Frigidaire FDB125RH Manuel utilisateur

PRODUCT NO. BASE MODEL NO. SERIES COLOR

FDB125RHB3 FDB125RH 24" Built-in black

FDB125RHD3 FDB125RH 24" Built-in almond

FDB125RHS3 FDB125RH 24" Built-in white

FDB125RHU1 FDB125RH 24" Built-in bisque

MARKET

North America

Publication No.

5995367199

020228

-EN/SERVICE /ECL

821

24" Built-In

DISHWASHER

Model No.

FDB125RH

FACTORY PARTS CATALOG

DISHWASHER

SERVICE DATA SHEET # - 154414801

OWNER’S GUIDE # - 154395101

INSTALLATION INSTRUCTIONS # - 154415901

ENERGY GUIDE LABEL # - 154399001

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

02/02 2

Publication No. FDB125RH

5995367199

CONTROL PANEL

# = Fast Moving Part 3 02/02

* = Non-Illustrated Part

FDB125RH Publication No.

5995367199

CONTROL PANEL

A = FDB125RH (FDB125RHS3)

B = FDB125RH (FDB125RHB3)

C = FDB125RH (FDB125RHD3)

D = FDB125RH (FDB125RHU1)

POS. NO PART NO DESCRIPTION

1 154398101 A - - - Panel,control ,white

1 154398103 - B C D Panel,control ,black

2 154400701 A - - - Insert,control panel ,white

2 154400703 - B C D Insert,control panel ,black

3 # 154393901 A B C D Timer

3* 5303318719 A B C D Screw,mtg.

8 # 154240401 A - - - Switch,rocker/selector ,white

8 # 154240403 - B C D Switch,rocker/selector ,black

13 154338301 A - - - Knob,timer ,white

13 154338303 - B C D Knob,timer ,black

20 154345102 A B C D Vapor Chamber Assy,w/vent gasket

25 154229201 A B C D Seal,chamber

* # 154394501 A B C D Wiring Harness

* 154399001 A B C D Label,energy guide

* 154283901 A B C D Screw,#8-10 ,3/8 phillips

02/02 4

Publication No. FDB125RH

5995367199

DOOR

# = Fast Moving Part 5 02/02

* = Non-Illustrated Part

FDB125RH Publication No.

5995367199

A = FDB125RH (FDB125RHS3)

B = FDB125RH (FDB125RHB3)

C = FDB125RH (FDB125RHD3)

D = FDB125RH (FDB125RHU1)

POS. NO PART NO DESCRIPTION

1 154345902 A B C D Spring,door ,(2)

1A 154325201 A B C D Linkage,door spring ,(2)

2 154093301 A B C D Screw,arm assy ,(4)

3 154325304 A B C D Arm Assy,LH

3A 154325303 A B C D Arm Assy,RH

* 154400601 A B C D Pin,arm assy

5 154079601 A B C D Nut,arm assy ,(4)

7 154299002 A B C D Door,inner assy

7A 154332701 A B C D Grate,liner

9 154230101 A B C D Dispenser,det/rinse aid ,includes #22

9* 154294701 A B C D Screw,#7 plas .375 ,(6) ,disp. assy.

10 154103702 A B C D Screw,latch mtg ,(2)

12 # 154361201 A - - - Latch assy,white

12 # 154361203 - B C D Latch assy,black

20 154359105 A - - - Door,white

20 154359107 - B - - Door,black

20 154359106 - - C - Door,almond

20 154359110 ---D Door,bisque

22 154388801 A B C D Cap,Rinse aid

49 154297602 A B C D Gasket,door ,bottom

50 154211401 A B C D Support,door hinge

51 154320301 A B C D Clamp,drip loop ,wire

* 154200601 A B C D Screw,#10-16 x 3/8

DOOR

02/02 6

Publication No. FDB125RH

5995367199

TUB

# = Fast Moving Part 7 02/02

* = Non-Illustrated Part

FDB125RH Publication No.

5995367199

A = FDB125RH (FDB125RHS3)

B = FDB125RH (FDB125RHB3)

C = FDB125RH (FDB125RHD3)

D = FDB125RH (FDB125RHU1)

POS. NO PART NO DESCRIPTION

1 # 154209204 A B C D Tub,plastic

2 154211601 A B C D Strike,door

3 # 154211801 A B C D Gasket,tub

4 154200602 A B C D Screw,10-16 x 3/8 ,hex

5 154333902 A B C D Roller,tub

6 5303943103 A B C D Screw,w/washer ,(8)

22 154239801 A B C D Tubing,water inlet

23 5303318539 A B C D Clamp,tubing ,(2)

24 # 154411002 A B C D Hose,drain

25 # 154209701 A B C D Float

28 154408701 A B C D Switch assy,float

29 # 154290204 A B C D Thermostat,re-settable

30 154241101 A B C D Retainer,thermostat

30* 154297701 A B C D Screw,retainer-thermo

* 154238304 A B C D Insulation,tub

* 154041001 A B C D Screw,plask #1 ,10-10 x 9/16

* 5300807270 A B C D Screw,(2) ,countertop mtg.

TUB

02/02 8

Publication No. FDB125RH

5995367199

MOTOR & PUMP

# = Fast Moving Part 9 02/02

* = Non-Illustrated Part

FDB125RH Publication No.

5995367199

A = FDB125RH (FDB125RHS3)

B = FDB125RH (FDB125RHB3)

C = FDB125RH (FDB125RHD3)

D = FDB125RH (FDB125RHU1)

POS. NO PART NO DESCRIPTION

1 # 154247601 A B C D Heater

1* 154106201 A B C D Nut,heater ,(2)

1* 154289801 A B C D Shield,heater terminal

2 154359701 A B C D Bracket,heater ,(2)

10 154335301 A B C D Cover,volute

13 154246801 A B C D Gasket,sump

14 154365903 A B C D Housing,sump

16 154246502 A B C D Retainer,sump

24 154414201 A B C D Spray arm,lower ,w/heat shield

24A 154335201 A B C D Nut,spray arm

40 154348401 A B C D Clamp,red ,pump

40 154348501 A B C D Clamp,silver ,pump

40* 154380601 A B C D Clamp,hose ,(1)

54 154234401 A B C D Hose,connector

55 154362301 A B C D Bracket,motor ,askoll

55* 5303316032 A B C D Screw,truss ss ,8 .625

59 154246901 A B C D O-ring,rear

59A 154247001 A B C D O-ring,front

60 154407401 A B C D Drain Pump Assy

60* 154234501 A B C D Bracket,motor ,drain

63 154252201 A B C D Base,soil director

64 154332602 A B C D Filter,soil director

65 154252401 A B C D Filter,polypro

70 # 154395402 A B C D Motor assembly,circulation ,w/o o’rings

* 154200601 A B C D Screw,#10-16 x 3/8

MOTOR & PUMP

02/02 10

Publication No. FDB125RH

5995367199

FRAME
