Frigidaire FBD2400KB - 24" Dishwasher Instructions d'installation

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric24" Built-In

Signature Features

Ready-Select™ Controls

Easily select options with the touch

of a button.

SpaceWise™

Silverware Basket

There’s a place for all of your

silverware in our multicompartment,

removable basket.

Quiet Dishwasher

A quiet performance every time.

Tall-Tub Design

Our large capacity, tall-tub dishwasher

fits up to 12 place settings so you can

wash more at once.

Product Dimensions

Height (Adjustable) 33-1/2" – 35"

Width 24"

Depth (Including Door) 25"

More Easy-To-Use Features

Energy Saver Dry Option

No heat dry option.

Low Rinse-Aid Indicator Light

2-Level Wash Tower Design

White Interior

UltraQuiet™

Sound Reduction System

Available in:

Dishwashers

FBD2400K W/ B / Q

White

(W)

Black

(B) Bisque

(Q)

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

1 For use on adequately wired 120V, dedicated circuit having

2-wire service with a separate ground wire. Appliance must be

grounded for safe operation.

Features

Control Design

Digital Display

Door Latch

Stay-Put Door Hinge Design

Low Rinse-Aid Indicator Light

Interior Design

Interior Color

Wash System

Wash Levels / Wash Speeds

Sound Package

Filter

Filter Trap

Soft Food Disposer

dB Level

Drying System

Cycles

Number of Cycles

Heavy

Normal

Light

Delicate

Favorite

China Crystal

Rinse Only

Energy Saver

Upper Rack Wash Only

Cycle Indicator Light

Control Lock

Options

Heat / No Heat Dry

Hi-Temp Wash

NSF® Certiﬁed Sanitize Rinse

Delay Start

Rack System

Rack Design / Rack Coating

Upper Rack –

Stemware / Champagne Glass Holders

Fold-Down Tines

Cup Shelves

Lower Rack –

SpaceWise™ Silverware Basket

Fold-Down Tines

Small Items Cover

Speciﬁcations

Water Inlet Location

Water Usage (Gallons)

Water Pressure (PSI)

Integral Air Gap on Supply

Leveling Legs

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating) @ 120 Volts 1

Amps @ 120 Volts

Shipping Weight (Approx.)

Mechanical

Yes

Tall Tub

White

Tower

2 / 1

UltraQuiet™

Plastic

Removable

Yes

Static

Yes

Standard / PVC

Standard

Left Bottom Front

7.2

20 – 120

Yes

Right Bottom Front

120V / 60 Hz / 15A

1.44

68 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Dishwashers

FBD2400K W/ B / Q 24" Built-In

24" Built-In Dishwashers

Frigidaire Baseline

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Depth (Min.)

34-1/4"

35-1/4"

24"

NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Meets requirements

of ASSE 1006

Product Dimensions

A - Height (Adjustable)

B - Width

C - Depth (Including Door)

D - Depth (To Tub Flange)

Depth with Door Open 90˚

33-1/2" – 35"

24"

25"

22-1/2"

49-1/4"
