving Method: T8F Chain
Packing: Carton
Steering Bar Angle: 45 °
LxWxH: 40x18.5x22.8"
01Technical
Specification
1
02Mini Parts
Description
2
Speed control handle
Gastankcover
kickstand
Disk brake
Rear tyre
Brake bar
Engine
Kill switch
Throttle cable
Gasoline tank
Chain adjuster
Pull start
Caliper
Front tyre
Front fender
Install shield.
Install plate, put a spacer ring rst, then x it. And insert fender to
plate.
03Fast Installation
3
Fix four screws on handlebar.
1. Inspect equipment
Check all bolts & nuts,brakes,engine etc.
2. Check and clean the air lter
The air lter must be often cleaned, or the polluted air lter will
lower the out put power of the engine. If the air lter is blocked
by dust, use gasoline to clean the air lter, then dip in the oil,
wring oil out and put the air lter back.
04Preparation
Before Start-up
