1 | FTP100 Installation and Operating Instructions Rev. 02

Touch Panel

Installation and

Operation Guide

2 | FTP100 Installation and Operating Instructions Rev. 02
Table of Contents
Safety ............................................................................................................................................................ 3
International Standards: ........................................................................................................................... 4
Safety: ................................................................................................................................................... 4
EMC: ...................................................................................................................................................... 4
Power ........................................................................................................................................................ 5
Installation: ............................................................................................................................................... 5
Cleaning: ................................................................................................................................................... 6
Setup: ............................................................................................................................................................ 7
Provided Contents .................................................................................................................................... 7
Requirements: ........................................................................................................................................... 8
Mounting Instructions .............................................................................................................................. 8
Connecting the FTP100 ............................................................................................................................. 9
Operating Instructions ............................................................................................................................ 11
Troubleshooting ...................................................................................................................................... 11
Specifications .............................................................................................................................................. 12
Display ..................................................................................................................................................... 12
Mechanical .............................................................................................................................................. 12
Electrical .................................................................................................................................................. 12










3 | FTP100 Installation and Operating Instructions Rev. 02

Safety

Notes Cautions and Warnings

This guide contains icons indicating a degree of importance to the user. They are indicated as

follows.

Note: Indicates information the user should consider optimizing use of this device.

Caution: Indicates potential for damage to device. User should follow instructions carefully to avoid

potential problems.

Electrical warning: Indicates potential for damage to device and harm to user from incorrect use of

electrical sources. User should follow instructions to operate device safely and properly.

4 | FTP100 Installation and Operating Instructions Rev. 02

International Standards:

Safety:

(1) UL 62368-1: Ed. 2 - Audio/video, information and communication technology

equipment - Part 1: Safety requirements

(2) EN/IEC 62368-1:2014 - Audio/video, information and communication technology

equipment - Part 1: Safety requirements

EMC:

(1) FCC 47 CFR Part 15, Subpart B – Verification - Title 47: Telecommunication; Part 15—

Radio Frequency Devices.

(2) ICES-003 Issue 6: 2016 - Information Technology Equipment (ITE) – Limits and

methods of measurement.

(3) EN 55032: 2015 + AC: 2016-07 - Information technology equipment Radio

disturbance characteristics. Limits and methods of measurement.

(4) CISPR 32: 2015/COR1:2016 - Information technology equipment Radio disturbance

characteristics. Limits and methods of measurement.

(5) AS/NZS CISPR 32:2015 - Information technology equipment Radio disturbance

characteristics. Limits and methods of measurement.

(6) EN 61000-3-2: 2014 - Limits for harmonic current emissions (equipment input

current ≤ 16 A per phase).

(7) EN 61000-3-3: 2013 - Limitation of voltage changes, voltage fluctuations and flicker

in public low-voltage supply systems, for equipment with rated current ≤ 16 A per

phase and not subject to conditional connection

(8) EN 55035: 2017 - Electromagnetic compatibility of multimedia equipment. Immunity

requirements.

(9) KN 32 - Electromagnetic compatibility of multimedia equipment – Emission

requirements.

(10) KN 35 - Electromagnetic compatibility of multimedia equipment – Immunity

requirements.

(11) VCCI-CISPR 32:2016 - Agreement of VCCI Council - Technical Requirements

(12) CNS 13438: 2006 Class A - Limits and Methods of Measurement of Radio

Interference Characteristics of Information Technology Equipment.

5 | FTP100 Installation and Operating Instructions Rev. 02

Power:

The FTP 100 should only be powered suing the recommend input specification. Failure to

do so may damage the device and prevent proper operation.

The power should be supplied from a grounded source for safety. Failure to do so may

result in electric shock.

Unplug the device during lightning storms or when storing for extended periods.

Do not overload power strips or connectors that this device is connected to. Failure to do

so may result in fire or electric shock.

Be sure that the supply you are using is rated to accept the local AC line voltage and

frequency available to you.

Installation:

Make sure the user is able to lift more than 50lbs. easily before handling the device.

During installation never place the device on anything that cannot support less than 50 lbs.

easily as well.

During installation it is recommended that 2 or more people are available for placement

prior to mounting.

Use the mounting hardware provided or equivalent. Any other hardware or

modifications to use other hardware may damage the device or lead to unsatisfactory

installation.

Allow for adequate space around monitor for air circulation. Failure to do so may lead to

overheating and cause a failure of operation.

Never place monitor on its screen directly unless on a soft scratch free surface to prevent

unwanted damage to the screen.

6 | FTP100 Installation and Operating Instructions Rev. 02

Cleaning:

Only use cleaning agents designed for regular cleaning of LCD screens. Use a soft lint free

cloth in combination.

Never spray cleaning agents directly onto the screen. Always spray liquid onto the cloth

and then begin wiping.

If glue or strong residue which normal LCD cleaning agents are unable to remove exists,

the use of a normal hexane agent is permissible.

7 | FTP100 Installation and Operating Instructions Rev. 02

Setup:

Provided Contents:

FTP100 Touch Panel (1)

Height – 14.37 in.

Length – 22.85 in.

Width – 2.44 in.

Weight – 35.05 lbs.

DIN Supply Output Cable (1)

Length – 15ft.

HDMI to Micro HDMI Cable (1)

Length – 15ft.

USB 2.0 to Mini USB Cable (1)

Length – 15ft.

Mounting Hardware (4)

M8 x 1.25 mm Thread, 20mm

Long screws.

8 | FTP100 Installation and Operating Instructions Rev. 02

Requirements:

1. No. 4 Philips head screwdriver.

2. 1 other person cable of lifting 50 lbs.

The Foresight Sports Touch Panel FTP100 uses a standard 200mm x 100mm VESA mounting

pattern using 8mm screws. To install the FTP100 follow the steps outlined below. In this

example the FTP100 is being mounted to a Foresight Sports bay divider but the application is

universal with a VESA approved mount.

Mounting Instructions:

STEP 1: Route the provide cables (USB, HDMI, Power) to your mounting location to ensure

proper length and at least 1 ft of slack (Fig. 1).

STEP 2: Hold the FTP100 near the mount aligning the screw holes to the holes of the mount.

(Fig. 1) Thread the screws into the FTP100, starting with the top 2. (Fig. 2) Tighten to a snug fit

allowing for slight movement needed to align bottom holes. Thread the remaining screws into

the FTP100 to a snug fit as well. At this point make sure the touchscreen is level and to your

liking. Fully tighten all 4 screws well so that the unit may not be shifted.

Fig 1.

Mounting

holes

Mounting

holes

Cable slack

9 | FTP100 Installation and Operating Instructions Rev. 02

Connecting the FTP100:

STEP 1: Lift the rubber flap (Fig. 3) located at the bottom of the touch panel to access the AC

Power, USB-B Mini and Micro HDMI ports

Top screws

Fig. 2

Fig. 3

10 | FTP100 Installation and Operating Instructions Rev. 02

STEP 2: Connect HDMI to Micro HDMI to the port underneath touch panel.

STEP 3: Connect USB to USB Mini cable from PC to port underneath touch panel.

STEP 4: Connect AC Power cable from 24-volt power source to port underneath touch panel

(red LED indicator light should turn on and fan inside touch panel should begin spinning).

DC Jack

HDMI Port

USB Port

Fig. 4
