FOS Technologies Luminus Manuel utilisateur

User’s Manual

Before you operate this fixture read the manual carefully. Always make sure to include the manual

if you pass/rent/sell the fixture to another user.

FOS Luminus Table

USER’S MANUAL

User’s Manual

TABLE OF CONTENT

1. WARNING ………………………………….….…….…………………………….………………………………………….2

1.1 Safety Instructions ………………………………………………….……………………………………………………….2

1.2 Rigging …………………………………………………………………………………………………………………….….…3

2. PRODUCT INTRUDUCTION …………………………………………………………………………….……………3

2.1 Items Included in the Tou r Pack. ….…………………………….…….…….…….…………………….……..........3

2.2 Product Overview…………………………………………………………………….……………………………………….3

2.2.1 Fixture Elements and Connectors …………………………………….………………….……………….4

2.2.2 Fixture Control Panel ……………………………………………………………………….……………….4

2.2.3 Fixture Dimensions ………………………………………..……………………………….………………..5

2.3 Storing the Fixture ……………………………….........……………………….…….……….………………………………5

2.4 Specifications ……………………………………………….………………………………….……….…………………… 6

3. INSTALLATION …………………………………………………………………………………………….…………………………7

4 BATTRY CHARGE …………………………………………………………………………………………….…………………………8

5. PRODUCT SETUP ……………....……………………………………………………………...………………………………….8

5.1 Menu Navigation ……………………………………………………………………………………….……………………9

5.2 DMX Addressing ………………………….……………………………………………………………………….10

5.3 Wireless DMX Setup …………………………………………………………….……………………………………….10

5.4 OLED Display Setup ………………………………………………………………………………………………………….12

5.5 ECO Mode ……….…………………………………………………………………….…………………………………12

5.6 Fixture Information……………………………………………………………………………………………………………12

5.7 Factory Reset ………………………….………..……………………………………。…………………………………………12

6. OPERATION …………………………………………………………………………………………………………………………….12

6.1 DMX Control Mode………………………………………………………………………….………………………………13

6.2 Master/Slave Mode …………………………………………………………………………………………………14

6.3 Auto Run Mode ………………………………………………………………………………………………………………14

6.4 Customized Colors…………………….………………………………………………………………………………………15

6.5 IR Remote Control.…………….………………………….……… ……………………………………………。……………15

7. MAINTENANCE ……………………………………………………………………….………………………………….…16

8. WARRANTY……………………………………………………………………….……………………………………………17

User’s Manual

1. WARNING

1.1 Safety Instructions

This product guide contains important information about the safe installation and use of this product. Please

read and follow these instructions carefully and keep this manual in a safe place for future reference.

When unpacking and before disposing of the carton, check there is no transportation damage before using

the product. Should there be any damage caused by transportation, consult your dealer and do not use the

apparatus.

The product is for indoor use only. Use only in dry locations. Keep this device away from rain and moisture,

excessive heat, humidity and dust. Do not allow contact with water or any other liquids. The product is not

designed or intended to be mounted directly on to inflammable surfaces.

The product is only intended for installation, operation and maintenance by qualified personnel.

The product must be installed in a location with adequate ventilation, at least 50cm from adjacent wall

surfaces. Be sure that no ventilation slots are blocked.

Do not directly look into the led. It can cause harm to your eyes. Do not look at the LEDs with a magnifying

glass or any other optical instrument that may concentrate the light output.

Do not attempt to dismantle and/or modify the product in any way.

Electrical connection must only be carried out by qualified personnel.

Before charging the fixture, ensure that the voltage and frequency of power supply match the power

requirements of the product.

Do not directly look into the light beam. It can cause harm to your eyes. Do not look at the led with a

magnifying glass or any other optical instrument that may concentrate the light output.

A rechargeable lithium ion battery is built inside this fixture. Please avoid bumping or plunging, it may cause

fire or explosion. Never store the battery when fully drained. Always recharge immediately when empty.

Make sure to fully charge all fixtures before storing them. Partially charged batteries will lose capacity. Fully

recharge every 6 months if not used.

When charging fixtures in flight case, always charge with the case open. It is recommended to charge at a

temperature between 0°C and 35°C.

