Freewing F-16 FIGHTING FALCON V3 Manuel utilisateur

MADE IN CHINA

www.sz-freewing.com

Wingspan:878mm

USER�MANUAL

F-16 FIGHTING FALCON V3

Iten No.: FJ211

Version No.: FJ211-V02

Introduction

Catalog

The F-16C "Fighting Falcon" is a single-engine multirole ﬁghter aircraft originally developed

for the United States Air Force (USAF). Designed as an air superiority day ﬁghter, it evolved into

a successful all-weather multirole aircraft. The F-16C features an internal M61 Vulcan cannon

and multiple locations for mounting weapons and other mission equipment. Operating in nearly

30 countries to this day, the F-16 has distinguished its place in aviation history.

Freewing has modeled this brilliant aircraft in EPO foam with a 70mm electric ducted fan

(EDF) powerplant. With a 1306mm length and 878mm wingspan, this 1/12 scale ﬂying replica

includes many exciting features! An accurate scale outline with sharp surface details and panel

lines make this model stand out at your airﬁeld. Removable main wings and a magnetic nose

cone make transport very convenient. The cockpit battery bay cover is secured with a sliding

latch to prevent separation during ﬂight, and the entire aircraft is reinforced with strategic

placement of carbon tubes to withstand vigorous ﬂying maneuvers.

Our Freewing 70mm F-16C V2 model jet uses electric retractable landing gear for lower drag

and better scale appearance during ﬂight. These powerplants achieve a maximum ﬂying speed

of 165kph, respectively. The aircraft is designed for stability, strong climbing performance, and

short takeoﬀ distance, suitable for all levels of jet pilots. The aircraft can also maintain a high

alpha of 30 degrees to demonstrate its superior low speed stability.

We feature this exciting aircraft in the modern three tone gray US Air Force base colors, and

three decal sets are included for you to choose from to customize your model from various actual

Air Force squadrons.

Introduction

Product basic parameters

Packing list

PNP Installation Instruction

Landing gear Installation Instructions

Control board Instruction

Motor parameters

Battery Installation

Center of Gravity

Control surface diagram

Important�additional�notes

Dual rates

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

www.freewing-model.com

Product basic parameters

Packing list

1306mm(51.4in.)

878mm(34.57in.)

The package don't include the missles and pylons, if you need, please contact your

local dealer.

Wing loading：2

145g/dm

Motor: 2957-2210KV I/RMotor

Ducted fan: 70mm 12-blade ducted fan

Flight speed: 165km/h

ESC:80A brushless ESC

Servo: 9g Hybrid digtal servo(6pcs)

Weight: 1550g (without battery)

Thrust: 2400g

Battery advise: 6S 3 5 0 0 -4 5 0 0 m A h

Standard version

专业版

NO. PNP KIT Plus Airframe

Fuselage

Main wing

Vertical tail

Horizontal tail

Nose cone、FIn

Missiles and pylons

Pushrod

Carbon tube

Glue/Decals

Manual

Parts Name

Airframe

KIT Plus

PNP

Parts Name

NO.

Pre-installed all

electronic parts Pre-installed

servo No electronic

equipment

Pre-installed

servo No electronic

equipment

Pre-install power

system and servos Optional part,

purchase seperately Optional part,

purchase seperately

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

Pre-installed all

electronic parts Pre-installed

servo No electronic

equipment

www.freewing-model.com

PNP Installation Instruction

1.Insert the carbon tube into fuselage.

Carbon tube（Ø6x500mm）

2 .Connect the main wing servo cable and fuselage

extension cable, then install left/right main wing.

main wing trough port

Install main wing

平尾组装

Install Fuselage

Screw（KA3x10 4pcs）

3 .Use 4pcs screws to ﬁx the main wing.

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

1.Use glue to attach the left/right tail fuselage pieces

onto the fuselage.

www.freewing-model.com

PNP Installation Instruction EN

平尾组装

Install Honrizotal Stabilizer

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

平尾组装

Install Vertical Stabilizer

Screw （H M 2 x4 m m 1 p cs)

1.Connect the rudder servo wire and fuselage extension wire.

2.Install the vertical tail on the fuselage and ﬁx it with screws

S cre w （K A 3 x1 0 m m 4 p cs)

Screw (K A 3x10mm 4pcs)

1.Insert the rotating shaft into the ﬁxing hole and

tighten it with screws.

2.Insert the rotating shaft into the horizontal tail,

and ﬁx it with a ﬁxing ring.

3.Follow the above steps to install the other side

horizontal tail.

ste p 1

1 First, lock the screw into the ﬁxing ring to half the depth..

.2 Place the ﬁxing ring into the horizontal tail groove.

