Fortinet FortiExtender 311F Manuel utilisateur
June 01, 2021
Copyright © 2021 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®,
FortiCare®and FortiGuard®, and certain other marks are registered trademarks
of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names
herein may also be registered and/or common law trademarks of Fortinet.
All other product or company names may be trademarks of their respective
owners. Performance and other metrics contained herein were attained in
internal lab tests under ideal conditions, and actual performance and other
results may vary. Network variables, dierent network environments and
other conditions may aect performance results. Nothing herein represents
any binding commitment by Fortinet, and Fortinet disclaims all warranties,
whether express or implied, except to the extent Fortinet enters a binding
written contract, signed by Fortinet’s General Counsel, with a purchaser
that expressly warrants that the identied product will perform according
to certain expressly-identied performance metrics and, in such event, only
the specic performance metrics expressly identied in such binding written
contract shall be binding on Fortinet. For absolute clarity, any such warranty
will be limited to performance in the same ideal conditions as in Fortinet’s
internal lab tests. In no event does Fortinet make any commitment related to
future deliverables, features or development, and circumstances may change
such that any forward-looking statements herein are not accurate. Fortinet
disclaims in full any covenants, representations, and guarantees pursuant
hereto, whether express or implied. Fortinet reserves the right to change,
modify, transfer, or otherwise revise this publication without notice, and the
most current version of the publication shall be applicable.
FortiExtender-311F&312F-QuickStart.indd 2FortiExtender-311F&312F-QuickStart.indd 2 6/1/2021 4:22:39 PM6/1/2021 4:22:39 PM
QuickStart Guide
Register for Support
Register your Fortinet product to receive:
• Technical Support
• New product features
• Protection from new threats
Vous devez enregistrer le produit pour recevoir:
• Support technique
• Nouvelles fonctionnalité s du produit
• Protection contre de nouvelles menaces
La reistrazione ti permette di usufruire di:
• Supporto Tecnico
• Nuove funzionalita
• Protezione dalle ultime minacce
Debe registrar el producto para recibir:
• Apoyo técnico
• Nuevas funcionalidades del producto
• Protección contra ataques
登録のお願い本日、フォーティネット製品の登録をしてください。登録すると次のメリットがあります。 テクニカルサポート • 新機能の追加 • 新しい脅威への防御请马上注册您的飞塔产品您在注册以后才能得到技术支持、新产品特点信息、最新威胁防护
https://support.fortinet.com
Toll free: 1 866 648 4638
Phone: 1 408 486 7899
Fax: 1 408 235 7737
Email: register@fortinet.com
FortiExtender-311F&312F-QuickStart.indd 3FortiExtender-311F&312F-QuickStart.indd 3 6/1/2021 4:22:39 PM6/1/2021 4:22:39 PM
Packing List
LTE/GPS Antennas
QuickStart Guide
Mounting Kit
Anchors and Screws
Drill Template Sticker
Rubber Feet
FEX-311F/312F
4
FortiExtender-311F&312F-QuickStart.indd 4FortiExtender-311F&312F-QuickStart.indd 4 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
5
Product Description
All FEX-311F and 312F products feature the same FEX-300F chassis with one (1) or two (2)
CAT16 LTE modules pre-installed, as highlighted below.
Model Modem
FEX-311F FEX-300F chassis with one (1) CAT16 LTE module pre-installed.
FEX-312F FEX-300F chassis with two (2) CAT16 LTE modules pre-installed.
Notes:
• CAT16 LTE modules (downlink: maximum 1 Gbps; uplink: maximum 150 Mbps)
• FEX-311F and 312F only support MicroSIM (3FF) SIM cards, which are not
included. You must purchase your own SIM cards.
Product Features
FortiExtender-311F&312F-QuickStart.indd 5FortiExtender-311F&312F-QuickStart.indd 5 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
6
Ports, LEDs, and Buttons
LAN (1–4) Ports & LEDs.
Port 4 is PoE PD LAN (802.3af/at)
USB 2.0 Port
12V/2A Input (optional)
(Use 12V/2A power adapter
with ID 2.1 mm plug.)
Console Port
Note: To access the device from its console port,
you must set the baud rate to 115200.
SFP Port & LED
Kensington Lock Slot Bluetooth LED
Bluetooth Button SIM Card Bay Reset/Default Button
WAN Port & LED
FortiExtender-311F&312F-QuickStart.indd 6FortiExtender-311F&312F-QuickStart.indd 6 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
7
LED Behavior and Description
SFP • Green Steady: 1 G network connected.