Please make sure the battery will be disposed of properly according to your local law when it runs out of its

life, so that to protect the environment.

This product is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

If this fixture is operated in any other way other than the one said in this manual, this device may suffer

damages and thus the warranty becomes void.

Always switch off the fixture when it is not in use or before cleaning it or before attempting

any maintenance work.

User’s Manual

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the

non-observance of this manual or any unauthorized modification to the fixture.

1.2 Rigging

Concerning rigging, trussing for this fixture, please follow the European and national guidelines.

Only the qualified technicians are allowed for the device installation,

The fixture must never be mounted for a possible swinging position, and a safety cord attached must always

be used.

2. PRODUCT INTRODUCTION

2.1 Items Included in Tour Pack

After receiving the fixture, please carefully unpack the product and make sure the following parts are all

included inside the package and are all in good condition.

- Tab le l ig ht Q 6 x 4 pcs

- ABS case x 1 pcs

- Extension x 4 pcs

- IR controller x 4 pcs

- Power station x 1 pcs

- Power cable x 1 pcs

- This manual x 1 pcs

In case the package is damaged from shipping, inform the carrier right away while keeping the damaged box

for inspection. Failure to report damage to the carrier immediately may cause invalidity to your claim. The

dealer or manufacture will not take any responsibilities for the damage.

In case there are parts missing from the box with a good condition, please contact your dealer or the

manufacturer immediately by email or in other written form.

2.2 Product Overview

Tab le li gh t Q 6 i s a b a tte ry pow er un it to li gh t u p d in ne r t ab le , n o m a tte r f or b anq ue t o r a ny ot he r e vents. It

has 6 RGB full color led and also 6 white led with high CRI. This table light can cover 360 degrees of your

table and create fantastic atmosphere of any event both indoor and outdoor. Its battery can work up to 10

User’s Manual

hours in auto run mode and around 12 hours in running single color.

Tab le l ig ht Q 6 can operate in wireless DMX mode, Master/Slave mode, and also in auto run mode. IR

controller is supplied to make remote control as well.

Its magnetic base helps it to stand right in the center of table or on any metal surface. You can also put it on

top of metal spike in your garden as a garden light.

Tab le l ig ht Q 6 is ra ted I P5 4. It is therefore suitable for indoor and outdoor applications.

2.2.1 Fixture Elements and Connectors

1. Removable top cover 2. Battery tube, also extensable with another tube

3. Magnetic base for mounting to any metal surfaceCharge 4. Metal plate

5. Led 6. OLED display 7. Touch button for setup

8. DC charge port 9. Antenna for wireless DMX transceiver

10. Wireless DMX indicator (blue led) 11. IR sensor 12. Power switch

2.2.2 Fixture Control Panel

There are 4 touch buttons on the OLED control panel: <MENU>, <ENTER>, <UP> and <DOWN>.

User’s Manual

1. Menu to select the programming functions

2. Enter Enter the current menu or confirm the current function value

3. Up Scroll “UP” through the menu list to increase the value of the current function

4. Down Scroll “DOWN” through the menu list to decrease value of the current function

2.2.3 Fixture Dimensions

Fixture Tour Pack

2.3 Storing the Fixture

Make sure to fully charge all fixtures before storing. Partially charged batteries will lose capacity. Fully

recharge every 6 months if not used.

User’s Manual

2.4 Specifications

Electrical

Power input

100-240VAC 50/60Hz

Power consumption

15W max.

Power input/output connector

Magnetic DC connector

Battery

11.1V 8.8Ah

Charge time

About 4.5 hours

Battery life

Around 5 hours at full color from one full charge

Around 10 hours for auto color mixing

Around 15 hours at running single color

Battery capacity

Percentage shown on OLED display

Light sources

Led

6x3W, RGB 3-in-1, 6x1W white led, CT6000~6500K

White led CRI

>90Ra

Beam angle

360o coverage

Led average life span

50,000 hours

Program

7 static color + 10 dynamic colors

Linear dimming 0-100% electronic dimmer

Built-in dimming curves

Strobe 0~25K Hz

Built-in color temperatures available

Customized program savable

Control

DMX protocol

Wireless DMX （transceiver）

Control mode

Master/Slave, Stand Alone; Wireless DMX, IR Remote Control

DMX channel

4/6/10 channel selectable

Control panel

OLED display with touch buttons

Physical & Construction

Housing

Die-cast aluminum and ABS

Housing finish

Mirror finish

Fixture dimensions (WxHxD)

147x345x200mm

Net weight

1.5 kg

Working temperature

-10oC - 45oC

Charge temperature

0oC - 45oC

IP rating

IP54

Cooling

Natural cooling, silent operation

User’s Manual

3 INSTALLATION

The fixture can be mounted to any metal surface.

