FMC Technologies Smith Meter Ultra Series Manuel d'instructions
Bulletin MNLS007 ║ Issue/Rev 0.0 (7/14)
Liquid Ultrasonic Flowmeters
Smith Meter®
Ultra™Series C Remote Display
Installation / Operation / Maintenance Manual
Rom
Page 2 • MNLS007 ║ Issue/Rev. 0.0 (7/14)
Important
All information and technical specications in this documentation have been carefully checked and compiled by the
author. However, we cannot completely exclude the possibility of errors. FMC Technologies is always grateful to be
informed of any errors.
Smith Meter® is a registered trademark of FMC Technologies.
Customer Support
Contact Information:
Customer Service
FMC Technologies Measurement Solutions, Inc.
1602 Wagner Avenue
Erie, Pennsylvania 16510 USA
P: +1 814 898-5000
F: +1 814 899-8927
www.fmctechnologies.com
Issue/Rev. 0.0 (7/14) ║ MNLS007 • Page 3
Ultra Series Remote Display I/O/M Manual Table of Contents
Table of Contents
1 – Overview....................................................................... 5
1.1. – Features .................................................................... 5
1.2. – Specifications ............................................................ 5
1.3. – Receipt of Equipment ................................................5
1.4. – Specifications ............................................................ 6
1.5. – Ultra 6c and Ultra 4c Architecture .............................. 6
1.6. – Receipt of Equipment ................................................6
1.7. – Pre-Installation Inspection ......................................... 6
2 – Installation.................................................................... 7
2.1. – Mechanical Installation ..............................................7
2.1.1. – General ...................................................................7
2.1.2. – For ATEX and IEC Installations .............................. 7
2.1.3. – For North American Installations ............................ 8
2.1.4. – All Installations - Notes ........................................... 9
2.1.5. – Installation of Cables .............................................. 9
3 – Display Control Board............................................... 11
3.1. – Wiring Examples/Information................................... 11
3.1.1. – Power Supply ....................................................... 11
3.1.2. – Network Ethernet Connection............................... 11
3.1.3. – Direct Connection to the Ultrasonic Meter ............12
4 – Powering Up the Remote Display ............................ 13
4.1. – Start-Up ...................................................................13
5 – User Display Interface............................................... 15
5.1. – Main Menu ...............................................................15
5.2. – Configuration ...........................................................15
5.2.1. – Configuration - General ........................................ 16
5.2.2. – Network Settings .................................................. 16
5.2.3. – Connections..........................................................17
5.2.4. – Modes ...................................................................19
5.3. – Maintenance Settings .............................................. 20
5.3.1. – Touch Screen Calibration ..................................... 21
5.4. – Information...............................................................21
5.5. – Reconnect ............................................................... 22
5.6. – Weights & Sealing Procedures ................................22
6 – Maintenance............................................................... 23
6.1. – Display HMI Electronics........................................... 23
6.1.1. – Board Replacement ..............................................23
6.2. – Returned Goods Policy............................................23
7 – Related Publications ................................................. 25
Page 4 • MNLS007 ║ Issue/Rev. 0.0 (7/14)
Issue/Rev. 0.0 (7/14) ║ MNLS007 • Page 5
Ultra Series C Remote Display I/O/M Manual Overview
1 – Overview
The Ultra Series Ultrasonic Flowmeter Remote Display Unit is a touch screen display designed
to be used as an HMI for FMC Technologies equipment with a web based operator interface.
The display is enclosed in an explosion proof housing and is designed to be located outdoors
and in hazardous environments. The Remote Display Unit includes all software for configuring
connections to the desired equipment and includes security functions for compliance with WELMEC
standards for weights and measures. Once configured, the display will automatically connect to
the desired Ultra Series flowmeter upon start up.
1.1 Features
• Touch Screen Display – The touch screen display is pressure sensitive and can
be activated with gloved hands.
• Security – The display includes built in security features for compatibility with
WELMEC standards for custody transfer.
• Configurable – The display can be configured to search for any FMC Technologies Ultra
Series meter on the network. Once configured the display will automatically connect to the
configured device.
• Automatic Connection – Once configured the display will automatically connect
to the configured device upon reboot.
1.2 Specifications
See specification sheet SSLS008, 5.7" Remote Display.
1.3 Receipt of Equipment
When the equipment is received, the outside packing case should be checked
immediately for any shipping damage. If the packing case has been damaged, the local
carrier should be notified at once regarding their liability. Carefully remove the unit from
its packing case and inspect for damage.
If damage has occurred during shipment or parts are missing, a written report should
be submitted to the Customer Service department by using the contact information at
the beginning of this manual.
Prior to installation, the unit should be stored in its original packing case and protected
from adverse weather conditions and abuse. Throughout the installation process, the
electronics should be protected from adverse weather conditions.
Page 6 • MNLS007 ║ Issue/Rev. 0.0 (7/14)
Ultra Series C Remote Display I/O/M Manual Overview
Issue/Rev. 0.0 (7/14) ║ MNLS007 • Page 7
Ultra Series C Remote Display I/O/M Manual Installation
2 – Installation
2.1. Mechanical Installation
2.1.1. General
The display is designed to be mounted to a plate through the holes tapped in to the rear
of the housing using size M6 x 1.8 screws.