• Green Flashing: 1 G network activity.
• OFF: No network connection.
WAN/LAN LEDs • Green Steady: 1 G network connected.
• Green Flashing: 1 G network activity.
• Amber Steady: 100 M network connected.
• Amber Flashing: 100 M network activity.
• O: No network connection.
Bluetooth LED • Green Steady: The Bluetooth conguration window is open.
(See Bluetooth Button below)
• Blue Flashing: Bluetooth conguration is in progress.
• Blue Steady: Bluetooth conguration is completed. The LED
turns o in 5 seconds.
• O: No Bluetooth conguration is allowed.
LED Behavior
Button Operating Instructions
Reset/Default Button • Press and hold for less than 5 seconds: Reset/Reboot the
device.
• Press and hold for more than 5 seconds: Restore the
device to its factory default settings.
Bluetooth Button • Press and hold for less than ve (5) seconds: Ignored.
• Press and hold for more than ve (5) seconds: Opens a
window (period of time) for Bluetooth conguration, and
turns on the Bluetooth LED. Note: The“window” closes
if no Bluetooth conguration activity occurs within 30
seconds. Re-pressing the button has no eect while
Bluetooth conguration is in progress or if it is completed
within ve (5) minutes.
Control Button Usage
FortiExtender-311F&312F-QuickStart.indd 7FortiExtender-311F&312F-QuickStart.indd 7 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
8
LTE Modem 1 RF Connectors
RF Connectors & System LEDs
Note:
1. The upper LTE LEDs are for LTE Modem 1; the lower LEDs are reserved for LTE
Modem 2.
2. The LTE LEDs apply to both Modems 1 and 2.
3. The Management and FortiSASE/LAN Extension LEDs apply to both FEX-311F and
FEX-312F models.
LTE Modem 2 RF Connectors (FEX-312F only)
Power
LTE Mode
Management
FortiSASE/LAN Extension
Main MIMO1 MIMO2 DIVERSITY/GNSS
LTE Modul 1
LTE Signal Level 1
LTE Signal Level 2
LTE Signal Level 3
LTE Signal Level 4
Main MIMO1 MIMO2 DIVERSITY/GNSS
FortiExtender-311F&312F-QuickStart.indd 8FortiExtender-311F&312F-QuickStart.indd 8 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
9
LED Description
Power • Green Steady—System has booted up, and is working
properly.
• Green Flashing—System is booting up.
• Amber—System is in error state.
• OFF—System is powered o.
LTE Mode • Green—System is running in LTE mode.
Management • Blue Steady—System is managed by FortiGate or
FortiExtender Cloud.
• Blue Flashing—System is connecting to a managing device.
• OFF—System is running in stand-alone mode.
FortiSASE/LAN
Extension
• Blue Steady—System is connected to FortiSASE/LAN
Extension.
• Blue Flashing—System is connecting to FortiSASE/LAN
Extension.
• Blue Rapidly Flashing—Error in connecting to FortiSASE/LAN
Extension.
• OFF—System is not connected to FortiSASE/LAN Extension.
Bluetooth • Green—Bluetooth conguration window is open upon
pressing the Bluetooth button. It closes in 30 seconds if no
conguration occurs.
• Blue Flashing—Bluetooth congurartion is in progress.
• Blue Steady—Bluetooth conguration is completed. The LED
turns o in 5 seconds.
• OFF—No Bluetooth conguration is allowed.
System LEDs on top of the FEX-311F/312F
FortiExtender-311F&312F-QuickStart.indd 9FortiExtender-311F&312F-QuickStart.indd 9 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
10
LTE LEDs Description
LTE • Green Steady—The modem is connected to the wireless
carrier and working properly.
• Green Flashing—The modem is booting up and connecting
to the wireless carrier.
• Green Rapid Flashing—The modem is detected, but is
experiencing some SIM or rmware error.
• OFF—The modem is not detected.
LTE Signal Strength
LEDs
(Green)
• 1 On—< 25%.
• 1 & 2 On—25% - 50%.
• 1, 2 & 3 On—50% - 75%.
• 1, 2, 3, & 4 On—> 75%.
Note: The above decriptions apply to both Modem 1 and Modem 2. Modem 2 applies to FEX
312F only.
FortiExtender-311F&312F-QuickStart.indd 10FortiExtender-311F&312F-QuickStart.indd 10 6/1/2021 4:22:40 PM6/1/2021 4:22:40 PM
