Frigidaire FRS23H7C Manuel utilisateur

N58L00001.eps N58FCCBBB2.eps N58RCCBBC4.eps N58BAAAAB1.eps

N58SKDEBD1.eps N58TAAAAB4.eps N58CAAAAC0.eps N58XEAAAA0.eps

N58YAAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps

Product No. FRS23H7CSB4 FRS23H7CSB5

Series R134a R134a

Color stain/blk stain/blk

Volts 115 115

Wiring Diagram 241526901 241526901

Owner's Guide 240389311 240389311

Market North America North America

Energy Guide 240592210 240592210

Service Data Sheet 240389616 240389616

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995440640

05/06/29

(EN/SERVICE/DCS)

357

SIDE-BY-SIDE

REFRIGERATOR

Model No.

FRS23H7C

Publication No: 5995440640 FRS23H7C

06/05 2

FREEZER DOOR

21C

22C

13A

22A

21A

N58FCCBBB2

FRS23H7C Publication No: 5995440640

# Functional Parts 3 06/05

* Non-Illustrated Parts

FREEZER DOOR

Model Index: AFRS23H7CS (FRS23H7CSB4)

BFRS23H7CS (FRS23H7CSB5)

POS. NO PART NO. DESCRIPTION

1 # 240390608 A B Gasket-frzr door, black, magnetic

4A 240367301 A B Bin-door, frzr-upper

4B 240359001 A B Bin-door

11 240554224 A B Door-frzr, stainless steel, complete assy

13A 240581906 A B Door Stop, black, frzr

18 240359108 A B Handle-door, black, LH

21 218781100 A B Screw, pan head, 8-18 x 0.625

21A 240598401 A B Screw, 10-32 x 1/2

21C 240521302 A B Screw, #8-18 x 3/4

22A 240328204 A B Bearing-hinge(frz), black, closer

22C 240328404 A B Bearing-hinge, black, upper

37 240359203 A B Trim-handle, 30.13", black, lower

68 241525101 A B Chute-ice

72 240421701 A B Button-handle mtg, dovetail

73 218396700 A B Block-handle mtg, dovetail

74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

* 240352102 A B Connector-water, straight

* 240470401 A B Connector-amp

* 240552102 A B Harness-wiring, door

* 5303918256 A B Dispenser heater kit

Publication No: 5995440640 FRS23H7C

06/05 4

REFRIGERATOR DOOR

FRS23H7C Publication No: 5995440640

# Functional Parts 5 06/05

* Non-Illustrated Parts

REFRIGERATOR DOOR

Model Index: AFRS23H7CS (FRS23H7CSB4)

BFRS23H7CS (FRS23H7CSB5)

POS. NO PART NO. DESCRIPTION

2 # 240390607 A B Gasket-refr door, black, magnetic

4 240363702 A B Bin-door, 2-liter

7 240338303 A B Door, dairy, clear

12 240572601 A B Label-nameplate

13 240581905 A B Door Stop, black, ref

15 240451979 A B Door-refr, stainless steel, complete assy

18 240359103 A B Handle-door, black, RH

21 218781100 A B Screw, pan head, 8-18 x 0.625

21A 240598401 A B Screw, 10-32 x 1/2

21C 240521302 A B Screw, #8-18 x 3/4

22 240328203 A B Bearing-hinge, black, closer

22B 240328404 A B Bearing-hinge, black, upper

27A 240396102 A B Retainer, tall bottle

37 240359203 A B Trim-handle, 30.13", black, lower

49 240324511 A B Bin-door, gallon

72 240421701 A B Button-handle mtg, dovetail

73 218396700 A B Block-handle mtg, dovetail

74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995440640 FRS23H7C

06/05 6

CABINET

40 66

14A

100

21C

30A

10A

N58BAAAAB1

150

FRS23H7C Publication No: 5995440640

# Functional Parts 7 06/05

* Non-Illustrated Parts

CABINET

Model Index: AFRS23H7CS (FRS23H7CSB4)

BFRS23H7CS (FRS23H7CSB5)

