Fostex IS205 Manuel utilisateur

Line selector

IS205

Thank you very much for purchasing a Fostex product.

This manual provides instructions for basic use of the unit.

Read this before using the unit for the first time.

8588135000

(594370)

Owner's Manual

 WARNINGS and PRECAUTIONS

• CAUTION: The symbol To prevent electric shock hazard, do not connect to

mains power supply while grille is removed.

• WARNING: An apparatus with CLASS I construction shall be connected to a

MAINS socket outlet with a protective earthing connection.

• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO

WIDE SLOT, FULLY INSERT.

• WARNING: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

• CAUTION: Use of any controls or adjustments or performance of procedures

other than those herein specified may result in hazardous radiation exposure.

• WARNING: Changes or modifications to this unit not expressly approved

by the party responsible for compliance could void the user’s authority to

operate the equipment.

• WARNING: Do not place the unit on top of any soft, porous, or sensitive

surfaces to avoid damaging the surface. Use a protective barrier between the

unit and surface to protect the surface.

• WARNING: Use of this unit near fluorescent lighting may cause interference

regarding use of the remote. If the unit is displaying erratic behavior move

away from any fluorescent lighting, as it may be the cause.

• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type.

• WARNING: Do not install this equipment in a confined space such as a book

case or similar unit.

• WARNING: Mains plug is used as disconnect device and it should remain

readily operable during intended use. In order to disconnect the apparatus

from the mains completely, the mains plug should be disconnected from the

mains socket outlet completely.

• Do not mix old and new batteries. Do not mix alkaline, standard (carbonzinc),

or rechargeable (ni-cad, ni-mh, etc) batteries.

CAUTION

WARNING: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USERSERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

 IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade or

the third prong are provided for your safety. If the provided plug does not

fit into your outlet, consult an electrician for replacement of the obsolete

outlet.

10) Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid

injury from tipover.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way,

such as power supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

15) The apparatus shall be used in an open area.

16) Apparatus shall not be exposed to dripping or splashing and that no

objects filled with liquids, such as vases, shall be placed on apparatus.

17) Mains plug is used as disconnect device. It shall remain readily operable and

should not be obstructed during intended use. To completely disconnect

the apparatus from supply mains, the main plug of the apparatus shall be

disconnected from the mains socket outlet completely.

Introduction

 Features of the IS205

• IS205 is an audio line selector with 2 inputs and 5 outputs.

• You can switch between several active speakers and 2 types of music source.

• Equipped with a volume knob to control the source volume.

• You can adjust the DIP switch settings to automatically switch between speakers.

• Equipped with highly reliable push switches.

• One of the 5 outputs is designed to be connected to a subwoofer or similar, and can be turned on

and off independently.

 Accessories

Supplied accessories are listed below. Confirm that these accessories are present after purchase.

• AC adaptor × 1

• Owner’s manual (this manual) × 1

Part names and functions

Top panel Rear panel

MAX

O U T P U T I NP U T

INPUT

VOLUME

MIN

INPUT2

OUTPUT

1 2 3 4 5

INPUT1

POWER

ON OFF

① ④

③

②

DC IN L

12345

OUTPUTINPUT1

ONOFF

POWER

MODE

12V 1.5A

⑤ ⑥ ⑦ ⑧ ⑨

① [OUTPUT] switches 1 - 5

Use to switch between outputs.

The color of the switches indicates their status.

Unlit: the switch is disabled (page 5)

Lights in green: the switch is enabled

Lights in yellow: the switch is selected

• You can select only one switch from

[OUTPUT1] to [OUTPUT4].

• The [OUTPUT5] switch can be turned on and

off independently. It is for subwoofers.

• If you press the selected switch again, the

output turns off (not selected).

②[INPUT] switches

Use to switch between input signals. The

selected switch lights in red.

③ [INPUT VOLUME] knob

Use to adjust the output level of the unit.

④[INPUT2] terminal

Connect to a portable audio player or similar

using a stereo mini cable.

⑤ [DC IN] terminal

Connect to an outlet using the supplied AC

adaptor.

⑥ [POWER] switch

Turn the unit on/off.

⑦ DIP switches for setting configuration

([MODE] switch)

Use to configure various settings.

⑧ [INPUT1] terminal

Connect to an audio player such as a CD player

using an RCA pin cable.

⑨ [OUTPUT] terminal (1-5)

Connect to an active speaker or similar using an

RCA pin cable.

