FRIMEC FCR200E Manuel utilisateur
FAN COIL UNIT
Models: FCR200 - 1400E
FCRQ400 - 800B
FCRQ400 - 800C
FCR200 -1400B
FFM800 - 3000B
FKM500 - 1400A
FWM300 - 800A
Air Handling System
FAS01-2020/21
Page 1
Contents
Contents .................................................................................................. 1
Product Nomenclature ............................................................................... 2
Features .................................................................................................. 7
Engineering Specifications .......................................................................... 8
Operating Range ............................................................................. 16
Sound Data ............................................................................................ 17
Sound pressure level ....................................................................... 17
Wiring Diagrams ..................................................................................... 25
Installation ............................................................................................ 28
Servicing and Maintenance ...................................................................... 34
Troubleshooting ......................................................................................35
© 2020 FRIMEC-INTERNATIONAL. All rights reserved.
Page 2
Product Nomenclature
Concealed Type Fan Coil Unit
FCR
800
E
L
H
E
D
F
FFM
F
With filter
N
No filter
D
Bottom return air plenum
B
Back return air plenum
N
No return air plenum
S
Standard drain pan
E
Extended drain pan
H
High static pressure (for
FFM only)
3
30Pa external static
pressure
6
60Pa external static
pressure
L
Left piping
R
Right piping
E
Product generation
800
Unit Size
FCR
Ceiling Concealed FCU
FFM
High Air Volume FCU
Page 3
Low Noise Concealed Type Fan Coil Unit
FCRQ
400
B
L
S
E
D
F
F
With filter
N
No filter
D
Bottom return air
plenum
B
Back return air
plenum
N
No return air plenum
S
Standard drain pan
A
Extended drain pan 200m
E
Extended drain pan 400m
3 30Pa external static
pressure
L
Left piping (facing
supply air duct)
R
Right piping (facing
supply air duct)
B
Product generation(AC Motor)
400
Unit Size
FCRQ
Low Noise Ceiling
Concealed FCU
C Product generation(DC Motor)
Page 4
High Delta-T Ceiling Concealed Type Fan Coil Unit
FCR
400
B
L
H
E
BF
BF
With return air plenum
NN
Without return air plenum
S
Standard drain pan
E
Extended drain pan
H
High external static pressure
L
Left piping (facing supply
air duct)
R
Right piping (facing supply
air duct)
B
Product generation
400
Unit Size
FCR
High Delta T Fan Coil
Unit
Page 5
Cassette Type Fan Coil Unit
FKM
500
A
A
Product generation
500
Unit Size
FKM
Cassette FCU
Wall Mounted Type Fan Coil Unit
FWM
300
A
A
Product generation
300
Unit Size
FWM
Wall Mounted FCU
Page 6
Features
Slim and Compact
Design
Light and rigid construction due to the compact and strong
structural design of the unit. Slim unit design also fulfills the
stringent space requirement of today’s building design. High Air
Volume FCU with the height of only 430mm is most suitable for
application that demand for high air flow but with space saving in
mind.
High Efficiency
Heat Exchanger
High quality copper pipes with slit profile aluminium fins are being
transformed into high efficiency heat exchanger through advance
design, manufacturing equipment and processes.
Low Noise
Through stringent static and dynamic balancing tests of motors,
coupled with high quality thermal and acoustic insulation in the
unit, superb low noise performance is achieved.
Multiple ESP Options
Standard fan coil units come with low ESP (0Pa) and high ESP
(30Pa and 60Pa) options to suit different applications. High Air
Volume FCU comes with Standard ESP (40 Pa) and High ESP (130
Pa) options to add to the product line up.
Simple Installation
Unique design of the fan coil units allow easy on-site modifications
of water pipes configuration (left or right). Accessories are also
available to ensure trouble-free installation.
Easy Maintenance
The fan coil units are equipped with high quality electrical motor
with low noise bearing that do not require lubrication and thus
minimum maintenance effort required. Blowers and also motors
can be dismantled individually if cleaning of heat exchanger is
needed. High efficiency filter provides better filtration than
normal filter with longer operational life and easy to clean.
No Leakage
One piece molded drain pan with integral thermal insulation and
professional welding skill enable all condensate water to be
collected and prevent condensation at the outside of the drain pan.
Superior Product
Quality
All fan coil units are manufactured in a ISO9001:2000 and
ISO14000:2004 certified manufacturing facility whereby highest
products’ quality is always top priority. The products’ high quality
standard has been recognized through successfully obtaining the
CE marking certification which in turn comply with the stringent
EU requirements.
Page 7
FCR-E/ FCR-B /
FCRQ-B/ FCRQ-C
FFM
FKM
FWM
Page 8
Engineering Specifications
General Data - Ceiling Concealed FCU (3 rows Coil) 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 7.0°C (inlet) / 12.0°C (outlet)
b) Air entering condition: 27.0°C DB / 19.5°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) The manufacturer reserves the rights to make changes to the above specification without prior notice.