.In se rt th e ro ta tin g sh aft in to th e ho rizo n ta l tail,3

ad ju st th e po sitio n of th e fixin g rin g , an d fin ally

tighten the screw.

4.Follow the above steps to install the other side

horizontal tail.

www.freewing-model.com

78mm

55mm

53mm

Servos install introduction EN

Aileron pushrod size Aileron pushrod mounting hole

Rudder pushrod size Rudder pushrod mounting hole

Elevator pushrod size Elevator pushrod mounting hole

Pushrod diameter Ø1.2mm

Pushrod diameter Ø1.5mm

Pushrod diameter Ø1.2mm

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

Install missiles and pylons

Step 1

(Note:�The package don't include the missles and pylons, if you need, please contact your local dealer.)

AIM-120 Pylon Step 2

Step 3

AIM-120 Missile

AIM-9 Missile

www.freewing-model.com

( 2-9/16")

65mm

Please refer to the following photo，assemble、replace、revise the nose landing gear

sparepart name and parameters

A- Jimi screws (M3x3 1pcs)

B- Wheel chock

C- Wheel

D- Nose gear main strut

E- L-Shape arm

F- Jimi screw (M3x3)

G- Nose gear steering ring

H- Nose gear steering rod

I - Metal shaft

J - Buckle (Ø2.0mm 1pcs)

K- Nose gear plastic cover(left)

L - Nose gear plastic cover(right)

M- Screw (PA1.7x8 2pcs)

M1- Screw (PB1.0x10 3pcs)

Step 1

Landing gear Installation Instructions EN

Install nose landing gear

N- Screw

O- Nose gear screw ﬁxed part

P- Nose gear installed set

Q- Servo

ScrewR- (PWA2.0x8 2pcs)

S- Steering pushrod

T- Nose cabin door

Step 2Step 3

Step 5Step 6

When installing,please check the flat position of spareparts,when screw to fix,the flat position must face to theNote ,

screw hole,just like this,it can fix successfully, the spareparts don t rotate and fall off.

(KA2.6x12 4pcs)

Step 4

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

A -

B-

C-

D-

E-

F-

Jimi screw (M3x3 1pcs)

Wheel chock

Wheel

Rear gear main strut

Electric retractable controller

Jimi screw (M3x3 2pcs)

G-

H-

I-

J-

Rear gear installed set

Rear gear screw ﬁxed part

Screw (KA2.6x12 8pcs)

Rear cabin door

Landing gear Installation Instructions EN

Install rear landing gear

Please assemble、�disassemble the rear landing gear

according to the following photo.

If you need to purchase other brand servo, please

refer to the following list to choose correct size servo.

Servo regulation

No.

Standard/Reverse

Nose steering

Left aileron

Right aileron

Left elevator

Right aileron

Rudder

Servo position Servo cable length

9g Digit-Hybrid

Standard

Reverse

Standard

100mm

200mm

900mm

200mm

Servo parameters

Step 1Step 2

Step 3

Step 4

7RF-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

www.freewing-model.com

Control board instruction EN

Motor parameters

F-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

Landing Gear

Flap

Landing gear

Rudder

Elevator

Aileron

(power to the receiver)

Landing Gear

Rudder/Nose steering

Elevator

Aileron

Flap

Rudder/Nose steering

Elevator

Aileron

Flap

According to the note, connect the

related servo cables in the control

board.

The control surface is not any note on

the control board, connect directly to

the receiver.

29571

www.freewing-model.com

Installed the battery and use velcro to fix.

battery compartment cover

battery

Velcro

battery tray

I n s t a l l b a t t e r y EN

Pull the sticker back

and open the cockpit.

4S 14.8V 2600~4000mAh

6S 22.2V 2600~4000mAh

discharge rate 30C >

The battery capacity and discharge rate

we advise to use are as follows:

Center of Gravity

Correct center of gravity is directly related to the success of the flight, please refer to the following CG diagram to

adjust your plane's center of gravity.

- You can move the battery forward or backward

to adjust the center of gravity.

- If you can not adjust the CG through move the

battery, you can also use some other suitable

material weight to counterweight, to make sure

that CG is in the correct position.

Before connect the battery and receiver, please

switch on the transmitter power and make sure the

throttle stick is in the lowest position.

Battery cabin space size:L=260 W=70 H=45(mm)

9RF-16 Fighting Falcon

Iten No.: FJ211

Version No.: FJ211-V02

Full-elevator horizontal tail install position

90mm

(3-1/2")

Please refer to the photo and set the correct full elevator

center position

18.5mm