• Connect the line output of the audio player

to the [INPUT1]/ [INPUT2] terminal.

• Connecting to speaker outputs of power

amplifiers or similar is dangerous. Do not do

this under any circumstances.

Settings

 Enabling and disabling outputs

1 Turn off the power.

2 Turn on the power while holding down the [OUTPUT] switches (from 1 to 5) you want

to enable. The enabled switches light in green. The unit memorizes which switches are

enabled/disabled and will keep these settings the next time the device is turned on.

 Configuring DIP switch settings

DIP switch

(default settings)

Switch position guide

Automatic switching

Automatic switching enables the unit to switch automatically between outputs 1 to 4. You can turn the

function on and off using DIP switches 1 to 3. You can set the switching interval between 5 seconds and

35 seconds in 5 second increments. The following table shows how to configure the DIP switches for

each switching interval length.

1 (5 seconds) 2 (10 seconds) 3 (20 seconds) Set interval length

(seconds)

OFF OFF OFF The function is turned off

ON OFF OFF 5

OFF ON OFF 10

ON ON OFF 15

OFF OFF ON 20

ON OFF ON 25

OFF ON ON 30

ON ON ON 35

• Automatic switching cannot be used with OUTPUT5.

• When you press an [OUTPUT] switch from 1 to 4 while automatic switching is on, the function turns off

for 30 seconds.

Automatic standby

When DIP switch no. 4 is on, if no OUTPUT is selected for approximately 4 hours, the unit automatically

goes into standby. In standby, all LED turn off and power consumption is reduced to 0.5 W or below.

Automatic standby is canceled when you press either an [INPUT] or [OUTPUT] switch, or turn the power

switch on or off. The unit does not enter automatic standby when the DIP switch is off.

4 Setting time (seconds)

OFF Auto standby is off

ON Auto standby is on

• When automatic switching is turned on, the unit does not enter automatic standby regardless of the DIP

switch setting.

Block diagram

INPUT1

(RCA)

INPUT2

(MINI-JACK)

VOLUME

OUTPUT1

OUTPUT2

OUTPUT3

OUTPUT4

OUTPUT5

Dimensional drawings

OUTPUT INPUT

INPUT

VOLUME

MIN MAX

1234 5 12

INPUT2

OUTPUT

12345

INPUT1 POWER

ON OFF

12V 1.5A

DC IN

12345

OUTPUTINPUT1

ONOFF

POWER

MODE

12V 1.5A

185

Specifications

[INPUT 1] terminal Connector RCA pin jack

[INPUT 2] terminal Connector Φ3.5 mm stereo mini jack

[OUTPUT] 1 - 5 terminals Connector RCA pin jack

Power 12 V DC

Power consumption 2.4 W maximum (automatic standby mode: 0.5 W or below)

External dimensions (mm) 185 (width) × 40 (height, including rubber feet) × 96 (depth)

Weight 470 g

FOSTEX CO.

1-1-109, Tsutsujigaoka, Akishima City, Tokyo, 196-8550, Japan

Declaration of EC Directive

This equipment is compatible with the EMC Directive (2004/108/EC) - Directive on approximation of member nation's ordinance

concerning the electromagnetic compatibility and with the Low Voltage Directive (2006/95/EC) - Directive on approximation of

member nation's ordinance concerning electric equipment designed to be used within the specified voltage range.

The Affect of Immunity on This Equipment

The affect of the European Specification EN61000-6-1 (coexistence of electromagnetic waves - common immunity specification)

on this equipment are as shown below.

In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency

magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by

generation of noise in some cases.

FOSTEX DISTRIBUTORS LIST IN EUROPE

* Including non-EU countries (as of Oct. 2014)

Austria

NAME: Mega Audio GmbH

ADD: Stromberger Str. 32, 55411 Bingen, Germany

TEL: (+49) 6721-94330, FAX: (+49) 6721-32046

Email: info@megaaudio.de

Web Site: http://www.megaaudio.de

Belgium

NAME: XLR sprl/bvba

ADD: Pierre Strauwenstraat 24, 1020 Brussels, Belgium

TEL: (+32) 2 520 0827, FAX: (+32) 2 521 1977

Email: info@xlrpro.be

Web Site: http://www.xlrpro.be

Czecho

NAME: Praha Music Center spol s.r.o.

