care of this and eliminate the need for un-muting the sound upon preset activation. It works by initially
checking to see if mute is active and, if it is, un-mute the Snow Commando prior to initiating playback of the
sound. Turning on favorite mute override can be done by accessing Sound Settings, highlighting the “Fav
Mute OR” menu item, pushing “Select”, then using the “Sound Up” or “Sound Down” to toggle between off
and on. Push “Select” a final time to set it. This setting is remembered between power cycles.
5-6 Display/Power: Backlight
This setting allows you to change the intensity of the backlight in a range from 5% - 100%. The lower the
intensity, the better your battery life will be. To adjust this setting, highlight the Backlight menu option,
push the “Select” button, and then use the “Sound Up” or “Sound Down” scroll buttons to cycle through the
values. When you have selected the desired backlight intensity, push the “Select” button a final time to set
it. This setting is remembered between power cycles.
5-7 Display/Power: Bklt T.O.
This setting allows you to set the duration for the backlight timeout. The backlight illuminates every time a
button is pressed. If the backlight is illuminated and you do not push a button within the set period of time,
the backlight will automatically shut off. Available values are 15 seconds, 30 seconds, and 1 minute. Keeping
this at a lower value will help promote maximum battery life. To adjust this setting, highlight the Backlight
T.O. menu option, push the “Select” button, and then use the “Scroll Up” or “Scroll Down” scroll buttons to
cycle through the values. When you have selected the desired backlight timeout period, push the “Select”
button a final time to set it. This setting is remembered between power cycles.
5-8 Display/Power: Contrast
This setting allows you to adjust the screen contrast. In ‘normal’ display mode (see 5-9 Display/Power: LCD
Mode), the higher the value, the darker the text will appear. In ‘inverse’ display mode, the higher the value,
the darker the background will appear. To change this value, highlight the contrast menu item, push the
“Select” button, then use the “Scroll Up” or “Scroll Down” buttons to cycle through the values. When you
have selected the desired contrast setting, push “Select” a final time to set it. This setting is remembered
between power cycles.
5-9 Display/Power: LCD Mode
This setting allows you to set the desired display mode. Available options include normal and inverse. In
normal mode, the text will appear as black and the background will be light. In inverse mode, the
background will be black with light text. To change this value, highlight the LCD Mode menu item, push the
“Select” button, then use the “Scroll Up” or “Scroll Down” buttons to cycle through the available options.
When you have selected the desired LCD Mode, push the “Select” button a final time to set it. This setting is
remembered between power cycles.
5-10 Display/Power: Auto Off
If you do not push a button on the remote for a set amount of time, the remote will automatically power
down to conserve battery life. The available options for this setting include 30 minutes, 45 minutes, 1 hour,
2 hours, and 4 hours. To change this value, highlight the Auto Off menu item, push the “Select” button, then
use the “Scroll Up” or “Scroll Down” buttons to cycle through the available options. When you have
selected the desired auto off period, push the “Select” button a final time to set it. This setting is
remembered between power cycles.
5-11 Timer/User: Stand Tmr
The elapsed timer (located on the bottom right of the display) allows you to see how long you have been on
a stand. The timer starts as soon as you turn on the Snow Commando transmitter. You can reset the timer
by accessing the Main Menu, selecting Timer/User option, and then selecting the “Stand Timer Reset.” The
timer will automatically reset to 00:00 if it is allowed to continue beyond 99:59.
