FlyTech POS 360 Series Manuel utilisateur
i
Revision v1.3 July 2009
Point-of-Sale
Hardware
System
User Manual
ii
Copyright 2009 July
All Rights Reserved
Manual Version 1.3
P/N: 3LMPP3600313
The information contained in this document is subject to change
without notice.
We make no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. We shall not be
liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of
this material.
This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced or translated to another language without
the prior written consent of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel®
Corporation. Microsoft® and Windows® are registered trademarks
of Microsoft Corporation.
Other trademarks mentioned herein are the property of their
respective owners.
iii
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrial power supply, turn
off the power switch and remove the power cord plug from the
wall socket. The wall socket must be easily accessible and in
close proximity to the machine.
2. Read these instructions carefully. Save these instructions for
future reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart,stand,or table.The
product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are
provided for ventilation;to ensure reliable operation of the product
and to protect it from overheating. These openings must not be
blocked or covered.The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar
surface.This product should never be placed near or over a
radiator or heat register,or in a built-in installation unless proper
ventilation is provided.
7. This product should be operated from the type of power indicated
on the marking label.If you are not sure of the type of power
available, consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid
of any kind on the product.
CE MARK This device complies with the requirements of the
EEC directive 2004/108/EC with regard to
“Electromagnetic compatibility” and 2006/95/EC
“Low Voltage Directive”.
FCC This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that
may cause undesired operation.
iv
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly.
Replace only with the same or equivalent type recommended by the
manufacturer. Discard used batteries according to the manufacturer’s
instructions.
LEGISLATION AND WEEE SYMBOL
2002/96/EC Waste Electrical and Electronic Equipment Directive
on the treatment, collection, recycling and disposal of electric
and electronic devices and their components.
The crossed dustbin symbol on the device means that it should not be
disposed of with other household wastes at the end of its working life.
Instead, the device should be taken to the waste collection centers for
activation of the treatment, collection, recycling and disposal
procedure.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for details of
where and how they can take this item for environmentally safe
recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
v
Revision History
Changes to the original user manual are listed below:
Version Date Description
1.0 2007 March •Initial release
1.1 2007 May •System Disassembly updated
1.2 2007
September •Cover page updated
•Connector Pin Definition updated
1.2a 2007
September •Cash Drawer Power Setting
Correction
1.2b 2008 June
•Cash Drawer Power Setting
Correction
•Updated specification with Second
Display options
•Updated Optional Items with Second
Display options
•Updated LCD ID jumper settings
1.3 2009 July
•Motherboard B78 v1.0 updated to
v2.2
•2nd display installation added
•VFD installation added
•SATA HDD photo added
•2-in-1 MSR + iButton module added
•2–in-1MSR + Finger Printer module
added.
•Remove Ventilation slots from rear
cover.
vi
Table of Contents
1 Item Checklist.............................. 1
1-1 Standard Items ..........................................................1
1-2 Optional Items ...........................................................2
2 System View................................. 3
2-1 Front View .................................................................3
2-2 Side View...................................................................4
2-3 Rear View..................................................................4
2-4 Bottom View ..............................................................5
2-5 I/O View.....................................................................5
3 Driver Installation ........................ 6
3-1 Driver List ..................................................................6
3-2 Chipset Driver Installation..........................................7
3-3 USB 2.0 Driver Installation.........................................8
3-4 VGA Driver Installation.............................................11
3-5 Audio Driver Installation...........................................12
3-6 10/100/1000MB LAN Driver Installation...................13
3-7 ELO Touch Driver Installation ..................................14
3-8 POSTouch Driver Installation...................................17
4 Peripherals Installation............. 21
4-1 MSR Module Installation..........................................21
4-2 2-in-1 MSR + Finger Print Module Installation.........23
4-3 2-in-1 MSR + iButton Module Installation.................23
4-4 Second Display Installation......................................24
4-5 VFD Installation .......................................................25
4-6 Cash Drawer Installation..........................................27
5 System Disassembly................. 29
5-1 Replacing SATA HDD ..............................................29
5-2 Replacing the CF Card Holder (Optional)................30
5-3 Replacing Motherboard & I/O Board........................31
5-4 Replacing Inverter Board & Touch Screen Board....33
6 Specification .............................. 35
7 Jumper Settings ........................ 37
7-1 B78 v2.2 Jumper Settings........................................38
vii
8 BIOS Settings............................. 43
8-1 BIOS Setup Utility....................................................43
8-2 Starting the BIOS Setup...........................................43
8-3 When a Problem Occurs..........................................43
8-4 BIOS Main Menu.....................................................43
1
1 Item Checklist
Take the system unit out of the carton. Remove the unit from the carton by
holding it by the foam inserts. The following contents should be found in the
carton:
1-1 Standard Items
a. Driver CD b. User Manual
c. Power Cable d. System
2
1-2 Optional Items
a. CF card holder b. MSR
c. 2-in-1 MSR + Finger Print Module d. 2-in-1 MSR + iButton Module
e. 10.4", 12.1" LCD Second Display f. VFD
3
2 System View
2-1 Front View
MSR
Power LED Power Switch Button
