Fromm P380 Manuel utilisateur

P380 Pneumatic Powered Plastic

Strapping Tool

OPERATION MANUAL

Machine

Pneumatic Powered Plastic Strapping Tool

Model

P380

Date

April 2018

Issue

FPA001

CONTENTS

1. General Information 1

1.1 Note of Installation 1

1.2 Notice of Operation 1

2. Specification 2

2.1 Specification Table 2

2.2 Chart of Types 3

2.3 Tool Description 3

3. Operation Description 4

3.1 Installation 4

3.2 Suspension of Tool 4

3.3 Adjustments 5

3.4 Feeding the Strap Around the Package 5

3.5 Inserting the Upper Strap 6

3.6 Inserting the Lower Strap 6

3.7 Tensioning the Strap 6

3.8 Sealing the Straps 7

3.9 Removing the Tool 7

3.10 Seal –Control 8

3.11 Cleaning 8

3.12 Air Unit 8

4. Safety Notices 9

5. Safety Rules for Strapping Tools 10

5.1 Joints 10

5.2 Dispensing Strap 10

5.3 Strap Warnings 10

5.4 Strap Breakage Hazard 10

5.5 Cutting Tensioned Strap 10

5.6 Fall Hazard 10

6. Maintenance and Trouble Shooting 11

6.1 Suggested Maintenance 11

6.2 Warranty Periods 11

6.3 Fromm Service Solutions 11

6.4 Possible troubleshooting causes and remedies 12

7. Contact Fromm Packaging 14

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 1

1. GENERAL INFORMATION

Congratulations on the purchase of your Fromm Pneumatic Powered Plastic

Strapping Tool. We trust you will have many years of packaging efficiency.

Before proceeding with the operation or installation of your new tool please read

this manual thoroughly and gain a full understanding of the requirements, features

and operation of your new tool.

1.1 Note of Installation

To ensure your tool operates in a safe manner please review the following

requirements:

1. Tool power is pneumatic air, 6.0 bars / 87 psi.

2. Keep work area clean.

3. Tool can operate in temperatures between -10℃and 45℃.

4. Please ensure you download and read our Install Guide before attempting it

yourself.

1.2 Notice of Operation

Before you start using the pneumatic tool, please review the following conditions:

1. Before operating, please read the operational manual carefully.

2. Ensure the switch is in the off position before connecting the air hose.

3. Avoid any damp object or water around the electric parts.

4. When a problem does occur, please check the troubleshooting section for more

information and advice.

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 2

2. SPECIFICATION

2.1 Specification table

Model

P380

Strap Width

13-19mm

Strap Thickness

0.4-1.35mm

Strap Tension

600-2000 Newtons

Tensioning Speed

120-260mm/s

Joint Strength

Approx. 75%

Tool Size with Suspension

Bracket

390mm(L)x135mm(W)x305mm(H)

Weight

6.8kg

Sound level

78dB

Air Pressure

6.0 bars / 87 psi

Joining Thread

G 1/4

Air Flow of Air Unit

Min. 520 NI/min with a maximum pressure drop of

0.5 bar / 7.25 psi

Air Consumption

Tensioning: Approx. 6.5 NI uncompressed air /sec

Sealing: Approx. 10.9 NI uncompressed air /sec

Oil for Air Unit

HL / CL ISO VG 10

Accessories:

Protection Plate

Package Dimensions

Diameter of round /

circular goods

Min 2 x Ø70mm Min Ø240mm

Width

Min 80mm

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 3

2.2 Chart of Types

Item No.

Model

Strap

Width

Strap

Thickness

49.3801

P380/13/0.40-0.64

13.0 mm

0.40 - 0.64 mm

49.3802

P380/13/0.64-1.05

13.0 mm

0.65 - 1.05 mm

49.3811

P380/15/0.40-0.64

15.0 mm

0.40 - 0.64 mm

49.3812

P380/15/0.65-1.05

15.0 mm

0.65 - 1.05 mm

49.3821

P380/16/0.40-0.64

16.0 mm

0.40 - 0.64 mm

49.3822

P380/16/0.65-1.05

16.0 mm

0.65 - 1.05 mm

49.3831

P380/19/0.40-0.64

19.0 mm

0.40 - 0.64 mm

49.3832

P380/19/0.65-1.05

19.0 mm

0.65 - 1.05 mm

49.3833

P380/19/1.06-1.35

19.0 mm

1.06 - 1.35 mm

2.3 Tool Description

Tensioner valvelever

Sealer valve lever

Handle lever

Seesaw lever

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 4

3. OPERATION DESCRIPTION

3.1 Installation

Compressed Air Connection

The compressed air should be connected to the tool preferably by a quick coupling.