POS. NO PART NO. DESCRIPTION

10 240435905 A B Cover-air duct

10A 240475906 A B Cover-evap coil, lower

11 5303208309 A B Plug-hole, factory test

14 # 240505801 A B Switch, light/lamp

14A# 215486600 A B Switch-light/lamp

21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500

22 240457702 A B Plate-door closer

23 240402701 A B Screw-#10-32 x 1/4 flat hd

28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special

30 240419101 A B Bracket-lower hinge, ref

30A 240419102 A B Bracket-lower hinge

37 240337603 A B Trim-cabinet corner, black, (2)

38 240327201 A B Bracket-upper hinge

40 240327007 A B Cover-upper hinge, black

41 241550801 A B Grommet-shelf mtg, 1.40" long

41* 241550701 A B Grommet-shelf mtg, .96" long

42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8

43 240335003 A B Roller Assy, adjustable,front, (2)

45 241500301 A B Screw, hex washer head, 8-18AB x 0.500

47 240349402 A B Channel-shelf mtg, side, (2)

58 218781100 A B Screw, pan head, 8-18 x 0.625

66 5304424968 A B Damper Cover Assy

66* 240518802 A B Pin-push, push-in, plastic

72 240324405 A B Grille/Kickplate, black

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 A B Roller, compressor base, rear, (2)

83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 241574601 A B Cover access

90 218249807 A B Seal-coil cover

91 240380101 A B Duct-ice maker

92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg

100 240423701 A B Support, crisper cover, front, (4)

100* 240350802 A B Support, crisper cover, rear, (4)

150 240368701 A B Guide-control bulb

* 240396801 A B Clamp, tube/wiring, nylon, black/natural

* 240479601 A B Plug, button, cab liner holes, (2)

* 240481601 A B Shim-lower hinge

* 5303305345 A B Paint, touch-up, black

Publication No: 5995440640 FRS23H7C

06/05 8

SHELVES

FRS23H7C Publication No: 5995440640

# Functional Parts 9 06/05

* Non-Illustrated Parts

SHELVES

Model Index: AFRS23H7CS (FRS23H7CSB4)

BFRS23H7CS (FRS23H7CSB5)

POS. NO PART NO. DESCRIPTION

2 241510603 A B Trim-basket

11 240350648 A B Shelf-freezer, glass, lower

11A 240350647 A B Shelf-freezer, glass, upper

15 240588001 A B Light Bulb

15A 240436702 A B Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature

16 240590401 A B Socket-light

16A# 241513901 A B Socket-light

16A* 241537502 A B Harness-wiring

24 240355204 A B Shelf-"Spill-Safe", fixed, (3)

24A 240350101 A B Shelf-"Spill-Safe", cantilever, sliding

24C 240355201 A B Shelf-"Spill-Safe", fixed, (1)

25 240354502 A B Cover-crisper pan, upper

25* 240362101 A B Clip-slide, cover-crisper

25A 240354602 A B Cover-crisper pan, lower

26 240354717 A B Pan-crisper, upper

26* 240349801 A B Clip-slide, pan-crisper

26A 240351101 A B Control-humidity

27 240354818 A B Pan-crisper, lower

39 240367601 A B Trim-shelf, front

42 240356501 A B Track, meat pan hanger, RH

42A 240349701 A B Hanger-meat pan, LH

42A* 240349901 A B Block-meat pan rail, LH

42A* 240350001 A B Spring-meat pan rail

47 240350613 A B Insert-pan cover, glass

47A 240350614 A B Insert-pan cover, glass

49 240564301 A B Basket-sliding

49B 240530503 A B Basket-sliding, upper, full

51 240343002 A B Hanger-basket, RH

51A 240395502 A B Hanger-basket, RH

52 240343102 A B Hanger-basket, LH

52A 240395602 A B Hanger-basket, LH

62 240355518 A B Pan-meat

81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

97 240545303 A B Water Tank Assy, coiled tubing, front filter

100 240326301 A B Cover-water tank

101 218493100 A B Screw, hex washer head, 8-18AB x 1-3/4

109 240351301 A B Base-crisper light socket

120 240342901 A B Shelf-ice cream

123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438

126 218867405 A B Channel, auger mtg, LH

126 218867406 A B Channel, auger mtg, RH

136 240424501 A B Dispenser-can, white

140 240430501 A B Channel, wtr tube cover

140A 240430503 A B Channel, wtr tube cover

141 240585403 A B Bracket-light socket

142 240582701 A B Shield-light, deli pan

Publication No: 5995440640 FRS23H7C

06/05 10

CONTROLS