3.1 The table light can be placed on the enclosed metal plate on dinner table. Put the metal plate

on dinner table or underneath tablecloth, put your table light to the center of the metal plate.

3.2 The table light can also be attachd to any solid metal surface. Make sure the surface is flat

and table light magnetic base can be attached to it safely.

3.3 Users can also place table light on top of our spike (sold seperately), thus temperarily use the

table light as garden light.

3.4 The table light battery tube can be extended with another tube to make the height double.

User’s Manual

4. BATTERY CHARGE

The fixture has a rechargeable lithium battery built in. Always store the fixtures with full battery. Depleted

batteries must be recharged immediately; otherwise fixture performance will suffer.

Battery runtime will decreased time by time. Battery runtime may be slightly shorter than predicted due to

different working enviroments.

The fixture has a magnetic DC charge connector. To charge yo ur table light, connect it to the magnetic

connector from the power station in the tour pack ABS case. and plug the power station to the mains. The

fixture will start to charge automatically. A normal charging time is about 4-5 hours.

Led turns on RED with very little intensity during charging time, and will turn to GREEN once battery is fully

charged.

Battery capacity can be easily seen on the OLED display.

It is recommended to charge the fixture at an ambient temperature between 0°C and 35°C.

When charging fixtures in the tour pack ABS case, make sure to keep the case open. If fixture is charged but

not in operation, please always keep the power switch “Off”.

Note: The battery must be replaced with an original one from the manufacuturer only.

5. PRODUCT SETUP

User’s Manual

5.1 Menu Navigation

Autres manuels pour Luminus

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels FOS Technologies Matériel de DJ

FOS Technologies

FOS Technologies 12R Hybrid PRO Manuel utilisateur

FOS Technologies

FOS Technologies FOS ACL Line 12 Manuel utilisateur

FOS Technologies

FOS Technologies FOS Spot 150W Manuel utilisateur

FOS Technologies

FOS Technologies Co2 LED DMX Manuel utilisateur

FOS Technologies

FOS Technologies ZOOM 2825 Manuel utilisateur

FOS Technologies

FOS Technologies FOS 12R Hybrid Manuel utilisateur

FOS Technologies

FOS Technologies SuperStorm L006796 Manuel utilisateur

FOS Technologies

FOS Technologies L004503 Manuel utilisateur

FOS Technologies

FOS Technologies Wash 360 LED Manuel utilisateur

FOS Technologies

FOS Technologies PAR 18x12W PRO Manuel utilisateur

FOS Technologies

FOS Technologies FOS Wash LED Quad II Manuel utilisateur

FOS Technologies

FOS Technologies A10-FB4 Manuel utilisateur

FOS Technologies

FOS Technologies FOS 20W RGB Manuel utilisateur

FOS Technologies

FOS Technologies FOS Glow Manuel utilisateur

FOS Technologies

FOS Technologies Wash LED Quad III Manuel utilisateur

FOS Technologies

FOS Technologies Roller 7R Manuel utilisateur

FOS Technologies

FOS Technologies 150W LED Spot Manuel utilisateur

FOS Technologies

FOS Technologies PAR COB 200W LED TW Manuel utilisateur

FOS Technologies

FOS Technologies FOS 12R Hybrid Manuel utilisateur

FOS Technologies

FOS Technologies FOS HYDRO BSW Manuel utilisateur

FOS Technologies

FOS Technologies Pixel Blade Ultra Manuel utilisateur

FOS Technologies

FOS Technologies FOS BEAM IP Manuel utilisateur

FOS Technologies

FOS Technologies FOS Spot 40W Manuel utilisateur

FOS Technologies

FOS Technologies TOURING PAR IP HEX Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
