Safety information.......................................2
Safety instructions...................................... 4
Product description.....................................6
Operation....................................................7
Daily use.....................................................9
Care and cleaning.................................... 11
Hints and tips............................................12
Troubleshooting........................................13
Installation................................................ 16
Technical information............................... 20
FRCF185W
User Manual
CONTENTS
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
if an incorrect installation and use causes injuries and
damages. Always keep the instructions with the appliance for
future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
•Do not let children play with the appliance.
•Cleaning and user maintenance shall not be made by
children without supervision.
•Keep all packaging away from children.
General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and
other working environments
–By clients in hotels, motels, bed and breakfast and other
residential type environments
•Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
•Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
2
SAFETY INFORMATION
•Clean the appliance with a moist soft cloth. Only use neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
•Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
3
SAFETY INFORMATION
Installation
WARNING!
Only a qualified person must install
this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction supplied
with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where there
is direct sunlight.
• Do not install this appliance in areas that
are too humid or too colds, such as the
construction appendices, garages or
wine cellars.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the power
supply. If not, contact an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
Use
WARNING!
Risk of injury, burns, electrical shock
or fire.
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless
they are stated applicable by the
manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level
of environmental compatibility. This gas
is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure
on the drink container.
• Do not store flammable gas and liquid in
the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
4
SAFETY INSTRUCTIONS
• Do not remove or touch items from the
freezer compartment if your hands are
wet or damp.
• Do not freeze again food that has been
thawed.
• Obey the storage instructions on the
packaging of frozen food.
Care and cleaning
WARNING!
Risk of injury or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• This appliance contains hydrocarbons in
the cooling unit. Only a qualified person
must do the maintenance and the
recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority for
information on how to discard the
appliance correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat
exchanger.
5
SAFETY INSTRUCTIONS
Product overview
1
4
2
3
5
1Control panel
2Flaps
3Freezer baskets
4Rating plate
5SpacePlus baskets
6
PRODUCT DESCRIPTION
Control panel
1 2 3 4 5
1Alarm light
2FastFreeze indicator
3FastFreeze switch
4Power indicator light
5Temperature regulator
Switching on
1. Insert the plug into the wall socket.
2. Turn the temperature regulator
clockwise to a medium setting.
The Power indicator light and the Alarm
light will light up.
Switching off
To turn off the appliance, turn the
Temperature regulator to the "O" position.
Temperature regulation
The temperature is automatically regulated.
1. Turn the Temperature regulator toward
lower settings to obtain the minimum
coldness.
2. Turn the Temperature regulator toward
higher settings to obtain the maximum
coldness.
A medium setting is generally the most
suitable. However, the exact setting
should be chosen keeping in mind that
the temperature inside the appliance
depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance.
If the ambient temperature is high or
the appliance is fully loaded, and the
appliance is set to the lowest
temperatures, it may run continuously
causing frost to form on the rear wall.
In this case the regulator knob must be
set to a higher temperature to allow
automatic defrosting and therefore
reduced energy consumption.
FastFreeze function
To activate the FastFreeze function, press
the FastFreeze switch.
The FastFreeze light will light up.
7
OPERATION
High temperature alarm
Temperature increase in the freezer
compartment (for example due to an earlier
power failure or door is open) is indicated
by alarm light flashing.
When normal conditions are restored the
alarm light will stop flashing.
8
OPERATION
WARNING!
Refer to Safety chapters.
Initial power on
CAUTION!
Before inserting the power plug in to
the outlet and switching on the cabinet
for the first time, leave the appliance
standing upright for at least 4 hours.
This will assure a sufficient amount of
time for the oil to return to the
compressor. Otherwise the
compressor or electronic components
may sustain damage.
Storage of frozen food
When first starting-up or after a period out
of use, before putting the products in the
compartment let the appliance run at least
2 hours with the FastFreeze function turned
on. The freezer drawers ensure that it is
quick and easy to find the food package
you want. If large quantities of food are to
be stored, remove all drawers except for
the bottom drawer which needs to be in
place to provide good air circulation. On all
shelves it is possible to place food that
protrude until 15 mm from the door.
WARNING!
In the event of accidental defrosting,
for example due to a power failure, if
the power has been off for longer that
the value shown in the technical
characteristics chart under "rising
time", the defrosted food must be
consumed quickly or cooked
immediately and then re-frozen (after
cooling).
Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
To freeze small amount of fresh foods it is
not necessary to change the present
setting.
To freeze fresh food activate the
FastFreeze function at least 24 hours
before placing the food to be frozen in the
freezer compartment.
Place the food to be frozen in the two top
compartments.
The maximum amount of food that can be
frozen in 24 hours is specified on the rating
plate, a label located on the inside of the
appliance.
The freezing process lasts 24 hours: during
this period do not add other food to be
frozen.
When the freezing process is completed,
return to the required temperature (see
"FastFreeze Function").
Thawing
Deep-frozen or frozen food, prior to being
used, can be thawed at room temperature.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
Removal of freezing baskets
and glass shelves from the
freezer
The freezing baskets have a limit stop to
prevent their accidental removal or falling
out. At the time of its removal from the
freezer, pull the basket towards yourself
and, upon reaching the end point, remove
the basket by tilting its front upwards.
9
DAILY USE
2
1
At the time of putting it back, slightly lift the
front of the basket to insert it into the
freezer. Once you are over the end points,
push the baskets back in their position.
The appliance is equipped with shelf stops
to secure the shelves.
The shelves must be lifted up (1) on each
side and than pulled outwards (2).
1
1
2
The glass shelves equipped with expander
rollers are secured with locking pins.
To remove them, loose the locking pin on
each side on the expander roller. If
necessary, use a screwdriver.
Afterwards pull out both locking pins (1)
and pull the glass shelf outwards (2).
2
1
1
1
10
DAILY USE
Table des matières
Autres manuels Frigidaire Congélateur
Frigidaire
Frigidaire FFU14FC4AW1 Manuel utilisateur
Frigidaire
Frigidaire FFU14FC4AW Manuel utilisateur
Frigidaire
Frigidaire FFU17M7HW - 17.1 cu. Ft. Manual Defrost Upright... Instructions d'utilisation et de sécurité
Frigidaire
Frigidaire FFC18K1CW Manuel utilisateur
Frigidaire
Frigidaire FFFC20M4TW Manuel du propriétaire
Frigidaire
Frigidaire FFC18C8CW Manuel utilisateur
Frigidaire
Frigidaire FFC15K1CW0 Manuel utilisateur
Frigidaire
Frigidaire FFC09K0CW0 Manuel utilisateur
Frigidaire
Frigidaire FFU14M5HW - 14.1 cu. Ft. Manual Defrost Upright... Manuel utilisateur
Frigidaire
Frigidaire FFFH20F2QW Manuel du propriétaire
Frigidaire
Frigidaire FFC0522DW - 5 cu. Ft. Chest Freezer Manuel utilisateur
Frigidaire
Frigidaire FFU14FC2CW Manuel utilisateur
Frigidaire
Frigidaire FFU17D7HW0 Manuel utilisateur
Frigidaire
Frigidaire FFU20F9GW Manuel utilisateur
Frigidaire
Frigidaire UF-13H Guide de référence rapide
Frigidaire
Frigidaire FFU17FK0DW Manuel utilisateur
Frigidaire
Frigidaire FFU11F0HW4 Guide de l'utilisateur
Frigidaire
Frigidaire FRF170FF Manuel utilisateur
Frigidaire
Frigidaire FFC20G4AW Manuel utilisateur
Frigidaire
Frigidaire FFU14F9G Manuel utilisateur