ADD: Ocelarska 937/39, Praha 9, 190 00, Czecho

TEL: (+420) 226-011-111, FAX: (+420) 226-011-112

Email: [email protected]

Web Site: http://www.pmc.cz

Denmark

NAME: SC Sound A/S

ADD: Dalgas Alle 15, DK-6600 Vejen, Denmark

TEL: (+45) 4399 8877, FAX: (+45) 4399 8077

Email: [email protected]

Web Site: http://www.sc-sound.dk

Finland

NAME: Noretron Oy Audio

ADD: Mankkaantie 32, FIN-02180 ESPOO, Finland

TEL: (+358) 10-525-8000, FAX: (+358) 10-525-8010

Web Site: http://www.noretron.fi

France

NAME: Sennheiser France

ADD: 128 bis, avenue Jean-Jaures, 94851 Ivry-sur-Seine Cedex, France

TEL: (+33) 1 4987 0300, FAX: (+33) 1 4987 0324

Web Site: http://www.sennheiser.fr

France

NAME: Selectronic (Speaker Components Only)

ADD: Zac de L’Oree du Golf, 16 rue Jules Verne, 59790 Ronchin, France

TEL: (+33) 328 550 328, FAX: (+33) 328 550 329

Email: contact@selectronic.fr

France

NAME: Hamy Sound (Headphones and USB DAC Only)

ADD: 28 Rue Edith Cavell, 92400 Courvevoie, France

TEL: (+33) 1 4788 4702, FAX: (+33) 1 4789 4872

Email: sav@hamysound.com

Web Site: http://www.hamysound.com

Germany

NAME: Mega Audio GmbH

ADD: Stromberger Str. 32, 55411 Bingen, Germany

TEL: (+49) 6721-94330, FAX: (+49) 6721-32046

Email: info@megaaudio.de

Web Site: http://www.megaaudio.de

Greece

NAME: Bon Studio S.A

ADD: 6 Zaimi Street, Exarchia, 106.83 Athens, Greece

TEL: (+30) 210-3809-605, 606, 607, 608

FAX: (+30) 210-3845-755, 210-3827-868

Email: bon@bonstudio.gr

Web Site: http://www.bonstudio.gr

Hungary

NAME: Mega Audio GmbH

ADD: Stromberger Str. 32, 55411 Bingen, Germany

TEL: (+49) 6721-94330, FAX: (+49) 6721-32046

Email: info@megaaudio.de

Web Site: http://www.megaaudio.de

Italy

NAME: Backline S.u.r.l.

ADD: Via dell’Aprica, 16 - 20158 Milano, Italy

TEL: (+39) 02 6901 5709, FAX: (+39) 02 6901 5645

Email: [email protected]

Web Site: http://www.backline.it

Italy

NAME: Art of Music sas (Hi-Fi system & Speaker Components)

ADD: Via Dal Lino 23/2, 40134 Bologna, Italy

TEL: (+39) 347 2532215

Email: artofmusic@libero.it

Web Site: http://www.balloacoustics.it

The Netherlands

NAME: Iemke Roos Audio B.V.

ADD: Kuiperbergweg 20, 1101 AG Amsterdam, The Netherlands

TEL: (+31) 20-697-2121, FAX: (+31) 20-697-4201

Email: sales@iemkeroos.nl

Web Site: http://www.iemkeroos.nl

Norway

NAME: Siv. Ing. Benum AS

ADD: P. O. Box 145, Vinderen, 0319 Oslo, Norway

TEL: (+47) 2213 9900, FAX: (+47) 2214 8259

Email: [email protected]

Web Site: http://www.benum.no

Poland

NAME: Mega Music Spolka z o.o

ADD: Ul. Lesna 15, 81-876 Sopot, Poland

TEL: (+48) 58-551-18-82, FAX: (+48) 58-551-18-72

Email: pro@megamusic.pl

Web Site: http://pro.megamusic.pl

Russia

NAME: MS-MAX

ADD: Entrance 12B, Kutuzovsky prospekt, 30/32, 121165, Moscow,

Russia

TEL: (+7) 495-234-0006, FAX: (+7) 495-249-8034

Email: [email protected]

Web Site: http://www.ms-max.ru

Russia

NAME: BLADE Group of Companies

ADD: Elizavetinskiy per, 12 Moscow 105005, Russia

TEL: +7 495 276 2076

FAX: +7 495 276 2076

Email: [email protected]