The display unit must be supplied with an Ethernet RJ45 connection and 24 VDC power.
The cable, conduit and conduit fittings for these connections must meet installation
requirements, such as hazardous area classifications, humidity, temperature, voltage,
current and others. All conduit connections must be installed with approved conduit seals
within the required distance according to the applicable electrical code(s).
The touch screen is protected by an intrinsic safe barrier. The enclosure must be
grounded as per national electrical code regulations, for example NEC/CEC etc.
2.1.2. For ATEX and IEC Ex Installations
The following installation instructions apply for the certified equipment listed in
the equipment covered portion of the table below as per section 1.06 of Annex II of
Directive 94/9/EC (ATEX Directive):
Standards used:
IEC 60079-0 6th Edition, EN 60079-0: 2012, UL 60079-0 4th Edition
IEC 60079-1 6th Edition, EN 60079-1: 2007, UL 1203 4th Edition
IEC 60079-11 6th Edition, EN 60079-11: 2012, UL 60079-ll 5th Edition, UL 913 7 Edi-
tion UL 1203 4th Edition
Cable entries must be in accordance to EN/IEC 60079-1 section 13.
For wiring systems utilizing cable glands, the gland and/or thread adaptor must be
Page 8 • MNLS007 ║ Issue/Rev. 0.0 (7/14)
Ultra Series C Remote Display I/O/M Manual Installation
Ex d certified. The cable end must be securely installed and, depending on the cable
type, be properly protected from mechanical damage.
For wiring systems utilizing conduit, an Ex d certified sealing device must be used
immediately at the entrance of the enclosure. Any unused entry must be suitably blocked
with an Ex d certified plug.
The maximum ambient temperature for the enclosure is 60°C; if the enclosure is directly
mounted to a process piping system that exceeds this value then the enclosure shall
be remotely mounted to guarantee the 60°C ambient is not exceeded.
Equipment bonding shall be provided at the external grounding facility terminal.
External connection is not required when using metallic conduit or armored cable.
CAUTION: To prevent ignition of hazardous atmospheres and to prevent electrical
shock, disconnect from supply circuits before opening, keep tightly closed when circuits
are in operation.
WARNING: Contains internal battery-powered circuit to prevent ignition of hazardous
atmospheres, do not open enclosure unless area is known to be non-hazardous. To
reduce the risk of ignition of hazardous atmospheres, conduit runs must have a sealing
fitting connected within 18 inches of the enclosure. Substitution of components may
impair intrinsic safety.
Special conditions for safe use:
• Select wiring and cable glands suitable for 90°C operation.
• Contact manufacturer at address listed for information on the dimensions of the
flameproof joints.
FMC Technologies Measurement Solutions, Inc.
1602 Wagner Avenue
Erie, Pennsylvania 16510
USA
2.1.3. For North American Installations:
Conduit connections must be in accordance to: USA – National Electric Code (NFPA
70), Canada – Canadian Electric Code (CSA C22.1).
A listed seal-off box must be used immediately at the entrance of the enclosure. (i.e.:
within 3 inches). Any unused entry must be suitably blocked with a suitable listed plug.
Marking Equipment Covered Certicate
Ex d ib IIB T5 Gb
IP66
Tamb = -40°C to +60°C
Remote Mounted
Display
DEMKO 13 ATEX
1204991X
IEC Ex UL 13.0019X
Issue/Rev. 0.0 (7/14) ║ MNLS007 • Page 9
Ultra Series C Remote Display I/O/M Manual Installation
2.1.4. All Installations – Notes
CAUTION: To prevent ignition of hazardous atmospheres, disconnect from supply cir-
cuit before opening any enclosure. Keep tightly closed when circuits are in operation.
WARNING: Contains internal battery-powered circuit. To prevent ignition of hazardous
atmospheres, do not open enclosure unless area is known to be non-hazardous.
DO NOT SWITCH POWER ON until all questions pertaining to installation wiring are
resolved. Any damage caused by unauthorized operation will void the warranty.
CAUTION: The cable installation must be performed according to the relevant cabling
lists and/or connection diagrams.
2.1.5. Installation of Cables
Due to customer or location specific requirements, the cables for communication and
power supply lines are not a part of the delivery. However, the technical specifications
for the cables MUST be followed. Prior to installation, these requirements must be
checked. The number of and types of cables are dependent on options utilized by the
end customer. A set of wiring diagrams are available covering the different options later
in this manual.
Cables must be protected against mechanical damage.
Be aware of the minimum bending radius of the cable. The bending radius for multi-
core cable is normally 6 times the diameter. However, the minimum bending radius for
a fiber optic cable may vary from this and must be checked with the cable manufacturer
in each case.
Page 10 • MNLS007 ║ Issue/Rev. 0.0 (7/14)
Ultra Series C Remote Display I/O/M Manual Installation
