Frigidaire FDB679GF Manuel utilisateur

PRODUCT NO. BASE MODEL NO. SERIES COLOR

FDB679GFC0 FDB679GF Pro Gallery black/stainless

FDB679GFC1 FDB679GF Pro Gallery black/stainless

FDB679GFC2 FDB679GF Pro Gallery black/stainless

FDB679GFW0 FDB679GF Pro Gallery white/stainless

FDB679GFW1 FDB679GF Pro Gallery white/stainless

FDB679GFW2 FDB679GF Pro Gallery white/stainless

MARKET

North America

Publication No.

5995336475

000414

-EN/SERVICE /ECL

821

24" BUILT-IN

DISHWASHER

Model No.

FDB679GF

FACTORY PARTS CATALOG

DISHWASHER

SERVICE DATA SHEET # - 154279801

OWNER’S GUIDE # - 154256001

WIRING DIAGRAM # - 154279801

101 Masters Blvd.

Anderson, SC 29624

This Publication Supercedes

Publication #5995292082

04/00 2

Publication No. FDB679GF

5995336475

CONTROL PANEL

# = Fast Moving Part 3 04/00

* = Non-Illustrated Part

FDB679GF Publication No.

5995336475

CONTROL PANEL

A = FDB679GF (FDB679GFC0)

B = FDB679GF (FDB679GFC1)

C = FDB679GF (FDB679GFC2)

D = FDB679GF (FDB679GFW0)

E = FDB679GF (FDB679GFW1)

F = FDB679GF (FDB679GFW2)

POS. NO PART NO DESCRIPTION

1 154222603 A B C D - - Panel-control,black

1 154222601 ----EF Panel-control,white

2 154254603 A B C - - - Insert-control pnl,black

2 154254601 ---DEF Insert-control pnl,white

3 # 154295801 A - - D - - Timer

3 # 154295701 - B C - E F Timer

3* 154095701 A B C D E F Screw-timer,thread rolling ,(2)

6 5300809317 A B C D E F Light assy

8 # 154214601 A B C D E F Switch-selector,6 button

10 5303318719 A - - D - - Screw,mtg.

10 154297701 - B C - E F Screw,retainer-thermo

11 5300809036 A B C D E F Lens-light

12 154253703 A B C - - - Pushbutton,black ,(6)

12 154253701 ---DEF Pushbutton,white ,(6)

13 154253603 A B C - - - Knob-timer,black

13 154253601 ---DEF Knob-timer,white

20 154228301 A B C D E F Duct-dynamic

25 154287301 A B C D E F Seal-chamber

26 154240501 A B C D E F O-ring,vent dr liner

27 154226701 A B C D E F Actuator-wax

28 154226901 A B C D E F Valve-vent

29 154226401 A B C D E F Gasket-valve

30 # 154226801 A B C D E F Blower-crossflow

31 154228101 A B C D E F Chamber-vapor

* 154131203 A B C D E F Shield-timer

* 154242201 A B C D E F Shield-switch

* # 154296201 A B C D E F Wiring Harness

04/00 4

Publication No. FDB679GF

5995336475

DOOR

# = Fast Moving Part 5 04/00

* = Non-Illustrated Part

FDB679GF Publication No.

5995336475

A = FDB679GF (FDB679GFC0)

B = FDB679GF (FDB679GFC1)

C = FDB679GF (FDB679GFC2)

D = FDB679GF (FDB679GFW0)

E = FDB679GF (FDB679GFW1)

F = FDB679GF (FDB679GFW2)

POS. NO PART NO DESCRIPTION

1 154226002 A B C D E F Spring-door,(2)

2 154093301 A B C D E F Screw-arm assy,(4)

3 154225901 A B C D E F Arm Assy,RH

3 154225902 A B C D E F Arm Assy,LH

3* 154211501 A B C D E F Pin-arm

5 154079601 A B C D E F Nut-arm assy,(4)

7 154299001 A - - D - - Door-inner assy

7 154299002 - B C - E F Door-inner assy

9 154230101 A B C D E F Dispenser-det/rinse aid

10 5300808658 A B C D E F Screw,#8A x .375"

12 # 154211201 A B C D E F Latch assy

12A 154293103 A B C - - - Handle-latch,black

12A 154293101 ---DEF Handle-latch,white

20 154281907 A B C D E F Panel-outer door,stainless steel ,

insulation incl

41 154207004 A B C D E F Towel bar assy

49 154297602 A B C D E F Gasket-door,bottom

50 154211401 A B C D E F Support-door hinge

* 154103702 A B C D E F Screw-latch mtg,(2)

* 154200601 A B C D E F Screw-#10-16 x 3/8

* 154213801 A B C D E F Cleaner,stainless steel

* 154253201 A B C D E F Insulation,door

* 5300808749 A B C D E F Screw,C.R. truss ,#8 .625

* 5300809055 A B C D E F Screw,cr truss s.s. ,8 .438

* 5300809696 - B C - E F Screw-#8-18

DOOR

04/00 6

Publication No. FDB679GF

5995336475

TUB

# = Fast Moving Part 7 04/00

* = Non-Illustrated Part

FDB679GF Publication No.

