Frigidaire FFGC3603LW Instructions d'installation

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

36" Gas

Drop-In Cooktop

FFGC3603L W

1When properly installed, meets the appliance

standards in the Americans with Disabilities Act

and the Architectural Barriers Act Accessibility

Guidelines as published by the United States

Access Board on June 23, 2004, as amended

August 5, 2005.

Burners

Right Front

Right Rear

Left Front

Left Rear

BTU

9,000

White

(W)

Product Dimensions

Width 36"

Depth 18-5/8"

Height 3-1/2"

More Easy-To-Use Features

Porcelain Cooktop Grates

Grates are durable and easy to clean.

LP Gas Conversion Option

A.D.A. Compliant1

Available in:

Spill Saver™ Drip Bowls

Cooktop features chrome drip bowls that

make cleaning up spills quick and easy.

Electronic Pilotless Ignition

Saves energy and can be ignited

manually when electricity is out.

Ready-Select™ Controls

Select options or control cooking

temperature with our easy-to-use

controls.

Color-Coordinated

Control Knobs

White cooktops come with matching

knobs.

Accessories information available

on the web at frigidaire.com

Granite Countertop

Installation Kit available.

USA

•

10200 David Taylor Drive •

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Drop-In Cooktop

FFGC3603L W 36" Gas

Features

Controls

Surface Type

Grates

Right Front Element (BTU)

Right Rear Element (BTU)

Left Front Element (BTU)

Left Rear Element (BTU)

Control Location

Knob Color

Knob Type

Bowl Type

Certiﬁcations

A.D.A. Compliant1

Speciﬁcations

Power Supply Connection Location

Gas Supply Connection Location

LP Gas Conversion Kit

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts2

Amps @ 120 Volts

Minimum Circuit Required (Amps)

Approved for Electric Single Wall Oven

Combination Installation

Shipping Weight (Approx.)

Ready-Select™

Color-Coordinated

Porcelain

Steel Round with

Black Gloss Finish

9,000

Center Front

Color-Coordinated

Plastic

Chrome

Yes

Center Front

Included

120V / 60V / 15A

1.0

30 Lbs.

1When properly installed, meets the appliance standards in the Americans

with Disabilities Act and the Architectural Barriers Act Accessibility

Guidelines as published by the United States Access Board on June 23,

2004, as amended August 5, 2005.

2For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

Product Dimensions

A - Width

B - Depth

C - Height

Cutout Dimensions

Width (Min.)

Width (Max.)

Depth (Min.)

Depth (Max.)

Height

34-1/4"

34-3/8"

16-5/8"

16-3/4"

36"

18-5/8"

3-1/2"

NOTE: Always consult local and national electric and gas codes. Refer to Product

Installation Guide for detailed installation instructions on the web at frigidaire.com.