It is very important to clean the compressed air with an air unit consisting of a

separator for water and dirt, a pressure regulator with a manometer and a lubricator

(see sketch).

3.2 Suspension of Tool

It is possible to suspend the tool on a spring loaded balancer using the suspension

bracket which is supplied with the tool. The suspension bracket has been designed

in such a way, that the tool can be used for all three working positions.

Main air line min. 2”

Air line min. 1/2”

Shut off valve

Pressure adjustment

valve with manometer

Air unit min. G1/2

Air hose

Max. length 5m

Min. Ø inside 10mm

Coupling min. G1/4

Filter with

water separator

Lubricator

(1 –2 drops/min)

Drain of main air line

with shut off valve

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 5

3.3 Adjustments

3.3.1 Preselecting of Strap Tension and Tensioning Speed

Do not adjust the tensioning force too high.

If the tensioning force is higher than the tensioning strength of the strap, the strap

will tear while tensioning.

Tensioning force and tensioning speed can be preselected at the control head.

Loose lock screw;

Press the control head against the tool and turn it.

Turning clockwise increases; turning counterclockwise decreases the tensioning

force and the tensioning speed resp..

Tight lock screw

3.3.2 Adjusting the Welding Time

Depending on the size and quality of the strap, different welding times are required.

The welding time can be set at the adjusting screw.

Turning clockwise increases the welding time.

Turning counterclockwise decreases the welding time.

3.4 Feeding the Strap Around the Package

The strapping is fed around the package as

illustrated.

Warning! The plastic strap which will be welded

must be free from oil, grease and other dirt.

Dirty plastic straps can’t be welded correct.

Lock screw

Control head

Adjustment screw

welding time

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 6

3.5 Inserting the Lower Strap

Lift and hold the handle lever with the right

hand. The left hand inserts the free end of the

strap.

First between welding gripper and the welding

stop gripper and then under the stop gripper

until it hits the strap stop.

Make sure that the strap is well aligned to both

strap stops!

With the thumb move the seesaw lever up. The

strap is locked.

Do not release the handle lever.

3.6 Inserting the Upper Strap

The left hand inserts the upper strap under the

welding gripper, over the stop gripper and

between tensioning wheel and sliding jaw until it

hits the strap stop.

Pull on the strap until the strap sling touches the

package.

Release the handle lever

The strap guides close and the tensioning wheel

will move down to the strap.

3.7 Tensioning the Strap

Press down the tensioner valve lever and then

release it again after the desired strap tension

has been reached.

The tensioning operation can be interrupted and

restarted at any time.

Seesaw lever

Lower strap

Stop gripper

Upper strap

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 7

3.8 Sealing the Straps

Press down and release immediately the

sealing valve lever.

The plastic strap is welded and cut off from the

rest of the strap.

After welding of the strapping it is neither

permitted to tension again nor to weld

again. After welding and cooling the tool

has to be removed from the strapping

before a new strapping cycle is started.

Disregard of this instruction can cause

severe malfunction and damage to the tool.

After the expiration of the adjusted sealing time, the seal has to cool down approx.

2 sec.

During that time the tool cannot be removed from the sealed strap.

After the expiration of the adjusted cooling time the welding jaw move upwards.

Now the tool can be removed from the strap.

The tool must not be removed from the strap as long as the cooling time is not

finished. Disregard of this regulation is causing insufficient seal efficiencies,

which can cause severe injuries.

3.9 Removing the Tool

Pull up the handle lever,

Pull the tool right and off the

strapping.

