i50s
Users Manual
ii
1
i50s Current Probe/
PSi50s Power Supply
Introduction
XWWarning
To avoid electrical shock or possible injury, do not use the
i50s Current Probe with oscilloscopes with floating inputs,
i.e. oscilloscopes not referenced to ground.
The i50s Current Probe (“the Probe”) has been designed for use with
oscilloscopes for accurate, non-intrusive measurement of ac, dc and complex
waveform currents. Using advanced Hall Effect technology the Probe can
accurately measure currents over the frequency range of dc to 50 MHz with a
measuring range up to 50 A peak. The Probe is a general purpose, universal
current Probe which can be used with any oscilloscope.
XWWarning
To avoid electrical shock or possible injury, use the PSi50s
Power Supply only with i50s Current Probes.
The PSi50s Power Supply (the “Power Supply”) is an external power supply
that can simultaneously power two i50s Current Probes. The Power Supply is
supplied from single-phase mains 115 or 230 V ac, with frequencies from 44
to 60 Hz, and provides a symmetrical dc voltage of ±12 V.
i50s
Users Manual
2
Safety Instructions
Please read this section carefully. It will make you familiar with the most
important safety instructions for handling your product. In this manual, a
Warning identifies conditions and actions that pose hazard(s) to the user. A
Caution identifies conditions and actions that may damage the Probe, Power
Supply, or the test instruments.
WX Warning
The Probe and Power Supply may only be used and
handled by qualified personnel. To avoid electrical shock
or personal injury, follow these precautions:
•Use caution during installation and use of these
products; high voltages and currents may be present
in circuits under test.
•Do not use the Probe or Power Supply if damaged.
Always connect the Probe to display device before it is
installed around the conductor.
•If the Probe or Power Supply is not used in a manner
specified by the manual, the protection provided may
be impaired.
•Use the Power Supply only with i50s Current Probes.
•Do not use the Probe without consulting local and
national safety codes and use of protection equipment
is recommended.
•Do not hold the Probe beyond the tactile barrier (see
Figure 1).
•Before each use, inspect the Probe and Power Supply.
Look for cracks or missing portions of the housing or
output cable insulation. Also look for loose or
weakened components. Pay particular attention to the
insulation surrounding the jaws.
•Use caution when working with voltages above 60 V
dc, 30 V ac rms or 42 V ac peak. Such voltages pose a
shock hazard.
•Do not use the Probe or Power Supply in wet
environments or in locations that hazardous gases
exist.
•Inspect the Power Supply and power cord and ensure
that they are not damaged.
•This product has no serviceable parts, do not open the
Power Supply.
•Check to make sure that the voltage selector switch on
the back panel of the Power Supply is set to the correct
mains input voltage before connecting power.
Current Probe
Symbols
3
Symbols
The table below lists the symbols used on the Probe and/or in this manual.
Symbol Description
~Do not dispose of this product as unsorted municipal
waste. Go to Fluke’s website for recycling information.
WImportant Information. See manual.
XHazardous Voltage. Risk of electric shock.
-Do not apply to or remove from hazardous, live conductors
without taking addition protective measures.
TDouble insulation.
IFuse.
)Conforms to Canadian Standards Association.
PComplies with the relevant European standards.
;Conforms to Australian standards.
CAT I
CAT I equipment is designed to protect against transients
from high-voltage, low-energy sources, such as electronic
circuits or a copy machine.
CAT II
CAT II equipment is designed to protect against transients
from energy-consuming equipment supplied from the fixed
installation, such as televisions, personal computers,
portable tools, and other household appliances.
i50s
Users Manual
4
Probe Features
exi01f.eps
A BNC Connector G Power Supply Connector
B Degauss Button H Grounding Lead
C Auto Zero Button I Ground Terminal LED
D Range Selection Button J Probe Measuring Head
E Indicator for Overheating K Tactile Barrier
F LED Indicator for Unlocked
Probe Head L Probe Head Opening
Lever
Figure 1. i50s Features
Current Probe
Probe Operating Instructions
5
Probe Operating Instructions
The following sections list the Probe operating instructions.
Connections
For these connections, refer to Figures 1 and 2. To connect the Probe, do the
following:
1. Connect the BNC connector, to the oscilloscope input. Ensure that the
input impedance is ≥ 1 MΩ.
2. Connect a ±12 V external power supply to the power supply connector on
the Probe interface. Do not switch on the power supply until the power
supply connections are made using the power supply cable with or without
the adapter provided.
3. When measuring currents with fast voltage variations (high dv/dt) of the
primary current, connect the ground terminal on the Probe to ground.
Probe Head Cable
i50s
(Power Supply)
Other
Power Supply
Power Supply Adapter
Probe Supply Cable
exi02f.eps
Figure 2. Connections
i50s
Users Manual
6
Activating the Probe
There are two possibilities of supplying power to the Probe:
1. Use the recommended PSi50s Power Supply.
2. Use any suitable power supply and connect the power supply lead using
the adapter provided (see Figure 2).
Note
In order for the Probe to function correctly, the characteristics of the
power supply must be in accordance with the requirements in
“Specifications”.
Before activating the Probe, ensure that the Probe head is locked with no
primary conductor (see Figure 3).
Probe LOCKED
Probe UNLOCKED
exi03f.eps
Figure 3. Locking and Unlocking the Probe
When turning on the Probe :
•All the LEDs will light up for one second.
•Demagnetization is automatically started; the DEGAUSS LED will light
up for approximately six seconds.
•Auto zero is initiated to remove the residual offsets for the two ranges.
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Fluke Alimentation