Web Site: http://www.blade.ru/

Russia

NAME: Qvinta Company LLC

ADD: Building 2, Street 26A, Dmitriy Uliyanova, Moscow 117036 Russia

TEL: +7 495 787 7767

Web Site: http://www.qvinta-audio.ru

Spain & Portugal

NAME: ATCONSUMER (Consumer, Hi-Fi system & Speaker Components)

ADD: PO BOX 15, 08340Vilassar de Mar, Barcelona, Spain

TEL: (+34) 609 288310

Email: info@atconsumer.es

Web Site: http://www.atconsumer.es

Spain & Portugal

NAME: Letusa (Pro Audio Products Only)

ADD: C/Laguna No.10, Poligono Industrial Urtinsa, 28923 Alcorcon,

Madrid, Spain

TEL: (+34) 91-4862800, FAX: (+34) 91-6414597

Email: [email protected]

Web Site: http://www.letusa.es

Sweden

NAME: Benum Nordic AS

ADD: Aldermansvagen 17, 171 48 Solna, Sweden

TEL: (+46) 8 207710

Email: [email protected]

Web Site: http://www.benum.se

Sweden, Norway, Finland & Denmark

NAME: Supersonic Svenska AB (Speaker Components Only)

ADD: PO BOX 42043, 126 12 Stockholm, Sweden

TEL: (+46) 8 744 4700

Email: [email protected]

Switzerland

NAME: Audio Bauer Pro AG

ADD: Bernerstrasse-Nord 182, CH-8064 Zurich, Switzerland

TEL: (+41) 44 432 3230, FAX: (+41) 44 432 6558

Email: info@audio-bauerpro.ch

Web Site: http://www.audio-bauerpro.ch

Turkey

NAME: Radikal Elektronik Ltd. Sti.

ADD: Ihlamur-Yildiz Cad, Kessaf Sok. 4/12 Besiktas, Istanbul 34353,

Turkey

TEL: (+90) (212) 259 7971, FAX: (+90) (212) 259 7993

Email: radikal@radikaltr.com

Web Site: http://www.radikaltr.com

Turkey

NAME: Extreme Audio

ADD: Sheraton Istanbul Maslak Kat B2 Buykdere Cad. Nr:233 Ucyol

Mevkii 34398 Maslak Istanbuul Turkey

TEL: +90 444 3760

Email: [email protected]om

Web Site: https://www.extreme-audio.com

NAME: SCV London

ADD: Unit C1 Belcon Industrial Estate, Geddings Road, Hodesdon,

Hertfordshire, EN11 0NT, UK

TEL: (+44) 03 301 222500, FAX: (+44) 20-8418-0624

Email: [email protected].uk

Web Site: http://www.scvlondon.co.uk

Ukraine

NAME: A & T Trade Petroshop

ADD: 29, Obolonskaya Str., Kiev, Ukraine 04071

TEL: (+380) 44-462-5358, FAX: (+380) 44-462-5092

Email: attrade@attrade.kiev.ua

Web Site: http://kiev.attrade.ru

Table des matières

Autres manuels Fostex Matériel de musique

Fostex

Fostex HP-A8 Instructions de montage

Manuels Matériel de musique populaires d'autres marques

DAPAudio

DAPAudio IPS-PT Manuel utilisateur

Dynacord

Dynacord DPM 8016 Manuel utilisateur

Subdecay

Subdecay Starlight Flanger Manuel utilisateur

Moen

Moen GEC8 Live Manuel utilisateur

Fender

Fender 1 Manuel utilisateur

Yamaha

Yamaha MLC-16 Manuel utilisateur

Sonuscore

Sonuscore TIME TEXTURES Manuel utilisateur

flight of harmony

flight of harmony V'Amp Manuel utilisateur

NANO

NANO PERFORMANCE MIXER Manuel utilisateur

Tascam

Tascam CD-GT2 Manuel utilisateur

BHI

BHI NEIM 1031 MKII Manuel utilisateur

Befaco

Befaco KICKALL Manuel utilisateur

Paia

Paia 9720 Mode d’emploi

limex

limex ALPIN MASTER 128 Manuel utilisateur

nord

nord Electro 3 Manuel utilisateur

Joemeek

Joemeek sixQ2 Manuel utilisateur

CARVIN

CARVIN 500W STEREO POWER MODULE - SCHEMA REV G Manuel utilisateur

Furutech

Furutech ADL GT40 Guide d'installation