P380 Pneumatic Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 8

3.10 Seal –Control

A regular control of the seal is necessary. The seal can be examined visually. Make

a seal, peel it apart and examine it as follows:

Correct Seal

The seal must be completely welded over the whole

width of the strap on a length of ca. 19mm. Minor

quantities of fused plastic may overflow on sides.

Welding Time Too Short

The plastic strap is not welded over the whole width of

the strap. The seal efficiency is insufficient.

Warning! Straps with insufficient seal strength must be

removed from the package. Adjust the welding time

(see 3.3.2).

Welding Time is Too Long

If the welding time is too long the straps are

overheated. The fused plastic overflows on both sides

of the straps. The seal efficiency is affected.

Warning! Straps with insufficient seal strength must be

removed from the package. Adjust the welding time

(see 3.3.2).

3.11 Cleaning

Clean tension and sealing parts from strap abrasion

regularly using compressed air.

Do not use any mechanical tool for cleaning.

When cleaning the surface of the tool do not use

water or aggressive solvents.

3.12 Air Unit

Checking the air-pressure daily (never exceed

6 bar / 87psi)

Checking oil-level daily

The water separator must be emptied before it

is full (unless automatic)

The filter has to be cleaned following the

instructions of the manufacturer of the air- unit

Check the function and proper adjustment of

the lubricator daily (approximately 1-2 drops/min.)

Openings for blowing out

the tensioning elements

Autres manuels pour P380

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fromm Équipement d'emballage

Fromm

Fromm P356.0001.01 Manuel utilisateur

Fromm

Fromm FS31 Series Manuel utilisateur

Fromm

Fromm AP250 Manuel utilisateur

Fromm

Fromm A3H.0003 Mode d’emploi

Fromm

Fromm P326 Mode d’emploi

Fromm

Fromm FSW10 Manuel utilisateur

Fromm

Fromm P331 M/HA Mode d’emploi

Fromm

Fromm P355.0001.01 Manuel utilisateur

Fromm

Fromm AP210 Manuel utilisateur

Fromm

Fromm P328S Manuel utilisateur

Fromm

Fromm A332 Manuel utilisateur

Fromm

Fromm AP210 Instructions d'utilisation

Fromm

Fromm A334 Mode d’emploi

Fromm

Fromm FS13 Series Manuel utilisateur

Fromm

Fromm P322 Mode d’emploi

Fromm

Fromm FS130 Series Manuel utilisateur

Fromm

Fromm P300 Manuel utilisateur

Fromm

Fromm P329 M Manuel utilisateur

Fromm

Fromm P328 M Manuel utilisateur

Fromm

Fromm A383.0001 Mode d’emploi

Fromm

Fromm P328 Mode d’emploi

Fromm

Fromm FS33 Series Manuel utilisateur

Fromm

Fromm P329 M/HA Mode d’emploi

Fromm

Fromm P328 A/A Manuel utilisateur

Manuels Équipement d'emballage populaires d'autres marques

U-Line

U-Line S-15188 Manuel utilisateur

ITATOOLS

ITATOOLS ITA22 Manuel utilisateur

Fieldpiece

Fieldpiece MG44 Manuel utilisateur

Smart wasp

Smart wasp X300 Manuel utilisateur

U-Line

U-Line S-1135 Manuel utilisateur

Z.R. Tools

Z.R. Tools MS25-1 Manuel utilisateur

Sipromac

Sipromac SIPROVAC 620A Manuel utilisateur

strapex

strapex STR 66 Manuel utilisateur

U-Line

U-Line H-5334 Manuel utilisateur

Imetec

Imetec Q5901 Manuel utilisateur

Transpak

Transpak TP-201 Mode d’emploi

Lacor

Lacor 69352 Fiche technique

Eastey

Eastey EXS-100 Manuel utilisateur

Inova

Inova SV 125 Manuel utilisateur

CombiSteel

CombiSteel 7529.0010 Manuel utilisateur

HUALIAN

HUALIAN HVC-260T/1A Manuel utilisateur

U-Line

U-Line H-2079 Manuel utilisateur

Strapack

Strapack iQ400 Instructions de fonctionnement
