Frigidaire FFGC3025LB Instructions d'installation

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

30" Gas

Drop-In Cooktops

FFGC3025L S / W/ B

1Select models only.

Burners

Right Front

Right Rear

Left Front

Left Rear

BTU

15,000

5,000

9,500

White

(W)

Stainless

(S)

Black

(B)

Product Dimensions

Width 30"

Depth 21-1/2"

Height 4-1/4"

More Easy-To-Use Features

Color-Coordinated Control Knobs

White and Black cooktops come with

matching knobs — while Stainless Steel

models feature our neutral black knobs.

Electronic Pilotless Ignition

Saves energy and can be ignited

manually when electricity is out.

Porcelain Cooktop Grates

Grates are durable and easy to clean.

LP Gas Conversion Option

Available in:

Durable Stainless Steel

Cooktop1

A premium look that stands up to

everyday use.

Quick Boil

Boil water faster with our 15,000 BTU

burner.

Ready-Select™ Controls

Select options or control cooking

temperature with our easy-to-use

controls.

Sealed Gas Burners

Enjoy easier cleanup and a burner that

stays looking great.

Accessories information available

on the web at frigidaire.com

Granite Countertop

Installation Kit available.

USA

•

10200 David Taylor Drive •

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Drop-In Cooktops

FFGC3025L S / W/ B 30" Gas

Product Dimensions

A - Width

B - Depth

C - Height

Cutout Dimensions

Width (Min.)

Width (Max.)

Depth (Min.)

Depth (Max.)

Height

27-1/4"

28-1/2"

19-1/8"

19-3/4"

30"

21-1/2"

4-1/4"

NOTE: Always consult local and national electric and gas codes. Refer to Product

Installation Guide for detailed installation instructions on the web at frigidaire.com.

Drop-In Gas Cooktops

Frigidaire Baseline

1For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

Features

Controls

Surface Type

Sealed Gas Burners

Grates

Right Front Element (BTU)

Right Rear Element (BTU)

Left Front Element (BTU)

Left Rear Element (BTU)

Control Location

Knob Color

Knob Type

Bowl Type

Speciﬁcations

Power Supply Connection Location

Gas Supply Connection Location

LP Gas Conversion Kit

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts1

Amps @ 120 Volts

Minimum Circuit Required (Amps)

Approved for Electric Single Wall Oven

Combination Installation

Shipping Weight (Approx.)

Ready-Select™

Deep-Well Stainless

Steel ( S ), Deep-Well

Color-Coordinated

Porcelain ( W/ B )

Yes

Continuous

Cast Iron with

Black Matte Finish

15,000

5,000

9,500

Right Side

Black ( S ),

Color-Coordinated

( W/ B )

Plastic

Right Rear

Included

120V / 60V / 15A

1.0

45 Lbs.