Model FCR 200E 300E 400E 500E 600E 800E 1000E 1200E 1400E
Air Flow
High CMH 350 520 680 850 1030 1380 1710 2040 2400
CFM 206 306 400 500 606 812 1006 1200 1412
Medium CMH 270 380 510 640 780 1030 1290 1540 1975
CFM 160 224 300 376 459 606 759 906 1160
Low CMH 190 280 340 450 560 740 890 1040 1255
CFM 112 165 200 265 329 435 524 612 738
Total Cooling
Capacity
High W 2250 3180 4050 4920 5830 8115 9300 11800 13000
Medium W 2025 2765 3480 4130 4895 6895 8185 10265 11700
Low W 1665 2290 2875 3245 4255 5760 6325 7905 7560
Sensible
Cooling
Capacity
High W 1450 2080 2920 3535 4320 5660 6695 7480 9360
Medium W 1275 1750 2455 2900 3675 4695 5760 6280 7950
Low W 960 1415 1960 2190 2980 3790 4285 4635 5710
External Static
Pressure
High Pa 60
Low 30
Filter
Type Washable Type
Material Nylon
Thickness 8mm
Fan
Type Centrifugal Forward Curved Blades
Quantity 1 2 2 2 2 3 4 4 4
Material Galvanized Steel
Drive Direct-drive
Motor
Type Permanent Split Capacitor with Thermal Overload Protection
Insulation Class Class B
Power Supply V/Ph/
Hz 220~240/1/50~60
Quantity 1 1 1 1 1 2 2 2 2
Rated Power
Input
at ESP: 60 Pa W 65 75 90 110 150 178 228 270 340
at ESP: 30 Pa W 42 55 65 82 105 148 171 212 253
Cooling Coil
Type Seamless copper tubes mechanically bonded to aluminium hydrophilic fins
and collars
Max. Working
Pressure MPa 2
Pipe Connection mm(in) DN20 (3/4") - Female Threaded
Water Flow Rate l/s 0.11 0.15 0.20 0.25 0.28 0.39 0.44 0.56 0.62
Water Pressure
Drop kPa 10 25 18 21 30 30 39 28 49
Net Weight kg 13 17 17 18 20 27 31 34 39
Dimension
Length mm 705 805 895 995 1105 1435 1635 1765 1765
Width mm 470 470 470 470 470 470 470 490 490
Height mm 240 240 240 240 240 240 240 250 300
Sound
Pressure Level
at ESP: 60 Pa dB (A) 42 44 47 47 50 52 54 54 56
at ESP: 30 Pa dB (A) 39 41 43 44 46 47 49 51 52
Condensate Drain Size mm(in) DN20 (3/4") - Male Threaded
Page 9
General Data - Low Noise Ceiling Concealed FCU 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 7.0°C (inlet) / 12.0°C (outlet)
b) Air entering condition: 27.0°C DB / 19.5°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) Extended drain pan is optional upon request
6) The manufacturer reserves the rights to make changes to the above specification without prior notice.
Model FCRQ 400B 500B 600B 800B
Air Flow
High CMH 680 850 1020 1360
CFM 400 500 600 800
Medium CMH 510 640 780 1030
CFM 300 376 459 606
Low CMH 340 450 560 740
CFM 200 265 330 435
Total Cooling Capacity
High W 4020 4850 6010 7950
Medium W 3540 4070 5050 6670
Low W 2925 3200 4385 5570
Sensible Cooling Capacity
High W 2970 3485 4455 5475
Medium W 2500 2860 3790 4540
Low W 1995 2160 3070 3665
External Static Pressure Pa 30
Filter
Type Washable Type
Material Nylon
Thickness 8mm
Fan
Type Centrifugal Forward Curved Blades
Quantity 2 2 2 3
Material Galvanized Steel
Drive Direct-drive
Motor
Type Permanent Split Capacitor with Thermal
Overload Protection
Insulation Class Class B
Power Supply V/Ph/Hz 220~240/1/50~60
Quantity 1 1 1 2
Rated Power Input at ESP: 30 Pa W 72 85 100 155
Cooling Coil
Type Seamless Copper Tubes Mechanically Bonded
to Aluminium Hydrophilic Fins and Collars
Max. Working
Pressure MPa 1.6
Pipe Connection mm(in) DN20 (3/4") - Female Threaded
Water Flow Rate l/s 0.20 0.24 0.30 0.40
Water Pressure Drop kPa 30 30 40 35
Net Weight kg 17 18 20 26
Dimension
Length mm 905 985 1185 1465
Width mm 490 490 515 515
Height mm 250 250 275 275
High Sound Pressure Level at ESP: 30 Pa (H) dB (A) 41 43 43 46
Medium Sound Pressure Level at ESP: 30 Pa (M) dB (A) 32 35 39 37
Low Sound Pressure Level at ESP: 30 Pa (L) dB (A) 23 26 30 28
Condensate Drain Size mm(in) DN20 (3/4") - Male Threaded
