iTView Mac
User’s Guide
Rev. 8/02
FCC NOTICE
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the installation manual, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measures:
•This unit was tested with shielded cable. Therefore, for
continued compliance, use the shielded cables provided with the
unit.
•Re-orient or relocate the unit or receiving antenna.
•Increase the separation between the computer/converter and
television.
•Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
You may find the following booklet helpful:
How to Identify and Resolve Radio-TV Interference Problems (stock
number 004-000-000345-4)
To order the booklet, write to:
The U.S. Government Printing Office
Washington D.C. 20402
COPYRIGHT
This document and the software described in it are copyrighted under
United States Copyright Laws. No part of this document or software
may be copied without prior written consent from FOCUS
Enhancements, Inc. except in the normal use of the software as
described in this documentation. All printed circuits, their physical
implementation on printed circuit boards and associated software are
copyrighted with all rights reserved. Under the copyright laws, the
printed circuit board, or the software programs provided may not be
copied in whole or part, without written consent of FOCUS
Enhancements, Inc., except in the normal use of the software
programs to make a backup copy. This exception does not allow
copies to be made for others, whether sold or not, but all of the
material may be sold, given, or loaned to another person. Under the
law, copying includes translating into another language or format.
Mac OS 7.1, 8.5, 9.0 and X are trademarks of the Apple Corporation.
All other products named are trademarks of their respective
manufacturers.
©2002 FOCUS Enhancements, Inc. All Rights Reserved
This is a blank page
Table of Contents
CHAPTER 1 INTRODUCTION 4
CHAPTER 2 HARDWARE INSTALLATION 10
Packing List 11
Inspecting the Equipment 11
Installing the RGB Cover on your iMac (Older Models) 13
Connecting the iTView Mac to a Television 15
Connecting the iTView Mac to a VCR 20
CHAPTER 3 ITVIEW MAC SOFTWARE 22
Installing the iTView Mac Control Panel Software 22
Functions of the iTView Mac LED 24
Screen Controls 24
TV Output Controls 27
Picture Setup 29
Additional Features 31
CHAPTER 4 TUNING YOUR TELEVISION 34
Brightness 35
Color 35
Sharpness 35
Tint or Hue 35
CHAPTER 5 TROUBLESHOOTING 36
Returning a Damaged or Failed iTView Mac Unit 38
iTView Mac User’s Guide
Preface 1
About the User’s Guide
The iTView Mac User’s Guide is designed to help you to quickly and
easily connect the hardware and install the software for this product.
The guide is divided into the following chapters:
Chapter 1: Introduction, which describes the key features and
functionality of the product and some of its many uses. The chapter
also discusses the notation conventions used in the guide.
Chapter 2: Hardware Installation, which describes the information
you should know before installing and connecting the iTView Mac
hardware, and the steps required to perform the installation.
Chapter 3: iTView Mac Software. Describes the steps required to
install the iTView Mac software control panel and how to operate the
program.
Chapter 4:Tuning Your Television , this chapter describes the
methods you can use to tune the image on your television
Chapter 5:Troubleshooting , describes possible problems that you
might encounter and ways to solve them.
iTView Mac User’s Guide
2 About This Guide
Notation Conventions
This user’s guide uses the following conventions to specify certain
types of information.
Warns you about potential problems and hazards during
the installation or use of the product. Read these
warnings carefully, and be sure you understand how
they relate to the installation procedures before
proceeding.
Note: Points out important or useful information.
Contact Information
To get information on the reseller nearest to you, to order
replacements parts, or for technical support contact one of the
following:
Worldwide Headquarters
1370 Dell Avenue
Campbell, CA 95008
Customer Service 800-338-3348 (U.S. Only)
Technical Support 408-370-9963
iTView Mac User’s Guide
4 Introduction
Chapter 1 Introduction
The iTView Mac converts the VGA output from your computer into
video that can be displayed on a television or recorded to a VCR.
iTView Mac automatically detects VGA ,SVGA, and XGA output
frequencies up to 152Hz and synchronizes it with your television. The
result is a high quality, flicker-free television display from your
computer.
Features
The iTView Mac includes the following features:
•Contains the industry leading FS 401 Chip which provides the
best possible resolution for PC-to-TV scan conversion
•Screen position controls
•Variable horizontal and vertical scaling controls
•Variable zoom controls
•Image freeze control
•Auto Pan in all directions via mouse control while in 2X Zoom
Mode
•Brightness, Contrast, Color Saturation, Sharpness, 2D Flicker
Filter Controls
•Easy plug-and-play installation for any iMac Flatpanel G4, G3,
and iMac DV personal computers
•Compatibility with any size television monitor (NTSC/PAL) with
an RCA (composite), S-Video, or SCART (Europe only) input
connector
•Support for 640 x 480 (VGA), 800 x 600 (SVGA) and 1024 x 768
(XGA) resolution at frequencies up to 152Hz
•Support for 24-bit color
iTView Mac User’s Guide
Chapter 1 5
•TrueScale™ image compression that precisely fits the image on
your television without dropping lines or altering video resolution
•Support NTSC and PAL systems
•Supports Composite and S-Video
•Works with multiple platforms including Mac OS 7.1 up to and
including Mac OS X
iTView Mac User’s Guide
6 Introduction
Modes of Operation
The iTView Mac has ability to operate in two separate modes:
Figure 1-1: Presentation Mode
1. Presentation Mode: Display the same image on your computer
and your television.