5995336475

A = FDB679GF (FDB679GFC0)

B = FDB679GF (FDB679GFC1)

C = FDB679GF (FDB679GFC2)

D = FDB679GF (FDB679GFW0)

E = FDB679GF (FDB679GFW1)

F = FDB679GF (FDB679GFW2)

POS. NO PART NO DESCRIPTION

1 # 154209301 A B C D E F Tub assy,w/frame parts

2 154211601 A B C D E F Strike-door

3 # 154211801 A B C D E F Gasket-tub

4 154041001 A B C D E F Screw,plask #1 ,10-10 x 9/16

5 154080001 A B C D E F Roller-tub

6 5303943103 A B C D E F Screw w/washer,(8)

22 154239801 A B C D E F Tubing-water inlet

23 5303318539 A B C D E F Clamp-tubing,(2)

24 154225601 A B C D E F Hose-drain

25 # 154209701 A B C D E F Float

28 # 154225501 A B C D E F Switch-float

28* 154209801 A B C D E F Bracket-float switch

29 # 154290202 A - - D - - Thermostat,high limit

29 # 154290203 - B C - E F Thermostat,high limit

30 154241101 A B C D E F Retainer-thermostat

* 154200601 A B C D E F Screw-#10-16 x 3/8

* 154238303 A B C D E F Insulation,blanket

* 154249401 A B C D E F Dampener-tub,front

* 154249402 A B C D E F Dampener-tub,back

TUB

04/00 8

Publication No. FDB679GF

5995336475

MOTOR & PUMP

# = Fast Moving Part 9 04/00

* = Non-Illustrated Part

FDB679GF Publication No.

5995336475

A = FDB679GF (FDB679GFC0)

B = FDB679GF (FDB679GFC1)

C = FDB679GF (FDB679GFC2)

D = FDB679GF (FDB679GFW0)

E = FDB679GF (FDB679GFW1)

F = FDB679GF (FDB679GFW2)

POS. NO PART NO DESCRIPTION

1 # 154247601 A B C D E F Heater

1* 154289801 A B C D E F Shield-heater terminal

1* 154106201 A B C D E F Nut-heater,(2)

2 154211001 A B C D E F Bracket-heater

7 154245901 A B C D E F Macerator

10 154245501 A B C D E F Cover-volute

12 154245801 A B C D E F Impeller

12* 154282701 A B C D E F Screw,ss impeller

13 154246801 A B C D E F Gasket-sump

14 154245401 A B C D E F Housing-sump

15 # 154246701 A B C D E F Check valve

16 154246501 A B C D E F Retainer,sump

24 154250901 A B C D E F Spray arm-lower,w/cover

24A 154250501 A B C D E F Spray arm-center

24A* 154252001 A B C D E F Nut-spray arm

32 154251701 A B C D E F Tube-delivery

32A 154251601 A B C D E F Gasket-delivery tube

34 154064901 A B C D E F Washer-insulating

40 154106801 A B C D E F Clamp-hose,(2)

54 154234401 A B C D E F Hose-connector

55 154245601 A B C D E F Bracket-motor

55A 154246201 A B C D E F Bracket-motor,front

56 # 154245702 A B C D E F Motor,circulation

56* 154287201 A B C D E F Screw,motor mounting

57 154246001 A B C D E F Barrel,front

57A 154246101 A B C D E F Barrel,rear

58 154246401 A B C D E F Check ball

59 154246901 A B C D E F O-ring,rear

59A 154247001 A B C D E F O-ring,front

60 154247501 A B C D E F Drain Pump Assy

60* 154234501 A B C D E F Bracket-motor,drain

61 154250201 A B C D E F Nozzle,3rd level ,spray arm

62 154292901 A - - D - - Support-spray arm,lower

62 154294101 - B C - E F Support-spray arm

63 154252201 A B C D E F Base-soil director

64 154252301 A B C D E F Filter-soil director

65 154283001 A - - D - - Filter Assy

65 154283002 - B C - E F Filter Assy

66 154252701 A B C D E F Trap-glass

67 154246601 A B C D E F Hose-drain,shunt

MOTOR & PUMP

04/00 10

Publication No. FDB679GF

5995336475

MOTOR & PUMP
