MultiLab™
Installation guide
System Requirements
To work with MultiLab, your system should be equipped with the
following:
Software
•Windows 98, ME, 2000 and XP
•Internet Explorer 5.0 or later (you can install Internet Explorer
5 when you install MultiLab, since it ships with the product)
Hardware
• Pentium II 600 MHz or higher (Pentium 4, 1.6 GHz or higher
is needed for video motion analysis recordings)
• 64 MB RAM (128 MB recommended)
• 10 MB available disk space for the MultiLab application (50
MB to install the supporting applications)
•Free serial or USB port
•To operate the video window your system should be equipped
with a video camera, an available USB port and a compatible
camera driver (installation includes camera driver for the supplied
Web camera)
•To be able to record and play voice comments your system
should be equipped with a sound card, a microphone and a
speaker (the camera supplied by Fourier includes a built-in
microphone)
MultiLab PC Installation
Instructions based on WinXP
Uninstalling MultiLab
Before installing your new version of MultiLab, uninstall any older
versions of the program.
NOTE: Uninstalling removes program files only. Project files and
worksheets you created or modified in MultiLab will remain
on your system and there is no need to create backups.
To uninstall the software
1. From the Start menu select Settings then click Control Panel.
2. Double click Add or Remove Programs.
3. Select MultiLab from the list of programs.
4. Click Remove.
5. In the following dialog box, click Yes to confirm that you want
to remove MultiLab.
6. When uninstall is complete you will be prompted to restart the
computer. Select Yes.
Installing MultiLab
1. Close all open programs.
2. Insert the CD labeled MultiLab into your PC’s CD-ROM drive.
3. Installation will begin automatically. You will first be prompted
to install MultiLab. Click Next to begin installation.
4. Enter user name and company name in the Customer
Information window. It is also recommended to install for all
users. Click Next.
5. In the Choose Destination Location window, the default
folder where MultiLab will be installed is C:\Program Files\Fourier
Systems\MultiLab. Click Browse to change this folder location,
or click Next.
6. MultiLab installation will proceed, followed by installation of
the D-Link Web cam driver. After installation is complete, you
are prompted to restart the computer. It is recommended to
restart the computer now.
Warning:
Do not connect MultiLogPRO or the supplied Web
camera to the PC before you install the MultiLab
software.
!
Integrating student
computing & science
If auto run is not working, open My Computer and click
on the CD drive folder (d: drive in most cases) and double-
click on the setup icon, then proceed as above.
NOTE: If you are reinstalling MultiLab after removing an
older version, the camera driver is already installed on your
system. In this case the installation program prompts you
to confirm the removal of the driver. Click Cancel to keep the
camera driver on your system.
NOTE: When you plug in the supplied Web camera for the
first time Windows will automatically detect the new device
and open the Found New Hardware Wizard. Follow the
on-screen instructions. When asked, select the Install software
automatically option (there is no need to insert the installation
CD). Windows will automatically detect and install the necessary
software.
Windows Media Encoder Component
If MultiLab fails to open properly, it is probably because one of
MultiLab’s components, Microsoft Windows Media Encoder, was
not successfully installed on your system during the normal
installation procedure. You must install it now.
To install Microsoft Windows Media Encoder:
1. Insert the CD labeled MultiLab into your CD-ROM drive.
2. If the installation program prompts to upgrade or reinstall
MultiLab, Click No or Cancel.
3. Navigate to My Computer, right click the Fourier Systems CD
icon to display a popup menu, and then click Explore.
4. Double click the Microsoft Windows Media Encoder 7.1
Distribution.exe icon to install this file.
5. After installation finishes, run MultiLab again.
www.fourier-sys.com © 2006 Fourier Systems Ltd.All rights reserved. Fourier Systems Ltd.logos and all other Fourier product or service names are registered trademarks or trademarks
of Fourier Systems.All other registered trademarks or trademarks belong to their respective companies.Doc. BK069,Rev.04/06
MultiLab™
Installation guide
Installing the USB driver
You will need to install a USB driver in order for the MultiLogPRO
to communicate with your PC via a USB port.
On Windows XP
1. Connect your data logger to a USB port on your PC and turn
the data logger on. Windows will automatically detect the
new device and open the Found New Hardware Wizard.
2. Select No, not this time to prevent Windows from searching
for software on the Internet, then click Next.
3. Insert the MultiLab installation CD into your CD drive. Select
the Install Software Automatically (Recommended) option.
Click Next.
4. Windows will automatically detect and copy the necessary files
to your system. Click Finish.
5. Windows will open the Found New Hardware Wizard for
a second time. Click Next.
6. Select No, not this time to prevent Windows from searching
for software on the Internet, then click Next.
7. Windows will automatically install the necessary components
on your system. Click Finish.
On previous Windows versions
1. Insert the CD labeled MultiLab into your CD drive. If installation
begins automatically (and you have already installed MultiLab),
click Cancel to stop installation.
2. Connect MultiLogPRO to a USB port on your PC and turn
MultiLogPRO on. Windows will automatically detect the new
device and open the Found New Hardware Wizard.
3. Select Specify the location of the driver, then click Next.
4. Select Search for the best driver for your device, then
check the Removable Media checkbox, and then click Next.
5. Windows will automatically detect and copy the necessary files
to your system. Click Finish.
6. Windows will open the Found New Hardware Wizard for
the second time. Click Next to complete the installation.
7. Windows will automatically install the necessary components
on your system. Click Finish.
Integrating student
computing & science
Note to Windows 2000 or XP users: MultiLab
needs to modify its folder when running. Ask your
System Administrator for permission to gain access
to all files in the MultiLab folder.
!
